ST STM32 Nucleo-64-P Series User manual

June 2022 UM2206 Rev 6 1/52
1
UM2206
User manual
STM32 Nucleo-64-P boards (MB1319)
Introduction
The STM32 Nucleo-64-P boards, based on the MB1319 reference board (NUCLEO-
L412RB-P, NUCLEO-L433RC-P, and NUCLEO-L452RE-P), provide an affordable and
flexible way for users to try out new concepts and build prototypes with the STM32
microcontroller and the external SMPS (switched-mode power supply), which provides
various combinations of performance, power consumption, and features.
ARDUINO® Uno V3 connectivity and ST morpho headers provide an easy means of
expanding the functionality of the Nucleo open development platform with a wide choice of
specialized shields.
The STM32 Nucleo-64-P boards do not require any separate probe, as they integrate the
ST-LINK/V2-1 debugger/programmer. The STM32 Nucleo-64-P boards come with the
comprehensive free STM32 software libraries and examples that are available with the
STM32Cube package.
Pictures are not contractual.
Figure 1. Nucleo-64-P board (top view) Figure 2. Nucleo-64-P board (bottom view)
www.st.com

Contents UM2206
2/52 UM2206 Rev 6
Contents
1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.1 Codification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Development environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Development toolchains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5 Quick start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.1 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
6 Hardware layout and configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.1 STM32 Nucleo-64-P board layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6.2 STM32 Nucleo-64-P board mechanical drawing . . . . . . . . . . . . . . . . . . . 15
6.2.1 Default board configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6.3 Cuttable PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6.4 Embedded ST-LINK/V2-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6.4.1 Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6.4.2 ST-LINK/V2-1 firmware upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6.4.3 Using the ST-LINK/V2-1 to program/debug the STM32 . . . . . . . . . . . . 18
6.4.4 Using the ST-LINK/V2-1 to program/debug an external STM32
application. 18
6.5 power supply and power selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.5.1 External power supply input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.5.2 External power supply output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.5.3 SMPS power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.6 Programming/debugging when the power supply is not from
ST-LINK (5V_ST_link) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.7 OSC clock sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.7.1 LSE: OSC 32 KHz clock supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.7.2 OSC clock supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

UM2206 Rev 6 3/52
UM2206 Contents
4
6.8 Reset sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.9 Virtual COM port: LPUART1/USART1 . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.10 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.11 Push-buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.12 IDD measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.13 Jumper configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.14 Configuration of the solder bridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.1 USB Micro-B connector CN1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.2 ARDUINO® Uno V3 connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7.3 ST morpho connectors CN5 and CN6 . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.4 External power connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
8 STM32 Nucleo-64-P board information . . . . . . . . . . . . . . . . . . . . . . . . . 42
8.1 Product marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
8.2 NUCLEO-L412RB-P product history . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
8.2.1 Product identification NUL412RBP$AU1 . . . . . . . . . . . . . . . . . . . . . . . . 42
8.2.2 Product identification NUL412RBP$AU2 . . . . . . . . . . . . . . . . . . . . . . . . 42
8.3 NUCLEO-L412RB-P product limitations . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.3.1 Product identification NUL412RBP$AU1 limitations . . . . . . . . . . . . . . . 43
8.3.2 Product identification NUL412RBP$AU2 limitations . . . . . . . . . . . . . . . 43
8.4 NUCLEO-L433RC-P product history . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.4.1 Product identification NUCLEOL433RCP/ . . . . . . . . . . . . . . . . . . . . . . . 43
8.4.2 Product identification NUL433RCP$AU1 . . . . . . . . . . . . . . . . . . . . . . . . 43
8.5 NUCLEO-L433RC-P product limitations . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.5.1 Product identification NUCLEOL433RCP/ limitations . . . . . . . . . . . . . . 43
8.5.2 Product identification NUL433RCP$AU1 limitations . . . . . . . . . . . . . . . 43
8.6 NUCLEO-L452RE-P product history . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.6.1 Product identification NUCLEOL452REP/ . . . . . . . . . . . . . . . . . . . . . . . 43
8.6.2 Product identification NUL452REP$AU1 . . . . . . . . . . . . . . . . . . . . . . . . 44
8.7 NUCLEO-L452RE-P product limitations . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8.7.1 Product identification NUCLEOL452REP/ limitations . . . . . . . . . . . . . . 44
8.7.2 Product identification NUL452REP$AU1 limitations . . . . . . . . . . . . . . . 44
8.8 Board revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Contents UM2206
4/52 UM2206 Rev 6
8.8.1 MB1319 revision B-02 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8.8.2 MB1319 revision C-01 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8.8.3 MB1319 revision C-02 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8.9 Board known limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8.9.1 Board MB1319 revision B-02 limitations . . . . . . . . . . . . . . . . . . . . . . . . 44
8.9.2 Board MB1319 revision C-01 limitations . . . . . . . . . . . . . . . . . . . . . . . . 44
8.9.3 Board MB1319 revision C-02 limitations . . . . . . . . . . . . . . . . . . . . . . . . 44
9 NUCLEO-L412RB-P, NUCLEO-L433RC-P, and NUCLEO-L452RE-P I/O
assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
10 Federal Communications Commission (FCC)
and ISED Canada Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
10.1 FCC Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
10.1.1 Part 15.19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
10.1.2 Part 15.21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
10.1.3 Part 15.105 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
10.2 ISED Canada Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
10.2.1 Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
10.2.2 Déclaration de conformité . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
11 CE / RED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
11.1 EN55032 / CISPR32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

