QUICKSTART GUIDE
v.1.0
LINK-MICRO-LTE

ENGLISH
2
In the box
NOTE: Memory card and batteries are sold separately.
1x LINK-MICRO-LTE camera
1x Antenna holder
1x Installation strap
1x Quickstart guide
1x SIM card that is preactivated and inserted in the camera
User manual, latest rmware, and FAQ available at:
support.spypoint.com
Components
Battery holder
Slot for installation strap
Locking latch
Cable lock hole
12V jack
Standard ¼’’20 tripod mount
Antenna
Detection lens
MicroSD card slot
Light sensor
Delay light
Photo lens
LED
ON/OFF switch
"STATUS" light
Battery compartment
SIM card slot
1
2
3
4
5
6
7
8
9
10
12
13
15
16
11
17
14

ENGLISH
3
13
14
15 16
12
17
3
4
6
7
1
2
5
8
9
10
11

ENGLISH
4
SELECT A POWER SOURCE
• Lithium or alkaline AA batteries (follow order/polarity indications)
• 12V rechargeable battery (#KIT-12V)
• 4.2V rechargeable battery pack (#LIT-10)
FOR BEST RESULTS AND NO LEAKAGE:
• Use only new lithium or alkaline batteries.
• Do not mix old and new batteries.
• Do not use rechargeable batteries (their lower voltage can generate operational issues).
HOW TO INSTALL AA BATTERIES PROPERLY
• Unlock and open the LINK-MICRO-LTE door.
• Take the battery holder out.
• Insert the AA batteries into the battery holder following polarity (+) and (-) indications.
• Place the battery holder back into the battery compartment.
FORMATTING YOUR M
icro
SD CARD
Before inserting the MicroSD card into your camera, it must be reformatted via
a computer to ensure proper functionality.
Memory card is sold separately. Whether you choose to use a MicroSD card you
previously used in another device or a brand new one you've just bought, its
capacity must not exceed 32 GB and it must be reformatted. Do no use the "Quick
format" option.
INSERTING A M
icro
SD CARD
• Ensure the camera is turned o.
• Insert a MicroSD memory card (up to 32 GB capacity) into the MicroSD
card slot with the label facing up.
• The card is inserted correctly when a click is heard.
Getting started
NOTE: We recommend using the SPYPOINT #LIT-10
rechargeable lithium battery pack, sold separately.

ENGLISH
5
SPYPOINT APP
Follow these steps:
1. On Google Play
TM
or the App Store
TM
, search for "SPYPOINT app."
2. Download and install the app on your smartphone or tablet.
3. Start the app. Select "ACTIVATE A DEVICE." In the list, select "LINK-MICRO-LTE"
then follow the steps.
4. When complete, a conrmation email will be sent to you with a generated password.
5. Log in to the SPYPOINT app using your email and password.
ACTIVATING YOUR CAMERA
You must activate your camera through the free "SPYPOINT
app" or SPYPOINT website under the MY ACCOUNT section.
FINDING THE ACTIVATION CODE
The activation code is located inside the camera case behind
the battery holder.You will need this unique code to activate
the LINK-MICRO-LTE.

ENGLISH
6
SPYPOINT website
Follow these steps:
1. On the SPYPOINT website, select "MY ACCOUNT" in the top navigation menu. On the
displayed page, select "Register," ll out the required elds, then log in.
2. Select the + sign on the far right of the page; in the list, select "LINK-MICRO-LTE," then
follow the steps.
3. When complete, a conrmation email will be sent to you with a generated password.
4. On the website, log in to your account using your email and password.
ACTIVATING YOUR CAMERA
NOTE: You can activate additional cameras and switch
between them in the SPYPOINT app or the "MY
ACCOUNT" section of the SPYPOINT website.
CHOOSING A PHOTO TRANSMISSION
PLAN FOR YOUR CAMERA
Select a photo transmission plan via the SPYPOINT app or website
1. Upon activating your camera, you will automatically benet from
our FREE monthly plan.
2. After your 30 days are up, you can select a new plan better suited
to your needs among the ones we oer or;
3. Keep your FREE monthly plan and continue receiving up to 100
photo transfers per month.

