SPX Waukesha Cherry-Burrell Universal Lobe... User manual

Read and understand this manual prior to
operating or servicing this product.
Instruction Manual
Universal Lobe Series
Rotary Positive Displacement Pump
Indianapolis Ɣ Chicago Ɣ San Juan
www.hollandapt.com
800-800-8464
[email protected]

611 Sugar Creek Road
Delavan, WI 53115 USA
Tel: [phone] or [phone]
Fax: [phone] or [phone]
E-mail: [email protected]
Web site: www.spxpe.com
Information contained in this manual is subject to change
without notice and does not represent a commitment on the
part Information contained in this manual is subject to
change without notice and does not represent a commit-
ment on the part of SPX Corporation. No part of this man-
ual may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying
and recording, for any purpose, without the express written
permission of SPX Corporation.
Copyright © 2009 SPX Corporation. All Rights Reserved.
Gore-Tex is a registered trademark of
W.L. Gore & Associates, Inc.
Kalrez is a registered trademark of DuPont Dow Elastomers.
Chemraz is a registered trademark of Green, Tweed & Co.
Issued Date: November 2009
Publication: 95-03092

November 2009 95-03092 Page 3
Waukesha Cherry-Burrell Table of Contents
Waukesha Cherry-Burrell Warranty .......................................................................5
Shipping Damage or Loss ....................................................................................................... 5
Warranty Claim ........................................................................................................................5
Safety ........................................................................................................................6
Replacement Labels ................................................................................................7
Application Instructions ............................................................................................................ 7
Care of Stainless Steel ............................................................................................8
Stainless Steel Corrosion ........................................................................................................ 8
Alloy 88 .................................................................................................................................... 8
Elastomer Seal Replacement Following Passivation ............................................................... 8
Introduction ..............................................................................................................9
Pump Receiving ...................................................................................................................... 9
Pump Characteristics .............................................................................................................. 9
Equipment Serial Number ....................................................................................................... 9
Pump Shaft Location ............................................................................................................... 9
Installation ..............................................................................................................10
Install Pump and Drive Unit ................................................................................................... 10
Install Connections and Piping .............................................................................................. 11
Install Check Valves .............................................................................................................. 12
Install Isolation Valves ........................................................................................................... 12
Install Relief Valves ............................................................................................................... 12
Inlet Side Strainers and Traps ............................................................................................... 13
Install Pressure Gauges ........................................................................................................ 13
Seal Flush Connections .........................................................................................................13
CIP (Clean-In-Place) Features .............................................................................................. 14
Check Coupling Alignment .................................................................................................... 15
Check Angular Alignment ...................................................................................................... 15
Check Parallel Alignment...................................................................................................... 15
Check Belt and Chain Drive Alignment .................................................................................. 16
Check Pump Rotation ............................................................................................................16
Operation ................................................................................................................17
Pre-Startup Checklist ............................................................................................................. 17
Startup Procedure ................................................................................................................. 17
Shutdown Procedure .............................................................................................................17
Emergency Shutdown Procedure .......................................................................................... 17
Maintenance ...........................................................................................................18
Important Safety Information ................................................................................................. 18
Lubrication ............................................................................................................................. 18
Maintenance Inspections ....................................................................................................... 19
Maintenance Inspection Chart ............................................................................................... 21
Annual Maintenance .............................................................................................................. 22
Cleaning ................................................................................................................................ 22
Fluid Head Disassembly ........................................................................................................ 23
Gear Case Disassembly ........................................................................................................ 25
Shaft Assembly ...................................................................................................................... 28
Gear Case Assembly .............................................................................................................30
Fluid Head Assembly ............................................................................................................. 41
Reference Tables .................................................................................................................. 44
Standard WCB O-Ring Selections, Descriptions and Color Codes ....................................... 45
Parts Lists ...............................................................................................................46
018-UL PD Pumps ................................................................................................................. 46
030-UL, 034-UL, 050-UL, 054-UL PD Pumps ....................................................................... 50
060-UL, 130-UL, 134-UL PD Pumps ..................................................................................... 56
220-UL PD Pumps ................................................................................................................. 62
320-UL PD Pumps ................................................................................................................. 66

