Debem Mb series Specification sheet

www.debem.it

MB 03/2014

INDUSTRIAL PUMPS - INDUSTRIEPUMPEN

petrochemical, food, mechanical, environmental, printing, chemical, painting, galvanic, textile and ceramic, industry

TÜV NORD Italia

S.r.l.

INSTRUCTIONS FOR USE AND MAINTENANCE

ISTRUZIONI PER L’USO

E LA MANUTENZIONE

POMPE CENTRIFUGHE ORIZZONTALI

HORIZONTAL CENTRIFUGAL PUMPS

USE AND

MAINTENANCE

INSTRUCTIONS

COD. MB-02-11-2009

MB 80

MB 100

MB 110

MB 120

MB 130

MB 140

MB 150

MB 155

MB 160

MB 180

BEDIENUNGS-UND WARTUNGSANLEITUNG

debem.it

Debem SRL

2014

Alle Rechte der vollständigen oder teilweisen Über-

setzung, des Nachdrucks und der Anpassung auf

irgendeine Weise sind in allen Ländern vorbehal-

ten.

Debem SRL

2014

All rights of total or partial translation, reproduction

and adaptation by any means are reserved

in all countries.

3debem.it

INHALT SEITE

VORWORT 4

EINFÜHRUNG IN DAS HANDBUCH 4

IDENTIFIKATION DER PUMPE 6

IDENTIFIKATIONSCODE 6

BESCHREIBUNG DER PUMPE 7

TECHNISCHE CHARAKTERISTIKA 8

GARANTIE 12

SICHERHEITSANFORDERUNGEN 13

TRANSPORT UND POSITIONIERUNG 15

ANSCHLUSS DES PRODUKTKREISLAUFS 18

ELEKTRISCHER ANSCHLUSS DES MOTORS UND ÜBERPRÜFUNG DER DREHUNG 19

INBETRIEBNAHME 23

ZEITPLAN DER REGELMÄSSIGEN WARTUNG 24

WARTUNG DES PRODUKTKREISLAUFS 25

ÖFFNUNG DER PUMPE UND INTERNE REINIGUNG 26

AUSBAU DER DICHTUNG 27

MONTAGE DER DICHTUNG UND DES MOTORS 28

FEHLERBEHEBUNG 29

STILLLEGUNG 31

ENTSORGUNG UND RÜCKBAU 31

ERSATZTEILE 32

INDEX PAGE

FOREWORD 4

INTRODUCTION 4

PUMP IDENTIFICATION 6

IDENTIFICATION CODES 6

PUMP DESCRIPTION 7

TECHNICAL FEATURES 8

WARRANTY 12

SAFETY RULES 13

TRANSPORT AND POSITIONING 15

CONNECTING THE PRODUCT CIRCUIT 18

ELECTRICAL MOTOR CONNESCTION AND ROTATION CHECK 19

START UP 23

STANDARD MAINTENANCE TIME-SCHEDULE 24

MAINTENANCE FOR THE PRODUCT CIRCUIT 25

PUMP OPENING AND INTERNAL CLEANING 26

SEALING DISASSEMBLY 27

SEALING AND MOTOR ASSEMBLY 28

TROUBLESHOOTING 29

DECOMMISSIONING 31

DEMOLITION AND DISPOSAL 31

SPARE PARTS 32

debem.it

VORWORT

Die Horizontalkreiselpumpen MB wurden in Übereinstimmung

mit der Maschinenrichtlinie 2006/42/EG hergestellt. Daher

stellen sie keine Gefahren für den Bediener, wenn sie nach

den Anweisungen dieses Handbuchs verwendet werden.

Das Handbuch muss für zukünftiges Nachschlagen des War-

tungspersonals in gutem Zustand und/oder in der Nähe der

Maschine aufbewahrt werden. Der Hersteller lehnt jede Haf-

tung für Änderungen, Manipulationen, falsche Anwendungen

oder Arbeiten, die den Inhalt dieses Handbuchs nicht einhal-

ten und die Schäden an der Gesundheit und Sicherheit von

Personen, Tieren und Gegenständen in der Nähe der Pumpe

verursachen können, ab.

Der Hersteller hofft, dass es Ihnen möglich sein wird, die vol-

len Leistungen der Horizontalkreiselpumpen MB zu nutzen.

Alle technischen Angaben beziehen sich auf die Standard-

pumpe MB (siehe “TECHNISCHE CHARAKTERISTIKA“),

aber es wird darauf hingewiesen, dass aufgrund der ständi-

gen Suche nach technologischen Innovationen und Qualität

die angegebenen Charakteristika ohne Vorankündigung ge-

ändert werden können.

Alle Zeichnungen und Darstellungen in den mit dem Gerät ge-

lieferten Dokumenten sind Eigentum des Herstellers, der sich

alle Rechte vorbehält und die Weitergabe an Dritte ohne seine

vorherige schriftliche Genehmigung VERBIETET.

ES SIND DAHER ALLE REPRODUKTIONEN, AUCH TEIL-

WEISE, DES HANDBUCHS, DES TEXTES UND DER

ZEICHNUNGEN STRENGSTENS VERBOTEN.

FOREWORD

The MB horizontal, centrifugal pumps have been manufactured

in accordance with the 2006/42/EC directives.

Therefore, when used according to the instructions contained

in this manual, the Boxer pumps will not pose any risk to the

operator.

This manual must be kept in good condition and/or be kept

with the machine as a reference for maintenance purposes.

The manufacturer declines any liability concerning any changes,

modications, incorrect use or operation not complying with the

contents of this manual and that may constitute a health and

safety hazard to people, animals or property nearby the pump.

The Manufacturer trusts you will take full advantage of the

performance offered by MB horizontal, centrifugal pumps.

All technical parameters refer to the standard MB models

(please see “TECHNICAL FEATURES”). However, the constant

search for innovation and technological quality means that the

characteristics detailed herein may change without prior notice.

All of the drawings and any other documentation supplied with

the pump are the property of the Manufacturer, who reserves

all rights and FORBIDS distribution to third parties without his

authorization in writing.

THEREFORE REPRODUCTION, EVEN PARTIAL, OF THIS

MANUAL, TEXT OR DRAWINGS IS STRICTLY FORBIDDEN.

EINFÜHRUNG IN DAS HANDBUCH

Das vorliegende Handbuch ist integraler Bestandteil der Pum-

pe und stellt eine SICHERHEITSEINRICHTUNG. Es enthält

wichtige Informationen, die dem Käufer und seinen Mitarbeitern

helfen, die Pumpe bei der Installation, Verwendung und War-

tung ihrer gesamten Lebensdauer in guten Zustand zu halten.

Zu Beginn jedes Kapitels und jedes Abschnitts wurde ein In-

formationsfeld eingefügt, das dem für die Eingriffe geschultem

Personal durch Symbole die obligatorische persönliche Schut-

zausrüstung und/oder den Energiestatus der Pumpe anzeigt.

Jedes Restrisiko, das während des Vorgangs auftreten kann,

wird durch entsprechende Symbole, die im Text integriert sind,

angezeigt.

Spezielle Symbole werden auch verwendet, um besondere

Informationen oder Ratschläge bezüglich der Sicherheit und

der ordnungsgemäßen Verwendung der Pumpe hervorzuheben

und zu differenzieren.

FÜR ALLE WEITEREN INFORMATIONEN BEZÜGLICH DES

INHALTS DIESES HANDBUCHS KONTAKTIEREN SIE BITTE

DEN KUNDENSERVICE DES HERSTELLERS.

INTRODUCTION

This manual is an integral part of the pump, and represents a

SAFETY DEVICE. It contains important information that will

assist the purchaser and his personnel in installing and using

the pump and ensuring that the pump is kept in safe and good

working order throughout its working life.

At the beginning of each chapter and section there is a status

bar: its symbols state the personnel qualied for the operation/

s in question, the compulsory individual protective devices to

wear and/or the power state of the pump. Any other hazard that

may occur during operations is highlighted by special symbols

embedded in the text.

Special identication symbols are used to highlight and differ-

entiate particular information or suggestions concerning safety

and the pump’s correct use.

FOR ANY FURTHER INFORMATION REGARDING THE

CONTENTS OF THIS MANUAL, PLEASE CONTACT THE

MANUFACTURER’S ASSISTANCE DEPARTMENT.

5debem.it

ACHTUNG: dieses Zeichen zeigt dem verantwortli-

chen Personal an, dass der beschriebene Vorgang

ein Expositionsrisiko mit Restgefahren mit der Mög-

lichkeit von gesundheitlichen Schäden oder Verletzungen,

wenn die beschriebenen Verfahren und Anforderungen

nicht in Übereinstimmung gemäß den Sicherheitsvorschrif-

ten ausgeführt werden, birgt.

HINWEIS: dieses Zeichen zeigt dem verantwortlichen

Personal, das der beschriebene Vorgang Schäden an

der Maschine und/oder ihren Komponenten und folglich

Risiken für den Bediener und/oder die Umwelt verursachen

kann, wenn er nicht in Übereinstimmung gemäß den Sicher-

heitsvorschriften ausgeführt wird.

ANMERKUNG: dieses Zeichen liefert Informationen

über den laufenden Betrieb, deren Inhalt von relevanter

Bedeutung ist.

SYMBOLE DER OBLIGATORISCHEN UND PERSÖN-

LICHEN SCHUTZAUSRÜSTUNG: dieses Zeichen zeigt

die Pflicht zum Tragen angemessener persönlicher

Schutzausrüstung und den Energiestatus aufgrund der

Gefahren, die beim Betrieb auftreten können, an.

BEDIENER: diese Qualifikation setzt umfassen-

de Kenntnisse und volles Verständnis der in der

Bedienungsanleitung des Herstellers enthaltenen

Informationen sowie spezische Fähigkeiten in Bezug auf den

Anwendungsbereich voraus.

INSTALLATIONS- UND WARTUNGSPERSONAL:

diese Qualikation setzt umfassende Kenntnisse und

volles Verständnis der in der Bedienungsanleitung des Herstel-

lers enthaltenen Informationen, spezisches Fachwissen bei

der Installation und den gewöhnlichen Wartungen sowie spezi-

sche Fähigkeiten in Bezug auf den Anwendungsbereich voraus.

ACHTUNG: das für die Installation, Inspektion und

Wartung der Pumpe verantwortliche Personal muss

über eine angemessene technische Ausbildung mit

ausreichenden Kenntnissen über den Anwendungsbereich

verfügen (geeignete Kompatibilität im Anwendungsbereich

und Risiken in Verbindung mit möglichen chemischen

Reaktionen des zu pumpenden Produkts).

PERSONAL FÜR DIE ELEKTRISCHE WARTUNG:

diese Qualikation setzt umfassende Kenntnisse und

volles Verständnis der in diesem Bedienungshandbuch

des Herstellers enthaltenen Informationen und technisches

Fachwissen, um Eingriffe elektrischerArt vorzunehmen, voraus:

Anschluss, regelmäßige Wartung und/oder Reparatur.

AUSSERORDENTLICHE VERFAHREN: identiziert

die Eingriffe, die den Technikern des Kundenservices

vorbehalten sind und ausschließlich in der Werkstatt

des Herstellers durchgeführt werden.

WARNING: this sign warns the relevant personnel

that the operation in question involves the risk of

exposure to various types of health hazards or

injuries, unless it is carried out according to current safety

norms.

WARNING: This sign warns the relevant personnel that

the operation in question might damage the machinery

and/or its components, with consequent hazard to the

operator and/or the environment, unless it is carried out in

accordance with current safety norms.

NOTE: This note supplies relevant and important infor-

mation on the current operation.

SYMBOLS FOR COMPULSORY AND PERSONAL

SAFETY: indicate compulsory, adequate personal

protection and the hazard/s that might occur during

operation consequent to the power status indicated.

OPERATOR: This qualication implies a full knowl-

edge and understanding of the information contained

in this manual, besides a specic competence in the

eld of employment.

INSTALLER AND MECHANICAL MAINTENANCE

OPERATOR: This qualication implies a full knowl-

edge and understanding of the information contained in the

manufacturer’s use manual, a specic competence to carry

our standard installation and maintenance operations beside

a specic competence in the eld of employment.

WARNING Installation, inspection and maintenance

personnel must have adequate technical training as

well as an adequate knowledge of their eld of op-

eration (correct compatibility of materials and hazards re-

lated to possible chemical REACTIONS OF THE PRODUCT

TO BE PUMPED.

ELECTRICAL INSTALLER-MAINTENANCE OP-

ERATOR: This qualication implies a comprehensive

knowledge and understanding of the information

contained in the manufacturer’s user manual, technical com-

petence specic to electrical operations: connection, standard

maintenance and/or repairs.

EXTRAORDINARY OPERATIONS: identify work re-

stricted to service technicians that can only be carried

out in the manufacturer’s workshop.

ATTENZIONE:

il personale addetto all’installazione, all’ispezio-

ne e alla manutenzione della pompa deve avere

adeguata preparazione tecnica unita a cognizioni

idonee al campo di applicazione (compatibilità ade-

guate in materia e rischi connessi ad eventuali reazio-

ni chimiche del prodotto da pompare).

INSTALLATORE/MANUTENTORE ELETTRICO:

questa qualifica presuppone una piena conoscenza e

comprensione delle informazioni contenute nel manuale

d’uso del costruttore, competenza tecnica specifica per

effettuare gli interventi di natura elettrica di: allacciamento,

manutenzione ordinaria e/o riparazione.

INTERVENTI STRAORDINARI: identifica gli interventi

riservati a tecnici del servizio di assistenza eseguiti

solo presso le officine del Costruttore.

WARNING

personnel responsible for pump installation,

inspection and maintenance shall possess a suitable

technical background along with knowledge of the

field of application (compatibility of materials and risks

associated with possible chemical reactions of the

product being pumped).

ELECTRICAL/FITTER AND MAINTENANCE

ENGINEER

this qualification implies complete familiarity and

understanding of the information contained in the

manufacturer’s user manual and specific electrotechnical

skills in carrying out: connection, routine maintenance and/

or repairs.

EXTRAORDINARY OPERATIONS: indicates

operations to be carried out solely at the

Manufacturer’s workshops by technical support staff.

ATTENZIONE:

il personale addetto all’installazione, all’ispezio-

ne e alla manutenzione della pompa deve avere

adeguata preparazione tecnica unita a cognizioni

idonee al campo di applicazione (compatibilità ade-

guate in materia e rischi connessi ad eventuali reazio-

ni chimiche del prodotto da pompare).

INSTALLATORE/MANUTENTORE ELETTRICO:

questa qualifica presuppone una piena conoscenza e

comprensione delle informazioni contenute nel manuale

d’uso del costruttore, competenza tecnica specifica per

effettuare gli interventi di natura elettrica di: allacciamento,

manutenzione ordinaria e/o riparazione.

INTERVENTI STRAORDINARI: identifica gli interventi

riservati a tecnici del servizio di assistenza eseguiti

solo presso le officine del Costruttore.

WARNING

personnel responsible for pump installation,

inspection and maintenance shall possess a suitable

technical background along with knowledge of the

field of application (compatibility of materials and risks

associated with possible chemical reactions of the

product being pumped).

ELECTRICAL/FITTER AND MAINTENANCE

ENGINEER

this qualification implies complete familiarity and

understanding of the information contained in the

manufacturer’s user manual and specific electrotechnical

skills in carrying out: connection, routine maintenance and/

or repairs.

EXTRAORDINARY OPERATIONS: indicates

operations to be carried out solely at the

Manufacturer’s workshops by technical support staff.

debem.it

IDENTIFIKATIONSCODE

IDENTIFICATION CODE

MB 100

PUMPENMODELL

MB 080 = MB 80

MB 100 = MB 100

MB 110 = MB110

MB 120 = MB 120

MB 130 = MB 130

MB 140 = MB 140

MB 150 = MB 150

MB 155 = MB 155

MB 160 = MB 160

MB 180 = MB 180

PUMP MODEL

MB 080 = MB 80

MB 100 = MB 100

MB 110 = MB 110

MB 120 = MB 120

MB 130 = MB 130

MB 140 = MB 140

MB 150 = MB.150

MB 155 = MB.155

MB 160 = MB.160

MB 180 = MB.180

MATERIAL DER PUMPE

P= polipropilene

EC = PVDF

PUMP MATERIAL

P= polypropylene

EC = PVDF

ART DER DICHTUNG

TLV = DICHTLIPPE VITON

TLD = DICHTLIPPE EPDM

TSV = FALTENBALGDICHTUNG VITON

TSD = FALTENBALGDICHTUNG EPDM

SEALING TYPE

TLV = VITON LIP SEAL

TLD = EPDM LIP SEAL

TSV = VITON BELLOW SEAL

TSD = EPDM BELLOW SEAL

MOTOR

N* = DREHSTROMMOTOR

A = MOTOR ATEX

M= EINPHASENMOTOR

MOTOR

N* = STANDARD MOTOR

A = ATEX MOTOR

M= SINGLE-PHASE MOTOR

P-

TLV

* Serienausstattung dreiphasiger Drehstrom-Asynchron-Motore (Eurospannung) (2 Pole) 50/60 Hz

* Standard motor is the three-phase induction type with European voltage (2-pole) 50Hz

IDENTIFIKATION DER PUMPE

Jede Pumpe ist mit einem Typenschild ausgestattet, das die

Spezikationen und das Baumaterial angibt. Bei jeglicher

Kommunikation mit dem Hersteller, dem Händler oder den

autorisierten Kundenzentren sind diese Daten anzugeben.

ACHTUNG: es ist verboten, das Typenschild der

Pumpe und/oder die auf dem Typenschild angege-

benen Daten zu entfernen und/oder zu verändern.

Der Identikationscode *, der unter dem Punkt “TYP” des Ty-

penschilds erscheint, speziziert die Zusammensetzung und

das Baumaterial der Pumpe, um die Eignung mit dem Produkt,

das gepumpt werden soll, zu bestimmen.

PUMP IDENTIFICATION

Each pump is tted with an identication plate detailing its

specication and materials. This data must always be reported in

all communications to the manufacturer, dealer or service

centres.

WARNING: It is forbidden to remove and/or modify

the identication plate and/or the data therein.

The identication code * listed aside the TYPE heading, details

the pump composition and manufacturing materials in order

to determine its suitability and compatibility with the product

to be pumped.

IDENTIFICAZIONE POMPA

Ogni pompa è corredata di una matrico-

la di identificazione che riporta le

specifiche e i materiali di composizione.

Per qualsiasi comunicazione con il

costruttore, il rivenditore o i centri di

assistenza autorizzati precisare i dati

riportati.

ATTENZIONE: è vietato rimuove-

re e/o alterare la matricola di

identificazione della pompa e/o i

dati in essa riportati.

Il codice identificativo * che compare

alla voce “TIPO” della matricola specifi-

ca la composizione ed i materiali

costruttivi della pompa al fine di determi-

nare l’idoneità e la compatibilità con il

prodotto che si desidera pompare.

