Operating instructions
Additional languages www.r-stahl.com
EN
GRP Flameproof Audible Signal -
110 dB(A)
Series YA6S

2
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
Contents
1 General Information ............................................................................................3
1.1 Manufacturer .......................................................................................................3
1.2 Information regarding the operating instructions .................................................3
1.3 Further documents ..............................................................................................3
1.4 Conformity with standards and regulations .........................................................3
2 Explanation of the symbols .................................................................................4
2.1 Symbols in these operating instructions .............................................................4
2.2 Warning notes .....................................................................................................5
2.3 Symbols on the device ........................................................................................5
3 Safety notes ........................................................................................................6
3.1 Operating instructions storage ............................................................................6
3.2 Safe use ..............................................................................................................6
3.3 Modifications and alterations ..............................................................................6
4 Function and device design ................................................................................6
4.1 Function ..............................................................................................................6
5 Technical data .....................................................................................................7
6 Transport and storage .........................................................................................8
7 Mounting and installation ....................................................................................9
7.1 Dimensions / fastening dimensions ....................................................................9
7.2 Mounting / dismounting, operating position ......................................................10
7.3 Installation .........................................................................................................16
8 Commissioning .................................................................................................16
9 Operation ..........................................................................................................17
9.1 Troubleshooting ................................................................................................17
10 Maintenance and repair ....................................................................................17
10.1 Maintenance .....................................................................................................18
10.2 Repair ...............................................................................................................18
10.3 Returning the device .........................................................................................19
11 Cleaning ............................................................................................................19
12 Disposal ............................................................................................................19
13 Accessories and Spare parts ...........................................................................19

224617 / YA6S60300010
2018-03-26·BA00·III·en·02
General Information
3
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
1 General Information
1.1 Manufacturer
1.2 Information regarding the operating instructions
ID-No.: 224617 / YA6S60300010
Publication Code: 2018-03-26·BA00·III·en·02
The original instructions are the English edition.
They are legally binding in all legal affairs.
1.3 Further documents
• Data sheet
For documents in additional languages, see www.r-stahl.com.
1.4 Conformity with standards and regulations
See certificates and EC Declaration of Conformity: www.r-stahl.com.
The device has IECEx approval. For certificate please refer to the IECEx homepage:
http://iecex.iec.ch/
R. STAHL Schaltgeräte GmbH
Business Unit Lighting & Signalling
Nordstr. 10
99427 Weimar
Germany
R. STAHL Schaltgeräte GmbH
Am Bahnhof 30
74638 Waldenburg
Germany
Phone:
Fax:
Internet:
E-mail:
[phone]
[phone]
www.r-stahl.com
[email protected]
Phone:
Fax:
Internet:
E-mail:
[phone]
[phone]
www.r-stahl.com
[email protected]

Explanation of the symbols
4224617 / YA6S60300010
2018-03-26·BA00·III·en·02
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
2 Explanation of the symbols
2.1 Symbols in these operating instructions
Symbol Meaning
Tips and recommendations on the use of the device
General danger
Danger due to explosive atmosphere
Danger due to energised parts
= Sounder
= Earth
= Sounder Stage 1
= Sounder Stage 2
= Sounder Stage 3
= Sounder Tone
= Telephone initiate
1
2
3

224617 / YA6S60300010
2018-03-26·BA00·III·en·02
Explanation of the symbols
5
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
2.2 Warning notes
Warnings must be observed under all circumstances, in order to minimize the risk due to
construction and operation. The warning notes have the following structure:
• Signalling word: DANGER, WARNING, CAUTION, NOTICE
• Type and source of danger/damage
• Consequences of danger
• Taking countermeasures to avoid the danger or damage
2.3 Symbols on the device
DANGER
Danger to persons
Non-compliance with the instruction results in severe or fatal injuries to
persons.
WARNING
Danger to persons
Non-compliance with the instruction can result in severe or fatal injuries to
persons.
CAUTION
Danger to persons
Non-compliance with the instruction can result in light injuries to persons.
NOTICE
Avoiding material damage
Non-compliance with the instruction can result in material damage to the device
and / or its environment.
Symbol Meaning
05594E00
CE marking according to the current applicable directive.
02198E00
According to marking, device certified for hazardous areas.
15649E00
Input
15648E00
Output