Page 4 95-03092 November 2009
Table of Contents Waukesha Cherry-Burrell
320-UL PD Pumps .................................................................................................................69
Universal UL PD Pump Seals ................................................................................................70
Vented Cover Parts - Model 018, 030, 034, 050, 054, 060, 130, 134 UL ..............................71
Vented Cover Parts - Model 220 UL ......................................................................................72
UL Pump Dimensions ........................................................................................... 73
Universal UL Pump Dimensions and Model Weights ............................................................. 73
Rectangular Flange Universal UL Pump Dimensions and Model Weights ............................74
Troubleshooting .................................................................................................... 75

Waukesha Cherry-Burrell Warranty
November 2009 95-03092 Page 5
Waukesha Cherry-Burrell Warranty
Seller warrants its products to be free from defect in materials and workmanship for a period of one (1) year
from the date of shipment. This warranty shall not apply to products which require repair or replacement due to
normal wear and tear or to products which are subjected to accident, misuse or improper maintenance. This
warranty extends only to the original Buyer. Products manufactured by others but furnished by Seller are
exempted from this warranty and are limited to the original manufacturer’s warranty.
Seller’s sole obligation under this warranty shall be to repair or replace any products that Seller determines, in
its discretion, to be defective. Seller reserves the right either to inspect the products in the field or to request
their prepaid return to Seller. Seller shall not be responsible for any transportation charges, duty, taxes, freight,
labor or other costs. The cost of removing and/or installing products which have been repaired or replaced
shall be at Buyer’s expense.
Seller expressly disclaims all other warranties, express or implied, including without limitation any warranty of
merchantability of fitness for a particular purpose. The foregoing sets forth Seller’s entire and exclusive liability,
and Buyer’s exclusive and sole remedy, for any claim of damages in connection with the sale of products. In no
event shall Seller be liable for any special consequential incidental or indirect damages (including without
limitation attorney’s fees and expenses), nor shall Seller be liable for any loss of profit or material arising out of
or relating to the sale or operation of the products based on contract, tort (including negligence), strict liability
or otherwise.
Shipping Damage or Loss
If equipment is damaged or lost in transit, file a claim at once with the delivering carrier. The carrier has signed
the Bill of Lading acknowledging that the shipment has been received from WCB in good condition. WCB is not
responsible for the collection of claims or replacement of materials due to transit shortages or damages.
Warranty Claim
Warranty claims must have a Returned Goods Authorization (RGA) from the Seller before returns will be
accepted.
Claims for shortages or other errors, exclusive of transitshortages or damages, must be made in writing to
Seller within ten (10) days after delivery. Failure to give such notice shall constitute acceptance and waiver of
all such claims by Buyer.

Safety Waukesha Cherry-Burrell
Page 6 95-03092 November 2009
Safety
READ AND UNDERSTAND THIS MANUAL PRIOR TO INSTALLING, OPERATING OR
SERVICING THIS EQUIPMENT
Waukesha Cherry-Burrell recommends users of our equipment and designs follow the latest Industrial Safety
Standards. At a minimum, these should include the industrial safety requirements established by:
1. Occupational Safety and Health Administration (OSHA), Title 29 of the CFR
Section 1910.212- General Requirements for all Machines
2. National Fire Protection Association, ANSI/NFPA 79
ANSI/NFPA 79- Electrical Standards for Industrial Machinery
3. National Electrical Code, ANSI/NFPA 70
ANSI/NFPA 70- National Electrical Code
ANSI/NFPA 70E- Electrical Safety Requirement for Employee Workplaces
4. American National Standards Institute, Section B11
Attention: Servicing energized industrial equipment can be hazardous. Severe injury or death can result from
electrical shock, burn, or unintended actuation of controlled equipment. Recommended practice is to
disconnect and lockout industrial equipment from power sources, and release stored energy, if present. Refer
to the National Fire Protection Association Standard No. NFPA70E, Part II and (as applicable) OSHA rules for
Control of Hazardous Energy Sources (Lockout-Tagout) and OSHA Electrical Safety Related Work Practices,
including procedural requirements for:
• Lockout-tagout
• Personnel qualifications and training requirements
• When it is not feasible to de-energize and lockout-tagout electrical circuits and equipment before working
on or near exposed circuit parts
Locking and Interlocking Devices: Thesedevices should be checked for proper working condition and
capability of performing their intended functions. Make replacements only with the original manufacturer’s
renewal parts or kits. Adjust or repair in accordance with the manufacturer’s instructions.
Periodic Inspection: Industrial equipment should be inspected periodically. Inspection intervals should be
based on environmental and operating conditions and adjusted as indicated by experience. At a minimum, an
initial inspection within 3 to 4 months after installation is recommended. Inspection of the electrical control
systems should meet the recommendations as specified in the National Electrical Manufacturers Association
(NEMA) Standard No. ICS 1.3, Preventative Maintenance of Industrial Control and Systems Equipment, for the
general guidelines for setting-up a periodic maintenance program.
Replacement Equipment: Use only replacement parts and devices recommended by the manufacturer to
maintain the integrity of the equipment. Make sure the parts are properly matched to the equipment series,
model, serial number, and revision level of the equipment.
Warnings and cautions are provided in this manual to help avoid serious injury and/or possible damage to
equipment.
DANGER: marked with a stop sign.
Immediate hazards which WILL result in severe personal injury or death.
WARNING: marked with a warning triangle.
Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION: marked with a warning triangle.
Hazards or unsafe practices which COULD result in minor personal injury or product or property
damage.

