SPT WA-9061H User manual

1
PORTABLE AIR CONDITIONER WITH HEATER
WA-9061H: 9,000 BTU
WA-1061H: 10,000BTU
☆ Read and retain these instructions for future reference
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194

2
SPECIFICATION
·
Model no. WA-9061H WA-1061H
Cooling capacity 9000 BTU/hr
2637 W 10000 BTU/hr 2930 W
Heating capacity 8500 BTU/hr
2491 watts 9500 BTU/hr 2783 watts
EER 9.38 9.35
Power/Ampere consumption – Cooling* 960W / 8.29 A 1070W / 8.7 A
Power/Ampere consumption – Heating* 840W / 7.75 A 950W / 8.18 A
Air volume (max. speed) 375m
3
/h 375m
3
/h
Humidity removal capacity 1 L/hr 1 L/hr
Power supply 110~120V/50Hz/1phase
Compressor rotary
Recommended room size 250 sq.ft. 300 sq.ft.
Refrigerant R410A
Fan speed 2
Timer 1~ 12 hours
Thermostat Cooling: 64~90°F (18~32°C)
Heating: 45~77°F (7~25°C)
Operating temperature 45 ~ 95°F
Exhaust pipe 5 x 59 in
Net Weight 47.4 lbs 55.12 lbs
Dimension 12W x 15D x 29.61H in
* Data may vary for technical reasons; for greater precision, please refer to the rating label
located on the back of the unit.
NOTE:
1. Measuring condition for above is:
Cooling: DB= 95°F / WB= 75°F
Heating: DB= 68°F / WB = 59°F
2. Current & Fuse: F2L250V or T2L250V
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194

3
BEFORE USE
GENERAL SAFETY
• Only use in the upright position on a flat level
surface and at least 14in. from any walls or
objects (fig 1 & 4).
• Do not place any objects on the unit or block the
air inlet / outlet (fig. 2).
• Closely supervise children and pets when unit is
in use.
ELECTRICAL SAFETY
• For indoor household use only.
• Switch off and unplug when not in use.
• Do not use in humid or wet environments. (fig 3)
• Do not pull the UNIT by the cord.
• IF THE SUPPLY CORD IS DAMAGED, TO
AVOID HAZARD, IT MUST BE REPLACED BY
AN ELECTRICIAN OR SIMILARLY QUALIFIED
PERSON.
FOR MAXIMUM EFFICENCY
• Use the unit in the recommended room size.
• Locate the unit where furniture cannot obstruct
the airflow.
• Close doors and windows.
• Keep curtains or blinds closed during the
sunniest part of the day.
• Keep filters clean.
• Set unit to maximum cooling on high initially and
once room has reached the desired conditions,
reduce temperature and fan speed settings.
• It is recommended to turn on the air conditioner
when ambient temperature reaches 75°F. Do
not wait until the room is excessively hot.
FIG. 1
FIG.2
FIG.3
FIG.4
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194

4
PARTS
Front Back
1. Display window
2. Control panel
3. Air outlet
4. Carrying handle
5. Caster
6. Cord storage
7. Air filter
8. Air inlet
9. Exhaust air outlet
10. Air inlet
11. Water stopper/drainage
Accessories
FIG.7
13. Exhaust hose
14. Slider kit adapter – connects exhaust hose
to slider kit.
15. Plastic slider kit – piece 1 of 2
16. Plastic slider kit – piece 2 of 2
17. Drain tube
18. Active carbon filter
19. Remote
FIG.6
FIG.5
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194

5
INSTALLATION
The unit is a portable air conditioner that may be moved from room to room.
1. Installing the plastic slider kit.
FIG.8
 Extend both ends of the exhaust hose by few inches.
 Connect hose to the back of unit by turning clockwise – do not over tighten.
 Connect adapter piece to hose by turning clockwise (with opening end facing you).
 Determine how many sections of the slider kit your window requires.
 Place slider kit inside the window frame and adjust height accordingly. Once set, insert
the small screw through side opening to secure.
 Align and insert adapter piece to opening on window kit.
 Slide window close against the window kit.
 The best distance between the machine and window or wall is 31-39 inches.
Mounting of the exhaust pipe
• Use only the hose provided and clip exhaust hose
to the back of the air conditioner
• Avoid kinks and bends in the exhaust hose. If
expelled air is not exhausted smoothly, it will build
up in the hose and lead to unit overheating and
shutting down. Refer to Fig 11 & 12 for correct
position.
• The hose may be extended from 11” to 59”. But
for maximum efficiency, use the shortest length
possible.
WARNING!
The length of the exhaust pipe is specially designed
according to the specification of this product. Do not
replace or prolong it with your own private hose as this
could cause the unit to malfunction.
Window kit
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194

