INTRODUCTION
The 13-HHC-B Hydraulic Cutter Remote is a lightweight,
compact and extremely durable tool that has been designed
for cutting a wide variety of materials.
The Cutter features insert type blades that can be easily
replaced in the field with the use of only a screw driver.
Other features include a hinged “ Flip Top” Head and a full
360 Degrees of head rotation.
The Cutter can be operated with any suitable hand or power
pump capable of pressure output of 10,000 PSI. No special
control valves are required since the cutter piston is spring
returned.
The 13-HHC is not to be used for hot line work.
SPECIFICATIONS
PUMP SECTION:
Injector Stroke: .56 in. (1.42 cm)
L P Output Per Stroke: .441 cu. in. (.007 liter)
H P Output Per Stroke: .034 cu. in. (.0005 liter)
L P Unloading Valve Setting: 500 psi (3,447 kPA)
L P Relief Valve Setting: 25 psi (172 kPA)
H P Relief Valve Setting: 10,000 psi (68,950 kPA)
Handle Effort: 4.2 lbs. per 1,000 psi
(1.90 kg per 6,895 kPA)
Reservoir Capacity: 8.5 cu. in. (.139 liter)
Oil Type Recommended: Amoco Rykon MV
TOOL SECTION:
Bore Diameter: 1.875 in. (4.76 cm)
Stroke: 2.180 in. (5.54 cm)
Cutting Force: 13.180 tons U.S.
(12.5 tons Metric
Head Rotation: 360 degrees continuous
GENERAL:
Total Weight: 20.1 lbs. (9.1 kg)
Size: 4.15 x 7.39 x 25.66 in.
long (10.54 x 18.77 x
65.17 cm long)
CUTTING CAPACITY: (See Notes)
Wire Rope: 1 in. (2.54 cm)
Soft Copper/Alum Wire: 1.25 in. (3.17 cm)
Gr. 2 Soft Steel Bolts: .875 in. (2.22 cm)
Bare Stranded Copper/ Alum Wire: 2.00 in. (5.08 cm)
ACSR Underground Power Cable: 2.00 in. (5.08 cm)
Stranded Galvanized Wire: .75 in. (1.90 cm)
WARNING
Notes:
Size shown are for stranded bare wires. When
cutting insulated wire, size is over insulation.
Rating for soft steel should not exceed ASTM
1022. Rating for hard drawn steel wire should not
exceed ASTM 1042.
13-HHC-B
HYDRAULIC CUTTER TOOL
Sheet No. 1 of 7
Rev Date: 12 Feb 2004

Operating Instructions and Parts List, Form No. 1000031, Back sheet 1 of 7
IMPORTANT SAFETY INFORMATION
It is the operators responsibility to read and
understand the following safety statements,
• Only qualified operators should install, operate,
adjust, maintain, clean, repair, or transport this
machinery.
• Inspect tool before use. Replace any worn or
damaged parts. Failure to observe these warning
can result in severe injury or death.
Keep hands away from the cutter head
assembly head when cutting.
To help prevent personal injury,
• Always wear eye protection whenever
operating hydraulic equipment.
• Always wear hearing protection as
required.
• Operation, repair, or maintenance of hydraulic
equipment should be performed by a qualified
person who understands the proper function of
hydraulic equipment per local directives and
standards.
• Hydraulic equipment must be assembled correctly
and then checked for proper function before use. Use
hydraulic components of the same hydraulic
pressure ratings. An appropriate hydraulic pressure
gauge is recommended to monitor pressure.
• Never place your hands or other body
parts near a hydraulic fluid leak.
Never use your hands or other body parts
to check for a possible leak.
High pressure fluid can be injected under your skin
causing serious injury and/or infection.
• Do not exceed cutting capacity of materials listed on
sheet one. Cutting of too large or too hard materials
could cause blades to shatter and cause injury.
• This tool is not insulated. When using this
unit near energized electrical lines, use
proper personal protective equipment.
• Do not cut piano or music wire.
• Do not operate cutter with top support open.
• Properly dispose of all fluids, components, and
assemblies at the end of their useful life.
• Hydraulic fluid should be compatible with all
hydraulic components.
IMPORTANT
WARNING
CAUTION
This is the safety alert symbol.
It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death
Denotes an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
Denotes a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Denotes a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Caution used without the safety alert symbol indicates
a potentially hazardous situation which, if not avoided,
may result in property damage.
Denotes an operating or service procedure or condition
considered essential for expedient and efficient
operation and service.
IMPORTANT
CAUTION
CAUTION
WARNING
DANGER
WARNING
WARNING