Waukesha Cherry-Burrell Replacement Labels
November 2009 95-03092 Page 7
Replacement Labels
WARNING: The following labels are installed on your equipment. If these labels are removed or become
unreadable contact Waukesha Cherry-Burrell customer service at 1-800-252-5200 or 262-728-1900, or
refer to “Parts Lists” on page 46 for replacement part numbers.
Application Instructions
Apply to clean, dry surface. Remove backing from label, place in proper position, protect with cover sheet and
burnish. (A soft rubber roller also may be used to press label into place.) Apply all labels to be readable from
front of pump.

Care of Stainless Steel Waukesha Cherry-Burrell
Page 8 95-03092 November 2009
Care of Stainless Steel
Stainless Steel Corrosion
Corrosion resistance is greatest when a layer of oxide film is formed on the surface of stainless steel. If film is
disturbed or destroyed, stainless steel becomes much less resistant to corrosion and may rust, pit or crack.
Corrosion pitting, rusting and stress cracks may occur due to chemical attack. Use only cleaning chemicals
specified by a reputable chemical manufacturer for use with 300 series stainless steel. Do not use excessive
concentrations, temperatures or exposure times. Avoid contact with highly corrosive acids such as
hydrofluoric, hydrochloric or sulfuric. Also avoid prolonged contact with chloride-containing chemicals,
especially in presence of acid. If chlorine-based sanitizers are used, such as sodium hypochlorite (bleach), do
not exceed concentrations of 150 ppm available chlorine, do not exceed contact time of 20 minutes, and do not
exceed temperatures of 104°F (40°C).
Corrosion discoloration, deposits or pitting may occur under product deposits or under gaskets. Keep surfaces
clean, including those under gaskets or in grooves or tight corners. Clean immediately after use. Do not allow
equipment to set idle, exposed to air with accumulated foreign material on the surface.
Corrosion pitting may occur when stray electricalcurrents come in contact with moist stainless steel. Ensure all
electrical devices connected to the equipment are correctly grounded.
Alloy 88
Waukesha Alloy 88 is the standard rotor material for Universal I, Universal II, Universal Lobe, Universal 420/
520 and 5000 Series Rotary PD pumps. This alloy was developed specifically for corrosion resistance and
close operating clearance requirements of high performance rotary positive displacement pumps. Alloy 88 is a
nickel-based, corrosion-resistant, non-galling or seizing material. The ASTM designation is A494 Grade
CY5SnBiM (UNS N26055), and the material is listed in the 3-A Sanitary Standards as acceptable for product
contact surfaces.
The above properties make Alloy 88 the ideal material forWaukesha stainless steel PD pumps. The non-
galling rotors permit close operating clearances in the liquid end. This provides low slip and minimum shear
damage. The rotors will not gall or seize if they come in contact with the body or cover during operation.
The corrosion resistance of Alloy 88 is approximately equal to AISI 300 Series Stainless Steel. However, Alloy
88 has limited resistance to certain aggressive chemicals that may be commonly used in contact with AISI 300
Series Stainless Steel.
Do not use Alloy 88 in contact with nitric acid. Nitric acid is commonly used to passivate new installations of
stainless steel equipment. Do not allow nitric acid based passivation chemicals to contact Alloy 88 rotors.
Remove the rotors during passivation and use a separate pump to circulate the passivation chemicals. Also, if
nitric acid-based CIP cleaning chemicals are used, remove the rotors prior to CIP cleaning and clean them
separately by hand in a mild detergent.
If you have questions regarding other aggressive chemicals, please contact Waukesha Cherry-Burrell
Application Engineering for assistance.
Elastomer Seal Replacement Following Passivation
Passivation chemicals can damage product contact areas of WCB equipment. Elastomers (rubber
components) are most likely to be affected. Always inspect all elastomer seals after passivation is completed.
Replace any seals showing signs of chemical attack. Indications may include swelling, cracks, loss of elasticity
or any other noticeable changes when compared with new components.

