SSS Siedle SIC 3000-01 Installation manual

Programming Instruc-
tions
Siedle Intercom
SIC 3000-01
ICI 3000-01

Door call follow-me function
Door release call number 18
Two-digit call number
With monitor 19
Movement sensor
Number of speech circuits
Clear speech circuit 20
Speech time limitation
Door communication only 21
Entitlement to transmit group
paging calls
Receiving group paging calls 22
Receiving group paging
calls in group (Defining own
group number) 23
Receiving collective
paging calls
Transmitting collective
paging calls 24
System SIC/ICI 3000-01:
Transmitting/receiving
messages 25
Message text/quickdial/external
button programming 26
Programming
message texts 27-30
Index of key words 31
Contents
2
Siedle Intercom SIC/ICI 3000-01
General remarks 3
Programming interface
Programming remarks 4
Programmable menu points 5
Commissioning
Own call number 6
Programming structure
SIC/ICI 3000-01 7
Service mode on/off 8
Service functions 9
Remote programming
Programming remarks 10
Programming mode on/off 11
Language 12
Basic status
Own call number 13
Code word 14
Music play-in
Receiving an alarm
Entitlement to receive
alarm 1-3 15
Emergency call / Door
loudspeaker parallel call 16
Doormatic
Caretaker 17

Siedle Intercom SIC/ICI 3000-01
General remarks
Programming of the Intercom sys-
tem SIC/ICI 3000-01 is per-
formed in dialogue with the user
and is supported by the display.
To ensure correct and fast pro-
gramming, check that the instal-
lation is complete and the mains
connection correct before begin-
ning with the input of data. The
entire Intercom system, i.e. all the
components connected to the
bus, can be programmed from
any optional SIC/ICI 3000-01,
whereby every call station can be
given an individual setting in line
with the particular requirements
of the user.
In order to prevent unauthorized
access to the programming
menu, it is protected by a code
word.
For fast, convenient operation, it
is possible to assign call numbers
or individual functions to the but-
tons of up to three multifunction
3
modules MFM 611-10. In additi-
on, one of these functions can
also be freely assigned to a sepa-
rate floating button.
To ensure fast and convenient
programming, call numbers or
individual functions can be stored
in the buttons of a multifunction
module MFM 611-10. The pro-
gramming instructions for this are
provided in the SIC 3000-01
operating instructions.
The industrial call station
ICI 3000-01 cannot be used in
combination with multifunc-
tion modules, audio privacy
receivers or video.
Remark:
For time-dependent control func-
tions in the Siedle intercom
system, we recommend additio-
nally installing a quartz system
clock CLK 3000-0.

Programming interface
Programming remarks
Numerical buttons for
entering numerical values
and call numbers
Call silencing button; used
in conjunction with the F
button, this takes you into
the service menu
Listen-in button; used in
conjunction with the F
button, this takes you out
of the service mode
C button; this can be used
to leave the programming
level at any time
R button; this is used to
scroll forwards through
the menu to the next
menu point
F button; this is used to
scroll backwards through
the menu to the previous
menu point; used in con-
junction with other but-
tons, it takes you
into the service and pro-
gramming mode
Call forwarding button;
this takes you up to the
previous menu point in
a sub-menu
Follow-me button; this
takes you down to the fol-
lowing menu point in
a sub-menu
Programming remarks
The menu points listed overleaf
can be scrolled through in the
programming menu using the
R button for forward movement
and the F button for backward
movement until you reach the
required menu point.
Inputs made in the programming
mode do not need to be con-
firmed. When scrolling forward,
the inputs you have made are
entered automatically into the
intermediate store and then into
the permanent memory after you
have left the programming mode
with the C button by resetting
the appliance. Only then are the
settings you have entered valid.
4
F
R
C

