Spirax Sarco HM Series User manual

IM-S03-11 CMGT Issue 5 1
HM and HM34 Inverted Bucket Steam Traps
HM Series
HM34 Series
1. Safety information
2. General product information
3. Installation
4. Commissioning
5. Operation
6. Maintenance
7. Spare parts
© Copyright 2020
Printed in GB
0670350/5
HM and HM34
Inverted Bucket Steam Traps
Installation and Maintenance Instructions
IM-S03-11
CMGT Issue 5

IM-S03-11 CMGT Issue 5
2
HM and HM34 Inverted Bucket Steam Traps

IM-S03-11 CMGT Issue 5 3
HM and HM34 Inverted Bucket Steam Traps
Safe operation of this product can only be guaranteed if it is properly installed, commissioned,
used and maintained by qualified personnel (see Section 1.11 ) in compliance with the operating
instructions. General installation and safety instructions for pipeline and plant construction, as
well as the proper use of tools and safety equipment must also be complied with.
1.1 Intended use
Referring to the Installation and Maintenance Instructions, name-plate and Technical Information
Sheet, check that the product is suitable for the intended use / application.
The product listed below complies with the requirements of the Pressure Equipment Directive
2014/68/EU and carries the mark when so required.
The product falls within the following Pressure Equipment Directive categories:
Product Group 2
Gases
Group 2
Liquids
HM and HM34 SEP SEP
i) The product has been specifically designed for use on steam, air or water /condensate which
are in Group 2 of the above mentioned Pressure Equipment Directive. The products’ use on
other fluids may be possible but, if this is contemplated, Spirax Sarco should be contacted to
confirm the suitability of the product for the application being considered.
ii) Check material suitability, pressure and temperature and their maximum and minimum values.
If the maximum operating limits of the product are lower than those of the system in which it
is being fitted, or if malfunction of the product could result in a dangerous overpressure or
overtemperature occurrence, ensure a safety device is included in the system to prevent such
over-limit situations.
iii) Determine the correct installation situation and direction of fluid flow.
iv) Spirax Sarco products are not intended to withstand external stresses that may be induced by
any system to which they are fitted. It is the responsibility of the installer to consider these
stresses and take adequate precautions to minimise them.
v) Remove protection covers from all connections before installation.
1.2 Access
Ensure safe access and if necessary a safe working platform (suitably guarded) before attempting
to work on the product. Arrange suitable lifting gear if required.
1.3 Lighting
Ensure adequate lighting, particularly where detailed or intricate work is required.
1.4 Hazardous liquids or gases in the pipeline
Consider what is in the pipeline or what may have been in the pipeline at some previous time.
Consider: flammable materials, substances hazardous to health, extremes of temperature.
1. Safety information

IM-S03-11 CMGT Issue 5
4
HM and HM34 Inverted Bucket Steam Traps
1.5 Hazardous environment around the product
Consider: explosion risk areas, lack of oxygen (e.g. tanks, pits), dangerous gases, extremes of
temperature, hot surfaces, fire hazard (e.g. during welding), excessive noise, moving machinery.
1.6 The system
Consider the effect on the complete system of the work proposed. Will any proposed action (e.g.
closing isolation valves, electrical isolation) put any other part of the system or any personnel at
risk?
Dangers might include isolation of vents or protective devices or the rendering ineffective of
controls or alarms. Ensure isolation valves are turned on and off in a gradual way to avoid system
shocks.
1.7 Pressure systems
Ensure that any pressure is isolated and safely vented to atmospheric pressure.
Consider double isolation (double block and bleed) and the locking or labelling of closed valves.
Do not assume that the system has depressurised even when the pressure gauge indicates zero.
1.8 Temperature
Allow time for temperature to normalise after isolation to avoid danger of burns.
1.9 Tools and consumables
Before starting work ensure that you have suitable tools and /or consumables available. Use only
genuine Spirax Sarco replacement parts.
1.10 Protective clothing
Consider whether you and/or others in the vicinity require any protective clothing to protect against
the hazards of, for example, chemicals, high / low temperature, radiation, noise, falling objects,
and dangers to eyes and face.
1.11 Permits to work
All work must be carried out or be supervised by a suitably competent person.
Installation and operating personnel should be trained in the correct use of the product according
to the Installation and Maintenance Instructions.
Where a formal ‘permit to work’ system is in force it must be complied with. Where there is no
such system, it is recommended that a responsible person should know what work is going on
and, where necessary, arrange to have an assistant whose primary responsibility is safety.
Post ‘warning notices’ if necessary.
1.12 Handling
Manual handling of large and/or heavy products may present a risk of injury. Lifting, pushing,
pulling, carrying or supporting a load by bodily force can cause injury particularly to the back.
You are advised to assess the risks taking into account the task, the individual, the load and the
working environment and use the appropriate handling method depending on the circumstances
of the work being done.

