SPX F2P10-19 12/24 V DC User manual

INSTRUCTION MANUAL
ORIGINAL INSTRUCTIONS/TRANSLATION OF ORIGINAL INSTRUCTIONS
READ AND UNDERSTAND THIS MANUAL PRIOR TO OPERATING OR SERVICING THIS
PRODUCT
Flexible Impeller Pumps
F2P10-19 12/24 V DC, F3B-19 12/24 V DC, F3B-19 Oil Change 12/24 V DC,
F38B-19 12/24 V DC, F4B-19 12/24 V DC
IB-414 R04 (05/2012)

Self-priming, flexible impeller pump flange mounted to DC motorn 12/24 V
Typical applications
Bilge pump, fresh water pump, deck washing, fuel oil transfer, fire pump, etc. F3B-19 Oil Change: Pump
for permanent installation near the boat engine. To be used for the draining/filling of engine oil. Flow
direction is easily changed with the integrated reversing switch.
Technical description
F2P10 F3B/F3B Oil Change F38B F4B
Body:
PTMT, Termoplastic polyester •
Brass • • •
Wearplates:
AISI 316, stainless steel •
Impeller:
NBR (nitrile) rubber • • • •
Seal:
Lipseal, NBR (nitrile) rubber • • • •
O-ring:
NBR (nitrile) rubber • • • •
Connections:
½” hose or ¾” NH •
R3/8” or 3/8 NPT •
R1/2” or ½” NPT or 1” hose (Ø25 mm) • •
Liquid temperature: Max +80°C. See page 12, ”Temperature”.
Motor: 0,12 kW Total enclosed Reversible
12/24 V with built in thermal protection
Shaft: AISI 316, stainless steel
Bearing: Ball bearing
The motor is ignition protected according to ISO 8846 (Small craft – Electrical devices - Protection
against ignition of surrounding flammable gases).
Type designation
Type Part No Type Part No
F2P10-19 ½” hose 12 V 10-24180-1 F3B-1907 Oil Change12 V 10-24760-03
F2P10-19 ½” hose 24 V 10-24180-2 F3B-1907 Oil Change24 V 10-24760-04
F2P10-19 ¾” NH 12 V 10-24180-3 F38B-19 12 V 10-24727-01
F2P10-19 ¾” NH 24 V 10-24180-4 F38B-19 24 V 10-24727-02
F3B-19 12 V 10-24516-01 F38B-1907 12 V 10-24727-03
F3B-19 24 V 10-24516-02 F38B-1907 24 V 10-24727-04
F3B-1907 12 V 10-24516-03 F4B-19 12 V 10-24689-01
F3B-1907 24 V 10-24516-04 F4B-19 24 V 10-24689-02
F3B-19 Oil Change12 V 10-24760-01 F4B-1907 12 V 10-24689-03
F3B-19 Oil Change24 V 10-24760-02 F4B-1907 24 V 10-24689-04