ENGLISH
7
Both the SPYPOINT app and website let you congure all the camera settings remotely.
They also provide basic information on your camera – such as: cellular signal
strength, battery level, and MicroSD card space used. This information is based
upon the latest connection with your camera.
New settings take eect every time the camera connects with the SPYPOINT app or
website. Below are the most basic settings you will congure.
BASIC PHOTO SETTINGS
Delay: Allows you to set the time interval between each detection before the
camera takes the next photo.
Multishot: Allows you to set the number of photos per detection (up to 2) with a
5-second delay between each photo.
Sensitivity: Allows you to set the detection sensitivity of the camera.
Camera name: Allows you to name each owned camera with a 30-character limit.
CELLULAR SETUP
First transfer time: Allows you to choose the time when the camera makes its
rst transfer of the day.
Transfer frequency: Allows you to choose the number of daily transfers.
ADVANCED OPTIONS/CONFIGURATION
Schedule: Allows you to set the period of operation for each day of the week.
For a 24-hour operation mode, both the start and stop times must be 12 AM.
CONFIGURING YOUR CAMERA
NOTE:
Camera transfers are set by default to every 4 hours from midnight.
For a complete list of specifications, features,
and settings, visit our LINK-MICRO-LTE page at
www.spypoint.com.

ENGLISH
8
FIRSTTIME SETUP
1. Turn on the camera.
2. The green "STATUS" light will ash while searching for a signal (can take a few minutes).
3. The "STATUS" light will light up in one of the following 3 colors:
-
Red: Insucient signal.
-
Orange: Acceptable signal.
-
Green: Optimal signal.
4. When the top right light ashes red, 30 seconds remain before the photo mode
is turned on. This allows you to leave the area without being photographed.
5. The camera is ready for use when all the lights turn o.
6. If the light is red during step 3, you should:
• Turn your camera o and then back on.
• Retry while pointing the antenna at dierent angles.
• Try moving it to a spot with better signal.
• Try our #CA-01 long-range cellular antenna (sold separately), which could help improve
signal strength.
STARTING YOUR CAMERA
1. Mount the camera using the installation strap.
2. The camera should be at the same height as the animal’s mid-body.
3. The targeted animal should be at 25 feet/7.5 meters away from the camera.
4. For brighter pictures at night, ensure you have elements in the background
to reect the IR ash.
INSTALLING YOUR CAMERA

ENGLISH
9
1. Mount the camera using the installation strap.
2. The camera should be at the same height as the animal’s mid-body.
3. The targeted animal should be at 25 feet/7.5 meters away from the camera.
4. For brighter pictures at night, ensure you have elements in the background
to reect the IR ash.
ONLY USE ORIGINAL SPARE PARTS AND ACCESSORIES.
If one day your camera has been used so intensively that it has to be replaced, or if
you no longer have any use for it, you are obliged to dispose of it at a recycling center.
Information on return points for your electrical appliance can be obtained from
your local waste disposal company or from your local administrative offices.
Electrical appliances not only contain valuable recyclable raw materials, but also
substances which, if disposed of improperly, can affect public health and the
environment. Help ensure that valuable raw materials are recycled when you return
your old appliance to a central collection point.
The WEEE (Waste Electrical and Electronic Equipment Directive ) symbol represents
the obligation that the labeled camera to be sent to a separate center for the proper
recycling of electrical and electronic equipment.
FREQUENCY RANGE:
800/ 850/ 900/ 1900/ 2100MHz
MAXIMUM TRANSMISSION POWER:
FREQUENCY
GSM850
EGSM900
DCS1800
PCS1900
GSM850 (8-PSK)
EGSM900 (8-PSK)
DCS1800 (8-PSK)
PCS1900 (8-PSK)
UMTS 2100
UMTS 1900
UMTS 900
UMTS 850
UMTS 800
DISPOSAL
FREQUENCY
MAX.
33DBM±2DB
33DBM±2DB
30DBM±2DB
30DBM±2DB
27DBM±3DB
27DBM±3DB
26DBM±3DB
26DBM±3DB
24DBM+1.7/3.7DB
24DBM+1.7/3.7DB
24DBM+1.7/3.7DB
24DBM+1.7/3.7DB
24DBM+1.7/3.7DB

ENGLISH
10
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
Operation is subject to the following two conditions:
1. This device must not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired operation.
FCC
THANK YOU FOR CHOOSING
FAQ, user manual & latest
rmware available at:
SUPPORT.SPYPOINT.COM
Live chat support at
Join the community
Sit back and relax as this device is covered by the "Know you’re
covered" 2-year warranty.We strive to provide our customers
with a positive experience and an outstanding service.