PUMP IDENTIFICATION

Each pump is fitted with an identifica-

tion plate detailing its specification and

materials.

This data must always be reported in

all communications to the manufac-

turer, dealer or service centres.

WARNING: It is forbidden to re-

move and/or modify the identifi-

cation plate and/or the data therein.

The identification code * listed aside

the TYPE heading, details the pump

composition and manufacturing

materials in order to determine its

suitability and compatibility with the

product to be pumped.

senza motore - whitout motor

DICHIARAZIONE DI CONFORMITA’

DECLARATION DE CONFORMITE - DECLARACION DE CONFORMIDAD

ERKLÄRUNG BEZÜGLICH EINHALTUNG DER VORSCHRIFTEN - DECLARATION OF CONFORMITY

TIPO/SERIE

TYPE / SERIE- TIPO / SERIE - TYP / SERIE - TYPE / SERIES

FABBRICATO DA:

FABRIQUE PAR - FABRICADA POR - HERGESTELLT VON - MANUFACTURED BY

MODELLO

MODELE - MODELO - MODELL - MODEL

CODICE

CODE - CODE - KODE - CODICE

MATRICOLA

SERIAL NUMBER - MATRICULE - MATRIKELNUMMER - MATRICULA

DEBEM SRL - Via del bosco 41 - 21052 Busto Arsizio (VA) - ITALIA

Questo prodotto è conforme alle seguenti direttive CE/EX e relativi standard armonizzati:

This product complies with the following European Community Directives CE/EX and relating harmonized standards:

Ce produit est conforme aux directives de la Communautè europèenne suivantes CE/EX et les normes correspondantes harmonisées:

Este producto cumple con las siguientes Directrices de la Comunidad Europea CE/EX y relativas normas armonizadas:

Dieses Produkt erfüllt die folgenden Vorschriften der Europäischen Gemeinschaft CE/EXund entsprechende harmonisierte Normen:

2006/42/CE Direttiva Macchine / Machinery Directive / Maschinenrichtlinie / Directive Machines / Directiva Máquinas

CE EMC 89/336/CEE e alla legislazione nazionale che le traspone - CE LVD 73/23/CEE e alla legislazione nazionale che le traspone

UNI EN ISO 12100-1: 2009 – Sicurezza del macchinario. Concetti fondamentali, principi generali di progettazione. Parte 1: terminologia di base, metodologia.

UNI EN ISO 12100-1: 2009 – Safety of the machinery. Fundamental notions, design general principles. Part 1: Basic terminology, methods.

UNI EN ISO 12100-1: 2009 – Sécurité des machines. Concepts fondamentaux, principes généraux de conception. Partie 1 : terminologie de base, méthodologie.

UNI EN ISO 12100-1: 2009 – Sicherheit von Maschinen.. Grundbegriffe, allgemeine Gestaltungsleitsätze. Teil 1: Grundsätzliche Terminologie, Methodologie.

UNI EN ISO 12100-1: 2009 – Seguridad de la maquinaria. Conceptos fundamentales, principios generales de diseño. Parte 1: terminología de base, metodología.

UNI EN ISO 12100-2: 2009 – Sicurezza del macchinario. Concetti fondamentali, principi generali di progettazione. Parte 2: principi tecnici.

UNI EN ISO 12100-2: 2009 – Safety of the machinery. Fundamental notions, design general principles. Part 2: Technical principles.

UNI EN ISO 12100-2: 2009 – Sécurité des machines. Concepts fondamentaux, principes généraux de conception. Partie 2 : principes techniques.

UNI EN ISO 12100-2: 2009 – Sicherheit von Maschinen. Grundbegriffe, allgemeine Gestaltungsleitsätze. Teil 2: Technische Leitsätze.

UNI EN ISO 12100-2: 2009 – Seguridad de la maquinaria. Conceptos fundamentales, principios generales de diseño. Parte 2: principios técnicos.

UNI EN ISO 3746: 2009 – Acustica. Determinazione dei livelli di potenza sonora delle sorgenti di rumore mediante misurazione della pressione sonora. Metodo di controllo

con una supercie avvolgente su un piano riettente.

UNI EN ISO 3746: 2009 – Sound. Determination of sound power levels for noise sources by measuring the sound pressure. Monitoring method with an enveloping surface

on a reecting plate.

UNI EN ISO 3746: 2009 – Acoustique. Détermination des niveaux de puissance sonore des sources de bruit par mesure de la pression acoustique. Méthode de contrôle

avec surface enveloppante sur plan rééchissant.

UNI EN ISO 3746: 2009 –Akustik. Bestimmung der Schalleistungsspegel von Geräuschquellen aus Schalldruckmessungen. Hüllächenverfahren über einer reektieren-

den Ebene.

UNI EN ISO 3746: 2009 – Acústica. Determinación de los niveles de potencia sonora de las fuentes de ruido mediante medición de la presión sonora. Método de control

con una supercie envolvente sobre una supercie reectante.

UNI EN ISO 11200: 2009 – Acustica. Rumore emesso dalle macchine e dalle apparecchiature. Linee guida per l’uso della norme di base per la determinazione dei livelli

di pressione sonora al posto di lavoro e in altre speciche posizioni.

UNI EN ISO 11200: 2009 – Sound. Noise done by the machines and the equipments. Guidelines for using the basic norms for determining the sound pressure levels in

the working place and in other specic positions.

UNI EN ISO 11200: 2009 – Acoustique. Niveau de bruit émis par les machines et par les appareils. Directives concernant l’utilisation de la norme de base pour la détermi-

nation des niveaux de pression sonore sur poste de travail et dans d’autres situations spéciques.

inserire qui tipo/serie

inserire qui modello

inserire qui codice

inserire qui matricola

7debem.it

BESCHREIBUNG DER PUMPE

Die Horizontalkreiselpumpen aus Kunstharz MB wurden

für das Pumpen von Flüssigkeiten unter dem Anschlag mit

scheinbarer Viskosität von 1 bis 500 cps aus chemisch mit

den Bauteilen der Pumpe kompatiblen Materialien entworfen

und hergestellt. Der Betrieb der Pumpe ist bei Betriebstem-

peraturen der Flüssigkeit von +3°C bis zu maximal 65°C bei

Pumpen aus PP und 95°C bei Pumpen aus PVDF zulässig;

je nach Art der Materialzusammensetzung der Pumpe (siehe

TECHNISCHE CHARAKTERISTIKA S. 9) ist es notwendig,

auf der Anlage eine Schutzvorrichtung zu installieren, die den

Betrieb und/oder das Erreichen der Schwellentemperatur ver-

hindert.

Die Kreiselpumpen MB sind für einen Betrieb bis zu einem

Maximum von 2900 Drehung/Minute vorgesehen, mit Moto-

ren mit Direktantrieb mit hinterer Axialdehnung (für die Dilata-

tion) mit den folgenden technischen Konstruktionsmerkmalen:

DREIPHASIGER ASYNCHRONMOTOR 2 POLE

- Eurospannung;

- S1 –Status (Dauerbetrieb)

- Isolationsklasse F

- Schutzgrad IP 55

ACHTUNG: dort, wo der Variationsbereich der

Umgebungstemperatur und der Prozesstempera-

turen des Fluids in der Nähe der maximalen Werte

der Pumpe liegen (siehe TECHNISCHE CHARAKTERISTI-

KA S. 9), ist es je nach Baumaterial erforderlich, an der

Anlage eine Schutzvorrichtung zu installieren, die den

Betrieb und/oder das Erreichen des Schwellenwerts der

Temperatur verhindert.

Funktionsprinzip

Die Horizontalkreiselpumpen MB müssen unter entsprechen-

den Vorsichtsmaßnahmen unter dem Anschlag installiert wer-

den, um die Bildung von Wirbeln und das folgende Ansaugen

von Luftblasen zu vermeiden. Sie darf ausschließlich bei GE-

TAUCHTER PUMPE betrieben werden. Das Laufrad, das fest

mit der Pumpenwelle und der Direktkupplungsmotor verbun-

den ist, wird zu einer voreingestellten Geschwindigkeit (max.

2.900 Drehungen/Minute), betrieben; dadurch wird durch die

Zentrifugalkraft ein Ansaugen in der Hauptleitung und eine

Förderleistung in der Nebenleitung erzeugt.

ACHTUNG: jede Verwendung der Horizontalkrei-

selpumpe MB für anderweitige als die zuvor be-

schriebenen Nutzungen wird als unsachgemäße Verwen-

dung betrachtet und ist daher vom Hersteller verboten.

Unsachgemäße Verwendung

Insbesondere IST die Verwendung der Pumpe MB für Folgen-

des VERBOTEN:

- das Pumpen von Benzin und/oder brennbaren Flüssigkeiten

- das Pumpen von üssigen Lebensmitteln;

- der Betrieb in einer anderen Drehrichtung als die festgelegte;

- der selbstansaugende Betrieb;

- der Betrieb mit Ansaugen im Beisein von Wirbeln, Turbulen-

zen oder Luftblasen;

der Vakuumbetrieb

- der Betrieb mit zu pumpenden, chemisch nicht mit den Bau-

materialien kompatiblen Flüssigkeiten;

Working principles

MB horizontal, centrifugal pumps must be installed below

head with appropriate procedures to avoid vortex formation

and consequent air bubble suction. The pump must work

ONLY when FLOODED.

The impeller - integrally joined to the shaft and to the direct

drive mounted motor- must be set in rotation at a preset speed

(max 2.900 revs/min); its centrifugal effect activates suction in

the main duct and delivery in the secondary duct

WARNING: use of MB horizontal, centrifugal

pumps or anything other than that previously de-

scribed is to be considered improper use and is

forbidden by Debem.

Improper use

It is SPECIFICALLY forbidden to use MB pumps:

- for pumping petrol and/or ammable liquids;

- for pumping food liquids;

- with an opposite rotation to the one specied;

- in self-priming working conditions;

- for suction in the presence of vortexes, turbulence or air bub-

bles;

- for vacuum service;

- with liquids that are chemically incompatible with the manu-

facturing materials;

PUMP DESCRIPTION

Recommended use

MB horizontal, centrifugal pumps made from resin have been

designed and manufactured to pump below head liquids hav-

ing an apparent viscosity between 1 and 500cps, and that

are chemically compatible with the components of the pump.

Fluid service temperatures must range from 3°C to a maximum

of 65°C for PP pumps and 95°C for PVDF pumps; according

to the type of material used to build the pump (pls refer to

TECHNICAL CHARACTERISTICS pg. 9).

MB centrifugal pumps are designed for a max working speed of

2900 revs/min, in direct drive with motors equipped with a rear

axial compensator (for dilation) having the following technical-

manufacturing characteristics:

THREE-PHASE/2 POLES ASYNCHRONOUS MOTOR

- Euro tension;

- S1 status (continuous service)

- Class F insulation;

- IP 55 protection rating.

WARNING: Whenever the variation range of envi-

ronmental temperature and of the uid process

temperature approaches the maximum pump tem-

peratures according to the pump’s construction materials

(pls refer to TECHNICAL CHARACTERISTICS, pg 10), it is

necessary to safeguard the plant installing a protection

device stopping the pump and/or preventing it from reach-

ing the threshold temperature.

debem.it

TECHNISCHE CHARAKTERISTIKA

Die Daten bezüglich der Leistungen beziehen sich auf die Standardausführung. Die Werte des “NENNDURCHFLUSSES“ und der “FÖR-

DERHÖHE MAX” beziehen sich auf das Pumpen von Wasser bei 18°C mit freiem Einlass und Auslass.

TECHNICAL SPECIFICATIONS

The data related to performance refer to standard procedures. The NOMINAL ow and the MAX head values refer to pumping

of water at 18°C with free-ow suction and delivery.

- der Betrieb mit Produkten in Suspension, deren spezi-

sches Gewicht über dem der Flüssigkeit (z.B. Wasser mit

Sand) liegt;

- mit Luftdrücken und Produkteigenschaften, die in Wider-

spruch zu den technischen Daten stehen;

- der Betrieb mit besonders hartem Wasser und Wasser mit

vielen Ablagerungen.

ACHTUNG: aufgrund der unendlichen Vielfalt von

Produkten und chemischen Zusammensetzungen

wird der Benutzer gehalten, über beste Kenntnis-

se der Reaktionen und Kompatibilität mit den Baumateri-

alien der Pumpe zu verfügen. Daher müssen vor der An-

wendung fachmännisch alle notwendigen Inspektionen

und Tests ausgeführt werden, um die geringsten Risiken

zu vermeiden, die der Hersteller nicht voraussehen und

für die er nicht verantwortlich gemacht werden kann.

ACHTUNG: jede Verwendung der Pumpe entge-

gen den im Bedienungshandbuch und in der War-

tungsanleitung angegebenen Anweisungen führt

zum Erlöschen der Sicherheitsanforderungen.

Es wurden die Risiken in Zusammenhanf mit der Ver-

wendung der Pumpe untern den spezischen im Bedie-

nungshandbuch und Wartungsanleitung beschriebenen

Bedingungen analysiert: die Analyse der Risiken in Zu-

sammenhang mit der Wechselwirkung mit anderen Kom-

ponenten des Systems ist dem Installateur zugewiesen.

- with products in suspension that have a higher specic

weight than the liquid (e.g. water and sand);

- with product temperatures and characteristics of the pump;

- with water that is particularly hard and/ or full of deposits.

WARNING: due to the wide variety of products

and chemical compositions, the operator is con-

sidered to be the best evaluator of reactions and

compatibility with the pump’s construction materials.

Therefore, before use, carry out all necessary checks and

tests to avoid any possible hazardous situation, that can-

not be predicted or for which the manufacturer cannot be

held liable.

WARNING: use of the pump that does not com-

ply with the instructions indicated in the use and

maintenance manual will cancel compliance to the

requirements for safety.

The risks associated with the use of the pump under the

exact conditions set forth in the use and maintenance

manual have been analysed, whilst the analysis of the

risks associated with the interface with other system

components must be carried out by the installer.

Principio di funzionamento

Le pompe centrifughe orizzontali MB

devono essere instalalte sotto battente

con opportuni accorgimenti per evitare la

formazione di vortici e la conseguente

aspirazione di bolle d’aria. Deve essere

fatta funzionare solo ed esclusivamente

a POMPA INVASATA. La girante,

solidale all’albero ed al motore montato

in presa diretta, viene messa in rotazio-

ne ad una velocità prestabilita (max

2.900 giri/min) creando, per effetto

centrifugo, un’aspirazione sul condotto

centrale e una mandata su condotto

periferico.

WARNING: use of MB

horizontal, centrifugal pumps or

anything other than that previously

described is to be considered

improper use and is forbidden by

Debem.

Improper use

It is SPECIFICALLY forbidden to use

MB pumps:

- for pumping petrol and/or flammable

liquids;

- for pumping food liquids;

- with an opposite rotation to the one

specified;

- in self-priming working conditions;

- for suction in the presence of

vortexes, turbulence or air bubbles;

-for vacuum service;

- with liquids that are chemically

incompatible with the manufacturing

materials;

- with products in suspension that have

a higher specific weight than the

liquid (e.g. water and sand);

- with product temperatures and

characteristics of the pump;

- with water that is particularly hard and/

or full of deposits.

Working principles

MB horizontal, centrifugal pumps must

be installed below head with

appropriate procedures to avoid vortex

formation and consequent air bubble

suction. The pump must work ONLY

when FLOODED.

The impeller - integrally joined to the

shaft and to the direct drive mounted

motor- must be set in rotation at a pre-

set speed (max 2.900 revs/min); its

centrifugal effect activates suction in

the main duct and delivery in the

secondary duct

ATTENZIONE: qualsiasi altro

impiego della pompa centrifu-

ga orizzontale MB differente da

quanto precedentemente precisato

è considerato improprio e quindi

vietato dalla ditta Debem.

Usi impropri

In particolare È VIETATO l’uso della

pompa MB per:

- il pompaggio di benzina e/o liquidi

infiammabili;

- il pompaggio di liquidi alimentari;

- l’impiego con senso di rotazione

contrario a quello stabilito;

- l’impiego autoadescante;

- l’impiego con l’aspirazione in presen-

za di vortici, turbolenze o bolle d’aria;

- l’impiego a vuoto;

- l’impiego con liquidi da pompare incom-

patibili chimicamente con i materiali di

costruzione;

- l’impiego con prodotti in sospensione di

peso specifico superiore a quello del

liquido (esempio acqua con sabbia);

- con temperature e caratteristiche del

prodotto in disaccordo con le caratteri-

stiche della pompa;

- l’impiego con acque particolarmente

dure e/o molto cariche di prodotti da

riporto.

fig. 1

fig. 2

MB-TL

MB-TS !

Principio di funzionamento

Le pompe centrifughe orizzontali MB

devono essere instalalte sotto battente

con opportuni accorgimenti per evitare la

formazione di vortici e la conseguente

aspirazione di bolle d’aria. Deve essere

fatta funzionare solo ed esclusivamente

a POMPA INVASATA. La girante,

solidale all’albero ed al motore montato

in presa diretta, viene messa in rotazio-

ne ad una velocità prestabilita (max

2.900 giri/min) creando, per effetto

centrifugo, un’aspirazione sul condotto

centrale e una mandata su condotto

periferico.

WARNING: use of MB

horizontal, centrifugal pumps or

anything other than that previously

described is to be considered

improper use and is forbidden by

Debem.

Improper use

It is SPECIFICALLY forbidden to use

MB pumps:

- for pumping petrol and/or flammable

liquids;

- for pumping food liquids;

- with an opposite rotation to the one

specified;

- in self-priming working conditions;

- for suction in the presence of

vortexes, turbulence or air bubbles;

-for vacuum service;

- with liquids that are chemically

incompatible with the manufacturing

materials;

- with products in suspension that have

a higher specific weight than the

liquid (e.g. water and sand);

- with product temperatures and

characteristics of the pump;

- with water that is particularly hard and/

or full of deposits.

Working principles

MB horizontal, centrifugal pumps must

be installed below head with

appropriate procedures to avoid vortex

formation and consequent air bubble

suction. The pump must work ONLY

when FLOODED.

The impeller - integrally joined to the

shaft and to the direct drive mounted

motor- must be set in rotation at a pre-

set speed (max 2.900 revs/min); its

centrifugal effect activates suction in

the main duct and delivery in the

secondary duct

ATTENZIONE: qualsiasi altro

impiego della pompa centrifu-

ga orizzontale MB differente da

quanto precedentemente precisato

è considerato improprio e quindi

vietato dalla ditta Debem.