Programmable menu points
5
Programmable Programming Factory set
menu points possibilities
Language version D=0, GB=1, F=2,
NL=3, DK=4, I=5 English
Basic status yes/no no
Own call number 1– 99 —-
Code word (0001– 9999) 1000
Music play-in
Receiving an alarm / alarm 1 (receive entitlement) yes/no no
Receiving an alarm / alarm 2 (receive entitlement) yes/no no
Receiving an alarm / alarm 3 (receive entitlement) yes/no no
Receiving an emergency call (receive entitlement) yes/no no
Receiving a door parallel call yes/no no
Doormatic entitlement (door release actuation after call) yes/no no
Caretaker entitlement (receiving all door calls) yes/no no
Door call follow-me function yes/no no
Door release call number 1– 99 0001
Two-digit call number 1) yes/no no
With monitor yes/no no
BMM entitlement (response to movement sensor signal) 4) yes/no no
Number of speech circuits 1) 1/2 2
Entitlement to clear speech circuits yes/no no
Speech time limitation
Door communication only? yes/no no
Group call transmit entitlement 2) yes/no no
Receive group calls? yes/no yes
Receive group calls in group 3) 1–9 1
Receive other group calls 3) yes/no no
Receive group calls in group 3) 1– 9 1
Receive collective calls yes/no yes
Collective call transmit entitlement yes/no no
1) Programming point only appears
in call stations connected to the
global bus
2) Programming point does not
appear when “door communi-
cation only“ has been activated
3) Programming point does not
appear unless ”Receive group
calls“ has been activated
4) Programming point only appears
if “With monitor“ has been acti-
vated
5) Programming point appears only
with the SIC 3000-01 not with
ICI 3000-01.

Commissioning
Own call number
6
Display
Enter the numbers “0, 4“
Display
Press the C button
Display
Display
Display
Remark:
Allocating call numbers as
described below applies only to
SIC/ICI 3000-01 appliances.
Supplementary devices such as
the TLC or BC must be set using
rotary switches at the device
itself.
Own call number
With a new appliance, no call
number has been set in the facto-
ry. In order to program an Inter-
com system, each call station
must first receive its own call
number.
Allocate a number to the call sta-
tion, e.g. number 4. When enter-
ing, first type in the ten
and then the unit.
Using the C button, leave this
input point.
The Intercom SIC/ICI 3000-01
carries out a reset, stores the call
number and indicates the soft-
ware version in the display, as
well as the stored call number for
you to check.
Then the time is superimposed.
Caution!
Any call number can only be allo-
cated once in the system. If
a call number is allocated twice
while you are commissioning a
call station, it is not possible for
you to quit the programming
mode with the C button. The dis-
play remains. In addition, when
actuating the C button,
the “engaged“ message appears
briefly.
Reset
••••••••••
013545 2.00 XX
Call number: 4
0:00
OWN CALL NUMBER
Call number --
OWN CALL NUMBER
Call number 04
04
C

7
Programming structure SIC/ ICI 3000-01
Initial status
9:23
Service mode
9:23
Service functions Programming menu of
selected call station
F F F F
F F 0 1
and code word
No access con-
trol
and call number of
the appliance
Quit service
mode
Programming
SIC 3000-0
Programming
TLC 3000-0
Programming
BC 3000-0
Quit the programming mode with the C button
The appliance carries out an automatic reset and
so stores the entered settings in the memory.
... and continue with the respective programming
instructions (the programming instructions for the
TLC and BC are provided with the respective devices)...








8
Service mode on/off
Access to the service mode is pro-
tected by a code word.
On delivery, the code word 1000
is defined.
Caution:
If you enter the wrong code
word three times in succession,
the SIC/ICI 3000-01 is disabled
for a period of around 6 minutes.
To execute the service functions
described below, or to branch
into the call station programming
level, you must first change into
the service mode.
Switching on the
service mode
Remark:
The maximum interval between
two inputs is 1.5 seconds. Inputs
must therefore be made quickly.
Caution:
If a period of ten minutes elapses
before making a further input or
branching into the programming
menu, the system automatically
quits the service mode.
Switching off the
service mode
Remark:
The maximum interval between
two inputs is 1.5 seconds. Inputs
must therefore be made quickly.
Press the F button twice and press
the call silencing button
The display changes from
to
and
Enter the factory or your own
personal code number
Display
Display
Press the F button twice and press
the listen-in button
The display changes from
to
and
1 0 0 0
Funcion
System
Service mode
Code word?
Service mode
Code word? ####
Service mode
Active
Function
System
Service mode
Passive
FF
FF

