Stamina INSTRIDE 55-1615 User manual

Owner's Manual
55-1615
STAMINA PRODUCTS
MADE IN CHINA
Product May Vary Slightly
From Pictured.
2007, 06
Exercise can present a health
risk. Consult a physician
beforebeginningany exercise
program with this equipment.
If you feel faint or dizzy,
immediately discontinue use
of this equipment. Serious
bodily injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur if
all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
tightened prior to each use.
Followallsafetyinstructionsin
this manual.
When calling for parts or
service, please specify the
following number.
WARNING
CAUTION:
Weight on this product should not exceed 250 lbs.
2007 Stamina Products, Inc.
2040 N. Alliance, Springfield, MO 65803
Customer Service Number
1 [phone]
www.staminaproducts.com
This Product is Produced Exclusively by

TABLE OF CONTENTS
Before starting any exercise or conditioning program you should consult with your personal
physician to see if you require a complete physical exam. This is especially important if you
are over the age of 35, have never exercised before, are pregnant, or suffer from any
illness. READ AND FOLLOW THE SAFETY PRECAUTIONS. FAILURE TO FOLLOW
THESE INSTRUCTIONS CAN RESULT IN SERIOUS BODILY INJURY.
WARNING:
2
SAFETY INSTRUCTIONS
WARNING:
Safety Instructions 2
Before You Begin 4
Hardware Identification Chart 5
Assembly Instructions 6
Set Up Instructions 10
Operational Instructions 11
Maintenance 13
Storage 13
Conditioning Guidelines 14
Warm-up and Cool-Down 15
Product Parts Drawing 16
Parts List 17
Warranty 19
Notes 20
Fax/Mail Ordering Form 22
Page Page
To reduce the risk of serious injury, read the following Safety Instructions before
using the INSTRIDE ELLIPTICAL.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
Read all warnings posted on the INSTRIDE ELLIPTICAL.
Read this owner's/user's manual and follow it carefully before using the INSTRIDE ELLIPTICAL.
We recommend that two people be available for assembly of this product.
Keep children away from the INSTRIDE ELLIPTICAL. Do not allow children to use or play on the
INSTRIDE ELLIPTICAL. Keep children and pets away from the INSTRIDE ELLIPTICAL when
it is in use.
It is recommended that you place this exercise equipment on an equipment mat.
Set up and operate the INSTRIDE ELLIPTICAL on a solid level surface. Do not position the
INSTRIDE ELLIPTICAL on loose rugs or uneven surfaces.
Make sure that adequate spaceis availableforaccesstoandaround the INSTRIDE ELLIPTICAL.
Inspect the INSTRIDE ELLIPTICAL for worn or loose components prior to use.
Tighten/replace any loose or worn components prior to using the INSTRIDE ELLIPTICAL.
Consult a physician prior to commencing an exercise program. If, at any time during exercise, you
feel faint, dizzy, or experience pain, stop and consult your physician.
Follow your physician's recommendations in developing your own personal fitness program.
Always choose the workout which best fits your physical strength and flexibility level. Know your
limits and train within them. Always use common sense when exercising.
Do not wear loose or dangling clothing while using the INSTRIDE ELLIPTICAL.
Never exercise in bare feet or socks; always wear correct footwear, such as running, walking, or
crosstraining shoes. Be sure that they fit well, provide foot support and feature non-skid rubber
soles.
Be careful to maintain your balance while using, mounting, dismounting, or assembling the
INSTRIDE ELLIPTICAL, loss of balance may result in a fall and serious bodily injury.
Keep both feet firmly and securely on the pedal caps while exercising.
The INSTRIDE ELLIPTICAL should not be used by persons weighing over 250 pounds.
The INSTRIDE ELLIPTICAL should be used by only one person at a time.
The INSTRIDE ELLIPTICAL is for consumer use only. It is not for use in public or semipublic
facilities.
Use two people to move the INSTRIDE ELLIPTICAL.