Usi impropri

In particolare È VIETATO l’uso della

pompa MB per:

- il pompaggio di benzina e/o liquidi

infiammabili;

- il pompaggio di liquidi alimentari;

- l’impiego con senso di rotazione

contrario a quello stabilito;

- l’impiego autoadescante;

- l’impiego con l’aspirazione in presen-

za di vortici, turbolenze o bolle d’aria;

- l’impiego a vuoto;

- l’impiego con liquidi da pompare incom-

patibili chimicamente con i materiali di

costruzione;

- l’impiego con prodotti in sospensione di

peso specifico superiore a quello del

liquido (esempio acqua con sabbia);

- con temperature e caratteristiche del

prodotto in disaccordo con le caratteri-

stiche della pompa;

- l’impiego con acque particolarmente

dure e/o molto cariche di prodotti da

riporto.

fig. 1

fig. 2

MB-TL

MB-TS

9debem.it

CARATTERISTICHE TECNICHE

I dati riferiti alle prestazioni si riferiscono alle esecuzioni

standard.

I valori di “Portata NOMINALE” e “Prevalenza MAX” sono

riferiti al pompaggio di acqua a 18°C con aspirazione e

mandata liberi.

TECHNICAL CHARACTERISTICS

The data related to performance refer to standard

procedures.

The NOMINAL flow and the MAX head values refer to

pumping of water at 18°C with free-flow suction and

delivery.

MB 110

MB 120

MB 130

MB 140

MB 150

MB 155

MB 160

MB 180

MB 80

MB 100

MB 80

MB 100

MB 110

MB 120

MB 130

MB 140

MB 150

MB 155

MB 160

debem.it

PUMPE MOTOR

abmessungen (mm) O

ØP KW HP MOTOR-

FORM

MOTOR-

GEHÄUSE

Tech.

Daten

Art ANSAU.

ØA

ABLASS

ØM L D E F H I C B N

80 TL

TS 1” 1/2 f 1” m 325 1 71 47 89 48 112 90 140 Ø8 0,37 0,5 B3-B14 71K2

100 TL

TS 1” 1/2 f 1” m 325 1 71 47 89 48 112 90 140 Ø8 0,55 0,75 B3-B14 71G2

110 TL

TS 2” m 1” 1/2 m 406 20 80 75 130 40 140 100 203 Ø10 1,1 1,5 B3-B5 80B2

120 TL

TS 2” m 1” 1/2 m 456 10 90 75 130 40 140 100 203 Ø10 1,5 2 B3-B5 90S2

130 TL

TS 2” m 1” 1/2 m 468 10 90 75 130 40 140 125 203 Ø10 2,2 3 B3-B5 90L2

140 TL

TS 2” m 1” 1/2 m 505 2 100 75 130 40 160 140 203 Ø12 3 4 B3-B14 100L2

150 TL

TS 2” 1/2 f 2” m 529 12 112 67,5 153 97 190 140 274 Ø12 4 5,5 B3-B5 112M2

155 TL

TS 2” 1/2 f 2” m 620 18 132 67,5 153 97 216 140 274 Ø12 5,5 7,5 B3-B5 132S2

160 TL

TS 2” 1/2 f 2” m 628 18 132 67,5 153 97 216 140 274 Ø12 7,5 10 B3-B5 132S2

180 TL

TS 2” 1/2 f 2” m 695 18 132 68 158 96 216 178 300 Ø12 11 15 B3-B5 132S2

Die angegebenen Werte sind Richtwerte und nicht bindend f = Innengewinde m = Außengewinde

PUMP MOTOR

dimension (mm) O

ØP KW HP MOTOR

SHAPE

MOTOR

CASING

Tech.

Data

Type SUCT.

ØA

DELIV.

ØM L D E F H I C B N

80 TL

TS 1” 1/2 f 1” m 325 1 71 47 89 48 112 90 140 Ø8 0,37 0,5 B3-B14 71K2

100 TL

TS 1” 1/2 f 1” m 325 1 71 47 89 48 112 90 140 Ø8 0,55 0,75 B3-B14 71G2

110 TL

TS 2” m 1” 1/2 m 406 20 80 75 130 40 140 100 203 Ø10 1,1 1,5 B3-B5 80B2

120 TL

TS 2” m 1” 1/2 m 456 10 90 75 130 40 140 100 203 Ø10 1,5 2 B3-B5 90S2

130 TL

TS 2” m 1” 1/2 m 468 10 90 75 130 40 140 125 203 Ø10 2,2 3 B3-B5 90L2

140 TL

TS 2” m 1” 1/2 m 505 2 100 75 130 40 160 140 203 Ø12 3 4 B3-B14 100L2

150 TL

TS 2” 1/2 f 2” m 529 12 112 67,5 153 97 190 140 274 Ø12 4 5,5 B3-B5 112M2

155 TL

TS 2” 1/2 f 2” m 620 18 132 67,5 153 97 216 140 274 Ø12 5,5 7,5 B3-B5 132S2

160 TL

TS 2” 1/2 f 2” m 628 18 132 67,5 153 97 216 140 274 Ø12 7,5 10 B3-B5 132S2

180 TL

TS 2” 1/2 f 2” m 695 18 132 68 158 96 216 178 300 Ø12 11 15 B3-B5 132S2

The above data is purely indicative and not binding f = female thread m = male thread

Debem kontaktierenask to Debem

11 debem.it

* Die Werte beziehen sich auf eine Pumpe mit freiem Einlass und Auslass mit Wasser bei 18°C.

* The values refer to a pump with open suction and delivery with water at 18°C

TECHNISCHE DATEN Maßeinheit MB

100

110

120

130

140

150

155

160

180

Ansaugung

(f = Innengewinde / m = Außen-

gewinde)

Zoll

1” 1/2 f 1” 1/2 f 2” m 2” m 2” m 2” m 2” 1/2 f 2” 1/2 f 2” 1/2 f 2” 1/2 f

Anschluss Ablass

(m = Außengewinde) Zoll 1”m 1”m 1” 1/2 m 1” 1/2 m 1” 1/2 m 1” 1/2 m 1” 1/2 m 2” m 2” m 2” m

Drehungen MAX Pumpe (nominal) Drehun-

gen/Min. 2900 2900 2900 2900 2900 2900 2900 2900 2900 2900

Temperatur MAX Betrieb der

Pumpe

- PP

C° 65 65 65 65 65 65 65 65 65 65

- PVDF

C° 95 95 95 95 95 95 95 95 95 95

Förderhöhe MAX *

m6 12 14 16 18 22 26 30 35 38

Durchuss MAX *

(bei 3000 Drehungen/Minute mit

Wasser bei 18°C)

mc/h 3 6 20 25 30 40 45 50 55 75

Nettogewicht PP

PVDF

8,5

9,5

8,5

9,5

15,5

16,5

20,5

22,5

23,5

59,5

62,5

Geräuschemission dB (A) 48 48 52 58 58 59 61 65 65 65

TECHNICAL DATA Unit MB

100

110

120

130

140

150

155

160

180

Suction Connection

(f = female thread / m = male

thread)

inches 1” 1/2 f 1” 1/2 f 2” m 2” m 2” m 2” m 2” 1/2 f 2” 1/2 f 2” 1/2 f 2” 1/2 f

Delivery connection

(m = male thread) inches 1”m 1”m 1” 1/2 m 1” 1/2 m 1” 1/2 m 1” 1/2 m 1” 1/2 m 2” m 2” m 2” m

MAX pump rev. (nominal) giri/

min. 2900 2900 2900 2900 2900 2900 2900 2900 2900 2900

MAX pumo temperature

- PP C° 65 65 65 65 65 65 65 65 65 65

- PVDF C° 95 95 95 95 95 95 95 95 95 95

MAX head * m 6 12 14 16 18 22 26 30 35 38

MAX ow rate*

(at 3000 rev/min with water at 18°C) mc/h 3 6 20 25 30 40 45 50 55 75

Net weight PP

PVDF

8,5

9,5

8,5

9,5

15,5

16,5

20,5

22,5

23,5

59,5

62,5

Noise dB (A) 48 48 52 58 58 59 61 65 65 65

ATTENZIONE:

il personale addetto all’installazione, all’ispezio-

ne e alla manutenzione della pompa deve avere

adeguata preparazione tecnica unita a cognizioni

idonee al campo di applicazione (compatibilità ade-

guate in materia e rischi connessi ad eventuali reazio-

ni chimiche del prodotto da pompare).

INSTALLATORE/MANUTENTORE ELETTRICO:

questa qualifica presuppone una piena conoscenza e

comprensione delle informazioni contenute nel manuale

d’uso del costruttore, competenza tecnica specifica per

effettuare gli interventi di natura elettrica di: allacciamento,

manutenzione ordinaria e/o riparazione.

INTERVENTI STRAORDINARI: identifica gli interventi

riservati a tecnici del servizio di assistenza eseguiti

solo presso le officine del Costruttore.

WARNING

personnel responsible for pump installation,

inspection and maintenance shall possess a suitable

technical background along with knowledge of the

field of application (compatibility of materials and risks

associated with possible chemical reactions of the

product being pumped).

ELECTRICAL/FITTER AND MAINTENANCE

ENGINEER

this qualification implies complete familiarity and

understanding of the information contained in the

manufacturer’s user manual and specific electrotechnical

skills in carrying out: connection, routine maintenance and/

or repairs.

EXTRAORDINARY OPERATIONS: indicates

operations to be carried out solely at the

Manufacturer’s workshops by technical support staff.

ATTENZIONE:

il personale addetto all’installazione, all’ispezio-

ne e alla manutenzione della pompa deve avere

adeguata preparazione tecnica unita a cognizioni

idonee al campo di applicazione (compatibilità ade-

guate in materia e rischi connessi ad eventuali reazio-

ni chimiche del prodotto da pompare).

INSTALLATORE/MANUTENTORE ELETTRICO:

questa qualifica presuppone una piena conoscenza e

comprensione delle informazioni contenute nel manuale

d’uso del costruttore, competenza tecnica specifica per

effettuare gli interventi di natura elettrica di: allacciamento,

manutenzione ordinaria e/o riparazione.

INTERVENTI STRAORDINARI: identifica gli interventi

riservati a tecnici del servizio di assistenza eseguiti

solo presso le officine del Costruttore.

WARNING

personnel responsible for pump installation,

inspection and maintenance shall possess a suitable

technical background along with knowledge of the

field of application (compatibility of materials and risks

associated with possible chemical reactions of the

product being pumped).

ELECTRICAL/FITTER AND MAINTENANCE

ENGINEER

this qualification implies complete familiarity and

understanding of the information contained in the

manufacturer’s user manual and specific electrotechnical

skills in carrying out: connection, routine maintenance and/

or repairs.

EXTRAORDINARY OPERATIONS: indicates

operations to be carried out solely at the

Manufacturer’s workshops by technical support staff.

debem.it

Die Horizontalkreiselpumpe MB ist ein hochwertiges Produkte,

das bei den Endbenutzern vollsten Anklang ndet.

Sollte ein Fehler auftreten, ist der KUNDENSERVICE des HER-

STELLERS, der Händler oder das Service-Center in Ihrer Nähe zu

kontaktieren. So schnell wie möglich erhalten Sie Unterstützung.

Geben Sie jedem Fall bitte folgende Informationen an:

A- die vollständige Adresse

B- die Kennzeichnung der Pumpe

C- die Beschreibung der Fehlstörung

Alle Pumpen MB werden durch folgende Formel abgedeckt:

1- Die Pumpe ist für 12 Monate auf alle mechanischen Teile, die

für fehlerhaft befunden werden, garantiert. Die Garantiezeit be-

ginnt mit dem Lieferdatum.

2- Jeder Fehler muss innerhalb von 8 Tagen schriftlich dem Her-

steller mitgeteilt werden.

3- Die Reparatur während der Garantiezeit erfolgt ausschließlich

in einer unserer Werkstätten nach Versand oder Zustellung der

defekten Pumpe.

4- Im Falle einer Reparatur oder bei Ersatz von Teilen der Pumpe

wird die Garantie nicht verlängert.

5- Die fehlerhaften Teile müssen dem Hersteller zurückgegeben

werden, der sich das Recht vorbehält, eine Überprüfung der Teile

in seiner eigenen Werkstatt durchzuführen, um den Fehler oder

externe Gründe, die den Schaden verursacht haben könnten, zu

ermitteln. Sollten die Teile nicht als fehlerhaft eingestuft werden,

behält sich der Hersteller das Recht vor, die gesamten Kosten der

zuvor unter Garantie ersetzten Teile in Rechnung zu stellen.

Der Hersteller übernimmt keine Kosten und Risiken für den Trans-

port der defekten Teile oder der reparierten Teile oder der Ersatz-

teile, einschließlich etwaiger Zollgebühren. Die Reparatur oder der

Ersatz der defekten Teile deckt alle Garantieverpichtungen ab.

Die Garantie umfasst KEINE indirekten Schäden und Fabrikati-

onsfehler. Zudem sind normale Verbrauchs- und Verschleißma-

terialien (Gleitringdichtungen, Dichtungen, usw.) von der Garantie

ausgeschlossen. Teile, die aufgrund von Nachlässigkeit oder einer

Fahrlässigkeit bei der Anwendung, falscher Installation, fehlender

oder unsachgemäßer Wartung, Transportschäden oder jeglichen

Umstand, der nicht auf Funktionsstörungen oder Verarbeitungs-

fehler zurückzuführen ist, nicht in der Garantie abgedeckt.

Insbesondere sind von der Garantie ausgeschlossen:

- Schäden, die durch unsachgemäßen Gebrauch oder falsche In-

stallation auf der Anlage verursacht wurden;

- anderweitige Verwendung der Pumpe als die vom Käufer beim

Moment der Bestellung angegebene;

- Schäden aufgrund der Verwendung unter trockenen Bedingun-

gen und/oder bei Vorhandensein von Luftblasen;

- Schäden durch Abrieb;

- Schäden aufgrund von Fremdkörpern in der Pumpe;

- Schäden aufgrund umgekehrter Drehung des Motors und der

Pumpe;

- Verwendung der Pumpe bei höheren Temperaturen als zulässig;

- Schäden an den Gleitringdichtungen, (besonders anfällig für

Verschleiß), es sei denn, es bestehen offensichtliche Konstrukti-

onsmängel;

- Schäden durch sehr hartes Wasser oder Wasser mit vielen Ab-

lagerungen;

Die Garantie ist in allen Fällen der unsachgemäßen oder miss-

bräuchlichen Anwendung und der Nichtbeachtung der in diesem

Handbuch enthaltenen Informationen ausgeschlossen.

Für alle Streitigkeiten ist das Gericht von Busto Arsizio zu-

ständig.

PRESCRIZIONI DI SICUREZZA

GARANTIE

The high quality of MB horizontal, centrifugal pumps has been

conrmed to us on many occasions by the end users.

However, should any defect appear, please contact the

Manufacturer’s After-Sales Service, your dealer or the nearest

Customer Service Department who will help you as quickly

as possible.

In any case, please provide:

A – Your complete address

B – Pump identication

C – Description of the anomaly.

All the MB pumps are covered by the following warranty:

1. Guarantee on mechanical parts of all MB pumps is for 12

months. The warranty period is calculated from the date of

delivery.

2. Every fault must be notied to the Manufacturer within 8 days.

3. Repairs under warranty will only be carried out in our work-

shop after receiving the pump.

4. The replacement or repair of parts does not extend the

warranty.

5. Faulty parts must be forwarded to the Manufacturer who

reserves the right to test them in this own workshop in order to

identify the fault or any external reason that may have caused

it. Should the parts be found not faulty, the Manufacturer re-

serves the right to invoice the total cost of the parts that had

been replaced under this warranty.

The Manufacturer is not liable for costs and risks connected

to transportation of faulty and repaired parts and neither for

those supplied as spare parts, including possible custom duties.

Repair and replacement of faulty parts entirely fulls the war-

ranty.

This warranty DOES NOT cover any indirect damages, in

particular lost production. Moreover, the warranty does not

cover any consumable materials (mechanical seals, gaskets).

The warranty does not include parts damaged as a conse-

quence of carelessness, neglect, incorrect installation, lack of

and/or incorrect maintenance, or damages due to transporta-

tion or to any other reason or event that is not directly linked to

functioning or manufacturing defects.

The following are specically excluded from the warranty:

- any damage caused by incorrect use or installation of the plant;

- use of the pump other than that declared by the purchaser

at the time of order;

- any damage cause by working in dry conditions and/or pres-

ence of air bubbles;

- any damage caused by abrasion;

- any damage caused by foreign matters in the pump;

- any damage caused by reverse rotation of the pump or motor;

- any damage caused by using the pump above the maximum

allowed temperature;

- any damage to mechanical sealing (being subject to wear),

except when a manufacturing defect is obvious;

- any damage caused by water with a high content of deposits.

The warranty is void in all cases of improper or incorrect use

and in case of negligence in following the information herein

contained.

For any controversy, the place of jurisdiction is Busto

Arsizio.

GB WARRANTY

13 debem.it

Gefährliche oder riskante Praktiken oder Praktiken, die nicht mit den

Sicherheitsanforderungen und dem in diesem Handbuch Beschrie-

benen übereinstimmen, können zu schweren Verletzungen, Materi-

alschäden und sogar zum Tod, für die nicht der Hersteller verantwort-

lich gemacht werden kann, führen.

ACHTUNG: diese Anweisungen sind für die Einhaltung

der Pumpe gemäß der Sicherheitsanforderungen un-

verzichtbar und müssen daher: verfügbar, bekannt und

verstanden worden sein und genutzt werden.

ACHTUNG: das für die Installation, die Inspektion und

die Wartung der Pumpe verantwortliche Personal muss

über eine angemessene technische Ausbildung sowie

ausreichende Kenntnisse über den Anwendungsbereich verfü-

gen (Kompatibilität und Risiken in Verbindung mit möglichen

chemischen Reaktionen des zu pumpenden Produkts).

ACHTUNG: jede Verwendung der Pumpe entgegen den

im Bedienungshandbuch und in der Wartungsanlei-

tung beschriebenen Anweisungen führt zum Erlöschen

der Garantie- und Sicherheitsanforderungen.

ACHTUNG: vor dem Eingriff an der Pumpe und/oder

vor der Ausführung von Wartungsarbeiten oder Repa-

raturen muss:

A- das Produkt, das gepumpt wird, aus dem Kreislauf abgelassen

werden;

B- für die interne Reinigung mit einem geeigneten (nichtbrennbaren

Fluid) gesorgt werden;

C- der Motor der Pumpe gestoppt werden;

D- die Absperrventile zum Produkt (Auslass und Einlass) manuell

geschlossen werden;

E- die Versorgungsspannung des Motors der Pumpe abgetrennt

werden;

F- jedem Eingriff die geeignete persönliche Schutzausrüstung ange-

legt werden (Gesichtsschutz, Handschuhe, geschlossene Schuhe,

Schürzen, usw.).

ACHTUNG: versichern Sie sich vor Verwendung der

Pumpe, dass das zu pumpende Fluid mit den Bauma-

terialien kompatibel ist: KORROSIONSGEFAHR, AUS-

STRÖMEN DES PRODUKTS UND/ODER EXPLOSIONEN AUF-

GRUND CHEMISCHER REAKTIONEN.