Service functions
9
Caution: The reset functions
return the targeted call stations
to the basic status, i.e. all current
calls are interrupted, call-back
requests and message texts are
cancelled, and call and micro-
phone silencing functions are
deactivated. However, call sta-
tion-specific programming is
retained.
If the call station is in the service
mode, it is possible to execute
the following functions.
Remark: The maximum interval
between two inputs is 1.5 sec-
onds. Inputs must therefore
be made quickly.
Software reset (local)
A reset is initiated at the input
appliance
Software reset (global)
A reset is initiated at all appli-
ances connected to the IC 3000-0
bus (including BC, SFM...)
Transmit time
The time set at the
SIC / ICI 3000-01 is transmitted
to all appliances connected to
the system.
If there is a system quartz clock
CLK 3000-0 installed, the date
and time are kept continuously
updated by the CLK.
Connected appliances
All appliances connected to the
selected bus are indicated in the
display together with appliance
type and call number. The num-
ber of the bus you wish to see
must be entered quickly after
“F, F, 0, 3“.
If this command is entered with-
out a subsequent bus number,
the appliances belonging to the
station’s own bus are displayed.
By entering “00“, the global bus
is displayed.
C button: Interrupts the display
at any time.
R button: Automatic termination
after display of the last appliance
Enter “F, F, 0, 0“
Enter “F, F, 0, 0, 1“
Enter “F, F, 0, 2“
Enter the numbers “F, F, 0, 3“ +
required bus number (e.g. no. 20)
Display changes from
to (example)
Press the R button to display the
next appliance
Interrupt by pressing the C or
R button
R
Vis enheder
Busnummer: 20
1. apparat SIC
Abonnent: 2001
RC
FF
FF
FF
FF
0
3
0 0
0 0 1
2
0

10
Remote programming
Programming remarks
only possible as long as a number
has been allocated to every appli-
ance in the system. This is of par-
ticular importance during initial
commissioning.
If either of the two call stations
has a power failure during remote
programming, both call stations
are returned to the basic status
after an automatic reset.
Remote programming
Using any optionally selected
intercom SIC/ICI 3000-01 call sta-
tion, it is possible to program any
of the appliances connected to
the system bus. However, this is
Programming remarks
In the programming menu,
the menu points appear in the
sequence listed on page 5. It is
possible to scroll through the list
forwards with the R button and
backwards with the F button until
you reach the required point.
If you do not wish to change a
value indicated in the display, sim-
ply scroll to the next point with
the F or R button.
If you do wish to change a set-
ting, enter the required value and
then continue to move through
the menu.
Remark:
This procedure is practically iden-
tical for every point appearing in
the menu.
Here, it is possible to define the
required functions at each menu
point by entering “0, 1“ or a
number combination.
There is no need to confirm
inputs.
When you scroll to the next
menu point, your inputs enter
an intermediate store.
After leaving the programming
mode (with the C button), the
inputs are stored and become
valid as a result of an automatic
reset of the programmed call sta-
tion.
Press the R or F button
Enter “0, 1“ or a number
sequence
Press the R or F button
10
FR
FR

11
Programming mode on/off
Function
System
Configuration
Call number ---
Configuration
Call number ---4
Reset
•••••••••• ---
9:23
C
menu if every appliance you wish
to program has been allocated
its own call number for unam-
biguous identification purposes.
Before it is possible to activate
the programming mode, first
the SIC/ICI 3000-01 has to be
switched to the service mode.
If you wish to change an appli-
ance setting, this can only be
done in the programming mode.
However, it is only possible to
branch into the programming
After programming, it is advis-
able to leave the service mode
manually. In this
way, you avoid the risk of
unauthorized or incorrect
operation during the ten min-
utes which elapse until the
system automatically quits the
service mode.
Following the reset, you are back
again in the service mode and
can continue with programming
another appliance by activating
the programming mode again.
Switching on the program-
ming mode
By entering “F, F, 0, 1“ and the
call number of the call station
from which you are working, its
programming menu is activated.
Remote programming of another
appliance, for example a SIC,
BC or TLC, is carried out by pro-
gramming its call number.
The procedure for remote pro-
gramming is identical to
that for programming the station
from which you are working.
To program the BC and TLC,
please use the respective pro-
gramming instructions.
Remark:
The maximum interval between
two inputs is 1.5 seconds. Inputs
must therefore be made quickly.
Switching off the program-
ming mode
To leave the service mode, press
the C button
The appliance carries out an auto-
matic reset and is then
ready for normal operation.
Continuous clock display
Enter “F, F, 0, 1“
The display changes from
to
and
Enter the call number of the
appliance you wish to program
(e.g. 4)
Display
Press C
Display
Display
FF01