UM2206 Rev 6 5/52
UM2206 List of tables
5
List of tables
Table 1. Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Table 2. Codification explanation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Table 3. ON/OFF convention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Table 4. Default jumper settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Table 5. ST-LINK jumper configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Table 6. Debug connector SWD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 7. power supply capabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table 8. SB9 configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Table 9. LPUART1 connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Table 10. USART1 connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Table 11. Jumper settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Table 12. Solder bridge configurations and settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Table 13. USB Micro-B pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Table 14. ARDUINO® connector pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Table 15. External power connector pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Table 16. NUCLEO-L412RB-P, NUCLEO-L433RC-P, and NUCLEO-L452RE-P
I/O assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Table 17. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

List of figures UM2206
6/52 UM2206 Rev 6
List of figures
Figure 1. Nucleo-64-P board (top view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Figure 2. Nucleo-64-P board (bottom view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Figure 3. Hardware block diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 4. STM32 Nucleo-64-P board top layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 5. STM32 Nucleo-64-P board bottom layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 6. STM32 Nucleo-64 -P board mechanical drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 7. USB composite device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 8. ST-LINK debugger: jumper configuration for on-board MCU . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 9. ST-LINK debugger: jumper configuration for external MCU . . . . . . . . . . . . . . . . . . . . . . . . 19
Figure 10. JP5[1-2]: 5V_STL power source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 11. JP5[3-4]: 5V_VIN power source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 12. JP5[5-6]: E5V power source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 13. JP6[7-8]: 5V_USB_CHG power source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 14. USB Micro-B connector CN1 (front view) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 15. ARDUINO® connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Figure 16. ARDUINO® connector pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 17. ST morpho connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 18. ST morpho connector pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Figure 19. External power connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

UM2206 Rev 6 7/52
UM2206 Features
51
1 Features
STM32L4 Series Arm®(a) Cortex®-M4 core-based microcontroller in an LQFP64
package
SMPS: significantly reduces power consumption in Run mode
32.768 kHz LSE crystal oscillator
One user LED shared with ARDUINO®
Two push-buttons: USER and RESET
ARDUINO® Uno V3 expansion connector
ST morpho expansion connector
External SMPS experimentation dedicated connector
Flexible board power supply: ST-LINK/V2-1 USB VBUS or external sources
On-board ST-LINK/V2-1 debugger/programmer with USB reenumeration capability:
mass storage, Virtual COM port, and debug port
Comprehensive free software libraries and examples available with the STM32Cube
package
Support of a wide choice of Integrated Development Environments (IDEs) including IAR
Embedded Workbench®, MDK-ARM, and STM32CubeIDE
a. Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.