Safety notes
6224617 / YA6S60300010
2018-03-26·BA00·III·en·02
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
3 Safety notes
3.1 Operating instructions storage
• Read the operating instructions carefully and store them at the mounting location of
the device.
• Observe applicable documents and operating instructions of the devices to be
connected.
3.2 Safe use
• Read and observe the safety notes in these operating instructions!
• Observe characteristic values and rated operating conditions on the rating and data
plates!
• Observe additional information plates on the device!
• Use the device in accordance with its intended and approved purpose only!
• We cannot be held liable for damage caused by incorrect or unauthorized use or by
non-compliance with these operating instructions.
• Before installation and commissioning, make sure that the device is not damaged!
• Work on the device (installation, maintenance, overhaul, repair) may only be carried
out by appropriately authorized and trained personnel.
3.3 Modifications and alterations
4 Function and device design
4.1 Function
Product series YA6S is designed to provide an audible signal which can be used to alert,
warn or draw attention to an event. Corrosion resistance is a key feature of the device
which is ideally suited for applications in the harshest of environments both onshore and
offshore.
DANGER
Explosion hazard due to modifications and alterations to the device!
Non-compliance results in severe or fatal injuries.
• Do not modify or alter the device.
No liability or warranty for damage resulting from modifications and
alterations.
DANGER
Explosion hazard due to improper use!
Non-compliance results in severe or fatal injuries.
• Use the device only according to the operating conditions described in
these operating instructions.

224617 / YA6S60300010
2018-03-26·BA00·III·en·02
Technical data
7
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
5 Technical data
Explosion Protection
Global (IECEx)
Gas and dust IECEx BAS 14.0064
IEC 60079-0: 2011 / IEC 60079-1: 2007 / IEC 60079-31: 2013
Ex d IIB T* Ta -** ... +** °C Gb
Ex d IIC T* Ta -** ... +** °C Gb
Ex tb IIIC T*** °C Ta -** ... +** °C Db IP66
Europe (ATEX)
Gas and dust Baseefa14ATEX0126
EN 60079-0: 2012 / EN 60079-1: 2007 / EN 60079-31: 2009
(IEC 60079-31: 2013)
E II 2 G Ex d IIB T* Ta -** ... Ta +** °C Gb
E II 2 G Ex d IIC T* Ta -** ... Ta +** °C Gb
E II 2 D Ex tb IIIC T*** °C Ta -** ... +** °C Db IP66
Product variant table
Certifications and certificates
Certificates IECEx, ATEX, Kazakhstan (TR), Russia (TR), Belarus (TR)
Ambient conditions
Operating
temperature range
Power and
voltage
Temperature
class
Max. surface
temperature
Ambient temperature
range
24 V DC T6 T75 °C -60 to +70 °C
48 V DC T6 T75 °C -60 to +70 °C
115 V AC T6 T77 °C -60 to +60 °C
T5 T87 °C -60 to +70 °C
240 V AC T6 T77 °C -60 to +60 °C
T5 T87 °C -60 to +70 °C
24/48 V DC -60 to +70 °C
115 V AC -40 to +60 °C
230 V AC -40 to +60 °C

Transport and storage
8224617 / YA6S60300010
2018-03-26·BA00·III·en·02
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
For further technical data, see www.r-stahl.com.
6 Transport and storage
• Transport and store the device only in the original packaging.
• Store the device in a dry place (no condensation) and vibration-free.
• Do not drop the device.
Technical Data
Electrical data
Rated operational
voltage
24 or 48 V DC
115 or 230 V AC
Current consumption
Operational
parameters
+/-10 %
Line monitoring yes
Inrush current
Acoustic data
Volume max. 110 dB(A)
Volume control 18 dB(A) adjustment
Sound stages
Sound selection via DIL switch
Mechanical data
Material
Enclosure glass reinforced polyester
Horn and trumpet flame retardant ABS
Assembly parts stainless steel
Bracket stainless steel
Labels polyester foil, adhesive
Degree of protection IP66 / IP67 acc. to IEC 60529
Mounting / Installation
Connection 2.5 mm2 terminals
24 V DC 280 mA
48 V DC 250 mA
115 V AC 76 mA
230 V AC 40 mA
DC 24 V / 48 V AC 115 V AC 230 V
Imax duration Imax duration Imax duration
14.5 A 220 μs 10 A 300 μs 25 A 310 μs
24 / 48 V DC 3
115 / 230 V AC 2