Für die Installation und den Einsatz müssen Sie die folgenden

Vorsichtsmaßnahmen einhalten:

- überprüfen Sie, dass die Pumpe getaucht ist und der Pegel über

dem Mindeststand steht (wenigstens 0,5m);

- überprüfen Sie, dass im behandelten Fluid keine Feststoffe vorhan-

den sind oder sein können;

- überprüfen Sie, dass keine Einschränkungen an der Ansaugung

der Pumpe vorhanden sind, um Kavitationserscheinungen oder

Kraftanstrengung des elektrischen Motors zu vermeiden;

- überprüfen Sie, dass die Verbindungsleitungen geeignet und wider-

standfähig sind und dass die Pumpe nicht unter dem Gewicht leidet;

- wenn die Pumpe über einen langen Zeitraum unbenutzt bleibt,

reinigen Sie sie sorgfältig, indem Sie eine Reinigungsüssigkeit

(nichtbrennbar), die mit den Materialien der Pumpe kompatibel ist,

zirkulieren lassen;

- wenn die Pumpe über einen langen Zeitraum ausgeschaltet bleibt,

ist es ratsam, für einige Minuten sauberes Wasser zirkulieren zu las-

sen, um das Risiko von Verkrustungen zu vermeiden;

- schützen Sie die Pumpe immer vor möglichen Stößen, die verse-

hentlich durch sich bewegende Teile entstehen können oder vor ver-

schiedenen schlagenden Materialien, die sie beschädigen und/oder

bei Kontakt mit ihren Materialien reagieren können;

- schützen Sie die Umgebung vor Spritzern durch unbeabsichtigte

Ausfälle der Pumpe;

PRESCRIZIONI DI SICUREZZA

SICHERHEITSANFORDERUNGEN

Dangerous or hazardous practices or practices not

complying with the safety rules and with that recommended

herein may cause injuries, material damage and even death

for which the manufacturer cannot be held responsible.

WARNING: these instructions are indispensable

for the pump to comply with safety requirements,

therefore they must be made known, available and

abided to.

WARNING: the personnel in charge of installing,

inspecting and servicing the pumps must have ad-

equate technical knowledge and training in the eld

of application (compatibility and hazards related to possible

chemical reaction of the product/s to pump).

WARNING: use of the pump that does not comply

to the instructions indicated in the use and mainte-

nance manual will invalidate all warranty and safety

requirements.

WARNING: before any operation on the pump and/

or before any maintenance or repair, proceed as

follows:

A – discharge the product being pumped;

B – proceed with washing the inside with appropriate liquid

(non-ammable);

C – stop the pump motor;

D – close the manual, shut-off valves (suction and delivery of

product);

E - section power to the pump motor;

F – Wear suitable individual protection before any intervention

(masks, gloves, closed shoes, aprons, etc.).

WARNING: before using the pump, ensure that the

uid to pump is compatible with the manufacturing

materials: CORROSION, LEAKAGE AND/OR EZPLO-

SION HAZARSDS DUE TO CHEMICAL REACTIONS.

For the installation and use, take the following precautions:

- check that the pump is ooded and the level is at least 0,5 m

higher;

- Check that no solid particles are or could oat in the uid;

- Check that there are no constraints to the pump suction, thus

avoiding cavitations and electrical motor strain;

- Check that the connecting pipes are suitable and resistant and

that the pump does not bear their weight;

- If the pump is to be inactive for long periods, clean it thoroughly

with a detergent uid (non-ammable) compatible with the pump’s

construction materials;

- if the pump must be turned off for a long period of time, be-

fore doing so circulate clean water for some minutes to avoid

incrustations;

- always protect the pump against possible collisions caused by

moving means or by various blunt materials that may damage it

or react with its materials;

- protect the pump’s surrounding environment from splashes

caused by accidental pump failure;

- Supply an adequate guard to collect and direct the treated

product that could leak.

GB SAFETY INSTRUCTIONS

debem.it

WARNING: It is FORBIDDEN to expose an MB pump

to dry working conditions; this could damage the

sealing, cause the elements exposed to horizontal

friction to melt and possibly cause a re.

WARNING: it is FORBIDDEN to use the pump for

self priming installation; the suction conduits must

always be installed below head and away from

vortexes or turbulence that could cause air retention and

damage the sealing.

WARNING: when pumping aggressive, toxic or haz-

ardous uids, the pump must be tted with a suitable

guard to contain collect and signal the product in

case of leakage: POLLUTION, CONTAMINATION, INJURY

AND/OR DEATH.

WARNING: It is forbidden to use the pump with uids

that are incompatible with the components materials

or in an environment with non-compatible uids.

WARNING: It is forbidden to install the pump without

tting the shut-off valves at the suction and delivery

of the product that enable the sectioning required

in case of leakage: HAZARD OF UNCONTROLLED

LEAKAGE OF THE PRODUCT.

WARNING: Should the user think that the tempera-

ture limits set forth in this manual may be exceeded

during service, a protection device must be installed on the

system to prevent global temperature (uid + ambient) from

reaching temperatures higher than 95°C for PVDF pimps and

65°C for PP (polypropylene) pumps.

WARNING: The pump must always be earthed, inde-

pendently from any other equipment connected to it.

WARNING: aggressive, toxic or hazardous uids

can cause severe physical injuries and/or damages

to health, consequently it is forbidden to return a

pump containing such products to either the manufacturer

or to a service centre. Empty and wash the internal circuit

and treat the pump before delivering it.

WARNING: the models with aluminium parts or com-

ponents in contact with the product cannot be used

for pumping III-trichloroethylene, chlorine methylene

or any halogenated, hydrocarbon-based solvent: EXPLO-

SION HAZARD DUE TO CHEMICAL REACTION.

WARNING: Check that there is no abnormal noise

during functioning. In this case, stop the operation

of the pump immediately.

WARNING: check that the output uid does not carry

air or gas; in this case, stop the pump immediately

and resolve the problem before restarting it.

- sorgen Sie für einen angemessenen Schutz, der mög-

liche Leckagen des Produkts durch einen übermäßigen

Verschleiß und/oder Vernachlässigung der Wartung sam-

melt und auffängt;

ACHTUNG: der Trockenlauf der Pumpe MB ist

VERBOTEN. Der Trockenlauf verursacht neben

Schäden an der Keramikbuchse die Verschmel-

zung von Elementen in Gleitreibung und daraus folgend,

einen möglichen Brand.

ACHTUNG: die Verwendung der Pumpe für

selbstansaugende Installationen ist VERBOTEN;

die Saugleitung muss immer unter dem Anschlag

und entfernt von Wirbeln und Turbulenzen, die das Zu-

rückhalten der Luft und Schäden an der Dichtung verur-

sachen können, installiert sein.

ACHTUNG: beim Pumpen von aggressiven, gifti-

gen oder gesundheitsschädlichen Flüssigkeiten

muss ein angemessener Schutz für die Rückhal-

tung, für das Auffangen und für die Meldung des Produkt

im Fall von Produktleckagen installiert werden: GEFAHR

DER VERSCHMUTZUNG, KONTAMINATION, VERLET-

ZUNG UND/ODER TOD.

ACHTUNG: es ist die Verwendung der Pumpe mit

nicht mit den Materialien der Komponenten kom-

patiblen Flüssigkeiten oder in Umgebungen, in

denen nicht kompatible Flüssigkeiten vorhanden sind,

verboten.

ACHTUNG: es ist die Installation der Pumpe ohne

Absperrventile des Produkts auf der Eintritts- und

Auslassseite, um im Falle von Leckagen das Ab-

trennen auszuführen, verboten: GEFAHR VON UNKONT-

ROLLIERTEM ENTWEICHEN DES PRODUKTS.

ACHTUNG: wo der Benutzer das Risiko einer

Überschreitung der Temperaturgrenzen, die in

diesem Handbuch festgelegt sind, befürchtet, ist

es notwendig auf dem System eine Schutzvorrichtung zu

installieren, die den Betrieb und/oder das Erreichen der

Schwellentemperatur (Fluid und Umgebung) von 95°C für

Pumpen aus PVDF und 65°C für die Pumpen aus PP (Po-

lypropylen) verhindert.

ACHTUNG: die Pumpe muss immer unabhängig

von anderen Organen mit denen Sie verbunden

ist, geerdet sein.

ACHTUNG: aggressive, giftige oder gefährliche

Flüssigkeiten können zu schweren Körperverlet-

zungen und/oder Gesundheitsschäden führen.

Daher ist es verboten, dem Hersteller oder einem Ser-

vice-Center einen Pumpe, die solche Produkte enthält,

zurückzugeben: entleeren und reinigen Sie den internen

Produktkreislauf und führen Sie vor dem Versand eine

Reinigung und Behandlung durch.

ACHTUNG: die Pumpenmodelle, die Komponen-

ten oder Teile aus Aluminium, die in Kontakt mit

dem Produkt sind, enthalten, können nicht für

das Pumpen von III-Trichlorethan, Methylenchlorid oder

Lösungsmitteln auf Basis von halogenierten Kohlen-

wasserstoffen verwendet werden EXPLOSIONSGEFAHR

AUFGRUND CHEMISCHER REAKTIONEN.

ACHTUNG: überprüfen Sie, dass während des

Betriebs keine ungewöhnlichen Geräusche auf-

treten. In diesem Fall blockieren Sie unverzüglich

den Betrieb der Pumpe.

PRESCRIZIONI DI SICUREZZA

15 debem.it

The operators in charge of the assembly / disassembly must

be informed and trained on the dangers relating to the use of

mechanical tools, even small ones .

When receiving the goods, check that the pump packaging is undam-

aged; afterwards proceed as follows:

1 According to the equipment size and weight the plant is either pack-

aged with cardboard, boxes or on pallets. Open and discard the pack-

aging;

2 Consult the Use and Maintenance Manual and comply with its

instructions;

3 Lift the pump with appropriate lifting means, suitable to the weight in-

dicated on the Id plate.

4 Check the correct tightening of all screws.

NOTE: MB pumps are supplied complete with motor. In case of future

handling, if the pump is detached from the motor, before pro-

ceeding with its positioning it must be assembled as described

in the Chapter: “ASSEMBLY OF ELECTRIC MOTOR SEAL-

ING”.

WARNING: the pumps are designed to be positioned and xed

horizontally from the ceiling using hangers or on the

oor on the feet of the motor. The horizontal, centrifugal

pumps are not self priming, therefore they must always

be installed next to the suction point, and without forming siphons

in suction.

6. Correctly position the pump in the installation area (as close as pos-

sible to the suction point) and proceed with bolting the motor feet ap-

propriately. Ensure that adequate space is left for future maintenance

operations.

Die für die Montage/Demontage verantwortlichen Bediener müssen

über die Gefahren, auch wenn sie noch so gering sind, in Verbindung

mit der Verwendung von mechanischen Werkzeugen ausgebildet

werden.

Nach Erhalt überprüfen Sie, dass die Verpackung und die Pumpe in-

takt sind und keine Schäden davongetragen haben. Ansonsten müs-

sen Sie wie folgt vorgehen:

1Je nach Größe und Gewicht der Lieferung wird sie in einer Karton-

verpackung, auf Paletten oder in einer Kiste geliefert: öffnen Sie sie bei

Empfang und entfernen Sie die Verpackung.

2Entnehmen Sie das Bedienungshandbuch und die Wartungsanlei-

tung und gehen Sie wie beschrieben vor.

3Heben Sie die Pumpe je nach dem auf der Kennzeichnung angege-

benen Gewicht mit einer entsprechenden Ladevorrichtung.

4Führen Sie eine Überprüfung der Befestigung aller Schrauben der

Pumpe aus.

ANMERKUNG: Die Pumpen MB werden vollständig mit Mo-

tor geliefert. Für zukünftige Umsetzungen müssen Sie, falls

die Pumpe ohne Motor ist, bevor Sie mit der Positionierung

fortfahren, für seine Montage sorgen. Gehen Sie dazu wie im Kapitel

“MONTAGE DES ELEKTRISCHEN MOTORS” beschrieben vor.

ACHTUNG: die für die Pumpe MB vorgesehene Positi-

onierung und die Befestigung erfolgt horizontal durch

Befestigung an der Decke oder auf dem Boden auf den

entsprechenden Füßen des Motors. Die Horizontalkreiselpum-

pen sind nicht selbstansaugend und müssen daher in der Nähe

der Entnahmestelle ohne Bildung von Siphonen auf der Ansau-

gung installiert werden.

6Positionieren Sie die Pumpe ordnungsgemäß am Aufstellungsort

(so nah wie möglich am Entnahmepunkt) und sorgen Sie für die Be-

festigung auf den Füßen des Motors mit den entsprechenden Mut-

terschrauben. Sorgen Sie für ausreichend Platz für eventuelle War-

tungsarbeiten.

WARNING: it is prohibited to use MB Pumps with

water that is particularly hard and/or has a high

content of deposits as it may cause anomalous

incrustations on the mechanical seal.

WARNING: the inner sealing component is exceed-

ingly exposed to wear. Its life span is strongly

inuenced by the working conditions, chemical and

physical stress or lack of maintenance. Tests carried out on

thousand of pumps indicate that its standard life span is in

excess of 1,500 hours. For safety reasons, in environments

characterised by the presence of aggressive products, it

is recommended to disassemble and check the sealing

every 500 hours and to replace them every 1,500 hours.

WARNING: Only use original spare parts for re-

placements.

The manufacturer is not liable for hazards to the operator,

technicians, people exposed, the pump and/or the environ-

ment caused by non-compliance with the above.

ACHTUNG: überprüfen Sie, dass im Fluid im Aus-

lass keine Luft oder Gas vorhanden ist. Ansonsten

stoppen Sie den Betrieb der Pumpe unverzüglich

und sorgen Sie vor dem Neustart für die Beseitigung der

Fehlstörung.

ACHTUNG: die Verwendung der Pumpen MB für

besonders hartes Wasser und/oder Wasser mit

vielen Ablagerungen, die anomale Verkrustungen

auf der mechanischen Dichtung verursachen, ist verboten.

ACHTUNG: die interne Keramikbuchse ist eine

Komponente, die einem starken Verschleiß unter-

liegt. Ihre Haltbarkeit wird stark von den Anwen-

dungsbedingungen und den chemischen und physika-

lischen Beanspruchungen oder der fehlenden Wartung

beeinusst. Aus Tests an Tausenden installierten Exemp-

laren von Pumpen übersteigt die normale Haltbarkeit 1.500

Stunden. Aus Sicherheitsgründen müssen der Ausbau und

die Überprüfung der Dichtung alle 500 Stunden und ihr Er-

satz alle 1.500 Stunden stattnden.

HINWEIS: Für den Ersatz der Verschleißteile verwen-

den Sie nur Original-Ersatzteile.

Bei Nichtbeachtung der oben aufgeführten Vorschriften

können Gefahren für den Bediener, die Techniker, die ex-

ponierten Personen, die Pumpe und/oder die Umwelt ent-

stehen, für die der Hersteller nicht haftbar ist.

PRESCRIZIONI DI SICUREZZA

TRANSPORT UND POSITIONIERUNG

TRANSPORTING AND POSITIONING

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1La fornitura viene spedita in imballo di

cartone, su pallet o in cassa: al

ricevimento aprire e rimuovere l’imbal-

lo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Provvedere al montaggio del motore

sul corpo della pompa e serrare la

ghiera di fissaggio.

TRANSPORT AND

POSITIONING

Check at time of delivery that the pump

and packaging are fully intact and have

suffered no damage, following which:

1The product is supplied in cardboard

packaging, on a pallet or in a crate.

Upon receipt, undo and remove the

packaging.

2Consult the use and maintenance

manual and follow its instructions to

the letter.

3Fit the motor to the pump body and

tighten the fixing nut.

ISTRUZIONI PER

L’USO E LA

MANUTENZIONE

INSTRUCTIONS

FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti di fissaggio.

NOTA

Le pompe TR vengono fornite con il

motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisogna provvedere

al suo montaggio operando come

descritto qui di seguito.

4Ensure that all fixing screws are

properly tightened.

NOTE:

TR pumps are supplied with a motor.

Should you decide to re-site the pump at

some future time, if the pump has no

motor, before positioning this needs to

be fitted by proceeding in the following

manner.

POMPE VERTICALI DA TRAVASO FUSTI

VERTICAL DRUM TRANSFER PUMPS

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1La fornitura viene spedita in imballo di

cartone, su pallet o in cassa: al

ricevimento aprire e rimuovere l’imbal-

lo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Provvedere al montaggio del motore

sul corpo della pompa e serrare la

ghiera di fissaggio.

TRANSPORT AND

POSITIONING

Check at time of delivery that the pump

and packaging are fully intact and have

suffered no damage, following which:

1The product is supplied in cardboard

packaging, on a pallet or in a crate.

Upon receipt, undo and remove the

packaging.

2Consult the use and maintenance

manual and follow its instructions to

the letter.

3Fit the motor to the pump body and

tighten the fixing nut.

ISTRUZIONI PER

L’USO E LA

MANUTENZIONE

INSTRUCTIONS

FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti di fissaggio.

NOTA

Le pompe TR vengono fornite con il

motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisogna provvedere

al suo montaggio operando come

descritto qui di seguito.

4Ensure that all fixing screws are

properly tightened.

NOTE:

TR pumps are supplied with a motor.

Should you decide to re-site the pump at

some future time, if the pump has no

motor, before positioning this needs to

be fitted by proceeding in the following

manner.

POMPE VERTICALI DA TRAVASO FUSTI

VERTICAL DRUM TRANSFER PUMPS

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1La fornitura viene spedita in imballo di

cartone, su pallet o in cassa: al

ricevimento aprire e rimuovere l’imbal-

lo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Provvedere al montaggio del motore

sul corpo della pompa e serrare la

ghiera di fissaggio.

TRANSPORT AND

POSITIONING

Check at time of delivery that the pump

and packaging are fully intact and have

suffered no damage, following which:

1The product is supplied in cardboard

packaging, on a pallet or in a crate.

Upon receipt, undo and remove the

packaging.

2Consult the use and maintenance

manual and follow its instructions to

the letter.

3Fit the motor to the pump body and

tighten the fixing nut.

ISTRUZIONI PER

L’USO E LA

MANUTENZIONE

INSTRUCTIONS

FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti di fissaggio.

NOTA

Le pompe TR vengono fornite con il

motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisogna provvedere

al suo montaggio operando come

descritto qui di seguito.

4Ensure that all fixing screws are

properly tightened.

NOTE:

TR pumps are supplied with a motor.

Should you decide to re-site the pump at

some future time, if the pump has no

motor, before positioning this needs to

be fitted by proceeding in the following

manner.

POMPE VERTICALI DA TRAVASO FUSTI

VERTICAL DRUM TRANSFER PUMPS

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1La fornitura viene spedita in imballo di

cartone, su pallet o in cassa: al

ricevimento aprire e rimuovere l’imbal-

lo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Provvedere al montaggio del motore

sul corpo della pompa e serrare la

ghiera di fissaggio.