IM-S03-11 CMGT Issue 5 5
HM and HM34 Inverted Bucket Steam Traps
1.13 Residual hazards
In normal use the external surface of the product may be very hot. If used at the maximum permitted
operating conditions the surface temperature of some products
may reach temperatures in excess of 425 °C (797 °F).
Many products are not self-draining. Take due care when dismantling or removing the product from
an installation (refer to ‘Maintenance instructions’).
1.14 Freezing
Provision must be made to protect products which are not self-draining against frost damage in
environments where they may be exposed to temperatures below freezing point.
1.15 Disposal
Unless otherwise stated in the Installation and Maintenance Instructions, this product is recyclable
and no ecological hazard is anticipated with its disposal providing due care is taken.
1.16 Returning products
Customers and stockists are reminded that under EC Health, Safety and Environment Law, when
returning products to Spirax Sarco they must provide information on any hazards and the
precautions to be taken due to contamination residues or mechanical damage which may present
a health, safety or environmental risk. This information must be provided in writing including Health
and Safety data sheets relating to any substances identified as hazardous or potentially hazardous.
1.17 Working safely with cast iron products on steam
Cast iron products are commonly found on steam and condensate
systems. If installed correctly using good steam engineering
practices, it is perfectly safe.
However, because of its mechanical properties, it is less forgiving
compared to other materials such as SG iron or carbon steel.
The following are the good engineering practices required to
prevent waterhammer and ensure safe working conditions on
a steam system.
Safe Handling
Cast Iron is a brittle material. If the product is dropped during
installation and there is any risk of damage the product should
not be used unless it is fully inspected and pressure tested by the
manufacturer.

IM-S03-11 CMGT Issue 5
6
HM and HM34 Inverted Bucket Steam Traps
Prevention of water hammer
Steam trapping on steam mains:
Steam Mains - Do's and Don'ts:
Steam Steam
Flow Flow
30 - 50 metre intervals
Gradient 1:100
Gradient 1:100
Trap set
Trap set
Trap set
Condensate
Condensate
Condensate
Steam
Steam

IM-S03-11 CMGT Issue 5 7
HM and HM34 Inverted Bucket Steam Traps
Prevention of tensile stressing
Pipe misalignment:
Installing products or re-assembling after maintenance:
Thermal expansion:
Do not over tighten.
Use correct torque gures.
1
1
4 2
3
8
2
6
3
7
Flange bolts should be gradually tightened across
diameters to ensure even load and alignment.
Guides
Guides
Limit
rods
Limit rods
Fixing point
Medium
distance
Small lateral
movement
Small lateral
movement
Large lateral
movement
Large lateral
movement
Short
distance Fixing point
Axial
movement
Axial movement
Guides
Guides
5
4

IM-S03-11 CMGT Issue 5
8
HM and HM34 Inverted Bucket Steam Traps
2.1 Description
The Spirax Sarco HM Series inverted bucket steam trap is manufactured in cast iron and has an integral
strainer as standard. It is designed to be installed in horizontal pipework and will operate on steam pressures
up to 14 bar g (203 psi g).
The Spirax Sarco HM34 series inverted bucket trap is similar to the HM Series but is manufactured in carbon
steel and will operate on steam pressures up to 32 bar g (464 psi g).
Note: For further information see the following Technical Information Sheets, TI-S03-02 for the HM Series
and TI-P072-01 for the HM34 Series, which gives full details of:- Materials, sizes and pipe connections,
dimensions, weights, operating ranges and capacities.
Fig. 1 HM00 (½") and HM10 (¾")
Fig. 2 HM12 (1")
Fig. 3 HM34 (½" and ¾")
Fig. 4 HM34 (1")
2. General product information

IM-S03-11 CMGT Issue 5 9
HM and HM34 Inverted Bucket Steam Traps
2.2 Sizes and pipe connections
HM Series
½" (HM00), ¾" (HM10) and 1" (HM12) screwed BSP or NPT.
DN15 (HM003), DN20 (HM103) and DN25 (HM123) standard flange BS 4504 and DIN PN16.
HM34 Series
½", ¾" and 1" screwed BSP or NPT and socket weld ends BS 3799 Class 3000
DN15, DN20 and DN25 standard flange BS 4504 PN40.
Flanges also available ANSI 150 and ANSI 300.
2.3 Materials
Trap HM Series HM34 Series
Cover Cast iron Cast steel
Body
½" and ¾"Cast iron Forged steel
1" Cast iron Cast steel
Internals Stainless steel Stainless steel
Note: For further information on materials see the following Technical Information Sheets: TI-S03-02 for the
HM Series and TI-P072-01 for the HM34 Series.