Waukesha Cherry-Burrell Introduction
November 2009 95-03092 Page 9
Introduction
Pump Receiving
DANGER: The pump contains
internal moving parts. DO NOT
put hands or fingers into the pump
body ports or drive area at any
time during operation. To avoid
serious injury, DO NOT install,
clean, service, or repair the pump
unless all power is off and locked
out.
All ports are covered at the factory to keep out foreign objects
during transit. If covers are missing or damaged, remove the
pump cover and thoroughly inspect the fluid head. Be sure the
pumping head is clean and free of foreign material before rotating
the shaft.
Each Waukesha Cherry-Burrell pump is shipped completely
assembled,lubricated and ready for use. Review “Operation” on
page 17 before operating the pump.
Pump Characteristics Waukesha Cherry-Burrell Universal Lobe pumps are positive-
displacement, low-slip, stainless steel pumps designed with
larger diameter shafts for greater strength and stiffness, mounted
on a heavy-duty cast iron bearing frame (stainless steel option
available) with double-tapered roller bearings.
• Designed for continuous operation.
• Rotor hubs are sealed from the product zone; rotors are
locked with belleville-style washers and torqued nuts that can
rotate securely in either direction (bi-directional).
• Non-galling “88” alloy rotors are standard; 316 material rotors
are optional.
• Seal flush is standard. Seal areas are interconnected to
improve circulation and draining of the seal flush fluid.
• Single mechanical seals are standard. Bodies are pre-drilled
with flush ports if double seals are required.
• Free-draining pump body and cover when mounted on its
side.
• CIP capability is standard.
Equipment Serial Number All Waukesha Cherry-Burrell pumps are identified by a serial
number on the gear case nameplate, which is stamped on the
pump body and cover.
CAUTION: The gear case, body, and cover must be kept
together as a unit due to backface, rotor and cover
clearances. Failure to do so will damage the pump.
Pump Shaft Location There are two pump drive shaft locations.
Figure 1 - Upper and Lower Shaft Mount Figure 2 - Sidemount Left Hand and Right Hand
(as viewed from pump cover)

Installation Waukesha Cherry-Burrell
Page 10 95-03092 November 2009
Installation
Install the pump and piping system in accordance with local
codes and restrictions. Practices described in this manual are
recommended for optimum performance.
All system equipment, such as motors, sheaves, drive couplings,
speed reducers, etc., must be properly sized to ensure
satisfactory operation of your Waukesha Cherry-Burrell pump
within its limits.
CAUTION: These pumps are positive displacement, low-
slip design and will be severely damaged if operated with
closed valves in the discharge or inlet lines. The pump
warranty is not valid for damages caused by a hydraulic
overload from operation or start-up with a closed valve in
the system.
Install Pump and Drive
Unit
WARNING: Full guards must be installed to isolate
operators and maintenance personnel from the rotating
components. Guards are provided with Waukesha Cherry-
Burrell pumps as part of a complete pump and drive
package.
In a typical installation configuration, the pump and drive unit are
mounted on a common base plate. The unit can be installed in
any of the arrangements shown in Figure 3 through Figure 6 (the
shaded area indicates the guard location).
NOTE: When installing unit as shown in Figure 6, level the unit
before installing the bolts.
Figure 3 - Portable Base
Figure 4 - Adjustable Leg Base
Figure 5 - Leveling and/or Vibration
Isolation Pads
Figure 6 - Permanent Installation on
Foundation