TRANSPORT AND

POSITIONING

Check at time of delivery that the pump

and packaging are fully intact and have

suffered no damage, following which:

1The product is supplied in cardboard

packaging, on a pallet or in a crate.

Upon receipt, undo and remove the

packaging.

2Consult the use and maintenance

manual and follow its instructions to

the letter.

3Fit the motor to the pump body and

tighten the fixing nut.

ISTRUZIONI PER

L’USO E LA

MANUTENZIONE

INSTRUCTIONS

FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti di fissaggio.

NOTA

Le pompe TR vengono fornite con il

motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisogna provvedere

al suo montaggio operando come

descritto qui di seguito.

4Ensure that all fixing screws are

properly tightened.

NOTE:

TR pumps are supplied with a motor.

Should you decide to re-site the pump at

some future time, if the pump has no

motor, before positioning this needs to

be fitted by proceeding in the following

manner.

POMPE VERTICALI DA TRAVASO FUSTI

VERTICAL DRUM TRANSFER PUMPS

debem.it

es ist

verboten,

Brände mit

Wasser zu

löschen

prohibition of

putting out res

with water

Put the following prohibition and danger signs near the place where the pump is installed

Positionieren Sie die folgenden Verbots- und Warnschilder in der Nähe des Aufstellungsortes der Pumpe

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1In funzione della grandezza e del

peso, la fornitura viene spedita in

imballo di cartone, su pallet o in

cassa: al ricevimento aprire e rimuove-

re l’imballo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Sollevare la pompa con idonee attrez-

zature di carico in funzione del peso

riportato in matricola.

.TRANSPORT AND

POSITIONING

When receiving the goods, check that

the pump packaging is undamaged;

afterwards proceed as follows:

1According to the equipment size and

weight the plant is either packaged

with cardboard, boxes or on pallets.

Open and discard the packaging;

2Consult the Use and Maintenance

Manual and comply with its

instructions;

3Lift the pump with appropriate lifting

means, suitable to the weight

indicated on the Id plate.

ISTRUZIONI PER L’USO E LA

MANUTENZIONE

INSTRUCTIONS FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti della pompa.

NOTA

Le pompe MB vengono fornite

complete di motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisognerà provvedere

al suo montaggio operando come

descritto al Capitolo “MONTAGGIO

DELLA TENUTA DEL MOTORE ELET-

TRICO”.

4Check the correct tightening of all

screws.

NOTE:

MB pumps are supplied complete

with motor. In case of future handling,

if the pump is detached from the motor,

before proceeding with its positioning it

must be assembled as described in

the Chapter: “ASSEMBLY OF

ELECTRIC MOTOR SEALING”.

POMPE CENTRIFUGHE ORIZZONTALI

HORIZONTAL CENTRIFUGAL PUMPS

ATTENZIONE: il posizionamento

ed il fissaggio previsto per la

pompa è in orizzontale mediante

staffaggio a soffitto o a pavimento

sugli appositi piedini del motore.

Le pompe centrifughe orizzontali

non sono autoadescanti pertanto

devono sempre essere installate in

prossimità del punto di prelievo

senza formare sifoni sull’aspira-

zione.

WARNING: the pumps are

designed to be positioned and

fixed horizontally from the ceiling

using hangers or on the floor on the

feet of the motor. The horizontal,

centrifugal pumps are not self

priming, therefore they must always

be installed next to the suction point,

and without forming siphons in

suction.

200 mm

livello min

min levele

6Posizionare correttamente la pompa sul

luogo di installazione (più vicina possi-

bile al punto di prelievo) e provvedere

allo staffaggio sui piedini del motore con

appositi bulloni. Prevedere uno spazio

sufficiente per le eventuali future manu-

tenzioni.

! 6. Correctly position the pump in the

installation area (as close as

possible to the suction point) and

proceed with bolting the motor feet

appropriately. Ensure that adequate

space is left for future maintenance

operations.

ATTENZIONE: il posizionamento

ed il fissaggio previsto per la

pompa è in orizzontale mediante

staffaggio a soffitto o a pavimento

sugli appositi piedini del motore.

Le pompe centrifughe orizzontali

non sono autoadescanti pertanto

devono sempre essere installate in

prossimità del punto di prelievo

senza formare sifoni sull’aspira-

zione.

WARNING: the pumps are

designed to be positioned and

fixed horizontally from the ceiling

using hangers or on the floor on the

feet of the motor. The horizontal,

centrifugal pumps are not self

priming, therefore they must always

be installed next to the suction point,

and without forming siphons in

suction.

200 mm

livello min

min levele

6Posizionare correttamente la pompa sul

luogo di installazione (più vicina possi-

bile al punto di prelievo) e provvedere

allo staffaggio sui piedini del motore con

appositi bulloni. Prevedere uno spazio

sufficiente per le eventuali future manu-

tenzioni.

! 6. Correctly position the pump in the

installation area (as close as

possible to the suction point) and

proceed with bolting the motor feet

appropriately. Ensure that adequate

space is left for future maintenance

operations.

ATTENZIONE: il posizionamento

ed il fissaggio previsto per la

pompa è in orizzontale mediante

staffaggio a soffitto o a pavimento

sugli appositi piedini del motore.

Le pompe centrifughe orizzontali

non sono autoadescanti pertanto

devono sempre essere installate in

prossimità del punto di prelievo

senza formare sifoni sull’aspira-

zione.

WARNING: the pumps are

designed to be positioned and

fixed horizontally from the ceiling

using hangers or on the floor on the

feet of the motor. The horizontal,

centrifugal pumps are not self

priming, therefore they must always

be installed next to the suction point,

and without forming siphons in

suction.

200 mm

livello min

min levele

6Posizionare correttamente la pompa sul

luogo di installazione (più vicina possi-

bile al punto di prelievo) e provvedere

allo staffaggio sui piedini del motore con

appositi bulloni. Prevedere uno spazio

sufficiente per le eventuali future manu-

tenzioni.

! 6. Correctly position the pump in the

installation area (as close as

possible to the suction point) and

proceed with bolting the motor feet

appropriately. Ensure that adequate

space is left for future maintenance

operations.

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1In funzione della grandezza e del

peso, la fornitura viene spedita in

imballo di cartone, su pallet o in

cassa: al ricevimento aprire e rimuove-

re l’imballo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Sollevare la pompa con idonee attrez-

zature di carico in funzione del peso

riportato in matricola.

.TRANSPORT AND

POSITIONING

When receiving the goods, check that

the pump packaging is undamaged;

afterwards proceed as follows:

1According to the equipment size and

weight the plant is either packaged

with cardboard, boxes or on pallets.

Open and discard the packaging;

2Consult the Use and Maintenance

Manual and comply with its

instructions;

3Lift the pump with appropriate lifting

means, suitable to the weight

indicated on the Id plate.

ISTRUZIONI PER L’USO E LA

MANUTENZIONE

INSTRUCTIONS FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti della pompa.

NOTA

Le pompe MB vengono fornite

complete di motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisognerà provvedere

al suo montaggio operando come

descritto al Capitolo “MONTAGGIO

DELLA TENUTA DEL MOTORE ELET-

TRICO”.

4Check the correct tightening of all

screws.

NOTE:

MB pumps are supplied complete

with motor. In case of future handling,

if the pump is detached from the motor,

before proceeding with its positioning it

must be assembled as described in

the Chapter: “ASSEMBLY OF

ELECTRIC MOTOR SEALING”.

POMPE CENTRIFUGHE ORIZZONTALI

HORIZONTAL CENTRIFUGAL PUMPS

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1In funzione della grandezza e del

peso, la fornitura viene spedita in

imballo di cartone, su pallet o in

cassa: al ricevimento aprire e rimuove-

re l’imballo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Sollevare la pompa con idonee attrez-

zature di carico in funzione del peso

riportato in matricola.

.TRANSPORT AND

POSITIONING

When receiving the goods, check that

the pump packaging is undamaged;

afterwards proceed as follows:

1According to the equipment size and

weight the plant is either packaged

with cardboard, boxes or on pallets.

Open and discard the packaging;

2Consult the Use and Maintenance

Manual and comply with its

instructions;

3Lift the pump with appropriate lifting

means, suitable to the weight

indicated on the Id plate.

ISTRUZIONI PER L’USO E LA

MANUTENZIONE

INSTRUCTIONS FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti della pompa.

NOTA

Le pompe MB vengono fornite

complete di motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisognerà provvedere

al suo montaggio operando come

descritto al Capitolo “MONTAGGIO

DELLA TENUTA DEL MOTORE ELET-

TRICO”.

4Check the correct tightening of all

screws.

NOTE:

MB pumps are supplied complete

with motor. In case of future handling,

if the pump is detached from the motor,

before proceeding with its positioning it

must be assembled as described in

the Chapter: “ASSEMBLY OF

ELECTRIC MOTOR SEALING”.

POMPE CENTRIFUGHE ORIZZONTALI

HORIZONTAL CENTRIFUGAL PUMPS

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1In funzione della grandezza e del

peso, la fornitura viene spedita in

imballo di cartone, su pallet o in

cassa: al ricevimento aprire e rimuove-

re l’imballo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Sollevare la pompa con idonee attrez-

zature di carico in funzione del peso

riportato in matricola.

.TRANSPORT AND

POSITIONING

When receiving the goods, check that

the pump packaging is undamaged;

afterwards proceed as follows:

1According to the equipment size and

weight the plant is either packaged

with cardboard, boxes or on pallets.

Open and discard the packaging;

2Consult the Use and Maintenance

Manual and comply with its

instructions;

3Lift the pump with appropriate lifting

means, suitable to the weight

indicated on the Id plate.

ISTRUZIONI PER L’USO E LA

MANUTENZIONE

INSTRUCTIONS FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti della pompa.

NOTA

Le pompe MB vengono fornite

complete di motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisognerà provvedere

al suo montaggio operando come

descritto al Capitolo “MONTAGGIO

DELLA TENUTA DEL MOTORE ELET-

TRICO”.

4Check the correct tightening of all

screws.

NOTE:

MB pumps are supplied complete

with motor. In case of future handling,

if the pump is detached from the motor,

before proceeding with its positioning it

must be assembled as described in

the Chapter: “ASSEMBLY OF

ELECTRIC MOTOR SEALING”.

POMPE CENTRIFUGHE ORIZZONTALI

HORIZONTAL CENTRIFUGAL PUMPS

allgemeine

Warnung

General

Danger Sign

Gefahr von

Elektrizität

danger high

voltage

Gefahr von

korrosivem

Material

Danger

Corrosive

Material

Gefahr von

brennbarem

Material

Danger

Flammable

Material

es muss eine

Schutzbrille

getragen

werden

Eye

protection

must be worn

es muss ein

Schutzanzug

getragen

werden

Safety overalls

must be worn

Gefahr von

explosivem

Material

Danger

Explosive

Material

es müssen

die Atemwege

geschützt

werden

Respiratory

equipment

must be worn

es müssen

Handschuhe

getragen

werden

Safety gloves

must be worn

es müssen

geschlossene

Schuhe

getragen

werden

Safety boots

must be worn

es muss eine

Schutzmaske

getragen werden

Face

protection

must be worn

Gefahr von

giftigem

Material

Danger Toxic

Material

Gefahr von

Spritzern von üs-

sigem glühendem

Material

Danger

Incandescent

Liquid Sprinkles

Verbot von

offenen

Flammen

Prohibition

on Open

Flames’ Use

Rauchverbot

No smoking

17 debem.it

ATTENZIONE: il funzionamento

delle pompe MB con elementi

pesanti in sospensione o a secco,

oltre che causare il

danenggiamento della tenuta,

provoca la fusione degli elementi in

attrito radente ed il conseguente,

possibile, incendio, pertanto atte-

nersi alle seguenti regole:

A- la pompa non è autoadescante

e deve essere posizionata sotto

battente;

B- il pescante del tubo di aspira-

zione della pompa deve essere

di forma da evitare intasamenti

dovuti al risucchio, di morchio e

sostanze pesanti e deve risultare

lontano da vortici o tubi di

riempimento della vasca;

C- il tubo di aspirazione non deve

formare sifoni;

WARNING: MB pumps working

with heavy elements in

suspension or in dry conditions can

damage the sealing as well as

causing the fusion of sliding friction

parts that may give rise to fire,

therefore the following rules must be

complied with:

A – the pump is not self priming

and must be positioned below

head:

B – the dip tube of the suction pipe

must be bent to avoid clogging

due to reflux, grit and heavy

matter, and it must be kept

away from vortexes or the tank

filling pipes;

C – the suction pipe must not

create siphons;

D- eventuali filtri di aspirazione

devono essere a cestello oppor-

tunamente sovradimensionati

(circa 3 volte la sezione di

aspirazione della pompa, per

evitare perdite di carico);

E- il pescante del tubo di aspira-

zione deve essere alloggiato

al’interno di idoneo stramazzo e

lontano da vortici, turbolenze e

scarichi liberi;

F- prevedere un dispositivo di

livello che determini l’arresto

del motore della pompa al di

sotto del livello minimo.

Il trasporto e posizionamento sono

così terminati.

D E F

livello minimo

min. level

D – any suction filters must be of

the basket-type and

appropriately over-

dimensioned (approx 3 times

the pump suction diameter, to

avoid loss of pressure);

E – the dip tube of the suction pipe

must be housed inside the weir

and away from vortexes,

turbulence and open drains;

F – fit a level regulator device that

can halt the motor when the

pump is under the minimum

level.

Transportation and positioning are

now completed.

ATTENZIONE: il funzionamento

delle pompe MB con elementi

pesanti in sospensione o a secco,

oltre che causare il

danenggiamento della tenuta,

provoca la fusione degli elementi in

attrito radente ed il conseguente,

possibile, incendio, pertanto atte-

nersi alle seguenti regole:

A- la pompa non è autoadescante

e deve essere posizionata sotto

battente;

B- il pescante del tubo di aspira-

zione della pompa deve essere

di forma da evitare intasamenti

dovuti al risucchio, di morchio e

sostanze pesanti e deve risultare

lontano da vortici o tubi di

riempimento della vasca;

C- il tubo di aspirazione non deve

formare sifoni;

WARNING: MB pumps working

with heavy elements in

suspension or in dry conditions can

damage the sealing as well as

causing the fusion of sliding friction

parts that may give rise to fire,

therefore the following rules must be

complied with:

A – the pump is not self priming

and must be positioned below

head:

B – the dip tube of the suction pipe

must be bent to avoid clogging

due to reflux, grit and heavy

matter, and it must be kept

away from vortexes or the tank

filling pipes;

C – the suction pipe must not

create siphons;

D- eventuali filtri di aspirazione

devono essere a cestello oppor-

tunamente sovradimensionati

(circa 3 volte la sezione di

aspirazione della pompa, per

evitare perdite di carico);

E- il pescante del tubo di aspira-

zione deve essere alloggiato

al’interno di idoneo stramazzo e

lontano da vortici, turbolenze e

scarichi liberi;

F- prevedere un dispositivo di

livello che determini l’arresto

del motore della pompa al di

sotto del livello minimo.

Il trasporto e posizionamento sono

così terminati.

D E F

livello minimo

min. level

D – any suction filters must be of

the basket-type and

appropriately over-

dimensioned (approx 3 times

the pump suction diameter, to

avoid loss of pressure);

E – the dip tube of the suction pipe

must be housed inside the weir

and away from vortexes,

turbulence and open drains;

F – fit a level regulator device that

can halt the motor when the

pump is under the minimum

level.

Transportation and positioning are

now completed.

ATTENZIONE: il funzionamento

delle pompe MB con elementi

pesanti in sospensione o a secco,

oltre che causare il

danenggiamento della tenuta,

provoca la fusione degli elementi in

attrito radente ed il conseguente,

possibile, incendio, pertanto atte-

nersi alle seguenti regole:

A- la pompa non è autoadescante

e deve essere posizionata sotto

battente;

B- il pescante del tubo di aspira-

zione della pompa deve essere

di forma da evitare intasamenti

dovuti al risucchio, di morchio e

sostanze pesanti e deve risultare

lontano da vortici o tubi di

riempimento della vasca;

C- il tubo di aspirazione non deve

formare sifoni;

WARNING: MB pumps working

with heavy elements in

suspension or in dry conditions can

damage the sealing as well as

causing the fusion of sliding friction

parts that may give rise to fire,

therefore the following rules must be

complied with:

A – the pump is not self priming

and must be positioned below

head:

B – the dip tube of the suction pipe

must be bent to avoid clogging

due to reflux, grit and heavy

matter, and it must be kept

away from vortexes or the tank

filling pipes;

C – the suction pipe must not

create siphons;

D- eventuali filtri di aspirazione

devono essere a cestello oppor-

tunamente sovradimensionati

(circa 3 volte la sezione di

aspirazione della pompa, per

evitare perdite di carico);

E- il pescante del tubo di aspira-

zione deve essere alloggiato

al’interno di idoneo stramazzo e

lontano da vortici, turbolenze e

scarichi liberi;

F- prevedere un dispositivo di

livello che determini l’arresto

del motore della pompa al di

sotto del livello minimo.

Il trasporto e posizionamento sono

così terminati.

D E F

livello minimo

min. level

D – any suction filters must be of

the basket-type and

appropriately over-

dimensioned (approx 3 times

the pump suction diameter, to

avoid loss of pressure);

E – the dip tube of the suction pipe

must be housed inside the weir

and away from vortexes,

turbulence and open drains;

F – fit a level regulator device that

can halt the motor when the

pump is under the minimum

level.

Transportation and positioning are

now completed.

WARNING: MB pumps working with heavy elements

in suspension or in dry conditions can damage the

sealing as well as causing the fusion of sliding fric-

tion parts that may give rise to re, therefore the following

rules must be complied with:

A – the pump is not self priming and must be positioned

below head:

B – the dip tube of the suction pipe must be bent to avoid

clogging due to reux, grit and heavy matter, and it must

be kept away from vortexes or the tank lling pipes;

C – the suction pipe must not create siphons;

D – any suction lters must be of the basket-type and

appropriately overdimensioned (approx 3 times

the pump suction diameter, to avoid loss of pressure);

E – the dip tube of the suction pipe must be housed

inside the weir and away from vortexes, turbulence and

open drains;

F – t a level regulator device that can halt the motor when

the pump is under the minimum level.

Transportation and positioning are now completed.

ACHTUNG: der Betrieb der Pumpen MB mit

schweren Elementen in Suspension oder der Tro-

ckenbetrieb kann neben Schäden an der Dichtung

auch einen Verschmelzung der Elemente in Gleitreibung

und ein daraus folgendes mögliches Feuer verursachen.