THANK YOU FOR PURCHASING THE
STAMINA INSTRIDE ELLIPTICAL
To help you get started, we have pre-assembled most of your
INSTRIDE ELLIPTICAL at the factory with the exception
of those few parts left unassembled for shipping purposes.
Simply follow the few assembly instructions set forth in this manual.
With regular workouts you will be getting your body into shape
and on your way to achieving a happier and healthier lifestyle.
3
Should you have any questions,
please call our Customer Service Department toll-free number,
1 [phone]
Monday - Thursday, 7:30 A.M. - 5:00 P.M. Central Time.
Friday, 8:00 A.M. - 3:00 P.M., Central Time.
TELEPHONE
CUSTOMER SERVICE
Tel: [phone]
FAX
CUSTOMER SERVICE
Fax: [phone]
MAIL
STAMINA PRODUCTS, INC.
ATTN: Customer Service
P.O. Box 1071
Springfield, MO. 65801-1071
ONLINE
CUSTOMER SERVICE
[e-mail]
[e-mail]
www.staminaproducts.com
CALL US FIRST

4
THE FOLLOWING TOOL IS INCLUDED FOR ASSEMBLY :
Upright
Left Cover
Front Stabilizer
Right Cover
Right Pedal Cap
Handrail
Rear Stabilizer
Right Pedal Arm
Foam Grip
Leveling Cap
Tension Knob
Meter
Endcap
Wrench
Allen Wrench (6mm)
BEFORE YOU BEGIN
Thank you for choosing the INSTRIDE
ELLIPTICAL. We take great pride in producing this
quality product and hope it will provide many hours
ofqualityexercisetomakeyoufeelbetter, look better
and enjoy life to its fullest.
Yes, it's a proven fact that a regular exercise
program can improve your physical and mental
health. Too often, our busy lifestyles limit our time
and opportunity to exercise. The INSTRIDE
ELLIPTICAL provides a convenient and simple
method to begin your assault on getting your body in
shapeandachievingahappierandhealthierlifestyle.
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.
Read this manual carefully before using the
INSTRIDE ELLIPTICAL.
Although Stamina constructs its products with the
finest materials and uses the highest standards of
manufacturing and quality control, there can
sometimes be missing parts or incorrectly sized
parts. If you have any questions or problems with
the parts included with your INSTRIDE
ELLIPTICAL, please do not return the product.
Contact us FIRST!
If a part is missing or defective, please call us toll
free at 1-800-375-7520 (in the U.S.). Our Customer
ServiceStaffisavailabletoassistyoufrom7:30A.M.
to5:00P.M.(CentralTime)MondaythroughThursday
and 8:00A.M. to 3:00 P.M. (CentralTime) on Friday.
If you would like to contact us on-line, go to our
websiteatwww.staminaproducts.com andaccessthe
Customer Service section.
Be sure to have the name and model number of
the product available when you contact us.
Left Pedal Cap Main Frame
Warning Label

5
Part No. and Description Qty
HARDWARE IDENTIFICATION CHART
This chart is provided to help identify the hardware used in the assembly process. Place the washers, the
end of the bolts, or screws on the circles to check for the correct diameter. Use the small scale to check the
length of the bolts and screws.
NOTICE: The length of all bolts and screws except those with flat heads is
measured from below the head to the end of the bolt or screw.
Flat head bolts and screws are measured from the top of the
head to the end of the bolt or screw.
mm.
in.
INCHES
MILLIMETERS
11/2021/2 31/2 41/2 51/2 61/2
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
6 8 10 12
3/16" 5/16" 1/2"3/8"1/4"
length
length
After unpacking the unit, open the hardware bag and make sure that you have all the following items.
Some hardware may be already attached to the part.
49 Bolt, Button Head (M8 x 1.25 x 57mm) 2
50 Bolt, Button Head (M8 x 1.25 x 60mm) 4
51 Bolt, Button Head (M8 x 1.25 x 100mm) 2
53 Bolt, Round Head (M6 x 1 x 43mm) 4
60 Nylock Nut (M8 x 1.25) 2
64 Acorn Nut (M8 x 1.25) 6
65 Arc Washer (M8) 8
66 Lock Washer (M8) 6

6
Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all
packing materials from your area and place them back into the box.Do not dispose of the packing materials
until assembly is completed. Read each step carefully before beginning. If you are missing a part please call
our toll-free number for assistance 1 [phone] or e-mail us at:
[e-mail]
ASSEMBLY INSTRUCTIONS
STEP 1
AttachtheFRONTSTABILIZER(2) ontotheMAIN FRAME(1) withBUTTONHEAD BOLTS(M8x1.25x60mm)
(50), ARC WASHERS(M8)(65), LOCK WASHERS(M8)(66), and ACORN NUTS(M8x1.25)(64).
STEP 2
AttachtheREAR STABILIZER(3) ontotheMAIN FRAME(1) withBUTTON HEAD BOLTS(M8x1.25x60mm)
(50), ARC WASHERS(M8)(65), LOCK WASHERS(M8)(66), and ACORN NUTS(M8x1.25)(64).
NOTE: You can adjust the LEVELING CAPS(44) on the REAR STABILIZER(3) to keep the INSTRIDE
ELLIPTICAL stable.