Waukesha Cherry-Burrell Installation
November 2009 95-03092 Page 11
Install Connections and
Piping
Fittings
Waukesha Cherry-Burrell produces a wide variety of fittings
made to meet your needs. Contact Waukesha Cherry-Burrell
Customer Service at 1-800-252-5200 or 262-728-1900 for
information on fittings.
Piping Support
Support all piping to the pump independently with hangers or
pedestals to minimize the forces exerted on the pump. Such
forces can cause misalignment of pump parts and lead to
excessive wear of rotors, bearings and shafts.
Figure 7 shows typical supporting methods used to independently
support each pipe, reducing the weighteffect of piping and fluid
on the pump.
Expansion Joints
Thermal expansion of piping can cause tremendous forces. Use
thermal expansion joints to minimize these forces on the pump.
Flexible joints can be used to limit transmission of mechanical
vibration. Ensure that the free ends of any flexible connections in
the system are anchored.
Inlet Piping
Install the pump below the supply liquid level to reduce air in the
system by flooded suction (Figure 9).
If the pump is installed above the supply liquid level, the piping on
the inlet side must slope up toward the pump, preventing air
pockets in the pipes (Figure 10).
Figure 7 - Piping Support
Figure 8 - Flexible Connections and
Supports
Figure 9 - Pump Below Supply
Figure 10 - Correct Piping to Prevent Inlet
Air Pockets

Installation Waukesha Cherry-Burrell
Page 12 95-03092 November 2009
Install Check Valves Inlet Side on Lift Applications
Use check valves to keep the inletline full, particularly with low-
viscosity fluids (Figure 11).
Discharge Side
For systems with liquid under a vacuum, install a check valve on
the discharge side of the pump. A check valve prevents backflow
(air or fluid) to aid in initial start-up by minimizing the required
differential pressure supplied by the pump to start the flow (Figure
12).
Install Isolation Valves
Isolation valves permit pump maintenance and safe pump
removal without draining the system (Figure 13, item A).
Install Relief Valves Install relief valves to protect the pump and piping system against
excessive pressure. WCB recommends installing an external
relief valve, designed to bypass fluid from the pump outlet to the
inlet side of system (Figure 14, item A).
NOTE: Integral relief valves are available, but are not
recommended on applications with viscosities over 500 cps or
where the discharge must be closed for more than a few minutes.
Prolonged operation of the pump with closed discharge will cause
heating of fluid circulating through the relief valve. If this is the
case, install an external relief valve to discharge externally
through the piping connected to the fluid source, or into inlet
piping near the source.
A. Inlet Check Valve
B. Foot Check Valve
Figure 11 - Inlet/Foot Check Valve
A. Closed Tank - produces vacuum on
liquid (Low Absolute Pressure)
B. Check Valve (outlet)
Figure 12 - Discharge Check Valve
Figure 13 - Isolation Valves
Figure 14 - Relief Valves

Waukesha Cherry-Burrell Installation
November 2009 95-03092 Page 13
Inlet Side Strainers and
Traps
Inlet side strainers and traps (Figure 15, items A and B) can be
used to prevent foreign matter from damaging the pump. Make
the selection carefully to prevent cavitation caused by the
restriction of the inlet. If the inlet strainers are used, they must be
serviced regularly to prevent clogging and flow stoppage.
Install Pressure Gauges
Pressure and vacuum gauges provide valuable information about
pump operation (Figure 16). Wherever possible, install gauges to
help provide information on the following:
• Normal or abnormal pressures
• Indication of flow
• Changes in pump condition
• Changes in system conditions
• Changes in fluid viscosity
Seal Flush Connections Pumps with double seals require flushing. The flush media
(typically water) must be connected and flowing whenever pump
is operated.
WARNING: Operating the pump without flush will damage
the seal and pump parts due to excess heat from dry
running.
Pump bodies have two 1/8-inch female pipe thread flush
connections located near bottom and top of body.
1. Connect the flush inlet to the lower connection, and the outlet
to the upper connection, to flood the flush area completely.
2. Connect the flush outlet for unrestricted flow to the drain.
NOTE: If steam is usedas flush media, connect the inlet at the
upper connection and the outlet at the lower connection, to
ensure condensation removal.
3. Use cool, filtered flush media to obtain maximum service life
of the seal components. If the pumped product is sticky or
solidifies at room temperature, use warm or hot flush media.
4. Install a pressure reducing valve and flow control valve
(needle valve) on the flush supply line. Set the supply
pressure at a maximum of 30 psi (2 bar) and adjust the flow
rate to approximately 1/4 gpm (more for high-temperature
applications).
A. Strainer B. Magnetic Trap
Figure 15 - Inline Strainers and Traps
Figure 16 - Pressure and Vacuum Gauges
UL Model 320
UL Models 018,
030, 050, 060, 130,
220
High Pressure Flush Low Pressure Flush
Figure 17 - Flush Piping Setup
Flush Out
Flush In
Flush Out
Flush In
IN
OUT
Restrictor
Valve Pressure
Gauge
Solenoid
Valve
IN
OUT
Restrictor
Valve