Daher sind folgende Regeln zu beachten:

A- die Pumpe ist nicht selbstansaugend und muss immer

unterhalb des Anschlags installiert sein;

B- Das Tauchrohr der Saugleitung der Pumpe muss so

geformt sein, um Verstopfungen durch das Ansaugen

von Schlamm und schweren Stoffen zu verhindern und

fern von Wirbeln oder Füllrohren der Wanne installiert

sein;

C- die Ansaugleitung darf keine Siphone bilden;

D- etwaige Sauglter müssen vom Korbtyp und entspre-

chend überdimensioniert (etwa 3 Mal der Ansaugdurch-

messer der Pumpe, um Druckverluste zu vermeiden) sein;

E- das Tauchrohr der Saugleitung muss in einem geeig-

neten Überlauf und entfernt von Wirbeln, Turbulenzen

und freien Ableitungen in der Wanne untergebracht sein;

F- sorgen Sie für einen Füllbegrenzer, der den Stopp des

Pumpenmotors bei Stand unter dem Mindestwert be-

stimmt.

Der Transport und die Positionierung sind somit beendet.

PRESCRIZIONI DI SICUREZZA

debem.it

Nachdem Sie die Positionierung durchgeführt haben, ist es

möglich, den Anschluss der Pumpe an den Produktkreislauf

anzuschließen. Der Vorgang wird im Folgenden beschrieben:

ACHTUNG: für die Verbindungen des Produktkreis-

laufs an die Pumpe dürfen nur Anschlüsse mit zy-

lindrischem Rohrgewinde aus mit dem zu pumpen-

den Fluid und dem Baumaterial des Dämpfers kompatiblen

Material verwendet werden.

BSP: Pumpe aus PP = Anschluss PP

1. Installieren Sie auf dem Anschluss des Ablass- und Einlass-

kollektors ein manuelles Kugelventil (mit vollem Durchgang) mit

dem gleichen Durchmesser des Anschlusses der Pumpe (nie

kleiner), um so das Auffangen des Fluids bei Leckagen und/

oder zukünftigen Wartungsarbeiten zu gewährleisten.

2. Sorgen Sie für die Installation der Muffen für die Befestigung

der Schläuche auf beiden manuellen Ventilen.

ACHTUNG: die Verbindungsleitungen an die Kol-

lektoren der Pumpe müssen FLEXIBEL UND MIT

EINER STEIFEN SPIRALE VERSTÄRKT SEIN und

mit einem Durchmesser, der niemals kleiner als die Verbin-

dungsstelle ist. Verwenden Sie für viskose Flüssigkeiten

Leitungen mit einem vergrößerten Durchmesser, beson-

ders auf der Absaugung.

Der DIREKTE Anschluss an die Pumpe mit starren Me-

tallrohren (an Pumpen aus Kunststoff und/oder mit koni-

schem Gewinde) ist verboten, da dadurch starke Belastun-

gen und/oder Vibrationen und ein Bruch der Kollektoren

und anderer Teile der Pumpe verursacht werden können.

Benutzen Sie immer exible Schläuche mit Anschlussstü-

cken aus dem gleichen Material wie das der Pumpe (PP mit

PP, PVDF mit PVDF).

Ebenso ist die Verwendung von Gewindesicherungsstof-

fen und/oder Teonpaste verboten. Der Installateur muss

bei der Montage auf die Zentrierung der Anschlüsse ach-

ten, um Risse bzw. ein Nachgeben der Gewinde zu vermei-

den.

Außerdem ist zu kontrollieren, ob nicht eventuell über-

schüssiges PTFE-Band und ein übermäßiger Anzugsdruck

den Kollektor oder andere Teile der Pumpen zu stark be-

lastet.

Besondere Beachtung ist Phänomenen von Spannungs-

korrosion zu schenken. Das Material der Pumpe kann

durch die kombinierte Wirkung von Korrosion und der An-

wendung einer Last verschleißen und dadurch der plötzli-

che und unerwartete Bruch der belasteten Teile verursacht

werden, insbesondere bei Temperaturgrenzwerten.

3. Sorgen Sie für den Anschluss der Einlass- und Ablassleitung.

Stellen Sie sicher, dass die Anschlussleitungen der Pumpe in-

nen sauber sind und auf keinen Fall Verarbeitungsrückstände

enthalten.

4. Sorgen Sie für die Befestigung der Leitungen mit entspre-

chenden Schellen.

ACHTUNG: stützen Sie ausreichend die Leitungen.

DIE LEITUNGEN MÜSSEN AUSREICHEND WIDER-

STANDSFÄHIG SEIN, UM SICH NICHT UNTER DER

SAUGWIRKUNG ZU VERFORMEN UND DÜRFEN NIEMALS

IN IRGENDEINER WEISE AUF DER PUMPE LASTEN UND

UMGEKEHRT.

ACHTUNG: kontrollieren Sie, dass im behandelte

Fluid keine festen Partikel großer Form oder von

schädlicher Form vorhanden sind oder sein kön-

nen und dass keine Einschränkungen am Einlass und/oder

Ablass der Pumpe vorhanden sind, um Kavitationserschei-

nungen oder Kraftanstrengung des Elektromotors oder

Trockenlauf zu vermeiden.

Der Anschluss an den Produktkreislauf ist somit beendet.

PRESCRIZIONI DI SICUREZZA

ANSCHLUSS DES PRODUKTKREISLAUFS

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1La fornitura viene spedita in imballo di

cartone, su pallet o in cassa: al

ricevimento aprire e rimuovere l’imbal-

lo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Provvedere al montaggio del motore

sul corpo della pompa e serrare la

ghiera di fissaggio.

TRANSPORT AND

POSITIONING

Check at time of delivery that the pump

and packaging are fully intact and have

suffered no damage, following which:

1The product is supplied in cardboard

packaging, on a pallet or in a crate.

Upon receipt, undo and remove the

packaging.

2Consult the use and maintenance

manual and follow its instructions to

the letter.

3Fit the motor to the pump body and

tighten the fixing nut.

ISTRUZIONI PER

L’USO E LA

MANUTENZIONE

INSTRUCTIONS

FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti di fissaggio.

NOTA

Le pompe TR vengono fornite con il

motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisogna provvedere

al suo montaggio operando come

descritto qui di seguito.

4Ensure that all fixing screws are

properly tightened.

NOTE:

TR pumps are supplied with a motor.

Should you decide to re-site the pump at

some future time, if the pump has no

motor, before positioning this needs to

be fitted by proceeding in the following

manner.

POMPE VERTICALI DA TRAVASO FUSTI

VERTICAL DRUM TRANSFER PUMPS

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1La fornitura viene spedita in imballo di

cartone, su pallet o in cassa: al

ricevimento aprire e rimuovere l’imbal-

lo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Provvedere al montaggio del motore

sul corpo della pompa e serrare la

ghiera di fissaggio.

TRANSPORT AND

POSITIONING

Check at time of delivery that the pump

and packaging are fully intact and have

suffered no damage, following which:

1The product is supplied in cardboard

packaging, on a pallet or in a crate.

Upon receipt, undo and remove the

packaging.

2Consult the use and maintenance

manual and follow its instructions to

the letter.

3Fit the motor to the pump body and

tighten the fixing nut.

ISTRUZIONI PER

L’USO E LA

MANUTENZIONE

INSTRUCTIONS

FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti di fissaggio.

NOTA

Le pompe TR vengono fornite con il

motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisogna provvedere

al suo montaggio operando come

descritto qui di seguito.

4Ensure that all fixing screws are

properly tightened.

NOTE:

TR pumps are supplied with a motor.

Should you decide to re-site the pump at

some future time, if the pump has no

motor, before positioning this needs to

be fitted by proceeding in the following

manner.

POMPE VERTICALI DA TRAVASO FUSTI

VERTICAL DRUM TRANSFER PUMPS

After having correctly positioned the plant, proceed with connect-

ing the pump to the product circuit, as follows:

WARNING: To connect the pump only use connec-

tions with cylindrical gas threads made with materials

compatible with the uid to be pumped and with the

pump materials. E.g: pump in PP = connections in PP

1. On the suction and delivery manifold, install a manual ball valve

(full-bore) with a diameter equal to the connection to the pump

(never smaller), to ensure uid shut-off in case of leaks and/or

future maintenance.

2. Proceed with installation of pipe couplings for fastening the

exible pipes on to both of the manual valves.

WARNING: The connection pipes to the pump must

be FLEXIBLE, RIGID SPIRAL REINFORCED pipes

never with a smaller diameter than the connection of

the pump. For viscous uids, use pipes with an OVERSIZED

DIAMETER, particularly in suction.

Do not attach the pump DIRECTLY with rigid metal pipes (on

plastic pumps) and/or pipes with tapered thread, as they can

cause severe stress and/or vibrations and breakage of the

manifolds and other parts of the pump.

Always use exible joints with ttings made of the same

material of the pump (PP with PP, PVDF with PVDF)

Do not use threadlockers and/or Teon paste. The installer

must ensure that the ttings are centred during assembly to

prevent cracks and/or to prevent the threads from yielding.

Also check that any excess PTFE tape and excessive clamp-

ing pressure does not place stress on the manifold or other

parts of the pump.

Pay particular attention to stress corrosion cracking. The

pump material may deteriorate due to the combined action of

corrosion and application of a load, which may cause parts

subjected to stress to break suddenly and unexpectedly,

especially at low temperatures

3. Proceed to connect the product suction and delivery pipes to

their respective joints.

Check if the connection tubes to the pump are clean inside and

do no contain any working residue.

4. Proceed with fastening the pipes with appropriate metal rings.

WARNING: the pipes must be adequately suppor-

ted; PIPES MUST BE STRONG ENOUGH NOT TO

DEFORM IN SUCTION AND MUST NEVER WEIGHT

THE PUMP DOWN OR VICEVERSA

WARNING: Check that the treated uid does not or

could not contain solid matters of a large size or with

a potentially damaging shape and that the intake

and/or delivery ports are not obstructed in order to avoid

cavitation or electric motor strain or dry operation.

The circuit connection is now completed.

! !

PRODUCT CIRCUIT CONNECTION

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1La fornitura viene spedita in imballo di

cartone, su pallet o in cassa: al

ricevimento aprire e rimuovere l’imbal-

lo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Provvedere al montaggio del motore

sul corpo della pompa e serrare la

ghiera di fissaggio.

TRANSPORT AND

POSITIONING

Check at time of delivery that the pump

and packaging are fully intact and have

suffered no damage, following which:

1The product is supplied in cardboard

packaging, on a pallet or in a crate.

Upon receipt, undo and remove the

packaging.

2Consult the use and maintenance

manual and follow its instructions to

the letter.

3Fit the motor to the pump body and

tighten the fixing nut.

ISTRUZIONI PER

L’USO E LA

MANUTENZIONE

INSTRUCTIONS

FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti di fissaggio.

NOTA

Le pompe TR vengono fornite con il

motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisogna provvedere

al suo montaggio operando come

descritto qui di seguito.

4Ensure that all fixing screws are

properly tightened.

NOTE:

TR pumps are supplied with a motor.

Should you decide to re-site the pump at

some future time, if the pump has no

motor, before positioning this needs to

be fitted by proceeding in the following

manner.

POMPE VERTICALI DA TRAVASO FUSTI

VERTICAL DRUM TRANSFER PUMPS

TRASPORTO E

POSIZIONAMENTO

Al ricevimento verificare che l’imballo e

la pompa siano integri e non abbiano

subito danni dopodichè bisogna:

1La fornitura viene spedita in imballo di

cartone, su pallet o in cassa: al

ricevimento aprire e rimuovere l’imbal-

lo.

2Prelevare il manuale d’uso e manu-

tenzione ed operare come descritto.

3Provvedere al montaggio del motore

sul corpo della pompa e serrare la

ghiera di fissaggio.

TRANSPORT AND

POSITIONING

Check at time of delivery that the pump

and packaging are fully intact and have

suffered no damage, following which:

1The product is supplied in cardboard

packaging, on a pallet or in a crate.

Upon receipt, undo and remove the

packaging.

2Consult the use and maintenance

manual and follow its instructions to

the letter.

3Fit the motor to the pump body and

tighten the fixing nut.

ISTRUZIONI PER

L’USO E LA

MANUTENZIONE

INSTRUCTIONS

FOR USE A N D

MAINTENANCE

4Effettuare una verifica del serraggio di

tutte le viti di fissaggio.

NOTA

Le pompe TR vengono fornite con il

motore. Nel caso di future

movimentazioni, se la pompa è in

assenza del motore, prima di procedere

al posizionamento bisogna provvedere

al suo montaggio operando come

descritto qui di seguito.

4Ensure that all fixing screws are

properly tightened.

NOTE:

TR pumps are supplied with a motor.

Should you decide to re-site the pump at

some future time, if the pump has no

motor, before positioning this needs to

be fitted by proceeding in the following

manner.

POMPE VERTICALI DA TRAVASO FUSTI

VERTICAL DRUM TRANSFER PUMPS

19 debem.it

Um den elektrischen Anschluss des Motors auszuführen,

muss wie folgt vorgegangen werden:

ACHTUNG: dieser Eingriff muss von einem ausge-

bildeten und autorisierten Elektriker durchgeführt

werden. Dabei darf keine Netzspannung auf dem

Netzkabel vorhanden sein.

1 Entfernen Sie die Klemmabdeckung des Motors.

2 Lösen Sie die Kabelverschraubung.

3 Stecken Sie das Netzkabel ein, ziehen Sie die Kabelver-

schraubung fest und klemmen Sie sie auf die Anschlüsse der

entsprechenden Kabeladern.

4 Stellen Sie sicher, dass die Daten der Motorspannung mit

denen der Netzspannung kompatibel sind.

ACHTUNG: den Motor mit Spannungen, die nied-

riger oder höher als die vorgesehenen sind, zu

speisen (siehe Anschlüsse λΔ), kann Schäden am

Motor hervorrufen.

5 Führen Sie die Verbindung des Erdungsleiters auf dem ent-

sprechenden Anschluss aus und ziehen Sie die Schrauben

fest.

ACHTUNG: die die dem Motor vorgeschaltete

elektrische Anlage muss mit einer Erdungsleitung

und richtig bemessenen Sicherungen ausgestat-

tet werden.

6 Sorgen Sie für eine efziente Erdungsleitung der Pumpe.

Installieren Sie dazu ein Kabel mit entsprechendem Quer-

schnitt, um etwaige statische Elektrizität zu entladen.

PRESCRIZIONI DI SICUREZZA

ELEKTRISCHER ANSCHLUSS DES MOTORS UND ÜBERPRÜFUNG DER DREHUNG

In order to carry out the electrical motor connection, proceed

as follows:

WARNING: this operation must be carried out by a

registered and qualied electrician, after discon-

necting power from the network.

1. Remove the cover of the motor terminal-box;

2. Loosen the cable-fastener;

3. Put the power cable in position, tighten the cable-fastener and

clamp the appropriate terminals to the cable conductors;

4. Check that the voltage of the motor is compatible with the

power supply

WARNING: supplying the motor with higher or lower

voltage than that required (see connection λΔ) can

damage or burn the motor.

5. Carry out the connection of the earthing conductor to the

appropriate clamp and tightly fasten the screw.

WARNING: the electrical plant upstream from the

motor must be adequately earthed and tted with

correctly dimensioned fuses.

6. Equip the pump with an earthing cable having a diameter

adequate to discharge static current.

ELECTRICAL MOTOR CONNECTION AND ROTATION CHECK

ELECTRICAL MOTOR

CONNECTION AND

ROTATION CHECK

In order to carry out the electrical

motor connection, proceed as follows:

WARNING: this operation must

be carried out by a registered

and qualified electrician, after

disconnecting power from the

network.

1. Remove the cover of the motor

terminal-box;

2. Loosen the cable-fastener;

3. Put the power cable in position,

tighten the cable-fastener and

clamp the appropriate terminals to

the cable conductors;

4. Check that the voltage of the motor

is compatible with the power supply.

ALLACIAMENTO ELETTRICO

DEL MOTORE E VERIFICA DI

ROTAZIONE

Per eseguire il collegamento elettrico

del motore bisogna:

ATTENZIONE: questo intervento

deve essere eseguito da un

tecnico elettricista qualificato ed

abilitato, in assenza di tensione sul

cavo di alimentazione.

1Rimuovere il coperchio della

morsettiera del motore.

2Allentare il pressacavo.

3Introdurre il cavo di alimentazione,

serrare il pressacavo e aggraffare sui

conduttori del cavo appositi capicorda

con foro.

4Verificare che i dati di tensione del

motore siano compatibili con quelli di

alimentazione.

AVVERTENZA: alimentare il

motore con tensioni inferiori o

superiori a quelle previste ( vedi

collegamenti ) causa il danneg-

giamento o addirittura la bruciatura

del motore.

5Effettuare il collegamento del condut-

tore di messa a terra sull’apposito

morsetto e serrare a fondo la vite.

ATTENZIONE: l’impianto elettri-

co a monte del motore deve

essere provvisto di efficiente linea

di messa a terra e di fusibili corret-

tamente dimensionati.

6Provvedere alla messa a terra del

corpo pompa con un cavo di adeguata

sezione per scaricare le correnti

statiche.

WARNING: supplying the motor

with higher or lower voltage

than that required (see connection

) can damage or burn the motor.

5. Carry out the connection of the

earthing conductor to the

appropriate clamp and tightly fasten

the screw.

WARNING: the electrical plant

upstream from the motor must

be adequately earthed and fitted with

correctly dimensioned fuses.

6. Equip the pump with an earthing

cable having a diameter adequate to

discharge static current.

ELECTRICAL MOTOR

CONNECTION AND

ROTATION CHECK

In order to carry out the electrical

motor connection, proceed as follows:

WARNING: this operation must

be carried out by a registered

and qualified electrician, after

disconnecting power from the

network.

1. Remove the cover of the motor

terminal-box;

2. Loosen the cable-fastener;

3. Put the power cable in position,

tighten the cable-fastener and

clamp the appropriate terminals to

the cable conductors;

4. Check that the voltage of the motor

is compatible with the power supply.

ALLACIAMENTO ELETTRICO

DEL MOTORE E VERIFICA DI

ROTAZIONE

Per eseguire il collegamento elettrico

del motore bisogna:

ATTENZIONE: questo intervento

deve essere eseguito da un

tecnico elettricista qualificato ed

abilitato, in assenza di tensione sul

cavo di alimentazione.

1Rimuovere il coperchio della

morsettiera del motore.

2Allentare il pressacavo.

3Introdurre il cavo di alimentazione,

serrare il pressacavo e aggraffare sui

conduttori del cavo appositi capicorda

con foro.

4Verificare che i dati di tensione del

motore siano compatibili con quelli di

alimentazione.

AVVERTENZA: alimentare il

motore con tensioni inferiori o

superiori a quelle previste ( vedi

collegamenti ) causa il danneg-

giamento o addirittura la bruciatura

del motore.

5Effettuare il collegamento del condut-

tore di messa a terra sull’apposito

morsetto e serrare a fondo la vite.

ATTENZIONE: l’impianto elettri-

co a monte del motore deve

essere provvisto di efficiente linea

di messa a terra e di fusibili corret-

tamente dimensionati.

6Provvedere alla messa a terra del

corpo pompa con un cavo di adeguata

sezione per scaricare le correnti

statiche.