Language
12
Language
To select the appropriate langua-
ge, enter the required code num-
ber.
The display changes continuously
between
and
and
and
and
and
enter required code number
Use the R button to scroll for-
wards
Use the F button to scroll back-
wards
Deutsch = 0
Pres. extn: 0
English = 1
Pres. extn: 0
Français = 2
Pres. extn: 0
Nederlands = 3
Pres. extn: 0
Dansk = 4
Pres. extn: 0
Italiano = 5
Pres. extn: 0
FR

Basic status
Own call number
13
The display changes continuously
between
and
“0“ = do not activate basic status
“1“ = activate basic status
Use the R button to scroll for-
wards
Use the F button to scroll back-
wards
Basic status
If you activate the basic status by
entering “1“ and then leaving
the programming mode using the
C button, all menu points of the
appliance are turned to their
basic, i.e. factory settings. All that
remains unaltered is the set call
number.
Remark:
The basic factory settings are list-
ed on page 5.
Note:
If a unit is reset to its basic status,
any personalized code word you
may have entered is replaced by
the default factory-set code word
”1000”. Correct this if necessary.
Basic status
Pres. extn: 0
1 = yes, 0 = no
Pres. extn: 0
OWN CALL NUMBER
Pres. extn: 04
Display
Enter the required code number
Use the R button to scroll for-
wards
Use the F button to scroll back-
wards
Own call number
If you wish to change the call
number of an appliance, enter
the new call number (1-99). If the
newly entered number already
exists in the same bus, the R and
F buttons for scrolling backwards
and forwards are disabled
until this has been corrected.
If you terminate the program-
ming routine with the
C button despite having entered
the same number twice, after
a reset the system once more
requests correction of the call
number. Using the C button, initi-
ate another reset process
after correcting the number.
FR
10
FR

14
Code word
Display
Enter the new code word
Display
Press the R button
Display
Enter the code word again to
check it
Display
Press the R button to scroll to the
next menu point
Press the F button to scroll back
to the previous menu point
Display
Display
If you do not wish to change
the code word, use the F and
R buttons to scroll to the next
menu point.
To check, enter the new code
word again
Once the code word has been
replaced correctly, the following
display appears when scrolling
to the next point:
Caution:
If the input made under “code
word“ and “code word check“
are not identical, the display on
the right appears and the previ-
ously valid code word is retained.
Code word
Pres. extn.
Code word
Pres. extn: ####
Code word check
Pres. extn.
Code word
Pres. extn: ####
Code word
replaced
Code word
not replaced
tem from unauthorized access.
Remark: Entering the code word
at one SIC/ICI 3000-01 alters the
code word of all the appliances
linked to the system at the time
of input.
Appliances integrated in the sys-
tem at a later date (new or used)
must be checked to ascertain
their code word and corrected if
necessary.
Caution: Treat your new sys-
tem code word as confiden-
tial!
Code word
This prevents unauthorized access
to the appliance configuration. In
the delivered status, the default
code word is always “1000“.
We recommend altering this
straight away to protect your sys-
FR
R