ASSEMBLY INSTRUCTIONS
7
Place the front end of the RIGHT PEDALARM(5) on the ROLLER(40). Connect the back end of the RIGHT
PEDAL ARM(5) to the RIGHT CRANK(32) located inside the CRANK DISK(29) as shown. Thread the
RIGHT PEDAL SHAFT(35) into the RIGHT CRANK(32) and tighten securely. Repeat on the left side.
STEP 4
There is a "L" decal on the LEFT PEDAL CAP(38), and a "R" decal on the RIGHT PEDAL CAP(39).
Attach the RIGHT PEDAL CAP(39) onto the RIGHT PEDAL ARM(5) with ROUND HEAD BOLTS
(M6x1x43mm)(53). Repeat on the left side.
NOTE:
There is a "L" decal on the LEFT PEDAL ARM(4), and a "R" decal on the RIGHT PEDAL
ARM(5).
The RIGHT PEDAL SHAFT(35) has right hand threads and is tightened by turning clockwise.
TheLEFT PEDALSHAFT(34) haslefthandthreadsandistightenedbyturning counter clockwise.
STEP 3
NOTE:
The LEFT and RIGHT PEDAL CAPS(38, 39) have a raised lip on two sides.Attach the LEFT and
RIGHT PEDAL CAPS(38, 39) to the LEFT and RIGHT PEDAL ARMS(4, 5) so the raised lip is on
the front and the inner side.
1.
2.
R
L
R
L

ASSEMBLY INSTRUCTIONS
8
STEP 5: Refer to the inset drawing. Lay the UPRIGHT(6) on the floor close to the front of the MAIN
FRAME(1). Turn the TENSION KNOB(22) on the UPRIGHT(6) counterclockwise as far as it can go, so the
cable end extends out of the metal fitting as far as possible. Connect the CABLE END of the TENSION
KNOB(22) into the SPRING HOOK on the end of the TENSION CABLE(21). Pull the CABLE on the
TENSION KNOB(22) firmly and insert the cable through the slot in the bracket. Then insert the METAL
FITTING on the end of the CABLE of the TENSION KNOB(22) into the hole at the end of the slot in the
BRACKET. Adjust the TENSION KNOB(22) and verify that the SPRING HOOK moves when the TENSION
KNOB(22) is adjusted.
Bracket
Cable End
Spring Hook
Metal Fitting
Insert the UPRIGHT(6) into the MAIN FRAME(1) and secure with BUTTON HEAD BOLTS
(M8x1.25x57mm)(49), ARC WASHERS(M8)(65), and NYLOCK NUTS(M8x1.25)(60).
STEP6: There is a strap attached inside of the UPRIGHT(6). This strap is to assist in pulling the SENSOR
WIRE(24) through the UPRIGHT(6).
Tie the strap to the plug end of the SENSOR WIRE(24). Pull the strap from the top of the UPRIGHT(6) to
pull the SENSOR WIRE(24) through the UPRIGHT(6) as shown in the above illustration. The SENSOR
WIRE(24) must extend out the top of the UPRIGHT(6).
Make sure the NYLOCK NUTS(M8x1.25)(60) fit into the hex holes on the top of the MAIN
FRAME(1) before tightening the BUTTON HEAD BOLTS(M8x1.25x57mm)(49).
Be careful not to damage the SENSOR WIRE(24) when assembling the UPRIGHT(6).
1.
2.
STEP 7
NOTE:
Strap
Strap

ASSEMBLY INSTRUCTIONS
9
STEP 8
Attach the HANDRAIL(7) ontothe UPRIGHT(6) with BUTTON HEAD BOLTS(M8x1.25x100mm)(51),ARC
WASHERS(M8)(65), LOCK WASHERS(M8)(66), and ACORN NUTS(M8x1.25)(64).
STEP 9
Installan AAAbattery into the METER(23).Seepage11fordetailedbatteryinstallationinstructions.Connect
the SENSOR WIRE(24) to the METER(23). Slide the METER(23) onto the bracket on the UPRIGHT(6).
CAUTION: Be careful not to damage the SENSOR WIRE(24) when sliding the METER(23).

