1 EVALUATION BOARD
The STA304 Digital Audio Processor is a single chip device implementing end to end digital solution for audio
application. In conjunction with STA500 Power Bridge it gives the full digital DSP-to-Power high quality chain
with no need for Digital-to Analog converters.
The STA304 Evaluation kit is an example for a general application involving all the STA304 and STA500 capa-
bilities, which gives the possibility to evaluate the system performances.
The evaluation kit consists of two boards, and control software. In the first board an STA304 and three STA500
are available, while the second is used to connect the main board to the PC. The control software allows then
to control all the evaluation board capabilities from a simple visual interface.
1.1 LPT Interface (LPT300)
In order to allow proper communication between the 3.3V powered (digital) evaluation board and a standard
LPT interface the STA304 evaluation kit includes also the LPT interface board (LPT300) shown in Figure 1.
Basically the interface will perform a signal level translation between 3.3V and 5V in both directions.
The LPT300 interface take the supply (both 3.3V and 5V) from pins 17 and 18 of the connector J2 (see Figure
2), so no regulators are on board. There is the possibility to have also the regulator on board (U3 and U4), but
in that case the pins 17 and 18 should be disconnected from the STA304 evaluation board. In Figure 2 the com-
ponents that are not needed for LPT300 (such as regulators) are drawn in dashed lines.
IMPORTANT: the LPT300 interface can have some problems if the PC LPT port is configured as "bi-direction-
al". In order to perform a quick test, after the LPT300 is connected to the STA304 board, switch on the supply
and try the "Test procedure" (see the SETUP section). If the test doesn't succeed, try to check the PC parallel
port settings: most PC in fact, can configure their LPT interface in different modes (SPP/EPP/ECP) and it could
happen that some of those configurations are not well suited to control our evaluation kit.
Figure 1. LPT300 Interface Layout
- JP1, JP3 open without U3
and U4. Supply from J2
connector (default for
LPT300).
by Luca Molinari
STA304 + STA500 DIGITAL AUDIO PROCESSOR
EVALUATION BOARD OPERATING MANUAL
www.BDTIC.com/ST

AN1456 APPLICATION NOTE
2/13
Figure 2. LPT300 interface schematic
SCL
SDA
PWDN
AC97_MODE
RESET
PWRDN THWARN Left
THWARN Right
THWARN LFE