224617 / YA6S60300010
2018-03-26·BA00·III·en·02
Mounting and installation
9
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
7 Mounting and installation
7.1 Dimensions / fastening dimensions
Dimensional Drawings (All Dimensions in mm [inches]) - Subject to Alterations
17150E00 16919E00
GRP Audible Signal Series YA6S
with L-Bracket
GRP Audible Signal Series YA6S
without L-Bracket
17159E00
L-Bracket
[ 5,70] Ø
263,50 [10,37]
95
[3,74]
33 [1,30]
Ø 9
[ 0,35]
Ø
75
[2,95]
105
[4,13]
[6,12]
155,50
189 [7,44]
[4,61]
117
Ø 145
178,50 [7,03]
75 [2,95]
32
[1,26]
178,50 [7,03]
33
[1,30]
3 x M6
[ 5,70]
Ø
Ø
145
263,50 [10,37]
20 [,9]0 7
75 2 95[, ]
ø9 [,]ø0 35
117 [4,61]
105 4 13[, ]

Mounting and installation
10 224617 / YA6S60300010
2018-03-26·BA00·III·en·02
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
7.2 Mounting / dismounting, operating position
• Mount the device on a flat surface suitable for its weight.
• Insert the cables using certified and flameproof cable glands which are suitable for the
gas group.
• Close unused entries using certified and flameproof stopping plugs.
7.2.1 Installation Conditions for Electrical Connection
DANGER
Risk of explosion!
Risk of injuries and material damage!
• Terminal sleeves are fitted, they must be gas-tight and applied with a
suitable tool.
DANGER
Explosion hazard!
Risk of injuries and material damage!
• Carefully remove or replace the components.
• Exposed joint surfaces must not be damaged and must be protected
from dust and dirt.
• Install the end flanges squarely without applying any force. Do not use
a hammer or other tools when working on the flanges and do not use the
fixing screws to pull down the flanges.
DANGER
Explosion hazard!
Risk of injuries and material damage!
• Only use cable glands with corresponding certificate. The cable glands
must be flameproof (Ex d) and suitable for the type of cable used.
• Close unused open holes in the enclosure with flameproof stopping
plugs.
• Close unused cable glands using flameproof plugs.
• Cable glands, stopping plugs and plugs must meet the requirements of
IEC/EN 60079-14.
• Installation of the cable gland must be performed in accordance with the
manufacturer's instructions.
• Cable entry temperature may reach 70 °C.
• To ensure degree of protection IP 66, a non-hardening sealant must be
applied to the threads.
DANGER
Danger due to energised parts!
Risk of death or severe injuries!
• Before opening and dismounting the device, disconnect it from the
power supply.
• Secure the device against unauthorized switching.

224617 / YA6S60300010
2018-03-26·BA00·III·en·02
Mounting and installation
11
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
7.2.2 Installation with mounting bracket
• Loosen 6 x cheese head screws (4) and remove end cap (3)
• Prepare cable gland
• Ensure earth connection
• Install cable gland
• Connect cables (see electrical connection)
• Fix bracket to wall • Attach device
17161E00 17219E00
17220E00
1Horn
2PCB
3End cap
4 Cheese-head screws M5 x 25
1
2
3
4

Mounting and installation
12 224617 / YA6S60300010
2018-03-26·BA00·III·en·02
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
7.2.3 Reassembly of Enclosure
• Lift end cap towards device.
• Replace cheese-head screws M5 x 25 (see information below) and tighten the screws
with a tightening torque of 4 Nm.
7.2.4 Electrical Connection
Key Components
Cable Connection
Interconnection of devices parallel
Up to 10 devices with common supplies may be connected as a single system loop.
See wiring diagrams for further information.
Circuit diagrams
17230E00
1 plug for sounder
2 PCB Termination board
3 Terminal blocks
4 Sound selection switch
(see tone table)
Key components YL6S
• The terminals accept wires of 2.5 mm2 or 14 to 18 AWG.
Line monitoring for devices with DC
• by reverse polarity
• by connecting an EOL resistor between 0 V and +V.
The resistance value is defined by the system developer.
Two signal levels for devices with AC
• by connecting the third wire.
Three signal levels for devices with DC
• by connecting the third and fourth wire.
4
3
2
1

224617 / YA6S60300010
2018-03-26·BA00·III·en·02
Mounting and installation
13
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
7.2.5 Earth Connection
Use of metallic cable glands
A slip on earth tag is provided with each device. This should be connected to the external
earth stud detailed above.
Device material
The GRP material used for the device enclosure has electrically conductive properties.
The material is antistatic and prevents build-up of electrical charges on its surface.
Surface resistivity < 108 Ω accordance to IEC 60093
17228E00 17193E00
Circuit diagram DC voltages Circuit diagram AC voltages
= Sounder Stage 1
= Sounder Stage 2
= Sounder Stage 3
17191E00
Earth connection
0V
1
+V
1
2
2
TELEPHONE
INITIATE
0V
+V +V
+V
3
+V
3
+V
N
N
1
L
1
L
2
L
2
L
L
L
TELEPHONE
INITIATE
NEUTRALNEUTR
0V
LIVE (Vac)
24/48 Vdc
2ND
STAGE
STROBE
AC/DC
1
2
3
E