Operating Instructions and Parts List, Form No. 1000031
OPERATING INSTRUCTIONS
Insert material to be cut between blades.
If part to be cut is very long, open cutter head by pulling out pull pin assembly, slide cutter over
part and close head, locking in place with pull pin assembly fully engaged.
Pump lever handle to close bottom blade on material.
After a few strokes, a slight click will be heard indicating that the pump has shifted into the high-
pressure stage. Continue pumping lever until material has been cut.
To retract piston, lift lever handle slightly and rotate handle clockwise until it stops. Push handle
downward until pressure release plunger has been depressed and piston retracted. Lifting lever
slightly at any time will stop piston retraction.
Note:
After extended use or cutting hard materials, blades will become worn and pitted. Kit No. 4-1235
is available from the factory for blade replacement. Replace worn or damaged blades to maintain
safe, efficient cutting operations.
Blade Replacement (Kit No. 4-1235)
To replace top blade, withdraw pull pin assembly and open top support. Remove slotted screw
and top blade. Insert new top blade with flat side facing bottom blade and secure with new
slotted screw and lockwasher.
To replace bottom blade, advance piston until bottom blade screw is exposed. Remove hex socket screw and bottom
blade. Insert new bottom blade with flat side facing top blade and secure with new screw.
Close top support and replace pull pin assembly. Cutter is now ready for use.
PERIODIC MAINTENANCE:
Occasionally lubricate pull pins and pivot pins with a molybdenum disulfide grease. The greatest single cause of
failure for hydraulic tools is dirt. Extreme caution should be used to prevent the entry of contaminant's into the unit.
Internal Relief Valve
If cutter fails to cut properly when blades appear to be in good condition, the internal relief valve may have lost its
proper setting (See “Pressure Gage Port”)
Pressure Gage Port
This cutter features a port for the installation of a gage to determine the high-pressure relief valve setting. (See 4-
0790 Gage Assembly)
Oil Leaks
A slight weeping of oil from the ram and pump seals is normal and required to keep moving parts lubricated.
Excessive leakage indicates a need for seal replacement.
Seal Replacement
Maintenance and repairs of this type should only be preformed by properly trained personnel in repair shops under
clean conditions. In addition to all parts shown on keyed parts list, 4-1161 Seal Kit and 4-1065 are available for
replacing seals in the cutter head sub-assembly and in the pump mechanism sub-assembly.
Sheet No. 2 of 7
Rev Date: 12 Feb 2004