Pressure and capacity data
(based on water at 20°C and at full voltage of the motor, 12.0 / 24.0 V unless specified otherwise)
F2P10-19
Amp draw
Bar kPa l/min USGPM 12V 24V
Continous duty
0 0 15,0 4,0 5,6 A 4,0 A
0,1 10 14,5 3,8 5,7 A 4,0 A
0,2 20 14 3,7 5,8 A 4,1 A
0,3 30 13,5 3,6 5,9 A 4,1 A
0,6 60 11,0 2,9 6,1 A 4,2 A
Intermittent duty
0,75 75 9,6 1,1 6,5 A 4,3 A
0,9 90 7, 0 1,8 6,5 A 4,8 A
Fuse required 10 A 8 A
F3B-19/F3B-19 Oil Change
Amp draw
Bar kPa l/min USGPM 12V 24V
Continous duty
0 0 21 5,5 8,4 A 4,0 A
0,1 10 20,5 5,4 8,5 A 4,0 A
0,2 20 20 5,3 8,6 A 4,1 A
0,3 30 19,5 8,2 8,8 A 4,1 A
0,6 60 1 7, 8 5,2 9,0 A 4,2 A
Intermittent duty
0,9 90 15,6 4,1 9,6 A 4,3 A
1,2 120 12 3,2 10,3 A 4,8 A
Oil 10W 40 (20° C)
0 0 15,7 4,14 16,1 A 7,68 A
Warm oil increases the flow and decreases the power
consumption
Fuse required Water 15 A 8 A
Oil 20 A 10 A
Installation and maintenance
Installation
General: Pump may be mounted in any position without loss of efficiency; however, it is suggested that
the pump head be down if vertical mounting is desired. Mount motor as close as possible to power
source to obtain full voltage.
The pump should be installed so that the motor is protected from rain or wash down.
When using a vac-on-switch, mount it on the connection on the inlet side of the pump. When using a
pressure switch, mount it on the outlet side of the pump.
F3B-19 Oil Change: Locate the pump near the engine so the length of the hose to the engine can be
kept as short as possible. To achieve best operation the pump should be installed at the same level as
the maximum level of oil in the engine. Mount the provided 3/8” gate valve between the engine and the
pump as a safeguard against accidental oil discharge during operation or draining. Use a reinforced oil
hose that can withstand 120°C for connection between the pump and oil receptacle. Note! The hose
between the motor and pump must use permanent connections.
Operation: F3B19-Oil Change: Before changing the oil, run the engine and let the temperature rise to
50°C to reduce the viscosity. This makes it easier to handle the oil. Turn off the engine. Open the gate
valve between the motor and pump. Make sure the discharge hose is securely positioned in a waste oil
receptacle. Note that the discharge hose may tend to move slightly during operation. Move the switch
F38B-19
Amp draw
Bar kPa l/min USGPM 12V 24V
Continous duty
0 0 35 9,2 10,9 A 5,0 A
0,1 10 33,8 8,9 11,0 A 5,1 A
0,2 20 32,2 8,5 11,0 A 5,1 A
0,3 30 31 8,2 11,1 A 5,2 A
0,6 60 25,5 6,7 11,9 A 5,4 A
Intermittent duty
0,9 90 15,3 4,0 13,6 A 6,0 A
1,2 120 2 0,5 15,8 A 7,1 A
Fuse required 20 A 10 A
F4B-19
Amp draw
Bar kPa l/min USGPM 12V 24V
Continous duty
0 0 48 12,7 12,2 A 6,5 A
0,1 10 45 11,9 12,3 A 6,7 A
0,2 20 44,5 11,7 12,2 A 6,8 A
0,3 30 41 10,8 13,1 A 7,1 A
0,6 60 34 9,0 14,9 A 7,5 A
Intermittent duty
0,9 90 25 6,6 16,5 A 7,8 A
1,2 120 11 2,9 18,3 A 8,8 A
Fuse required 25 A 15 A

in the flow direction to the receptacle. When the oil is drained (check with the dipstick of the engine)
switch off the pump immediately by moving the integrated switch to its centre position. Change the oil
receptacle to the container with new oil. Start the pump by pressing the switch in the flow direction to
the motor. Use the dipstick of the engine to make sure the right amount of oil has been filled into the
engine. Note! As soon as all oil has been drained from the engine, or when the container for refilling oil
into the engine is empty, the pump must be stopped immediately. Otherwise there is a risk of dry running
which will damage the impeller.
Wiring dimensions
(based on 3% voltage drop)
Wire size Max wire length in m*
F2P10-19 F3B-19
F3B-10 Oil Change
F38B-19 F4B-19
12V 24V 12V 24V 12V 24V 12V 24V
1,5 mm23,7 m 14,6 m 3,7 m 14,6 m
2,5 mm26,1 m 24,4 m 6,1 m 24,4 m 2,7 m 11,0 m 2,7 m 11,0 m
4 mm29,8 m 9,8 m 4,4 m 17,6 m 4,4 m 17,6 m
6 mm214,6 m 14,6 m 6,6 m 26,3 m 6,6 m 26,3 m
10 mm224,4 m 24,4 m 17,6 m 17,6 m
25 mm227,4 m 27,4 m
* The wire length is the total distance from the battery to the pump and back to the battery. It is
recommended to use a relay to shorten the main leaders.
Wiring table
All DC pumps F3B-19 Oil Change
Electrical installation
The pump must be installed according to ISO 10133 (Small craft - Electrical system - Extra low voltage
DC installation for continuous current). Note: The fuse must be ignition protected.
The motor is equipped with built in thermal protection to prevent the motor from overheating. The
protection is automatically restored when the motor is cooled. If the pump is connected with separate
earth lead, this should be yellow/green and connected to the motor base. See the wiring table above for
correct installation. Negative wire must be black.
Choose wire size in accordance with total wire length (see table above). The wire connections must
be sealed with a marine sealant or sealed cable connectors.Other electrical devices, eg switch, circuit
breaker, must be installed between the pump and the positive (+) lead on the battery (on the red wire).
Note: Before installation with electrical control systems, check that equipment to be used is of sufficient
rated capacity to accept ampere draw of motor. Low voltage will cause motor to overheat.
Max 0,2 m
Terminal
fuse
Terminal
fuse
Black
Pump Pump
Black
Green/yellow Green/yellow
Red Red
Switch
Max 0,2 m