Music play-in
Receiving an alarm
Entitlement to receive alarm 1–3
The display changes continuously
from
to
”0”: no music play-in
”1”: music play-in
Use the R button to scroll for-
wards
15
MUSiIC PLAY-IN
Pres. extn: 0
1 = yes, 0 = no
Pres. extn: 0
Music play-in
In this menu point, the music
play-in function is enabled for
the respective unit.
Remark
The music play-in function is not
enabled in the standard default
status.
The display changes continuously
from
to
and
“0“ for “suppress alarm“
“1“ for “receive alarm“
Use the R button to scroll for-
wards
Use the F button to scroll back-
Entitlement to receive alarm 1– 3
Entitlement for your call station
to receive alarm 1– 3 can be
entered here.
The R button takes you to the
next alarm in the menu
Remark: The fourth possible
alarm message (Alarm 0) cannot
be suppressed and can therefore
also not be programmed.
This type of alarm message is re-
ceived by every SIC/ICI 3000-01.
RECEIVE ALARM
Pres. extn: 0
From alarm 1
Pres. extn: 0
1 = yes, 0 = no
Pres. extn: 0
these alarm signals must be
assigned to each call station sepa-
rately. An alarm is indicated opti-
cally and acoustically at an enti-
tled call station. If a message text
has been programmed for this
function, it will appear on the dis-
play.
Receiving an alarm
In combination with special func-
tion modules, an intercom station
can be set to receive and evaluate
up to 4 different alarm signals.
Entitlement to receive three of
FR
10
FR
10

Emergency call
Door loudspeaker parallel call
The display changes continuously
from
to
“0“ for “suppress emergency
call“
“1“ for “receive emergency call“
Use the R button to scroll for-
wards
Use the F button to scroll back-
wards
The display changes continuously
from
to
and
“0“ for “suppress door call“
“1“ for “receive door call“
Use the R and F buttons to scroll
forwards or backwards
16
Emergency call
Emergency calls transmitted by
a special function module can
be received provided the
SIC/ICI 3000-01 has been pro-
grammed for entitlement.
Door loudspeaker parallel call
If you wish a call from the door
loudspeaker to be directed to sev-
eral intercom stations, these must
be entitled to receive a
door loudspeaker parallel call.
Note:
Initiation of a parallel call when
pressing the call button is pro-
grammed in the TLC 3000-0.
RECEIVE EMERGENCY CALL
Pres. extn: 0
1 = yes, 0 = no
Pres. extn: 0
DOOR L:PARALLEL CALL
Pres. extn: 0
RECEIVE?
Pres. extn: 0
1 = yes, 0 = no
Pres. extn: 0
FR
10
FR
10

17
Doormatic
Caretaker
The display changes continuously
from
to
and
“0“ for no Doormatic activation
entitlement
“1“ entitlement to activate the
Doormatic function
Use the R button to scroll for-
wards
Use the F button to scroll back-
wards
The display changes continuously
from
to
and
“0“ for no caretaker activation
entitlement
“1“ entitlement to activate the
caretaker function
Use the R button to scroll for-
wards
Use the F button to scroll back-
wards
Doormatic
The doormatic function permits
automatic actuation of the door
release following a door call. This
omits the need for manual door
release, for example during con-
sulting hours in doctors’ surg-
eries.
To allow you to activate the door-
matic function, the respective call
station must have the necessary
entitlement.
Caretaker
With the caretaker function, it is
possible to fetch all door calls to
the call station at which this func-
tion is activated.
For this, the respective call station
must be entitled to activate the
caretaker function.
DOORMATIC
Pres. extn: 0
ENTITLEMENT
Pres. extn: 0
1 = yes, 0 = no
Pres. extn: 0
CARETAKER
Pres. extn: 0
ENTITLEMENT
Pres. extn: 0
1 = yes, 0 = no
Pres. extn: 0
FR
10
FR
10