Operating Instructions and Parts List, Form No. 1000031, Back sheet 2 of 7
Filling Reservoir
To add or replace oil in the cutter, retract blade completely. Loosen the reservoir
handle stop screw and remove the handle. Remove the reservoir plug and O-ring seal. Pull the stem of the reservoir
bladder out as far as possible. Add oil until it fills the stem. See “Compatible Hydraulic Fluids” section.
TROUBLE SHOOTING
If the blade will not extend completely, and pumping becomes easier, it will generally be found that there is an
insufficient amount of oil in the compressor's hydraulic system. This trouble can also be caused by faulty pump
plunger packing or release valve packing by the pressure release valve being stuck open, or by foreign matter
preventing the release valve balls from seating properly. Faulty packing will usually be detected by excess oil leakage
around the pump plunger. A stuck valve ball can usually be freed by rapping the tool sharply.
Avoid damage to other parts in the process of rapping. Foreign matter can frequently
be flushed from a valve seat by pumping very rapidly with abrupt strokes.
If the blade will not retract completely, it will generally be found that there is too much oil in the cutter’s hydraulic
system. Drain enough to permit complete retraction. If the blade will not retract and the oil reservoir is not full, the ram
is likely being held by a deformed washer.
A small amount of leakage is desirable around the ram; pump plunger, and pressure release valve plunger to
lubricate these parts. If enough leakage occurs to cause the oil to run, the packing should be replaced.
Compatible Hydraulic Fluids:
The use of Amoco Rykon MV oil is recommended. Compatible fluids include:
Mobil DTE 13
Mobil ATF 220
Shell Tellus 32
Arco Dexron III
Citgo AW32
Citgo Dexron III
Other fluids also may be used if they meet or exceed the following specifications:
Viscosity: 180 SSU at 100 degree F.
Flash Point: 350 degree F
Pour Point: -50 degree F
CAUTION

Operating Instructions, Form No. 1000031, Back sheet 2 of 3
INSTRUCTIONS FOR CONVERSION TO 13-HCR TOOL
1. Fully retract tool ram and make sure all pressure has dissipated.
2. Place tool in a vise with handles pointing upward. Remove adhesive label covering slot in cylinder.
3. Pry hooked end of retaining wire out of slot in cylinder.
4. Holding hooked end of wire with pliers, rotate cylinder to force retaining wire out of groove and through slot.
Discard wire.
5. Carefully separate pump assembly from cylinder assembly, holding discharge spring in place.
6. Apply lubricant to groove in end cap of remote tool and to retaining wire.
7. Insert end cap into back end of cylinder assembly. Rotate cylinder assembly until hole in end cap appears in
slot in cylinder.
8. Place hooked end of new wire from conversion kit into hole in end cap. Align free length of wire along slot
in cylinder. Rotate cylinder assembly in opposite direction to feed wire through slot and into groove.
9. When wire is fully engaged, hooked end will snap out of hole in end cap to permit full head rotation.
Wedge spring pin in slot in cylinder, allowing wire to move freely beneath. Seal slot with new adhesive label.
10. Purge air from remote tool and pump system using normal fill and bleed procedures.
WIRE SLOT IN CYLINDER
13-HHC TOOL
CUTTER HEAD SUB-ASSEMBLY
(PART NUMBER 4-0929)
REMOTE END CAP ASSEMBLY
(PART NUMBER 4-0765)
CONVERSION ASSEMBLY
(PART NUMBER 4-0766)
1-RETAINING WIRE
1-WRAP AROUND DECAL
Sheet No. 3 of 7
Rev Date: 12 Feb 2004
®
SPX Corporation, Rockford, IL 61109 USA
http://www.powerteam.com Made in USA
®
SPX Corporation, Rockford, IL 61109 USA
http://www.powerteam.com Made in USA
®
SPX Corporation, Rockford, IL 61109 USA
http://www.powerteam.com Made in USA

Operating Instructions and Parts List, Form No. 1000031, Back sheet 3 of 7
PARTS LIST
14-0812 1 Handle Assembly, Lift
210006 2 Screw, Socket Head
310228 2 Washer, Plain
41000056 1 Decal, (Tradename Power Team)
53-9678 1 Retaining Wire
61000054 1 Decal, (Warning)
7420691 1 Decal, (Product Blank)
83000089 1 Pump, Mechanical Sub
Assembly
94-0929 1 Cutter Head Sub Assembly
ITEM NOT SHOWN
2000147 1 Bag, Nylon Carrying
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
SECTION A-A
A
A
1
2
34
5
8
9
Apply "White Lube"
Lithium (213083)
grease to wire and
groove before
assembling
7
6
®
SPX Corporation, Rockford,IL 61109 USA http://www .powerteam.com
Madein USA
1000056
DO NOT ADVANCE BLADE WITH HEAD OPEN . KEEP HANDS AWAYFROM CUTTER HEAD ASSEMBLY WHEN CUTTING
DO NOT EXCEED CUTTING CAPACITY OF MATERIALS LISTED IN OPERATING INSTRUCTION MANUAL
1000054
13-HHC-B