Installation Waukesha Cherry-Burrell
Page 14 95-03092 November 2009
5. Also install a solenoid valve in the flush supply and wire it in
series with the motor starter to provide an automatic start/
stop of the flush media flow before the motor turns on and
after the motor turns off.
NOTE: If the pumped product contains abrasive solids or
hardens on the seal faces, an alternate high pressure barrier
flush arrangement may be used. A very small amount of flush
liquid enters the pumped liquid, therefore the flush media must be
compatible with the product. Contact WCB Application
Engineering for assistance.
CIP (Clean-In-Place)
Features
WCB UL pumps are designed to provide CIP solutions complete
access to all product contact surfaces. The flat body profile
allows complete draining of the side-mounted pump, and
provides the CIP solution access to the entire cover o-ring
groove.
Use the following guidelines when designing and installing the
CIP system to ensure successful cleaning:
• Ensure that the velocity rate of CIP solutions is adequate to
clean the entire circuit. For most applications, a velocity of 5
ft/sec is sufficient. For the CIP solution to achieve the proper
velocity, the pump drive must have enough speed range and
horsepower. The required inlet pressure also must be
satisfied. If the pump does not supply enough CIP solution
velocity, a separate CIP supply pump with an installed
bypass may be used. To determine the appropriate bypass
arrangement, contact WCB Application Engineering.
• Ensure that a differential pressure is created across the
pump. Differential pressure will push CIP solutions through
close-clearance areas of the pump, resulting in better
cleaning action. The high pressure side may be either the
inlet or outlet side. 30 psi (2 bar) differential pressure is
adequate for most applications.
• The pump must be operated during CIP to increase
turbulence and cleaning action within the pump. If complete
draining is required, the pump must be in the side mount
position.

Waukesha Cherry-Burrell Installation
November 2009 95-03092 Page 15
Check Coupling Alignment
Pumps and drives ordered from the factory and mounted on a
common base plate are aligned before shipment. Alignment
must be re-checked after the complete unit has been installed
and piping completed. Periodic re-checking is advisable during
the pump service life.
• WCB recommends using a flexible coupling to connect the
drive to the pump. Several different types are available,
including couplings with slip or overload provisions.
Waukesha Cherry-Burrell provides Lovejoy (Figure 18) or
T.B. Woods®(Figure 19) couplings unless otherwise
specified when ordering. Flexible couplings can be used to
compensate for end play and small differences in alignment.
• Align the pump and drive shaft as closely as possible:
Pump and Drive are factory aligned.
Re-check alignment after installation and before start-up.
Re-check alignment periodically, to maximize service life.
Check Angular Alignment
1. Using feeler gauges or taper gauges (Figure 20, items A and
B), check the alignment at four points every 90 degrees
around the coupling; adjust to equal dimension at all
points.
2. Set the space between the coupling halves to the
manufacturer’s recommended distance.
3. Install shims to bring the system into alignment.
Check Parallel Alignment
1. Check both the horizontal and vertical alignment of the pump
and drive using a straight edge.
2. Using a feeler gauge at location “A” in Figure 21, determine
the direction and amount of movement needed (Figure 21,
item B).
3. If necessary, shim at location "C" and/or move the drive as
needed.
Figure 18 - Lovejoy Coupling
Figure 19 - T.B. Woods®Coupling
Figure 20 - Check Angular Alignment
Figure 21 - Check Parallel Alignment

Installation Waukesha Cherry-Burrell
Page 16 95-03092 November 2009
Check Belt and Chain
Drive Alignment
Use a straight edge to visually check the belt or chain alignment.
Keep the shaft distance to a minimum (Figure 22, item A).
After the piping is complete and before the belts are installed,
manually turn the pump shaft to ensure that it turns freely.
Check Pump Rotation Check the direction of the drive rotation to determine the rotation
direction of the pump (Figure 23). After the correct drive rotation
is verified, connect the coupling and assemble the pump and
coupling guards.
NOTE: The pump covers in the following figures have been
removed to view rotor rotation. Never operate the pump with the
covers removed.
Figure 23 - Upper Shaft Drive Flow, Lower Shaft Drive Flow and Vertical Porting Flow
and Pump Rotation (Liquid End Shown)
Figure 22 - Aligning Belt and Chain Drives