18
Door call follow-me function
Door release call number
The display changes continuously
from
to
and
“0“ No entitlement
“1“ Entitlement
Use the R button to scroll for-
wards
Use the F button to scroll back-
wards
Actuation of the door release
button without a previous
door call:
The system opens the door
release whose number is entered
in this programming menu.
The display changes continuously
from
to
If you wish to alter this setting,
enter the new call number
(e.g. 0023)
The display changes continuously
from
to
Use the R or F button to continue
Door call follow-me function
At call stations with entitlement
to use the door call follow-me
function, it is possible to fetch
door calls intended for another
call station.
Remark:
If the caretaker function is acti-
vated in the system, this will can-
cel the door call follow-me func-
tion for as long as the caretaker
function remains active, as the
caretaker function has a higher
system priority.
Door release call number
The call number of a door release
which you wish to be able to
actuate without a previous door
call must be entered here. The
input is not valid for the entire
system, but only for the pro-
grammed call station.
Remark:
The entered call number for the
door release must always have
four digits.
DOOR CALL FOLLOW-ME
Pres. extn: 0
ENTITLEMENT?
Pres. extn: 0
1 = yes, 0 = no
Pres. extn: 0
DOOR RELEASE
Pres. extn: 0001
CALL NUMBER
Pres. extn: 0001
DOOR RELEASE
Pres. extn: 0023
CALL NUMBER
Pres. extn: 0023
Actuation of the door release
button after a door call:
The system automatically actu-
ates the door release at
the door station which made
the door call.
FR
10
FR

19
Two-digit call number
With monitor
The display changes continuously
from
to
and
“0“ for 4-digit call number
“1“ for 2-digit call number
Press the R or F button
The display changes continuously
from
to
“0“ = without monitor activation
“1“ = with monitor activation
Use the R button to scroll for-
wards
Use the F button to scroll back-
wards
With monitor
If a monitor is assigned to the
intercom station, this is automati-
cally switched on following an
incoming door call, provided enti-
tlement has been programmed
here.
This menu point is not accessed
with industrial call station
ICI 3000-01, as combination
with video is not possible.
Two-digit call number
This function is used to optimize
the dialling speed in single-bus
intercom systems, i.e. those with-
out bus coupler.
As only two-digit numbers can be
assigned in this type of system,
the appliance initiates the call as
soon as you have typed in the
second digit.
This menu point also appears
in systems with local buses only
in appliances connected to the
global bus, but in this case must
be deactivated by entering “0“.
CALL NUMBER
Pres. extn: 0
2-DIGIT?
Pres. extn: 0
1 = yes, 0 = no
Pres. extn: 0
WITH MONITOR?
Pres. extn: 0
1 = yes, 0 = no
Pres. extn: 0
FR
10
FR
10

Movement sensor
Number of speech circuits
Clear speech circuit
The display changes continuously
from
to
“0“: Do not switch on monitor
“1“: Switch on monitor
Use R button to scroll forwards
Use F button to scroll backwards
20
Movement sensor
Movement sensor entitlement is
only significant in conjunction
video and a monitor.
If this function is activated, the
camera and monitor are activated
by one of the movement sensor
module’s switching outputs. If the
previous menu point “with moni-
tor“ is not activated, BMM inter-
rogation is suppressed.
Display
Enter either “1“ or “2“ speech
circuits
Use the R button to scroll for-
wards
Use the F button to scroll back-
wards
The display changes continuously
from
to
and
“0“: Do not switch on monitor
“1“: Switch on monitor
Use the R or F button to scroll
forwards
Number of speech circuits
This menu point only appears
for appliances connected to the
global bus. The Intercom
SIC/ICI 3000-01 only has two
speech circuits available. If you
wish to integrate the system into
an already existing installation,
and there are insufficient wires
available for 2 speech circuits, the
system can only be operated with
one speech circuit. However, pay
attention to ensure that the same
number of speech circuits is
entered all appliances connected
to the global bus.
BMM ENTITLEMENT
Pres. extn: 0
1 = yes, 0 = no
Pres. extn: 0
NUMBER OF SPEECH. PATHS?
Pres. extn: 2
SPEECH PATH FREE
Pres. extn: 0
RC AUTHORIZATION
Pres. extn: 0
Clear speech circuit
You may give the device autho-
risation to interrupt existing con-
nections if all speech circuits are
engaged. This should only be
permitted for devices which need
to pass on information in urgent
cases.
1 = yes, 0 = no
Pres. extn: 0
0
R
1
F
FR
10
FR
10