6
Carbon Filter Installation
1. Remove filter frame from unit.
2. Remove the filter fixer from the filter frame.
3. Remove active carbon filter from plastic bag.
4. Insert active carbon filter to filter frame.
5. Replace filter fixer to frame. The active
carbon filter is now held in between the filter
frame and filter fixer.
6. Replace filter frame to unit.
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194

7
OPERATION
Control panel
1. Mode (function) select button
2. Timer button
3. “Water Full” indicator
4. Sleep button
5. Fan speed button
6. Low fan speed indicator
7. High fan speed indicator
8. Receiver for remote control
9. Sleep operation indicator
10. “Temperature down” button
11. ON/OFF (power) button
12. “Temperature up” button
13. Timer operation indicator
14. Compressor operation indicator
15. Heat mode indicator
16. Fan mode indicator
17. Cooling mode indicator
18. Auto mode indicator
Turning ON/OFF
1. Press ON/OFF button and unit will start automatically. If ambient temperature is:
 Above 74°F/23°C, the unit will work in Cool mode.
 Above 68°F/20°C but below or equal to 74°F/23°C, th e unit will work in Fan mode.
 Below 68°F/20°C, the unit will work in Heat mode.
2. Indicators of the functions in progress will illuminate.
NOTE: The display window shows ambient room temperature from 32~122°F/0~50
o
C.
3. To turn the unit off, press ON/OFF button again.
Setting mode/function
Press MODE button to select desired working mode: AUTO, COOL, FAN or HEAT.
The indicator of selected mode will illuminate.
Setting temperature
1. Press 'Temperature up' or 'Temperature down' button to set desired temperature.
2. The display window will show the set temperature as the UP or DOWN buttons are pressed.
Once the buttons are release, display will revert to show the ambient temperature.
3. The pre-set temperature is 75°F/24°C for cooling an d 68°F/ 20°C for heating.
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194

8
Setting fan speed
1. Press SPEED button to choose the desired fan speed, high or low. The corresponding
indicator (HI or LOW) will illuminate.
2. If the unit is operating in AUTO mode, the SPEED button is invalid. Unit will automatically
choose the fan speed based on the ambient temperature.
Setting timer
1. If unit is in operation, pressing the TIMER button will set the operating hours (from 1 to 12
hours). Once the set time has been reached, unit will turn off automatically. Timer indicator
will illuminate. Display window shows the hour(s) as TIMER button is pressed.
2. If unit is off, pressing the TIMER button will pre-set the time for the unit to come on. For
example, if you set the timer to 2, the unit will begin operating after 2 hours.
Sleep function
1. When selected in COOL mode: unit will increase the set temperature by 2°F /1°C after the
first hour and another 2°F /1°C after the second hour, then keeps at that temperature.
2. When selected in HEAT mode: unit will decrease the set temperature by 2°F /1°C after the
first hour and another 2°F /1°C after the second hour, then keeps at that temperature.
3. In SLEEP mode, fan speed will be kept at LOW.
4. Pressing the SLEEP button again will revert set temperature and fan speed back to pre-
selected settings.
5. The unit will shut down automatically after operating in SLEEP mode for 12 hours
continuously.
NOTE: SLEEP function is not available in AUTO or FAN mode.
HEAT mode
1. When HEAT mode is selected, the ambient warm air will be recycled and utilized to heat the
area where it is required. The Exhaust Pipe must be fitted properly to exhaust the cold
air outdoors.
2. Continuous drain is mandatory when unit operates in heat mode.
3. The working temperature range for heating function is 45~77°F/7~25°C. If ambient
temperature is outside this range, the unit may not work properly.
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194

9
Remote control
All functions can also be performed with the supplied remote control.
The remote control requires two (2) AAA batteries.
Directing air flow
Manually adjust the louvers left & right or up & down to direct
air flow.
FIG. 17
NOTICE !
 To prolong the life of the compressor after powering off the unit please wait at least 3
minutes before turning it back on.
 When operating in COOL mode the cooling system will switch off when ambient
temperature falls below set temperature. The fan however will continue to run. Once
ambient temperature rises above the selected level cooling will resume.
 When operating in HEAT mode heating will switch off when ambient temperature is
higher than set temperature. The fan however will continue to run. Once ambient
temperature drops below the selected level heating will resume.
 This machine is equipped with ANTI-FROST function. When unit is operating in low
temperature surroundings the heating function may be paused at times to defrost.
When this occurs just wait for heating to resume.
Fig.16
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194