Waukesha Cherry-Burrell Operation
November 2009 95-03092 Page 17
Operation DANGER: The pump contains internal moving parts. DO
NOT put hands or fingers into the pump body ports or drive
area at any time during operation. To avoid serious injury,
DO NOT install, clean, service, or repair the pump unless
all power is off and locked out.
CAUTION: These pumps are positive displacement, low-
slip design and will be severely damaged if operated with
closed valves in discharge or inlet lines. The pump
warranty is not valid for damages caused by a hydraulic
overload from operation or start-up with a closed valve in
the system.
Pre-Startup Checklist 1. Ensure that the pump is correctly installed as described in
“Installation” on page 10. Review “Install Relief Valves” on
page 12 and install relief valves as needed.
2. Check the coupling alignment. See “Check Coupling Align-
ment” on page 15.
3. Ensure that the pump and piping are clean and free of foreign
material such as welding slag, gaskets, etc.
CAUTION: Do not use this pump
to flush a newly-installed system.
Severe damage may occur to the
pump and system if the pump is
used to flush the system.
Remove the rotors during
system flushing.
4. Ensure that all piping connections are tight and leak-free.
Where possible, check the system with non-hazardous fluid.
5. Ensure that the pump and drive are lubricated. See “Lubrica-
tion” on page 18.
6. Ensure that all guards are in place and secure.
WARNING: Full guards must be
installed to isolate operators and
maintenance personnel from
rotating components. Guards are
provided with Waukesha Cherry-
Burrell pumps as part of a
complete pump and drive
package.
7. Double mechanical seals require adequate supply and flow of
clean flushing fluids.
8. Ensure that all valves are open on the discharge side and a
free flow path is open to the destination.
9. Ensure that all valves are open on the inlet side and fluid can
fill the pump. A flooded suction installation is recommended.
WARNING: Do not start a pump
with seal flush unless the seal
flush is installed and on.
10. Check the direction of pump and drive rotation to ensure that
the pump will rotate in the proper direction. See “Check Pump
Rotation” on page 16.
Startup Procedure 1. Start the pump drive. Where possible, start at a slow speed
or jog.
2. Ensure that the liquid is reaching the pump within 60 sec-
onds. If pumping does not begin and stabilize, check“Trou-
bleshooting” on page 75.
Shutdown Procedure 1. Shut off power to the pump drive.
2. Shut off supply and discharge lines.
Emergency Shutdown
Procedure
Emergency Shutdown Procedures should be documented by
plant personnel after assessing system-wide requirements.

Maintenance Waukesha Cherry-Burrell
Page 18 95-03092 November 2009
Maintenance
Important Safety
Information
DANGER: The pump contains internal moving parts. DO
NOT put hands or fingers into the pump body ports or drive
area at any time during operation. To avoid serious injury,
DO NOT install, clean, service or repair the pump unless all
power is off and locked out.
Before detaching port connections to the pump:
• Close the suction and discharge valves.
• Drain the pump and clean or rinse, if necessary.
• Disconnect or shut off the electrical supply andlock out all
power.
Lubrication Drive Lubrication
Refer to the manufacturer’s manual shipped with the drive for
proper drive lubrication and frequency.
Gears
Gears are factory-lubricated with gear oil at the quantity shown in
Table 2. Change the oil every 500 hours.
Gear Oil Specification
ISO Grade 320, SAE 140 or AGMA Number 6EP.
Bearings
Bearings are factory-lubricated with grease. Re-grease them at
the quantity shown in Table 2. Grease the bearings every 250
hours.
Excess grease will accumulate in the gear case and must be
removed through the cleanout hole covered with a plastic plug
(Figure 24, item 48).
Bearing Lubricant Grease
NLGI Grade No. 2, EP, Lithium-based lubricant is standard.
Table 2: Lubrication Quantities
Model Oil Capacity (Gears) Grease Quantity
(per Bearing)
Top or Bottom Side Mount Front Back
018UL 1.3 oz (40 ml) 3.3 oz (100 ml) 0.37 oz (11 cc) 0.13 oz (4 cc)
030UL, 050UL 2.0 oz (60 ml) 4 oz (120 ml) 0.60 oz (18 cc) 0.21 oz (6 cc)
060UL, 130UL 6.0 oz (170 ml) 9.5 oz (280 ml) 0.84 oz (25 cc) 0.76 oz (22 cc)
220UL, 224UL 11 oz (320 ml) 20 oz (600 ml) 1.33 oz (39 cc) 1.03 oz (30 cc)
320UL 17 oz (500 ml) 44 oz (1300 ml) 1.96 oz (58 cc) 1.16 oz (34 cc)
Figure 24 - Lubrication Points
PD100-042a
24F 67
24D
24F
48
24D 24L
AB
Table 1: Callout table for Figure 24
A. Upper Shaft Drive Pump (Standard)
B. Lower Shaft Drive Pump (Optional)
24D. Oil Drain Plug
24F. Oil Fill Plug
24L. Oil Level Check Plug, Sightglass
48. Grease Clean-out Plug
67. Grease Fittings