IM-S03-11 CMGT Issue 5
10
HM and HM34 Inverted Bucket Steam Traps





 

Temperature °C
HM Series
Pressure bar g
Steam saturation curve
The product must not be used in this region.
*PMO Maximum operating pressure recommended for saturated steam 14 bar g (203 bar g).
∆PMX - Maximum differential pressure
Size
Maximum differential pressure bar
48.5 10 12.5 14
Screwed
½" HM00/8 HM00/7 HM00/6 — —
¾" HM10/10 HM10/8 —HM10/7 —
1" HM12/12 HM12/10 — — HM12/7
Flanged
DN15 HM003/8 HM003/7 HM003/6 — —
DN20 HM103/10 HM103/8 —HM103/7 —
DN25 HM123/12 HM123/10 — — HM123/7
Note: The pressure limit of the flange type should be greater than the pressure limit of the internal mechanism
selected.
2.4 Limiting conditions
HM HM34
Maximum body designed conditions PN16 PN40
PMA Maximum allowable pressure 16 bar g (232 psi g) 40 bar g (580 psi g)
TMA Maximum allowable temperature 300 °C (572 °F) 300 °C (572 °F)
PMO Maximum operating pressure 16 bar g (232 psi g) 40 bar g (580 psi g)
TMO Maximum operating temperature 300 °C (572 °F) 300 °C (572 °F)
Designed for a maximum cold hydraulic test pressure of: 24 bar g (348 psi g) 60 bar g (870 psi g)
2.5 Operating range

IM-S03-11 CMGT Issue 5 11
HM and HM34 Inverted Bucket Steam Traps





    
Pressure bar g
Temperature °C
The product must not be used in this region.
*PMO Maximum operating pressure recommended for saturated steam 32 bar g (464 bar g).
∆PMX - Maximum differential pressure
Size
Maximum differential pressure bar
48.5 12 20 32
DN15 - ½" HM34/8 HM34/7 HM34/6 HM34/5 HM34/4
DN20 - ¾" HM34/10 HM34/8 HM34/7 HM34/6 HM34/5
DN25 - 1" HM34/12 HM34/10 HM34/8 HM34/6 HM34/5
Note: The pressure limit of the flange type should be greater than the pressure limit of the internal mechanism
selected.
HM34 Series
Steam saturation
curve

IM-S03-11 CMGT Issue 5
12
HM and HM34 Inverted Bucket Steam Traps
After installation or maintenance ensure that the system is fully functioning. Carry out tests on any alarms
or protective devices.
Under most conditions the trap will discharge condensate with a blast type action. Under low load and/or low
pressure applications the discharge may tend to 'dribble'. Condensate is discharged at steam temperature
so due care must be given to the site of the discharge.
Note: Before actioning any installation observe the 'Safety information' in Section 1.
Referring to the Installation and Maintenance Instructions, name-plate and Technical Information Sheet,
check that the product is suitable for the intended installation.
3.1 Check materials, pressure and temperature and their maximum values. If the maximum operating
limit of the product is lower than that of the system in which it is being fitted, ensure that a safety
device is included in the system to prevent overpressurisation.
3.2 Determine the correct installation situation and the direction of fluid flow.
3.3 Remove protective covers from all connections.
3.4 The trap must be installed with the body upright so that the bucket is rising and falling vertically. When
superheat conditions exist the trap body may need to be primed with water prior to steam being turned
on to avoid steam blowing through the trap.
3.5 Inverted bucket steam traps do not permit rapid release of air. On process applications, in particular,
this can lead to slow warm-up times and waterlogging of the steam space. A separate external air
vent is therefore required in parallel to vent air efficiently. Any bypass should be positioned above the
trap. If it is below, and is leaking or left open, the waterseal could be blown away leading to steam
wastage (see Fig. 5). Where inverted bucket traps are fitted in exposed conditions the possibility of
freezing damage can be reduced by thermal insulation.
3.6 Traps must be installed in a horizontal pipeline with the strainer pocket at the bottom. The inlet of the
trap should be below the drain point of the plant being drained, so that a waterseal can be maintained
around the open end of the bucket. A small drop leg should precede the trap - typically 150 mm (6").
3.7 Where the trap discharges into a closed condensate return system or where there is a lift at the trap,
a check valve should be fitted downstream of the trap.
3.8 If the trap has to be installed at a higher point than the drainage point then a small bore riser into a
'U' seal should be used. A check valve should be fitted before the trap to prevent the loss of the internal
waterseal. See Fig. 6.
Note: If the trap is to discharge to atmosphere ensure it is to a safe place, the discharging fluid may be at a
temperature of 100 °C (212 °F).
3. Installation
4. Commissioning
5. Operation