Ordering information UM2206
8/52 UM2206 Rev 6
2 Ordering information
To order an STM32 Nucleo-64-P board, refer to, refer to Table 1. Additional information is
available from the datasheet and reference manual of the target STM32.
2.1 Codification
The meaning of the codification is explained in Table 2.
Table 1. Ordering information
Order code Board
reference Target STM32
NUCLEO-L412RB-P
MB1319
STM32L412RBT6P
NUCLEO-L433RC-P STM32L433RCT6P
NUCLEO-L452RE-P STM32L452RET6P
Table 2. Codification explanation
NUCLEO-XXYYRT-P Description Example: NUCLEO-L452RE-P
XX MCU series in STM32 32-bit Arm Cortex
MCUs STM32L4 Series
YY MCU product line in the series STM32L452
R STM32 package pin count 64 pins
T
STM32 flash memory size:
– B for 128 Kbytes
– C for 256 Kbytes
– E for 512 Kbytes
512 Kbytes
-P STM32 has an external SMPS function External SMPS

UM2206 Rev 6 9/52
UM2206 Development environment
51
3 Development environment
3.1 System requirements
Multi-OS support: Windows® 10, Linux® 64-bit, or macOS®(a)(b)(c)
USB Type-A or USB Type-C® to Micro-B cable
3.2 Development toolchains
IAR Systems® - IAR Embedded Workbench®(d)
Keil® - MDK-ARM(d)
STMicroelectronics - STM32CubeIDE
a. macOS® is a trademark of Apple Inc., registered in the U.S. and other countries and regions.
b. Linux® is a registered trademark of Linus Torvalds.
c. Windows is a trademark of the Microsoft group of companies.
d. On Windows® only.

Conventions UM2206
10/52 UM2206 Rev 6
4 Conventions
Table 3 provides the conventions used for the ON and OFF settings in the present
document.
In this document, the references for all information that is common to all sale types, are
‘STM32 Nucleo-64-P board’ and ‘STM32 Nucleo-64-P boards’.
Table 3. ON/OFF convention
Convention Definition
Jumper JPx ON Jumper fitted
Jumper JPx OFF Jumper not fitted
Jumper JPx [1-2] Jumper fitted between pin 1 and pin 2
Solder bridge SBx ON SBx connections closed by 0 Ω resistor
Solder bridge SBx OFF SBx connections left open
Resistor Rx ON Resistor soldered
Resistor Rx OFF Resistor not soldered
Capacitor Cx ON Capacitor soldered
Capacitor Cx OFF Capacitor not soldered

UM2206 Rev 6 11/52
UM2206 Quick start
51
5 Quick start
This section describes how to start development quickly using the STM32 Nucleo-64-P
board.
Before installing and using the product, accept the Evaluation Product License Agreement
from the www.st.com/epla webpage.
5.1 Getting started
The STM32 Nucleo-64-P board is a low-cost and easy-to-use development kit to evaluate
and start quickly a development with an STM32 microcontroller in an LQFP64 package. To
start using this board, follow the steps below:
1. Check the jumper position on the board, as shown in Table 4: Default jumper settings.
2. For correct identification of all device interfaces from the host PC, install the Nucleo
USB driver available on the www.st.com/stm32nucleo webpage, before connecting the
board.
3. To power the board, connect the Nucleo-64-P board before a PC with a USB Type-A or
USB Type-C® to Micro-B cable through USB connector CN1. As a result, the green
LED LD3 (5 V PWR) lights up, LD1 (COM) and green LED LD4 blink.
4. Press user button B1 (blue).
5. Observe that the blinking frequency of the three green LEDs LD4 changes by clicking
on the button B1.
6. The software demonstration and the several software examples that allow the user to
use the Nucleo features, are available at the www.st.com/stm32nucleo webpage.
7. Develop an application using the available examples.

Hardware layout and configuration UM2206
12/52 UM2206 Rev 6
6 Hardware layout and configuration
The STM32 Nucleo-64-P board is designed around the STM32 microcontrollers in a
64-pins LQFP package.
Figure 3 illustrates the connection between the STM32 and the peripherals (ST-LINK/V2-1,
push-buttons, LEDs, ARDUINO® Uno V3 connector, and ST morpho connectors).
Figure 4 and Figure 5 show the location of these features on the STM32 Nucleo-64-P
board.
The mechanical dimensions of the board are shown in Figure 6.
Figure 3. Hardware block diagram
ST-LINK/V2-1 Part
STM32 microcontroller
OSC_32
SWD
VDD_MCU
3.3V / 1.8V
32 KHz
crystal
VCP
UART
GPIO
GPIO
LED
GPIO
Embedded
ST-LINK/V2-1
SWD
SWD VCP
UART
USB Micro- B
connector
B1
User
B2
Reset
ARDUINO
®
ST morpho
GPIO
ARDUINO
®
ST morpho
5V
PWR SEL
5V
LED
VDD_1V2
Ext PWR
Jumper
JP
nRST
VCP
JP STL
nRST
COM