SET UP INSTRUCTIONS
10
Equipment Mat
Adjust the LEVELING CAPS(44) on the REAR STABILIZER(3) so that the INSTRIDE
ELLIPTICAL sets on the floor without rocking.
Grasp the HANDRAIL(7) and REAR STABILIZER(3) to move the INSTRIDE ELLIPTICAL,
two people are required for moving. Do not use the Pedal Arms to move the INSTRIDE
ELLIPTICAL. The Pedal Arms will move and may pinch your hand or fingers.
LEVELING:
MOVING:
Locate and read the WARNING LABEL(69) on the INSTRIDE ELLIPTICAL. Make sure that
all users read the WARNING LABEL(69).
CAUTION:
FUNCTION INSPECTION:
Visually inspect the INSTRIDE ELLIPTICAL to verify that assembly is as shown in the above illustration.
Check the function of the INSTRIDE ELLIPTICAL. Stand on the foot pedals and place your hands at a
comfortable position on the handrail. Slowly move your highest foot forward and follow the natural path of
the machine. Turn the crank slowly through one complete revolution to verify that the drive train functions
properly. Adjust the TENSION KNOB(22) and verify that it functions properly.
Place theINSTRIDE ELLIPTICAL intheareawhere it willbeused.Itisrecommendedthat the INSTRIDE
ELLIPTICAL be placed on an equipment mat. The INSTRIDE ELLIPTICAL is approximately 33 1/2" long
x 17 3/4" wide x 46 3/4" tall. (These dimensions may vary up to one inch.)An area 4 feet wide x 5.5 feet long
is required for safe operation of the INSTRIDE ELLIPTICAL. Make sure that adequate space is available
for access to and passage around the INSTRIDE ELLIPTICAL.

11
USING THE ELECTRONIC METER
CALORIES:
TIME:
DISTANCE:
POWER OFF:
AutomaticallyscansTIME, SPEED,DISTANCE, andCALORIES in sequence with achange
every four seconds. Press and release the button until "SCAN" appears on the display.
Automaticshut offafter fourminutesofinactivity.
POWER ON:
FUNCTIONS:
Displays the time from one second up to 99:59 minutes.
SPEED:
SCAN:
FUNCTION BUTTON:
Displays the current speed from zero to 999.9 Miles per hour.
Displays the calorie consumption from zero to 999.9 Kcal.
Thecaloriereadoutisanestimate foranaverageuser.Itshouldbe usedonlyas acomparison
between workouts on this unit.
Displays the distance from zero to 999.9 miles.
OPERATIONAL INSTRUCTIONS
Pedal movement or press the button.
Open the Battery Door on the back of the meter.
The meter operates with an AAA battery, included. Refer to the
illustration to install or replace the battery.
1.
2.
HOW TO INSTALL AND REPLACE BATTERY:
Rechargeable battery is not recommended.1.
NOTE:
The meter will shut off automatically after four minutes of inactivity. All function values will
be kept. Push the button and hold it down for three seconds to reset all functions to zero.
NOTE:
AAA Battery
Press and release to select functions.
Press and hold for three seconds to reset all
functions to zero.
MODE/RESET :

OPERATIONAL INSTRUCTIONS
To increasetheload,turnthe TENSION KNOB(22) clockwise.
To decrease the load, turn the TENSION KNOB(22)
counterclockwise.
LOAD ADJUSTMENT
12
EXERCISE WORKOUT
To start using the INSTRIDE ELLIPTICAL simply stand on the foot pedals with the front of your shoes
close to the front edge of the pedal cap. Place your hands at a comfortable position on the handrail. Simply
move your highest foot forward and follow the natural path of the machine.
Start on a load level that is comfortable to familiarize yourself with the machine. Once you are comfortable
start adjusting the load level to achieve the workout desired.
Forward and Reverse
The INSTRIDE ELLIPTICAL can be used in the forward and reverse direction to vary the muscles that
you work out. This will also vary your workout helping you to stay motivated. To change directions, simply
slow the pedals down until they stop and switch directions.
Load Level Adjustment
The load level of INSTRIDE ELLIPTICAL can be changed at any time during your workout.Adjusting your
load level will allow you to increase or decrease your intensity level.