Operating Instructions and Parts List Form No. 1000031
13-9008 1 Cable Assembly
211089 1 Washer, Flat
35-3481 1 Screw, Drive
419733 1 Washer, Back-up
510809 1 Screw, Soc. Hd. (5/16-18 x 1-1/4)
65-0873 1 Screw, Hollow Set
73-9698 1 Blade, Top
811032 1 Ring, Retaining
910266 1 O-Ring
10 3-9005 1 Piston
11 4-0669 1 Cylinder
12 5-2386 1 Pin, Spring
13 3-9700 1 Support, Top
14 4-0668 1Yoke
15 5-3859 1 Pin Assembly, Pull
16 5-3860 1 Ring, Grip
17 3-8223 1 Pin, Pivot
18 5-3172 2 Retaining Ring
19 3-9007 1 Retaining Wire
20 5-3245 1 Ring, Back-Up
21 11351 1 Washer, Ext. Tooth
22 10174 1 Screw, Rd. Hd. (1/4-20 x 1/2)
23 3-9699 1 Blade, Bottom
24 5-3914 1 Pin
25 3-4145 1 Washer, Nylon
26 4-0670 1 Spring Assembly
27 5-3427 1 O-Ring
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
1
2
3
A
B
B
C
C
D
D
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
SECTION C-C
SECTION D-D
20 21
23
22 24 25 26
27
SECTION A-A SECTION B-B
Apply "White Lube"
Lithium (213083)
grease to wire and
groove before
assembling
1
2
3
4
5
6
7
13-9680 1 Tube, Transfer
25-3245 1 Ring, Back-Up
310266 1 O-Ring
43-9683 1 Retaining, Swivel
511032 1 Ring, Retaining
63-4144 1 Spring, Tension
73-9012 1 Retainer, Threaded
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
CUTTER-HEAD SUB ASSEMBLY 4-0929
SPRING ASSEMBLY - 4-0670
Sheet No. 4 of 7
Rev Date: 12 Feb 2004

Operating Instructions and Parts List, Form No. 1000031, Back sheet 4 of 7
PARTS LIST
1
2
34
5
6
1
2
3
Insert Spacer before
pressing in Bushings.
Press Bushings in flush with
inside surface using arbor press.
Slot in pin must be facing front
(9 o'clock in this view)
13-8348 1 Head, Lever
23-4838 4 Bushing
311566 1 Pin, Spring
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
13-1091 1 Screw, Adjusting
25-1264 1 Screw, Set
33-1232 1 Body, Valve
43-1234 1 Spring, Compression
53-0654 1 Plunger, Valve
63-1233 1 Washer, Seal
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
HIGH PRESSURE RELIEF VALVE 3-2716
LEVER HEAD SUB-ASSEMBLY 3-8352

Operating Instructions and Parts List Form No. 1000031
PARTS LIST
Sheet No. 5 of 7
Rev Date: 12 Feb 2004
12345
SECTION VIEW
15-0425 1 Screw, Set
23000086 1 Handle/Adapter Sub-Assembly
35-2377 .1 oz Cement
43-5056 1 Grip, Handle
54-0413 1 Plug, Felt
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
RESERVOIR HANDLE ASSEMBLY 3000087
1
2
3
4567
8
9
13-8352 1 Head Sub-Assembly, Lever
210138 1 Screw, Set
33-8349 1 Shaft, Release
45-2538 .1 oz. Adhesive
52000148 1 Handle
65-2377 .1 oz. Cement
73-5056 1 Grip, Handle
83-8351 1 Spring, Torsion
93-8350 1 Pin, Striker
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
LEVER ASSEMBLY 3000088