Self-priming
Pump is self-priming up to 3m (for F4B 4 m). Intake lines must be air-tight to ensure selfpriming.
Note: Pump will prime when impeller is dry but suction lift up to 3m (for F4B 4 m) is only obtainable
when impeller is lubricated with liquid being pumped or Johnson Impeller lubricant.
For permanent installations where suction lift exceeds 4 m, a foot valve should be used to assure priming
on start up.
Continuous duty
For continuous duty 0,6 bar (60 kPa) maximum head is permissible. Normal working temperature of the
motor may reach approx. +80°C (surface temperature) which may burn your skin.
Varning! Dry running
Do not run dry for more than 30 seconds. Lack of liquid will burn the impeller and damage the seals.
If the pump is used for fuel oil transfer it should be equipped with a vacuum switch. When the liquid has
been evacuated the electric supply is automatically switched off.
Varning! Caution Explosion Hazard
Do not pump gasoline, solvents, thinners, highly concentrated or organic acids. If corrosive fluids must
be handled, pump life will be pro-longed if flushed with water after each use or after each work day.
Varning! Caution. Explosion Hazard.
Never operate a motor which in any way has been manipulated and lost it’s full enclosure.
Temperature
Max ambient temperature: +60°C. The life of the impeller depends on the temperature of liquid being
pumped.
Temperatures between +5°C and +55°C give normal life. Higher or lower temperature will reduce the
life.
When the pump is used as bilge pump
Max total head 6 m. The pump must be installed so that the motor is protected from splash from bilge
water.
The pump must be fitted with a strainer or other means of preventing debris from entering the pump.
Freezing weather
Drain unit by loosening the endcover. Glycol based anti-freezes can be used but do not use petroleum
based anti-freeze compounds.
Waste handling/material recycling
At the product’s end of life please dispose of the product according to applicable law. Where applicable
please disassemble the product and recycle the parts material.

Service instructions F2P10 (see page 42)
Disassembly
1. Back off the endcover screws (7), remove the endcover/wearplate (5) and O-ring (6).
2. Pull out the impeller (3) using a slip joint plier or other suitable implements.
3. Loosen and remove the screws (14) holding the pump body to the motor.
4. Remove the retaining ring (13) and the lip seal (4).
5. Do not disassemble the motor.
Assembly
1. Moisten the new lip seal with soapy water (5% soft soap), mount the seal with the lip facing
towards the impeller.
2. Lubricate the motor shaft with vaseline of the like. Fit the body to the motor.
3. Lubricate inside the pump body where the impeller should be placed with Johnson Impeller
lubricant (09-47086) , glycerine, liquid hand soap or similar. Also lubricate the surface of the
endcover.
4. Fit the impeller with a rotating movement in the intended direction of the pump rotation.
5. Lubricate the O-ring with with Johnson Impeller lubricant (09-47086) , glycerine, liquid hand soap
or similar and fit it in its position and fasten the endcover/wearplate.
Service instructions F3B-19 / F3B-19 Oil Change / F38B-19 / F4B-19
(see page 43-46)
Disassembly
1. Back off the endcover screws (7), remove the endcover (5) and O-ring (6).
2. Pull out the impeller (3) using a slip joint plier.
3. Back off and remove the nuts (8) and washers (9) holding the body. Separate the body from the
motor.
4. Remove the lip seal (4).
5. Do not disassemble the motor.
Assembly
1. Moisten the new lip seal with soapy water (5% soft soap), mount the seal with the lip facing
towards the impeller.
2. Lubricate the motor shaft with vaseline/ glycerin. Fit the body to the motor.
3. Lubricate inside the pump body where the impeller should be placed with Johnson Impeller
lubricant (09-47086) , glycerine, liquid hand soap or similar. Also lubricate the surface of the
endcover.
4. Fit the impeller with a rotating movement in the intended direction of the pump rotation.
5. Lubricate the O-ring with with Johnson Impeller lubricant (09-47086) , glycerine, liquid hand soap
or similar and fit it in its position and fasten the endcover.
Impeller
The impeller is a very important security device and should be replaced every year with a Johnson
original impeller and Johnson impeller lubricant 09-47086.