WARNING: supplying the motor

with higher or lower voltage

than that required (see connection

) can damage or burn the motor.

5. Carry out the connection of the

earthing conductor to the

appropriate clamp and tightly fasten

the screw.

WARNING: the electrical plant

upstream from the motor must

be adequately earthed and fitted with

correctly dimensioned fuses.

6. Equip the pump with an earthing

cable having a diameter adequate to

discharge static current.

ELECTRICAL MOTOR

CONNECTION AND

ROTATION CHECK

In order to carry out the electrical

motor connection, proceed as follows:

WARNING: this operation must

be carried out by a registered

and qualified electrician, after

disconnecting power from the

network.

1. Remove the cover of the motor

terminal-box;

2. Loosen the cable-fastener;

3. Put the power cable in position,

tighten the cable-fastener and

clamp the appropriate terminals to

the cable conductors;

4. Check that the voltage of the motor

is compatible with the power supply.

ALLACIAMENTO ELETTRICO

DEL MOTORE E VERIFICA DI

ROTAZIONE

Per eseguire il collegamento elettrico

del motore bisogna:

ATTENZIONE: questo intervento

deve essere eseguito da un

tecnico elettricista qualificato ed

abilitato, in assenza di tensione sul

cavo di alimentazione.

1Rimuovere il coperchio della

morsettiera del motore.

2Allentare il pressacavo.

3Introdurre il cavo di alimentazione,

serrare il pressacavo e aggraffare sui

conduttori del cavo appositi capicorda

con foro.

4Verificare che i dati di tensione del

motore siano compatibili con quelli di

alimentazione.

AVVERTENZA: alimentare il

motore con tensioni inferiori o

superiori a quelle previste ( vedi

collegamenti ) causa il danneg-

giamento o addirittura la bruciatura

del motore.

5Effettuare il collegamento del condut-

tore di messa a terra sull’apposito

morsetto e serrare a fondo la vite.

ATTENZIONE: l’impianto elettri-

co a monte del motore deve

essere provvisto di efficiente linea

di messa a terra e di fusibili corret-

tamente dimensionati.

6Provvedere alla messa a terra del

corpo pompa con un cavo di adeguata

sezione per scaricare le correnti

statiche.

WARNING: supplying the motor

with higher or lower voltage

than that required (see connection

) can damage or burn the motor.

5. Carry out the connection of the

earthing conductor to the

appropriate clamp and tightly fasten

the screw.

WARNING: the electrical plant

upstream from the motor must

be adequately earthed and fitted with

correctly dimensioned fuses.

6. Equip the pump with an earthing

cable having a diameter adequate to

discharge static current.

ELECTRICAL MOTOR

CONNECTION AND

ROTATION CHECK

In order to carry out the electrical

motor connection, proceed as follows:

WARNING: this operation must

be carried out by a registered

and qualified electrician, after

disconnecting power from the

network.

1. Remove the cover of the motor

terminal-box;

2. Loosen the cable-fastener;

3. Put the power cable in position,

tighten the cable-fastener and

clamp the appropriate terminals to

the cable conductors;

4. Check that the voltage of the motor

is compatible with the power supply.

ALLACIAMENTO ELETTRICO

DEL MOTORE E VERIFICA DI

ROTAZIONE

Per eseguire il collegamento elettrico

del motore bisogna:

ATTENZIONE: questo intervento

deve essere eseguito da un

tecnico elettricista qualificato ed

abilitato, in assenza di tensione sul

cavo di alimentazione.

1Rimuovere il coperchio della

morsettiera del motore.

2Allentare il pressacavo.

3Introdurre il cavo di alimentazione,

serrare il pressacavo e aggraffare sui

conduttori del cavo appositi capicorda

con foro.

4Verificare che i dati di tensione del

motore siano compatibili con quelli di

alimentazione.

AVVERTENZA: alimentare il

motore con tensioni inferiori o

superiori a quelle previste ( vedi

collegamenti ) causa il danneg-

giamento o addirittura la bruciatura

del motore.

5Effettuare il collegamento del condut-

tore di messa a terra sull’apposito

morsetto e serrare a fondo la vite.

ATTENZIONE: l’impianto elettri-

co a monte del motore deve

essere provvisto di efficiente linea

di messa a terra e di fusibili corret-

tamente dimensionati.

6Provvedere alla messa a terra del

corpo pompa con un cavo di adeguata

sezione per scaricare le correnti

statiche.

WARNING: supplying the motor

with higher or lower voltage

than that required (see connection

) can damage or burn the motor.

5. Carry out the connection of the

earthing conductor to the

appropriate clamp and tightly fasten

the screw.

WARNING: the electrical plant

upstream from the motor must

be adequately earthed and fitted with

correctly dimensioned fuses.

6. Equip the pump with an earthing

cable having a diameter adequate to

discharge static current.

ELECTRICAL MOTOR

CONNECTION AND

ROTATION CHECK

In order to carry out the electrical

motor connection, proceed as follows:

WARNING: this operation must

be carried out by a registered

and qualified electrician, after

disconnecting power from the

network.

1. Remove the cover of the motor

terminal-box;

2. Loosen the cable-fastener;

3. Put the power cable in position,

tighten the cable-fastener and

clamp the appropriate terminals to

the cable conductors;

4. Check that the voltage of the motor

is compatible with the power supply.

ALLACIAMENTO ELETTRICO

DEL MOTORE E VERIFICA DI

ROTAZIONE

Per eseguire il collegamento elettrico

del motore bisogna:

ATTENZIONE: questo intervento

deve essere eseguito da un

tecnico elettricista qualificato ed

abilitato, in assenza di tensione sul

cavo di alimentazione.

1Rimuovere il coperchio della

morsettiera del motore.

2Allentare il pressacavo.

3Introdurre il cavo di alimentazione,

serrare il pressacavo e aggraffare sui

conduttori del cavo appositi capicorda

con foro.

4Verificare che i dati di tensione del

motore siano compatibili con quelli di

alimentazione.

AVVERTENZA: alimentare il

motore con tensioni inferiori o

superiori a quelle previste ( vedi

collegamenti ) causa il danneg-

giamento o addirittura la bruciatura

del motore.

5Effettuare il collegamento del condut-

tore di messa a terra sull’apposito

morsetto e serrare a fondo la vite.

ATTENZIONE: l’impianto elettri-

co a monte del motore deve

essere provvisto di efficiente linea

di messa a terra e di fusibili corret-

tamente dimensionati.

6Provvedere alla messa a terra del

corpo pompa con un cavo di adeguata

sezione per scaricare le correnti

statiche.

WARNING: supplying the motor

with higher or lower voltage

than that required (see connection

) can damage or burn the motor.

5. Carry out the connection of the

earthing conductor to the

appropriate clamp and tightly fasten

the screw.

WARNING: the electrical plant

upstream from the motor must

be adequately earthed and fitted with

correctly dimensioned fuses.

6. Equip the pump with an earthing

cable having a diameter adequate to

discharge static current.

ATTENZIONE:

il personale addetto all’installazione, all’ispezio-

ne e alla manutenzione della pompa deve avere

adeguata preparazione tecnica unita a cognizioni

idonee al campo di applicazione (compatibilità ade-

guate in materia e rischi connessi ad eventuali reazio-

ni chimiche del prodotto da pompare).

INSTALLATORE/MANUTENTORE ELETTRICO:

questa qualifica presuppone una piena conoscenza e

comprensione delle informazioni contenute nel manuale

d’uso del costruttore, competenza tecnica specifica per

effettuare gli interventi di natura elettrica di: allacciamento,

manutenzione ordinaria e/o riparazione.

INTERVENTI STRAORDINARI: identifica gli interventi

riservati a tecnici del servizio di assistenza eseguiti

solo presso le officine del Costruttore.

WARNING

personnel responsible for pump installation,

inspection and maintenance shall possess a suitable

technical background along with knowledge of the

field of application (compatibility of materials and risks

associated with possible chemical reactions of the

product being pumped).

ELECTRICAL/FITTER AND MAINTENANCE

ENGINEER

this qualification implies complete familiarity and

understanding of the information contained in the

manufacturer’s user manual and specific electrotechnical

skills in carrying out: connection, routine maintenance and/

or repairs.

EXTRAORDINARY OPERATIONS: indicates

operations to be carried out solely at the

Manufacturer’s workshops by technical support staff.

ATTENZIONE:

il personale addetto all’installazione, all’ispezio-

ne e alla manutenzione della pompa deve avere

adeguata preparazione tecnica unita a cognizioni

idonee al campo di applicazione (compatibilità ade-

guate in materia e rischi connessi ad eventuali reazio-

ni chimiche del prodotto da pompare).

INSTALLATORE/MANUTENTORE ELETTRICO:

questa qualifica presuppone una piena conoscenza e

comprensione delle informazioni contenute nel manuale

d’uso del costruttore, competenza tecnica specifica per

effettuare gli interventi di natura elettrica di: allacciamento,

manutenzione ordinaria e/o riparazione.

INTERVENTI STRAORDINARI: identifica gli interventi

riservati a tecnici del servizio di assistenza eseguiti

solo presso le officine del Costruttore.

WARNING

personnel responsible for pump installation,

inspection and maintenance shall possess a suitable

technical background along with knowledge of the

field of application (compatibility of materials and risks

associated with possible chemical reactions of the

product being pumped).

ELECTRICAL/FITTER AND MAINTENANCE

ENGINEER

this qualification implies complete familiarity and

understanding of the information contained in the

manufacturer’s user manual and specific electrotechnical

skills in carrying out: connection, routine maintenance and/

or repairs.

EXTRAORDINARY OPERATIONS: indicates

operations to be carried out solely at the

Manufacturer’s workshops by technical support staff.

ALLACCIAMENTO DEL

CIRCUITO PRODOTTO

Dopo aver eseguito il posizionamento è

possibile effettuare l’allacciamento della

pompa al circuito del prodotto operando

come segue:

ATTENZIONE: per le connessioni

ai collettori della pompa impie-

gare unicamente raccordi con

filettature gas cilindrico di materiale

compatibile con il fluido da pompare

e con il materiale di costruzione

della pompa.

ES.: pompa in PP = racc. PP

1Installare sull’attacco collettore di

mandata e scarico una valvola manua-

le a sfera (a passaggio totale) di

uguale diametro all’attacco della

pompa (mai più piccola) per garantire

l’intercettazione del fluido in caso di

perdite e/ofuture manutenzioni.

2Provvedere all’installazione dei

manicotti per il fissaggio dei tubi

flessibili su entrambe le valvole

manuali.

PRODUCT CIRCUIT

CONNECTION

After having correctly positioned the

plant, proceed with connecting the

pump to the product circuit, as follows:

WARNING: To connect the

pump only use connections

with cylindrical gas threads made

with materials compatible with the

fluid to be pumped and with the

pump materials

E.g: pump in PP = connections in PP

1. On the suction and delivery

manifold, install a manual ball valve

(full-bore) with a diameter equal to

the connection to the pump (never

smaller), to ensure fluid shut-off in

case of leaks and/or future

maintenance.

2. Proceed with installation of pipe

couplings for fastening the flexible

pipes on to both of the manual

valves.

ATTENZIONE: i tubi di allaccia-

mento alla pompa devono

essere di tipo FLESSIBILE E RINFOR-

ZATO CON SPIRALE RIGIDA di diame-

tro mai inferiore all’attacco della

pompa. Per fluidi viscosi impiegare

tubi con DIAMETRO MAGGIORATO

specialmente sull’aspirazione.

L’allacciamento con tubi rigidi può

provocare forti vibrazioni.

3Provvedere all’allacciamento del tubo

di aspirazione e mandata del prodotto

sui rispettivi attacchi.

WARNING: The connection

pipes to the pump must be

FLEXIBLE, RIGID SPIRAL

REINFORCED pipes never with a

smaller diameter than the

connection of the pump. For viscous

fluids, use pipes with an OVERSIZED

DIAMETER, particularly in suction.

Connection with rigid pipes can

cause strong vibrations.

3. Proceed to connect the product

suction and delivery pipes to their

respective joints.

ALLACCIAMENTO DEL

CIRCUITO PRODOTTO

Dopo aver eseguito il posizionamento è

possibile effettuare l’allacciamento della

pompa al circuito del prodotto operando

come segue:

ATTENZIONE: per le connessioni

ai collettori della pompa impie-

gare unicamente raccordi con

filettature gas cilindrico di materiale

compatibile con il fluido da pompare

e con il materiale di costruzione

della pompa.

ES.: pompa in PP = racc. PP

1Installare sull’attacco collettore di

mandata e scarico una valvola manua-

le a sfera (a passaggio totale) di

uguale diametro all’attacco della

pompa (mai più piccola) per garantire

l’intercettazione del fluido in caso di

perdite e/ofuture manutenzioni.

2Provvedere all’installazione dei

manicotti per il fissaggio dei tubi

flessibili su entrambe le valvole

manuali.

PRODUCT CIRCUIT

CONNECTION

After having correctly positioned the

plant, proceed with connecting the

pump to the product circuit, as follows:

WARNING: To connect the

pump only use connections

with cylindrical gas threads made

with materials compatible with the

fluid to be pumped and with the

pump materials

E.g: pump in PP = connections in PP

1. On the suction and delivery

manifold, install a manual ball valve

(full-bore) with a diameter equal to

the connection to the pump (never

smaller), to ensure fluid shut-off in

case of leaks and/or future

maintenance.

2. Proceed with installation of pipe

couplings for fastening the flexible

pipes on to both of the manual

valves.

ATTENZIONE: i tubi di allaccia-

mento alla pompa devono

essere di tipo FLESSIBILE E RINFOR-

ZATO CON SPIRALE RIGIDA di diame-

tro mai inferiore all’attacco della

pompa. Per fluidi viscosi impiegare

tubi con DIAMETRO MAGGIORATO

specialmente sull’aspirazione.

L’allacciamento con tubi rigidi può

provocare forti vibrazioni.

3Provvedere all’allacciamento del tubo

di aspirazione e mandata del prodotto

sui rispettivi attacchi.

WARNING: The connection

pipes to the pump must be

FLEXIBLE, RIGID SPIRAL

REINFORCED pipes never with a

smaller diameter than the

connection of the pump. For viscous

fluids, use pipes with an OVERSIZED

DIAMETER, particularly in suction.

Connection with rigid pipes can

cause strong vibrations.

3. Proceed to connect the product

suction and delivery pipes to their

respective joints.

ALLACCIAMENTO DEL

CIRCUITO PRODOTTO

Dopo aver eseguito il posizionamento è

possibile effettuare l’allacciamento della

pompa al circuito del prodotto operando

come segue:

ATTENZIONE: per le connessioni

ai collettori della pompa impie-

gare unicamente raccordi con

filettature gas cilindrico di materiale

compatibile con il fluido da pompare

e con il materiale di costruzione

della pompa.

ES.: pompa in PP = racc. PP

1Installare sull’attacco collettore di

mandata e scarico una valvola manua-

le a sfera (a passaggio totale) di

uguale diametro all’attacco della

pompa (mai più piccola) per garantire

l’intercettazione del fluido in caso di

perdite e/ofuture manutenzioni.

2Provvedere all’installazione dei

manicotti per il fissaggio dei tubi

flessibili su entrambe le valvole

manuali.

PRODUCT CIRCUIT

CONNECTION

After having correctly positioned the

plant, proceed with connecting the

pump to the product circuit, as follows:

WARNING: To connect the

pump only use connections

with cylindrical gas threads made

with materials compatible with the

fluid to be pumped and with the

pump materials

E.g: pump in PP = connections in PP

1. On the suction and delivery

manifold, install a manual ball valve

(full-bore) with a diameter equal to

the connection to the pump (never

smaller), to ensure fluid shut-off in

case of leaks and/or future

maintenance.

2. Proceed with installation of pipe

couplings for fastening the flexible

pipes on to both of the manual

valves.

ATTENZIONE: i tubi di allaccia-

mento alla pompa devono

essere di tipo FLESSIBILE E RINFOR-

ZATO CON SPIRALE RIGIDA di diame-

tro mai inferiore all’attacco della

pompa. Per fluidi viscosi impiegare

tubi con DIAMETRO MAGGIORATO

specialmente sull’aspirazione.

L’allacciamento con tubi rigidi può

provocare forti vibrazioni.

3Provvedere all’allacciamento del tubo

di aspirazione e mandata del prodotto

sui rispettivi attacchi.

WARNING: The connection

pipes to the pump must be

FLEXIBLE, RIGID SPIRAL

REINFORCED pipes never with a

smaller diameter than the

connection of the pump. For viscous

fluids, use pipes with an OVERSIZED

DIAMETER, particularly in suction.

Connection with rigid pipes can

cause strong vibrations.

3. Proceed to connect the product

suction and delivery pipes to their

respective joints.

4Provvedere al fissaggio dei tubi con

apposite fascette.

ATTENZIONE: supportare ade-

guatamente le tubazioni; LE

TUBAZIONI DEVONO ESSERE SUFFI-

CIENTEMENTE RESISTENTI DA NON

DEFORMARSI SOTTO ASPIRAZIONE

E NON DEVONO MAI GRAVARE IN

ALCUN MODO SULLA POMPA E

VICEVERSA.

ATTENZIONE: controllare che

nel fluido trattato non vi siano o

non vi possano essere parti solide di

dimensioni elevate o forma dannosa

e che non ci siano restrizioni sul-

l’aspirazione e/o sulla mandata

della pompa per evitare fenomeni

rispettivamente di cavitazione e

sforzo del motore elettrico o funzio-

namento a secco.

L’allacciamento del circuito del

prodotto è così terminato.

4. Proceed with fastening the pipes with

appropriate metal rings.

WARNING: the pipes must be

adequately supported; PIPES

MUST BE STRONG ENOUGH NOT

TO DEFORM IN SUCTION AND

MUST NEVER WEIGHT THE PUMP

DOWN OR VICEVERSA

WARNING: Check that the

treated fluid does not or could

not contain solid matters of a large

size or with a potentially damaging

shape and that the intake and/or

delivery ports are not obstructed in

order to avoid cavitation or electric

motor strain or dry operation.

The circuit connection is now

completed.

debem.it

8 ALLACCIAMENTO PER

MOTORE ASINCRONO TRIFASE

La disposizione delle barrette dei

morsetti dei motori trifase deve essere

variata.

8.1 CON ALIMENTAZIONE TENSIONE

INFERIORE

(schema a triangolo )

L’alimentazione del motore con tensio-

ne inferiore (esempio: A = 230-400V

alimentazione a 230V; B =400-690V

alimentazione a 400V) deve essere

effettuata sui morsetti con le barrette

disposte secondo lo schema “a triango-

lo ”.

8.2 CON ALIMENTAZIONE TENSIONE

SUPERIORE (schema a stella )

L’alimentazione del motore con tensio-

ne superiore (esempio: A = 230-400V

alimentazione a 400V; B =400-690V

alimentazione a 690V) deve essere

effettuata sui morsetti con le barrette

disposte secondo lo schema “a stella

”.