Waukesha Cherry-Burrell Maintenance
November 2009 95-03092 Page 19
Maintenance Inspections DANGER: The pump contains internal moving parts. DO
NOT put hands or fingers into the pump body ports or drive
area at any time during operation. To avoid serious injury,
DO NOT install, clean, service or repair the pump unless all
power is off and locked out.
Detecting wear in the early stages can reduce repair costs and
down time. A simple “look-feel” inspection of the pump during
breakdown cleaning is recommended to detect signs of trouble at
an early stage.
A detailed maintenance inspection should be scheduled annually.
See “Annual Maintenance” on page 22.
Refer to the “Maintenance Inspection Chart” on page 21 for
possible causes and solutions to common issues discovered
during inspection.
Inspection of Rotor Tips
Remove the cover (see “Remove Cover” on page 23) and check
for metal-to-metal contact between the rotor wings. When contact
is detected, repair or replace the pump.
Visually inspect the rotors for rotor-to-rotor contact and rotor-to-
body contact. Manually rotate the pump drive shaft and ensure
that the rotor-to-rotor clearance is equal on both sides as
indicated in Figure 25. If contact occurs, see “Checking for Proper
Clearance” on page 39 for proper clearances.
Inspection of Rotor and Shaft Spline
Visually inspect the rotor and shaft spline (Figure 26) for
excessive wear; replace as necessary.
Inspection of Shaft
Visually inspect the shaft for twists or bends; replace it as
necessary.
Inspection of Rotor Hub End
Visually inspect the rotor hub end (Figure 26, item A) for
excessive wear; replace it as necessary. Each time rotors are
removed, replace the o-rings on the hub.
Figure 25 - Rotor-to-Rotor Tip Clearance
30° 30°
PD100-511
Figure 26 - Rotor
PD100-510
A

Maintenance Waukesha Cherry-Burrell
Page 20 95-03092 November 2009
Inspection of Shaft Shoulder
Visually inspect the shaft shoulder (Figure 27, item A) for
excessive wear; replace it as necessary. If the shaft shoulder has
a sharp edge, remove the edge with a file to prevent cutting the
shaft o-ring on installation.
NOTE: Rotor hub and shaft shoulder wear are caused by
operating with a loose rotor nut(s) for extended periods.
Inspection of Gears and Bearings
Gear backlash
With the fluid head and seals removed, feel for gear backlash by
rotating either shaft by hand. The other shaft must engage
immediately. Perform this check three times at 60-degree
intervals. If play (backlash) is evident, remove the gear case
cover, check the gear teeth for wear, and ensure that the gear is
not loose on the shaft. If the gear teeth are worn, replace the
gears. If the gear is loose on the shaft, inspect the shaft key and
keyway; replace as necessary.
Check bearing condition
With the fluid head and seals removed, check the bearing
condition by applying (by hand) an up or down force of
approximately 30 lbs (14 kg). If movement of either shaft can be
detected, the bearing may be failing. Also check the shaft
movement forward or backward. If the bearing is failing, replace
the bearing and review the lubrication section on page 18.
Figure 27 - Shaft Shoulder
PD100-519
A
Figure 28 - Backlash Check
PD100-512
Figure 29 - Bearing Deflection Check
PD100-513
30 lb
14 kg
30 lb
14 kg