Mounting and installation
14 224617 / YA6S60300010
2018-03-26·BA00·III·en·02
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
7.2.6 Sound Tone Selection
• For signal tone selection and its switch positions refer to the table below.
• Check if the correct switch positions of the selected signal tones have been selected.
• Do not use tone 12, 14 and 32 for AC variants.
Tone table
Tone
no.
Version Frequency
Sound selection
switch 12345
(ON = 1)
Repeti-
tion rate
(sec)
Special application
Tone
01
v800-1000 00000 0.5 Fire alarms - Level
crossing
Tone
02
Alternate two-tone 2500-3100 10000 0.5 Security alarms
Tone
03
Alternate fast two-tone 800-1000 01000 0.25 Increased urgency -
Level crossing
Tone
04
Alternate fast two-tone 2500-3100 11000 0.25 Security deterrent
Tone
05
Alternate two-tone 440-554 00100 0.4/0.1 AFNOR, France
Tone
06
Alternate two-tone 430-470 10100 1.0
Tone
07
Alternate very fast
two-tone
800-1000 01100 0.13
Tone
08
Alternate very fast
two-tone
2500-3200 11100 0.07
Tone
09
Alternate two-tone 440-554 00010 2.0 Turn out, Sweden
(SS 031711)
Tone
10
Continuous tone 700 10010 All clear, Sweden
(SS 031711)
Tone
11
Continuous tone 1000 01010
Tone
12
Continuous tone 1000 11010
Tone
13
Continuous tone 2300 00110
Tone
14
Continuous tone 440 10110
Tone
15
Interrupted tone 1000 01110 2.0
Tone
16
Interrupted tone 420 11110 1.25 AS2220, Australia
Tone
17
Interrupted tone 1000 00001 0.5
Tone
18
Interrupted tone 2500 10001 0.25
Tone
19
Interrupted tone 2500 01001 0.5

224617 / YA6S60300010
2018-03-26·BA00·III·en·02
Mounting and installation
15
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
The PFEER sound signals recommended by UKOOA are:
Details sound selection switch
Tone
20
Interrupted tone 700 11001 6/12 Important message,
Sweden
Tone
21
Interrupted tone 1000 00101 1.0
Tone
22
Interrupted tone 700 10101 4.0 Air-raid alarm,
Sweden
Tone
23
Interrupted tone 700 01101 0.25 Local warning,
Sweden
Tone
24
Interrupted tone 720 11101 0.7/0.3 Industrial alarm,
Germany
Tone
25
Interrupted, fast,
rising volume
1400 00011 0.25
Tone
26
Fast siren 250-1200 10011 0.085
Tone
27
Rising constantly,
falling
1000 01011 10/40/10 Industrial alarm,
Germany
Tone
28
ISO 8201 Evacuation 800-1000 11011 As stand-
ard
International
evacuation alarm
Tone
29
Fast whoop 500-1000 00111 0.15
Tone
30
Slow whoop 500-1200 10111 4.5 Evacuation,
The Netherlands
Tone
31
Reverse sweep 1200-500 01111 1.0 Fire alarm, Germany
(DIN 33404)
Tone
32
Siren 500-1200 11111 3.0
General alarm Sound signal 15 Interrupted tone 1000 Hz
PAPA Sound signal 31 Reverse sweep 1200-500 Hz
Toxic gas Sound signal 11 Continuous tone 1000 Hz
17192E00
Tone table
TELEPHONE
INITIATE
NEUTRALNEUTR
0V
LIVE (Vac)
24/48 Vdc
2ND
STAGE
3RD
STAGE
STROBE
AC/DC
123