IM-S03-11 CMGT Issue 5 13
HM and HM34 Inverted Bucket Steam Traps
Fig. 5
Fig. 6
Air vent
Bypass
'HM' trap
Check valve
Check valve
'HM' trap

IM-S03-11 CMGT Issue 5
14
HM and HM34 Inverted Bucket Steam Traps
Note: Before actioning any maintenance program observe the 'Safety information' in Section 1.
Warning
The body/cover gasket and strainer cap gasket contain a thin stainless steel support ring which
may cause physical injury if not handled and disposed of carefully.
6.1 Before undertaking any maintenance on the trap it must be isolated from both the supply line and
return line and any pressure allowed to safely normalise to atmosphere. The trap should then be allowed to
cool. When reassembling, ensure that all joint faces are clean.
6.2 How to fit the valve and seat assembly:
-Undo the cover bolts and nuts (2) and remove the cover from the body.
-Unhook the bucket (4) from the valve lever (10).
-Remove the valve guide plate by undoing the two screws (5).
-Remove the seat (8) from the cover.
-Ensure all joining faces are clean and then screw in the new seat to the recommended
tightening torque. Use a small amount of joining paste on the threads.
-Fit new valve guide plate with the two screws supplied and refit the new lever. Ensure that the valve and
seat are aligned correctly before finally tightening the guide plate screws.
-Hook the bucket to the lever and ensure gasket faces on the body cover are clean.
-Using a new cover gasket (7) refit the cover to the body ensuring the small ferrule (11) is positioned
correctly. Tighten cover bolts / nuts to the recommended tightening torque (see Table 1).
6.3 How to clean / replace the strainer screen:
-Undo the strainer cap (13) and remove the screen (12) and gasket (14).
-Clean or replace the strainer screen (12).
-Ensure threads are clean.
-Refit new strainer cap gasket and locate the screen in the strainer cap.
-Screw into the body and tighten to the recommended torque (see Table 1).
6. Maintenance

IM-S03-11 CMGT Issue 5 15
HM and HM34 Inverted Bucket Steam Traps
12
14
7
11
4
2
2
13
Fig. 7
HM Series shown
Valve seat
assembly
10
8
5
6
Table 1
Recommended tightening torques
Item no. or
mm Nm (lbf ft)
2
HM
½"
and
¾"
M6 x 25 15 - 16 (11 - 12)
1" M12 x 45 85 - 95 (61 - 68)
HM34
½"
and
¾"
M8 x 30 25 - 28 (18 - 20)
1" M12 x 45 25 - 28 (18 - 20)
8
HM
½"
and
¾"
13 50 - 55 (36 - 40)
1" 13 80 - 88 (57 - 63)
HM34
½"
and
¾"
13 50 - 55 (36 - 40)
1" 13 80 - 88 (57 - 63)
13
HM
½"
and
¾"
22 M28 90 - 100 (64 - 72)
1" 27 M32 125 - 145 (89 - 104)
HM34
½"
and
¾"
22 M28 90 - 100 (64 - 72)
1" 27 M32 125 - 145 (89 - 104)

IM-S03-11 CMGT Issue 5
16
HM and HM34 Inverted Bucket Steam Traps
The spare parts available are shown in heavy outline. Parts drawn in a grey line are not supplied as spares.
Available spares
Valve and seat assembly 5, 6 (2 off), 8, 10
Bucket 4
Cover gasket and ferrule (packet of 3 each) 7, 11
Strainer screen 12
Strainer screen gasket (packet of 3) 14
Set of cover bolts and nuts (set of 6) (HM34 only) 2
How to order spares
Always order spares by using the description given in the column headed 'Available spares' and state the
size and series of the trap.
Example: 1 - Valve and seat assembly for DN15 HM34/7 Spirax Sarco inverted bucket steam trap.
7. Spare parts

IM-S03-11 CMGT Issue 5 17
HM and HM34 Inverted Bucket Steam Traps
12
14
7
11
10
8
5
6
4
2
2
13
Fig. 8 HM Series shown
Valve seat
assembly

IM-S03-11 CMGT Issue 5
18
HM and HM34 Inverted Bucket Steam Traps

IM-S03-11 CMGT Issue 5 19
HM and HM34 Inverted Bucket Steam Traps

IM-S03-11 CMGT Issue 5
20
HM and HM34 Inverted Bucket Steam Traps