UM2206 Rev 6 13/52
UM2206 Hardware layout and configuration
51
6.1 STM32 Nucleo-64-P board layout
Figure 4. STM32 Nucleo-64-P board top layout

Hardware layout and configuration UM2206
14/52 UM2206 Rev 6
Figure 5. STM32 Nucleo-64-P board bottom layout

UM2206 Rev 6 15/52
UM2206 Hardware layout and configuration
51
6.2 STM32 Nucleo-64-P board mechanical drawing
Figure 6. STM32 Nucleo-64 -P board mechanical drawing
6.2.1 Default board configuration
By default the STM32 Nucleo-64-P board is delivered with the external SMPS 1.1 V enabled
and VDD@3.3 V. It is possible to set the board for VDD@1.8 V. Before switching to 1.8 V, the
user must check that the extension module and the external shields connected to the
Nucleo-64-P board are 1.8 V compatible.
The default jumper configuration and VDD@1.8 V setting are shown in Table 4.

Hardware layout and configuration UM2206
16/52 UM2206 Rev 6
6.3 Cuttable PCB
An STM32 Nucleo-64-P board is divided into two parts: ST-LINK and target STM32. The
ST-LINK part of the PCB can be cut out to reduce the board size. In this case, the remaining
target STM32 part can only be powered by VIN, E5V, and 3.3 V on the CN5 ST morpho
connector, or by VIN and 3.3 V on the CN8 ARDUINO® connector.
It is still possible to use the ST-LINK part to program the STM32, using wires between the
CN3 and SWD available signals on the ST morpho connector (SWCLK CN5 pin 17, SWDIO
CN5 pin 15, and NRST CN5 pin 14, at the same I/O level as VDD_MCU).
6.4 Embedded ST-LINK/V2-1
The ST-LINK/V2-1 programming and debugging tool is integrated on the
STM32 Nucleo-64-P board.
For information about debugging and programming features, refer to the ST-LINK/V2 in-circuit
debugger/programmer for STM8 and STM32 user manual (UM1075) at the www.st.com
website.
The changes versus the ST-LINK/V2 version are listed below.
New features supported on ST-LINK/V2-1 are:
USB software reenumeration
Virtual COM port interface on USB
Mass storage interface on USB
USB power management request for more than 100mA current on USB
The following features are no more supported on ST-LINK/V2-1:
SWIM interface
Application voltage lower than 3 V (need to add level shifter to support it)
Table 4. Default jumper settings
Jumper Definition Default position Comment
CN2 SWD interface ON [1-2] ON[3-4] On-board ST-LINK/V2-1 debugger
JP1 STLK_RST OFF -
JP4 T_NRST ON -
JP5 5 V power selection ON [1-2] 5 V from ST-LINK
JP6 IDD measurement ON STM32 VDD current measurement
JP7 VDD_MCU
ON [1-2] (default) VDD_MCU voltage selection 3.3 V
ON [2-3] (optional) VDD_MCU voltage selection 1.8 V
JP8 VDD_IN_SMPS ON VDD_1V2 SMPS input power supply

UM2206 Rev 6 17/52
UM2206 Hardware layout and configuration
51
The embedded ST-LINK/V2-1 can be used in two different ways according to the jumper
configuration (refer to Table 5):
Program/debug the STM32 on board,
Program/debug an STM32 in an external application board using a cable connected to
the SWD connector.
6.4.1 Drivers
Before connecting the STM32 Nucleo-64-P board to a Windows® PC (XP, 7, 8, and 10)
through USB, install the driver for the ST-LINK/V2-1 that is available at the www.st.com
website.
In case the STM32 Nucleo-64-P board is connected to the PC before installing the driver, the
PC device manager may report some Nucleo interfaces as “Unknown”. To recover from this
situation, after installing the dedicated driver, the association of “Unknown” USB devices
found on the STM32 Nucleo-64-P board to this dedicated driver, must be updated in the
device manager manually.
Note: It is recommended to proceed by using the USB composite device, as shown in Figure 7.
Figure 7. USB composite device
6.4.2 ST-LINK/V2-1 firmware upgrade
The ST-LINK/V2-1 embeds a firmware upgrade mechanism for the in-situ upgrade through
the USB port. As the firmware may evolve during the lifetime of the ST-LINK/V2-1 product
(for example new functionalities, bug fixes, support for new microcontroller families), it is
recommended to keep the ST-LINK/V2-1 firmware up to date before starting to use an
STM32 Nucleo-64-P board. The latest version of this firmware is available at the www.st.com
website.
Table 5. ST-LINK jumper configuration
CN Definition Default position Comment
CN3
T_SWCLK / T_SWDIO ON [1-2] ON [3-4] ST-LINK/V2-1 functions enabled for
on-board programming (default)
T_SWCLK / T_SWDIO OFF [1-2] OFF [3-4] ST-LINK/V2-1 functions enabled from
external connector (SWD supported)