Commissioning
16 224617 / YA6S60300010
2018-03-26·BA00·III·en·02
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
7.3 Installation
8 Commissioning
Before commissioning, ensure the following:
• the device has been installed according to regulations.
• the power supply voltage and the rated operational voltage are identical.
• the required cable diameter for cable glands has been used.
• the cable entries and stopping plugs have been securely tightened.
• the cables are correctly connected.
• the connection has been performed correctly.
• all screws and nuts are tightened according to regulations.
• the connection chamber is clean.
• the device is not damaged.
• no foreign bodies are inside the device.
• the device is sealed according to regulations.
WARNING
Danger of electric shock due to energised parts!
Non-compliance can result in severe or fatal injuries.
• All connections and wiring must be disconnected from the power supply.
• Secure the connections against unauthorized switching.
DANGER
Explosion hazard!
Risk of injuries and material damage!
• Operate the device only if it is not damaged.
• If the thread is damaged, the device must be replaced immediately.
• Handle the device and the components very carefully.
• Exposed joint surfaces must be protected from dust, dirt and damage.
• Mount the end flanges squarely and do not apply any force.
• Do not use a hammer or any other metal instruments to work on the
flange.
• Do not use the fixing screws to pull down the flange.
• Install the device only in a clean and dry operating environment.
DANGER
Explosion hazard due to incorrect installation!
Non-compliance results in severe or fatal injuries.
• Check the device for proper installation and function before
commissioning.
• Comply with the national regulations.

224617 / YA6S60300010
2018-03-26·BA00·III·en·02
Operation
17
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
9 Operation
The device is used to warn and alert by means
• of a sound signal.
9.1 Troubleshooting
If an error occurs please re-visit the earlier sections of this document.
If the error cannot be eliminated using the mentioned procedures:
• Contact R. STAHL Schaltgeräte GmbH.
For fast processing, have the following information ready:
• Type and serial number
• Purchase information
• Error description
• Intended use (in particular input / output wiring)
10 Maintenance and repair
WARNING
Risk of electric shock or malfunctioning of the device due to unauthorized
work!
Non-compliance can result in severe injuries and material damage.
• Work performed on the device must only be carried out by appropriately
authorized and qualified electricians.

Maintenance and repair
18 224617 / YA6S60300010
2018-03-26·BA00·III·en·02
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
10.1 Maintenance
• Determine the type and extent of inspections in compliance with the relevant national
regulations.
• Adapt inspection intervals to the operating conditions.
The following tests and measures must be carried out during regular maintenance.
10.2 Repair
Observe the relevant national regulations in the country of use.
Check Measures
the permissible ambient temperature If exceeding the permissible ambient
temperature or falling below the device
must be taken out of operation.
the enclosure components for formation
of cracks and damage.
Replace the exchangeable enclosure
components. If the enclosure components
are non-exchangeable, the device must be
taken out of operation.
its intended use If the device is not used according to its
intended use, it must be taken out o
f operation.
if the conductors are clamped properly clamp loose conductors tightly.
the cables for ageing and damage replace damaged or aged cables.
the seals for ageing and damage replace damaged, aged and porous seals
and completely change enclosure
components with foamed seal.
DANGER
Explosion hazard due to improper repair!
Non-compliance results in severe or fatal injuries.
• Repair work on the devices must be performed only by
R.STAHL Schaltgeräte GmbH.

224617 / YA6S60300010
2018-03-26·BA00·III·en·02
Cleaning
19
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
EN
GRP Flameproof Audible Signal - 110 dB(A)
Series YA6S
10.3 Returning the device
• Only return or package the devices after consulting R. STAHL!
Contact the responsible representative from R. STAHL.
R. STAHL's customer service is available to handle returns if repair or service is required.
• Contact customer service personally.
or
• Go to the www.r-stahl.com website.
• Under "Support" > "RMA form", select "Request RMA slip".
• Fill out the form and send it.
Confirmation will be sent. R. STAHL's customer service will contact you.
You will receive an RMA slip after speaking with customer service.
• Send the device along with the RMA slip in the packaging to
R. STAHL Schaltgeräte GmbH (refer to Section 1.1 for the address).
11 Cleaning
• Clean the device only with a cloth, brush, vacuum cleaner or similar items.
• When cleaning with a damp cloth, use water or mild, non-abrasive, non-scratching
cleaning agents.
• Do not use aggressive detergents or solvents.
12 Disposal
• Observe national and local regulations and statutory regulation regarding disposal.
• Separate materials when sending it for recycling.
• Ensure environmentally friendly disposal of all components according to the statutory
regulations.
13 Accessories and Spare parts
NOTE
Malfunction or damage to the device due to the use of non-original components.
Non-compliance can result in material damage.
• Use only original accessories and spare parts from R. STAHL Schaltgeräte GmbH.
For accessories and spare parts, see data sheet on our homepage
www.r-stahl.com.
