Spring V11 User manual

Operating Warnings Pump Controller - Quick Start Guide V11 Analogue
Adjust your flow settings carefully. Repeated false dead-end detection
indicates that the Cal value should be increased (clockwise is less sensitive).
For absolute safety always wire through the pump pressure switch.
(The pressure switch can be bypassed if absolutely necessary - the
unit will protect itself under normal conditions.)
This is a WATER PUMP controller: it will not work with air in the system.
Always prime your system before starting work. If air in the system causes
false dead-end detection, increase Cal value (clockwise is less sensitive).
Do not set the Cal value too high. Setting it higher than necessary
places extra strain on both the pump and the controller in a dead
end situation. This can result in damage to both the pump and
your controller.
Specification
Supply Voltage
Maximum Current
Typical Drive Current
Enclosure Material
Water Resistance
Dimensions
Working Temperature
11 - 15 VDC
10A
4-5A
ABS
IP65
115 x 65 x 40 (mm)
0 to 40 Deg C
Value
DISCLAIMER
THE MANUFACTURER RESERVES THE RIGHT TO MAKE CHANGES TO ANY PRODUCT HEREIN TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN. THE MANUFACTURER DOES NOT ASSUME ANY LIABILITY ARISING
OUT OF THE APPLICATION OR USE OF ANY PRODUCT OR CIRCUIT DESCRIBED HEREIN. Make sure correct fuse is fitted inline. Failure to do so will result in damage to the unit.
Observe correct battery polarity. Failure to do so will result in damage to the unit.
Fuse 7.5A
+
12V
Battery
Step 1
Connect the pump controller in accordance with this diagram.
NOTE: only fit the fuse once all connections are made.
For more information and videos on how to use Spring controllers please visit: www.springltd.co/videos
Copyright © 2019 Spring (Europe) Ltd. All rights reserved.
V11 Wiring
Pump
5
6
7
8
9
10
4
3
2
1
PS DE BATT
MAX
DEAD END
CALIBRATION
MIN
0
PUMP
FLOWRATE

Connect your hose and brush to the pump.
Turn on the controller by turning the PUMP
FLOWRATE dial clockwise - water needs to be
flowing to the brush.
Turn the DEAD END CALIBRATION dial to
maximum (fully clockwise) to let the flow of
water start.
Slowly turn the DEAD END CALIBRATION
dial back down (anti-clockwise) until the
water flow stops. The DE LED will illuminate.
Turn the DEAD END CALIBRATION dial back up
(clockwise) a little until the water flow re-starts
and remains constant.
Step 2 Step 3 Operation Set up - Calibration V11 Analogue V11 Analogue
LED
If LED is ON then pressure switch has been activated or
motor disconnected.
If activated by a flow restriction in your system then
remove the restriction (e.g. hose kink) to reset the pump
pressure switch and resume pumping.
If LED is ON then a dead end has been detected. If this is
not the case try increasing the Cal value. In dead end the
controller will stop the water flow. If activated by a flow
restriction in your system then remove the restriction
(e.g. hose kink) to resume pumping.
If LED is ON battery voltage is ok.
If the LED is flashing battery voltage is 11.0V or less. The
controller will shutdown the pump to protect your battery
if the voltage falls below 10.5V. Note: permanent damage
to your battery cells can occur below 10.5V.
Description
PS LED
DE LED
BATT LED
To adjust the water flow simply turn the PUMP FLOWRATE dial up
(clockwise) to increase the flow and turn down (anti-clockwise) to
decrease the flow.
Note: the higher the water flow the harder the pump is working
(drawing a higher current). Higher current draw will reduce working
time per battery charge.
5
6
7
8
9
10
4
3
2
1
0
PUMP
FLOWRATE
5
6
7
8
9
10
4
3
2
1
0
PUMP
FLOWRATE
Increase Decrease
The controller should now be calibrated to your system and we would
expect the dial to point between 12 and 2 O’Clock. However this is
system dependent.
Note: in a properly calibrated system, DE will be detected by the controller
long before PS (pressure switch) is activated by the pump - due to a restriction.
This saves wear on the pressure switch and resumes pump operation
(and working) far more quickly when the flow is started at the pole again (e.g.
pole valve opened, hose kink removed or pole reconnected).
5
6
7
8
9
10
4
3
2
1
0
PUMP
FLOWRATE
MAX
DEAD END
CALIBRATION
MIN
MAXMIN
MAXMIN