Hardware layout and configuration UM2206
18/52 UM2206 Rev 6
6.4.3 Using the ST-LINK/V2-1 to program/debug the STM32
To program the STM32, place the two jumpers marked in red on the CN2 connector, as
shown in Figure 8. Do not use the SWD connector to avoid disturbing the communication
with the STM32 microcontroller of the Nucleo-64-P board.
Figure 8. ST-LINK debugger: jumper configuration for on-board MCU
6.4.4 Using the ST-LINK/V2-1 to program/debug an external STM32
application.
It is very easy to use the ST-LINK/V2-1 to program the STM32 on an external application.
Simply remove the two jumpers from CN2, as shown in Figure 9, and connect the
application to the SWD debug connector according to Table 6.
Note: JP4 NRST (target STM32 RESET) must be OFF when CN3 pin 5 is used in an external
application.

UM2206 Rev 6 19/52
UM2206 Hardware layout and configuration
51
Figure 9. ST-LINK debugger: jumper configuration for external MCU
Table 6. Debug connector SWD
Connector Pin
number Pin name Signal name STM32 pin Function
SWD
CN3
1 1 VDD_TARGET:
AIN_1 PA0 VDD from application
2 2 T_JTCK PA5 SWD clock
3 3 GND PA12 Ground
4 4 T_JTMS PA14 SWD data
input/output
5 5 T_NRST PB0 RESET of target
STM32
6 6 T_SWO PA10 SWD out (optional)

Hardware layout and configuration UM2206
20/52 UM2206 Rev 6
6.5 power supply and power selection
6.5.1 External power supply input
Several DC power supplies can power the STM32 Nucleo-64-P board. It is possible to
supply the STM32 Nucleo-64-P board with any of the following sources:
5V_ST_LINK from the ST-LINK USB connector
VIN (7 V-12 V) from ARDUINO® connector or ST morpho connector
E5V from ST morpho connector
5V_USB_CHARGER from ST-LINK USB
3.3 V on ARDUINO® connector or ST morpho connector
Note: If an external 5V DC power source is used, a power supply unit or a piece of auxiliary
equipment complying with the EN-60950-1: 2006+A11/2009 standard, which must be safety
extra-low voltage (SELV) with limited power capability, must power the Discovery kit.
The power supply capabilities are shown in Table 7.
5V_ST_LINK is a DC power with limitations from the ST-LINK USB connector (USB type
Micro-B connector of ST-LINK/V2-1). In this case, the JP5 jumper must be on pins 1 and 2
to select the 5V_STL power source on the JP5 silkscreen. This is the default setting. If the
USB enumeration succeeds, the 5V_ST_LINK power is enabled, by asserting the
PWR_ENn signal (from STM32F103CBT6). This pin is connected to a power switch ST890,
Table 7. power supply capabilities
Input power
name
Connector
pins
Voltage
range
Max
current Limitation
VBUS
(5V_STLINK) CN1 pin 1 4.75 to 5.25 V 500 mA
The maximum current depends on the
USB enumeration:
– 100 mA without enumeration
– 500 mA with enumeration OK
VIN
CN8 pin 8
CN5 pin 24 7 to 12 V 800 mA
From 7 to 12 V only and input current
capability is linked to input voltage:
– 800 mA input current when VIN=7 V
– 450 mA input current when
7 V<VIN<9 V
– 300 mA input current when
10 V>VIN>9 V
– less than 300 mA input current when
VIN>10 V
E5V CN5 pin 6 4.75 to 5.25 V 500 mA
5V_USB_CHG CN1 pin 1 4.75 to 5.25 V 500 mA
The maximum current depends on the
USB wall charger used to power the
Nucleo board
3.3V
CN8 pin 4
CN5 pin 16
JP6 pin 2
3.0 to 3.6 V - Used when ST-LINK part of PCB not
used or removed and SB13 OFF