Accessories
Vacuum switch 09-45053
•For automatic shut off operation.
•To prevent pump damage.
The vacuum switch works with all selfpriming impeller pumps and should
be used for e.g. bilge pumping/emptying of tanks to prevent the pump
from running dry.
The vacuum switch automatically shuts the pump off when the bilge/tank is
dry. With the switch fitted, you can start the pump by remote push button
or manually by depressing lever on the switch.
Varning! The switch is not ignition protected.
Deckwash kit 09-46533
For convenient deckwash:
•pressure switch
•check valve
•triggel nozzle

Parts list
Pos Description F2P10-19 F3B-19
F3B-19 Oil Change
F38B-19 F4B-19
1 Body (-19) 21-4943-02 01-24480-1 01-24452-3 01-24452-1
Body (-1907) - 01-24480-2 01-24452-4 01-24452-2
Body (3/4” NH) 21-4943-21 - - -
2 Motor 12 V 01-35285-01 01-24676-01
Motor 24 V 01-35285-02 01-24676-02
3 Impeller 09-1077B-9 09-843S-9 09-824P-9 09-824P-9
4 Lip seal 0.2233.402 0.2233.007 0.2233.007 0.2233.007
5 Endcover 21-4944 01-43141 01-42398 01-42398
6 O-ring 0.2172.506 0.2173.436 0.2173.470 0.2173.470
7 Screw 0.0141.001 0.0279.501 0.0279.501 0.0279.501
8 Nut 0.0192.001 0.0185.309 0.0185.389 0.0185.069
9 Washer - 0.0353.301 0.0353-301 0.0350.207
10 Slinger 21-1616 0.2173.470 0.2173.470 0.2173.470
11 Plug - 0.2500.805 0.2500.805 0.2500.805
12 Foot kit 09-47194 09-47194 09-47194 09-47194
13 Retaining ring 0.0357.002 - - -
14 Screw 0.0256.011 - - -
15 Intermediate flange 01-45449 - - -
Service kit 09-45594
Pos: 2,6,7,9,11
09-47406
Pos: 3,4,6,7
09-46600
Pos: 3,4,6,7
09-46600
Pos: 3,4,6,7
Switch
F3B19 Oil Change
09-47196

14
8
6
4
2
15
17
10
2
5
13
16
3
7
1
A
A
117
52 11
17
89
111
52 11
17
89
3/4"-11 1/2 NH
171
5158
1/2"
3
16
1000±5
A-A
F2P10-19
Weight 1,6 kg
Dim. mm

F3B-19
8
9
7
10
4
3
6
1
5
2
16 17
11
55 51
168 89
113
100
52 16
G
1000±5
A-A
Weight 2 kg
Dim. mm

F3B-19 Oil-Change
Weight 2,1 kg
Dim. mm
8
7
9
610
4
1
5
17
3
2
A
A
A-A
171,5
51
114,5
89
72,3
1000
54,6
G
100
113
68

F38B-19
8
9
7
10
6
4
11
1
5
3
2
16 17
IN
N
I
A
R
D
O
T
R
E
V
O
C
IN
R
O
T
A
T
I
O
N
L
SWEDEN
O
JOHNSON PUMP AB
O
S
E
N
A
A
G
25,4O
34 (2x)
120
52 12,2
5157
175
A-A
Weight 3 kg
Dim. mm

F4B-19
Weight 3 kg
Dim. mm
IN
N
I
A
R
D
O
T
R
E
V
O
C
IN
R
O
T
A
T
I
O
N
L
SWEDEN
O
JOHNSON PUMP AB
O
S
E
N
1000
±
10
Ø
25,4
G
120
34 (2x)
2
55
45 ±1,5 12
7 5 6 11 3 1 4 8
9
10 14
12
2 13
208
61
Learn more about boat plumbing on our website.