Operating Instructions and Parts List, Form No. 1000031, Back sheet 5 of 7
PARTS LIST
13-5134 1 Bracket, Fulcrum
210008 2 Screw, SHC
33-9676 1 Block, Pump
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
AA
C
CD
D
BB
1
2
3
SECTION A-A SECTION B-B
1
2
3
4
5
6
7
8
910
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
15
14
28
(Torque to
35 ft. lbs.)
13-2716 1 Valve, H.P. Relief
23-7629 1 Filter, Intake
310374 1 Ball
43-5129 1 Spring, Compression
55-0873 1 Screw, Hollow
610378 1 Ball
75-2551 1 Screw, Set
810266 1 O-Ring
910375 1 Ball
10 4-0495 1 Insert, H.P. Discharge
11 5-2923 1 Spring, Compression
12 5-3674 1 Spring, Compression
13 12184 1 Ring, Back-Up
14 5-0341 2 Screw, Set
15 10419 2 Ball
16 12223 1 Ball
17 5-0343 1 Screw, Set
18 5-0659 1 Screw, Set
19 5-1992 1 Spring, Compression
20 12223 1 Ball
21 5-3399 1 Screw, Set
22 10374 1 Ball
23 5-0121 1 Pin, Spring
24 5-3261 1 O-Ring
25 3-7474 1 Plunger, L.P.
26 10375 1 Ball
27 5-0649 1 Screw, Set
28 5-3855 1 Plug, Seal
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
PUMP BLOCK ASSEMBLY 4-0640
PUMP BLOCK ASSEMBLY 4-0640

Operating Instructions and Parts List Form No. 1000031
PARTS LIST
Sheet No. 6 of 7
Rev Date: 12 Feb 2004
SECTION D-D
SECTION C-C
SECTION E-E
EE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
14-0642 1 Injector Assembly
25-0049 1 Ring, Back-Up
35-3341 1 Quad-Ring
44-0641 1 Housing, H.P.
512098 2 O-Ring
65-0341 1 Screw, Set
710419 1 Ball
810374 1 Ball
93-5129 1 Spring, Compression
10 3-5011 1 Plunger, Release
11 3-5010 1 Screw
12 12098 2 O-Ring
13 10264 1 O-Ring
14 3-5009 1 Insert
15 10423 1 Ball
16 5-3000 1 Spring, Compression
17 12223 1 Ball
18 5-3260 1 Spring, Compression
19 5-2062 1 Screw, Set
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
PUMP BLOCK ASSEMBLY 4-0640

Operating Instructions and Parts List, Form No. 1000031, Back sheet 6 of 7
PARTS LIST
1
2
3
AA
4
5
6
7
8
910
11
12
SECTION A-A
13 14
15
15-3913 1 Washer
2252248 1 Screw, Shoulder
33-1199 1 Pin, Fulcrum
4251925 2 Ring, Retaining
510228 1 Washer
65-2716 1 Nut, Lock
73000088 1 Handle Assembly
83-4917 1 Lifter, Injector
94-0640 1 Block Assembly, Pump
10 5-2820 1 O-Ring
11 4-0635 1 Bladder
12 3000087 1 Lever Assembly
13 10267 1 O-Ring
14 4-0425 1 Plug, Bladder
15 4-0413 1 Plug, Felt Reservoir
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
PUMP MECHANISM SUB ASSEMBLY 3000089

Operating Instructions and Parts List Form No. 1000031
PARTS LIST
Sheet No. 7 of 7
Rev Date: 12 Feb 2004
A
A
SECTION A-A
1
2
3
4
5
6
1251069 1 Ring, Retaining
23-8123 1 Injector, L.P.
35-2380 1 O-Ring
45-2726 1 Ring, Back-Up
510266 1 O-Ring
64-0643 1 Injector, H.P.
Item Part No. Item Part No.
No. No. Req’d Description No. No. Req’d Description
INJECTOR SUB - ASSEMBLY 4-0642