10
DRAINAGE
During the cooling process, some water will be extracted from the air into the unit.
If the reservoir is full, both of the compressor (cooling) and motor (fan) will stop and unit will
emit a Buzz (press any button to stop the buzz); the Water Full indicator will also be
flashing.
Before cooling can resume, empty the water tank:
1. Turn off the air conditioner and avoid moving it when full.
2. Position a container (a water tray for example)
underneath the drain spout.
3. Remove the drain knob & rubber plug and allow water
to drain out.
4. When the container is almost full replace the rubber
plug and empty the water tray. Repeat until the unit is
emptied.
5. Replace rubber plug and tighten drain knob firmly.
6. Switch on the unit –
the Water Full indicator should no
longer be flashing.
Continuous drainage (if you wish to operate the unit without the need to empty the water tank):
• Remove the drain knob and rubber plug and retain
for future use.
• Connect the supplied drain tube to the drain spout
as shown and locate the other end into a drain.
• Note the drainage is gravity-pulled, the drain tube
must not have any incline.
• The drain tube can be extended by adding an
extension tube with a suitable connector.
Note
• Drain tube must be paralleled or below outlet level.
• Flashing ‘Water Full’ indicator will not function in
continuous drainage.
• To extend the water tube, connect with another
tube (OD: 18mm)
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194

11
MAINTENANCE
Always unplug the air conditioner from power source before cleaning.
Clean regularly to maximize the efficiency of the air conditioner.
Cleaning the housing
 Use a soft, damp cloth to wipe the body clean.
 Never use aggressive chemicals, gasoline, detergents, chemically treated cloths, or other
cleansing solutions. These products may blemish the cabinet.
Cleaning the filter
 Use a vacuum cleaner or tap the filter lightly to first remove any loose particles, then rinse
thoroughly under running water (no hotter than 104°F/40°C).
 Dry thoroughly before replacing.
 Never operate the unit without the filters.
End of season storage
• Drain water from the unit.
• Operate the unit in FAN mode for a few hours to
thoroughly dry the inside.
• Clean or change the filters.
• Unplug and store the power cord as shown.
• Replace in the original carton or cover for storage.
TROUBLE SHOOTING
The air conditioner does not
run
 Is the air conditioner plugged in?
 Is there a power failure?
 Is the Water Full indicator flashing?
 Is the room temperature below the set temperature?
The machine seems to do
little
 Is there direct sunshine? (Please close curtain)
 Too many windows or doors open?
 Too many people in the room?
 Is there something in the room producing lots of heat?
The machine seems to do
nothing.
 Is the filter dusty, contaminated?
 Is the air intake or output blocked up?
 Is the room temperature below set temperature?
Too noisy  Is the machine positioned unevenly, creating vibration?
 Is the floor underneath the machine uneven?
The compressor doesn’t run.
 It is possible the overheat protection is on. Just wait for
the temperature to drop.
☆
☆☆
☆ Never try to repair or dismantle the unit yourself
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194

12
Your Guarantee
If this product is found to be faulty as a result of faulty materials or workmanship
within one year from date of purchase, it will be repaired free of charge.
This guarantee is subject to the following terms:
• Sunpentown must be notified of the fault.
• Proof of purchase must be presented to Sunpentown’s nominated representative.
• The warranty will be void if the product if modified, misused or repaired by an unauthorized
person.
• The warranty after repair will not be extended beyond the original one-year period.
• All replacement parts will be new or reconditioned.
• Parts, which are replaced, become the property of Sunpentown.
• The warranty applies for the use of the product in the USA only.
What is NOT COVERED:
• Warranty does not include freight charges.
• Incidental or consequential damage caused by possible defects with this product.
• Damage to product caused by improper power supply voltage, accident, fire, floods or acts of
nature.
• Failure of product resulting from unauthorized modifications to the product.
• Improper installation or failure to perform the necessary maintenance.
This GUARANTEE is in addition to your Statutory Rights
SUNPENTOWN INTERNATIONAL INC.
14625 Clark Ave. City of Industry, CA 91745
Tel: [phone]
[e-mail]
www.sunpentown.com
www.sylvane.com 1-800-934-9194www.sylvane.com 1-800-934-9194