7 ALLACCIAMENTO PER

MOTORE MONOFASE

La disposizione delle barrette dei

morsetti determina il senso di rotazione

del motore monofase.

Per l’allacciamento bisogna:

7.1Allentare i dadi dei morsetti mostrati

in figura.

7.2Inserire i terminali dei due conduttori

sui rispettivi contatti mostrati in

figura.

7.3Rimontare le ranelle dentate ed i

rispettivi dadi e serrarli a fondo.

NOTA: Per invertire il senso di

rotazione del motore monofase

bisogna cambiare la disposizione delle

barrette e ripetere le operazioni

precedentemente descritte per

l’allacciamento.

7 SINGLE-PHASE MOTOR

CONNECTION

The arrangement of the clamps bars

determines the single-phase motor

rotation direction.

In order to carry out the connection,

proceed as follows:

7.1 Loosen the clamps nuts as in the

figure.

7.2 Insert the two conductors

terminals on their respective

contacts as in figure.

7.3 Reassemble the washers and

respective nuts and fasten tightly.

NOTE: In order to invert the

single-phase motor rotation

direction, change the arrangement of

the bars and repeat the operations

described above for the connection.

8 THREE-PHASE,

ASYNCHRONOUS MOTOR

CONNECTION

The arrangement of the clamp bars

must be changed.

8.1 WITH LOWER VOLTAGE POWER

(triangular diagram )

The power supply to a motor with lower

voltage (e.g. A= 23-400V power at

230V; B= 400-690V power at 400V)

must be carried out with the bars

arranged according to the triangular

diagram

8.2 WITH HIGHER VOLTAGE

POWER (Star diagram)

Power supply of a motor with higher

voltage (e.g. A= 239-400V power at

400V; B= 400-690V power at 690V)

must be carried out with the barrette

arranged according to the “star”

diagram

7.1

7.3

L N

L1 L2 L3

7.2

L1 L2 L3

MOTORE MONOFASE

SINGLE-PHASE MOTOR

u1 v1 w1

v2 u2 w2

MOTORE ASINCRONO TRIFASE

COLLEGAMENTO A TRIANGOLO

THREE-PHASE, ASYNCHRONOUS

MOTOR TRIANGULAR CONNEC.

A = 230V

B = 400V

A = 400V

B = 690V

8.1

8.2

MOTORE ASINCRONO TRIFASE

COLLEGAMENTO A STELLA

THREE-PHASE, ASYNCHRONOUS

MOTOR STAR CONNECTION

u1 v1 w1

v2 u2 w2

8 ALLACCIAMENTO PER

MOTORE ASINCRONO TRIFASE

La disposizione delle barrette dei

morsetti dei motori trifase deve essere

variata.

8.1 CON ALIMENTAZIONE TENSIONE

INFERIORE

(schema a triangolo )

L’alimentazione del motore con tensio-

ne inferiore (esempio: A = 230-400V

alimentazione a 230V; B =400-690V

alimentazione a 400V) deve essere

effettuata sui morsetti con le barrette

disposte secondo lo schema “a triango-

lo ”.

8.2 CON ALIMENTAZIONE TENSIONE

SUPERIORE (schema a stella )

L’alimentazione del motore con tensio-

ne superiore (esempio: A = 230-400V

alimentazione a 400V; B =400-690V

alimentazione a 690V) deve essere

effettuata sui morsetti con le barrette

disposte secondo lo schema “a stella

”.

7 ALLACCIAMENTO PER

MOTORE MONOFASE

La disposizione delle barrette dei

morsetti determina il senso di rotazione

del motore monofase.

Per l’allacciamento bisogna:

7.1Allentare i dadi dei morsetti mostrati

in figura.

7.2Inserire i terminali dei due conduttori

sui rispettivi contatti mostrati in

figura.

7.3Rimontare le ranelle dentate ed i

rispettivi dadi e serrarli a fondo.

NOTA: Per invertire il senso di

rotazione del motore monofase

bisogna cambiare la disposizione delle

barrette e ripetere le operazioni

precedentemente descritte per

l’allacciamento.

7 SINGLE-PHASE MOTOR

CONNECTION

The arrangement of the clamps bars

determines the single-phase motor

rotation direction.

In order to carry out the connection,

proceed as follows:

7.1 Loosen the clamps nuts as in the

figure.

7.2 Insert the two conductors

terminals on their respective

contacts as in figure.

7.3 Reassemble the washers and

respective nuts and fasten tightly.

NOTE: In order to invert the

single-phase motor rotation

direction, change the arrangement of

the bars and repeat the operations

described above for the connection.

8 THREE-PHASE,

ASYNCHRONOUS MOTOR

CONNECTION

The arrangement of the clamp bars

must be changed.

8.1 WITH LOWER VOLTAGE POWER

(triangular diagram )

The power supply to a motor with lower

voltage (e.g. A= 23-400V power at

230V; B= 400-690V power at 400V)

must be carried out with the bars

arranged according to the triangular

diagram

8.2 WITH HIGHER VOLTAGE

POWER (Star diagram)

Power supply of a motor with higher

voltage (e.g. A= 239-400V power at

400V; B= 400-690V power at 690V)

must be carried out with the barrette

arranged according to the “star”

diagram

7.1

7.3

L N

L1 L2 L3

7.2

L1 L2 L3

MOTORE MONOFASE

SINGLE-PHASE MOTOR

u1 v1 w1

v2 u2 w2

MOTORE ASINCRONO TRIFASE

COLLEGAMENTO A TRIANGOLO

THREE-PHASE, ASYNCHRONOUS

MOTOR TRIANGULAR CONNEC.

A = 230V

B = 400V

A = 400V

B = 690V

8.1

8.2

MOTORE ASINCRONO TRIFASE

COLLEGAMENTO A STELLA

THREE-PHASE, ASYNCHRONOUS

MOTOR STAR CONNECTION

u1 v1 w1

v2 u2 w2

8 ALLACCIAMENTO PER

MOTORE ASINCRONO TRIFASE

La disposizione delle barrette dei

morsetti dei motori trifase deve essere

variata.

8.1 CON ALIMENTAZIONE TENSIONE

INFERIORE

(schema a triangolo )

L’alimentazione del motore con tensio-

ne inferiore (esempio: A = 230-400V

alimentazione a 230V; B =400-690V

alimentazione a 400V) deve essere

effettuata sui morsetti con le barrette

disposte secondo lo schema “a triango-

lo ”.

8.2 CON ALIMENTAZIONE TENSIONE

SUPERIORE (schema a stella )

L’alimentazione del motore con tensio-

ne superiore (esempio: A = 230-400V

alimentazione a 400V; B =400-690V

alimentazione a 690V) deve essere

effettuata sui morsetti con le barrette

disposte secondo lo schema “a stella

”.

7 ALLACCIAMENTO PER

MOTORE MONOFASE

La disposizione delle barrette dei

morsetti determina il senso di rotazione

del motore monofase.

Per l’allacciamento bisogna:

7.1Allentare i dadi dei morsetti mostrati

in figura.

7.2Inserire i terminali dei due conduttori

sui rispettivi contatti mostrati in

figura.

7.3Rimontare le ranelle dentate ed i

rispettivi dadi e serrarli a fondo.

NOTA: Per invertire il senso di

rotazione del motore monofase

bisogna cambiare la disposizione delle

barrette e ripetere le operazioni

precedentemente descritte per

l’allacciamento.

7 SINGLE-PHASE MOTOR

CONNECTION

The arrangement of the clamps bars

determines the single-phase motor

rotation direction.

In order to carry out the connection,

proceed as follows:

7.1 Loosen the clamps nuts as in the

figure.

7.2 Insert the two conductors

terminals on their respective

contacts as in figure.

7.3 Reassemble the washers and

respective nuts and fasten tightly.

NOTE: In order to invert the

single-phase motor rotation

direction, change the arrangement of

the bars and repeat the operations

described above for the connection.

8 THREE-PHASE,

ASYNCHRONOUS MOTOR

CONNECTION

The arrangement of the clamp bars

must be changed.

8.1 WITH LOWER VOLTAGE POWER

(triangular diagram )

The power supply to a motor with lower

voltage (e.g. A= 23-400V power at

230V; B= 400-690V power at 400V)

must be carried out with the bars

arranged according to the triangular

diagram

8.2 WITH HIGHER VOLTAGE

POWER (Star diagram)

Power supply of a motor with higher

voltage (e.g. A= 239-400V power at

400V; B= 400-690V power at 690V)

must be carried out with the barrette

arranged according to the “star”

diagram

7.1

7.3

L N

L1 L2 L3

7.2

L1 L2 L3

MOTORE MONOFASE

SINGLE-PHASE MOTOR

u1 v1 w1

v2 u2 w2

MOTORE ASINCRONO TRIFASE

COLLEGAMENTO A TRIANGOLO

THREE-PHASE, ASYNCHRONOUS

MOTOR TRIANGULAR CONNEC.

A = 230V

B = 400V

A = 400V

B = 690V

8.1

8.2

MOTORE ASINCRONO TRIFASE

COLLEGAMENTO A STELLA

THREE-PHASE, ASYNCHRONOUS

MOTOR STAR CONNECTION

u1 v1 w1

v2 u2 w2

8 ALLACCIAMENTO PER

MOTORE ASINCRONO TRIFASE

La disposizione delle barrette dei

morsetti dei motori trifase deve essere

variata.

8.1 CON ALIMENTAZIONE TENSIONE

INFERIORE

(schema a triangolo )

L’alimentazione del motore con tensio-

ne inferiore (esempio: A = 230-400V

alimentazione a 230V; B =400-690V

alimentazione a 400V) deve essere

effettuata sui morsetti con le barrette

disposte secondo lo schema “a triango-

lo ”.

8.2 CON ALIMENTAZIONE TENSIONE

SUPERIORE (schema a stella )

L’alimentazione del motore con tensio-

ne superiore (esempio: A = 230-400V

alimentazione a 400V; B =400-690V

alimentazione a 690V) deve essere

effettuata sui morsetti con le barrette

disposte secondo lo schema “a stella

”.

7 ALLACCIAMENTO PER

MOTORE MONOFASE

La disposizione delle barrette dei

morsetti determina il senso di rotazione

del motore monofase.

Per l’allacciamento bisogna:

7.1Allentare i dadi dei morsetti mostrati

in figura.

7.2Inserire i terminali dei due conduttori

sui rispettivi contatti mostrati in

figura.

7.3Rimontare le ranelle dentate ed i

rispettivi dadi e serrarli a fondo.

NOTA: Per invertire il senso di

rotazione del motore monofase

bisogna cambiare la disposizione delle

barrette e ripetere le operazioni

precedentemente descritte per

l’allacciamento.

7 SINGLE-PHASE MOTOR

CONNECTION

The arrangement of the clamps bars

determines the single-phase motor

rotation direction.

In order to carry out the connection,

proceed as follows:

7.1 Loosen the clamps nuts as in the

figure.

7.2 Insert the two conductors

terminals on their respective

contacts as in figure.

7.3 Reassemble the washers and

respective nuts and fasten tightly.

NOTE: In order to invert the

single-phase motor rotation

direction, change the arrangement of

the bars and repeat the operations

described above for the connection.

8 THREE-PHASE,

ASYNCHRONOUS MOTOR

CONNECTION

The arrangement of the clamp bars

must be changed.

8.1 WITH LOWER VOLTAGE POWER

(triangular diagram )

The power supply to a motor with lower

voltage (e.g. A= 23-400V power at

230V; B= 400-690V power at 400V)

must be carried out with the bars

arranged according to the triangular

diagram

8.2 WITH HIGHER VOLTAGE

POWER (Star diagram)

Power supply of a motor with higher

voltage (e.g. A= 239-400V power at

400V; B= 400-690V power at 690V)

must be carried out with the barrette

arranged according to the “star”

diagram

7.1

7.3

L N

L1 L2 L3

7.2

L1 L2 L3

MOTORE MONOFASE

SINGLE-PHASE MOTOR

u1 v1 w1

v2 u2 w2

MOTORE ASINCRONO TRIFASE

COLLEGAMENTO A TRIANGOLO

THREE-PHASE, ASYNCHRONOUS

MOTOR TRIANGULAR CONNEC.

A = 230V

B = 400V

A = 400V

B = 690V

8.1

8.2

MOTORE ASINCRONO TRIFASE

COLLEGAMENTO A STELLA

THREE-PHASE, ASYNCHRONOUS

MOTOR STAR CONNECTION

u1 v1 w1

v2 u2 w2

8 ALLACCIAMENTO PER

MOTORE ASINCRONO TRIFASE

La disposizione delle barrette dei

morsetti dei motori trifase deve essere

variata.

8.1 CON ALIMENTAZIONE TENSIONE

INFERIORE

(schema a triangolo )

L’alimentazione del motore con tensio-

ne inferiore (esempio: A = 230-400V

alimentazione a 230V; B =400-690V

alimentazione a 400V) deve essere

effettuata sui morsetti con le barrette

disposte secondo lo schema “a triango-

lo ”.

8.2 CON ALIMENTAZIONE TENSIONE

SUPERIORE (schema a stella )

L’alimentazione del motore con tensio-

ne superiore (esempio: A = 230-400V

alimentazione a 400V; B =400-690V

alimentazione a 690V) deve essere

effettuata sui morsetti con le barrette

disposte secondo lo schema “a stella

”.

7 ALLACCIAMENTO PER

MOTORE MONOFASE

La disposizione delle barrette dei

morsetti determina il senso di rotazione

del motore monofase.

Per l’allacciamento bisogna:

7.1Allentare i dadi dei morsetti mostrati

in figura.

7.2Inserire i terminali dei due conduttori

sui rispettivi contatti mostrati in

figura.

7.3Rimontare le ranelle dentate ed i

rispettivi dadi e serrarli a fondo.

NOTA: Per invertire il senso di

rotazione del motore monofase

bisogna cambiare la disposizione delle

barrette e ripetere le operazioni

precedentemente descritte per

l’allacciamento.

7 SINGLE-PHASE MOTOR

CONNECTION

The arrangement of the clamps bars

determines the single-phase motor

rotation direction.

In order to carry out the connection,

proceed as follows:

7.1 Loosen the clamps nuts as in the

figure.

7.2 Insert the two conductors

terminals on their respective

contacts as in figure.

7.3 Reassemble the washers and

respective nuts and fasten tightly.

NOTE: In order to invert the

single-phase motor rotation

direction, change the arrangement of

the bars and repeat the operations

described above for the connection.

8 THREE-PHASE,

ASYNCHRONOUS MOTOR

CONNECTION

The arrangement of the clamp bars

must be changed.

8.1 WITH LOWER VOLTAGE POWER

(triangular diagram )

The power supply to a motor with lower

voltage (e.g. A= 23-400V power at

230V; B= 400-690V power at 400V)

must be carried out with the bars

arranged according to the triangular

diagram

8.2 WITH HIGHER VOLTAGE

POWER (Star diagram)

Power supply of a motor with higher

voltage (e.g. A= 239-400V power at

400V; B= 400-690V power at 690V)

must be carried out with the barrette

arranged according to the “star”

diagram

7.1

7.3

L N

L1 L2 L3

7.2

L1 L2 L3

MOTORE MONOFASE

SINGLE-PHASE MOTOR

u1 v1 w1

v2 u2 w2

MOTORE ASINCRONO TRIFASE

COLLEGAMENTO A TRIANGOLO

THREE-PHASE, ASYNCHRONOUS

MOTOR TRIANGULAR CONNEC.

A = 230V

B = 400V

A = 400V

B = 690V

8.1

8.2

MOTORE ASINCRONO TRIFASE

COLLEGAMENTO A STELLA

THREE-PHASE, ASYNCHRONOUS

MOTOR STAR CONNECTION

u1 v1 w1

v2 u2 w2

7 SINGLE-PHASE MOTOR CONNECTION

The arrangement of the clamps bars determines the single-

phase motor rotation direction.

In order to carry out the connection, proceed as follows:

7.1 Loosen the clamps nuts as in the gure.

7.2 Insert the two conductors terminals on their respective

contacts as in gure.

7.3 Reassemble the washers and respective nuts and fasten

tightly.

NOTE: In order to invert the single-phase motor rotation

direction, change the arrangement of the bars and repeat

the operations described above for the connection.

8 THREE-PHASE, ASYNCHRONOUS MOTOR CONNECTION

The arrangement of the clamp bars must be changed.

8.1 WITH LOWER VOLTAGE POWER (triangular diagram Δ )

The power supply to a motor with lower voltage (e.g. A = 23-

400V power at 230V; B = 400-690V power at 400V) must be

carried out with the bars arranged according to the triangular

diagram Δ.

8.2 WITH HIGHER VOLTAGE POWER (Star diagram Y)

Power supply of a motor with higher voltage (e.g. A = 239-400V

power at 400V; B = 400-690V power at 690V) must be carried

out with the barrette arranged according to the “star” diagram Y.

7 ANSCHLUSS DES EINPHASIGEN MOTORS

Die Anordnung der Klemmleisten bestimmt die Drehrichtung

des einphasigen Motors.

Für den Anschluss muss man wie folgt vorgehen:

7.1 Lösen Sie die Muttern der Klemmen wie auf der Darstel-

lung abgebildet.

7.2 Fügen Sie Anschlüsse der beiden Leiter in die entspre-

chenden auf der Darstellung abgebildet Klemmen.

7.3 Montieren Sie die verzahnten Unterlegscheiben und die

entsprechenden Muttern und ziehen Sie sie fest.

ANMERKUNG: Um die Drehrichtung des einpha-

sigen Motors umzukehren, muss man die Anord-

nung der Klemmleisten ändern und den zuvor

beschriebenen Vorgang für den Anschluss wiederholen.

8 ANSCHLUSS DES DREIPHASIGEN ASYNCHRONMO-

TORS

Die Anordnung der Klemmleisten der dreiphasigen Motoren

muss geändert werden.

8.1 BEI NIEDRIGER STROMVERSORGUNG (Dreiecksdia-

gramm Δ)

Die Stromversorgung des Motors bei niedriger Spannung

(Beispiel: A = 230-400V

Versorgung bei 230V; B =400-690V

Versorgung bei 400V) muss auf den Klemmen mit den Leisten

gemäß dem „Dreiecksschema Δ“ durchgeführt werden.

8.2 BEI HOHER STROMVERSORGUNG (Sterndiagramm Y )

Die Stromversorgung des Motors bei hoher Spannung (Bei-

spiel: A = 230-400V

Versorgung bei 400V; B =400-690V

Versorgung bei 690V) muss auf den Klemmen mit den Leisten

gemäß dem „Sternschema Y“ durchgeführt werden.

PRESCRIZIONI DI SICUREZZA

DREIPHASIGEN ASYNCHRONMOTORS

DREIECKSDIAGRAMM

DREIPHASIGEN ASYNCHRONMOTORS

STERNDIAGRAMM

EINPHASIGEN MOTOR

Other manuals for MB series

This manual suits for next models