STORAGE
13
1.
2.
3.
4.
To store the INSTRIDE ELLIPTICAL simply keep it in a clean dry place.
TheINSTRIDE ELLIPTICALis approximately33 1/2" long x173/4"widex 46 3/4"tall.Thesedimensions
will vary. Please measure your INSTRIDE ELLIPTICAL if exact dimensions are needed.
GrasptheHANDRAIL(7)andREAR STABILIZER(3) tomove the INSTRIDE ELLIPTICAL, two people
are required for moving.Do not use the Pedal Arms to move the INSTRIDE ELLIPTICAL.
To avoid damage to the METER(23), remove the battery before storing the INSTRIDE ELLIPTICAL for
one year or more.
MAINTENANCE
The safety and integrity designed into the INSTRIDE ELLIPTICAL can only be maintained when the
INSTRIDE ELLIPTICAL is regularly examined for damage and wear. Special attention should be given to
the following:
Adjust the TENSION KNOB(22) and verify that the Flywheel System provides tension. The Flywheel
System should provide many years of use.
Verify that the WARNING LABEL(69) is present and legible. Replace the WARNING LABEL(69) if it is
missing or damaged.
It is the sole responsibility of the user/owner to ensure that regular maintenance is performed.
Worn or damaged components shall be replaced immediately or the INSTRIDE ELLIPTICAL removed
from service until repair is made.
Only Stamina Products supplied components shall be used to maintain/repair the INSTRIDE
ELLIPTICAL.
Keep your INSTRIDE ELLIPTICAL clean by wiping with an absorbent cloth after use.
1.
2.
3.
4.
5.
6.

14
CONDITIONING GUIDELINES
How you begin your exercise program depends on your physical condition. If you have been inactive for
several years or are severely overweight, start slowly and increase your workout time gradually. Increase
your workout intensity gradually, too, by monitoring your heart rate while you exercise.
Initially you may only be able to exercise within your target zone for a few minutes; however, your aerobic
capacity will improve over the next six to eight weeks. It is important to pace yourself while you exercise so
you don't tire too quickly.
Measure your heart rate periodically during your workout by stopping the
exercise but continuing to move your legs or walk around. Place two or three
fingerson your wristand takea six second heartbeatcount. Multiplythe results
by ten to find your heart rate. For example, if your six second heartbeat count
is 14, your heart rate is 140 beats per minute. A six second count is used
because your heart rate will drop rapidly when you stop exercising.Adjust the
intensity of your exercise until your heart rate is at the proper level.
wrist pulse
Have your doctor review your training and diet programs.
Begin your training program slowly with realistic goals that have been set by you and your physician.
Warm up before you exercise and cool down after you work out.
Take your pulse periodically during your workout and strive to stay within a range of 60% (lower
intensity) to 90% (higher intensity) of your maximum heart rate zone. Start at the lower intensity and
build up to higher intensity as you become more aerobically fit.
If you feel dizzy or lightheaded you should slow down or stop exercising.
Target Heart Rate Zone Estimated by Age*
Remember to follow these essentials:
To determine if you are working out at the correct intensity, use a heart rate monitor or use the table below.
For effective aerobic exercise, your heart rate should be maintained at a level between 60% and 90% of
your maximum heart rate. If just starting an exercise program, work out at the low end of your target heart
rate zone.As your aerobic capacity improves, gradually increase the intensity of your workout by increasing
your heart rate.
Forcardiorespiratorytraining benefits,theAmerican College of SportsMedicinerecommendsworking
out within a heart rate range of 55% to 90% of maximum heart rate. To predict the maximum heart
rate, the following formula was used: 220 - Age = predicted maximum heart rate
*
20 years
25 years
30 years
35 years
40 years
45 years
50 years
55 years
60 years
65 years
70 years
Target Heart Rate Zone
(55%-90% of Maximum Heart Rate) Average Maximum Heart Rate 100%
Age
110-180 beats per minute
107-175 beats per minute
105-171 beats per minute
102-166 beats per minute
99-162 beats per minute
97-157 beats per minute
94-153 beats per minute
91-148 beats per minute
88-144 beats per minute
85-139 beats per minute
83-135 beats per minute
200 beats per minute
195 beats per minute
190 beats per minute
185 beats per minute
180 beats per minute
175 beats per minute
170 beats per minute
165 beats per minute
160 beats per minute
155 beats per minute
150 beats per minute

15
WARM-UP and COOL-DOWN
Warm-up The purpose of warming up is to prepare your body for exercise and to minimize injuries.Warm
up for two to five minutes before strength-training or aerobic exercising. Perform activities that raise your
heart rate and warm the working muscles.Activities may include brisk walking, jogging, jumping jacks, jump
rope, and running in place
Stretching Stretching while your muscles are warm after a proper warm-up and again after your strength
or aerobic training session is very important. Muscles stretch more easily at these times because of their
elevatedtemperature,which greatly reducestheriskof injury.Stretchesshouldbeheldfor15to30seconds.
Do not bounce.
Suggested Stretching Exercises
Remember always to check with your physician before starting any exercise program.
Cool-Down The purpose of cooling down is to return the body to its normal, or near normal, resting state
at the end of each exercise session.A proper cool-down slowly lowers your heart rate and allows blood to
return to the heart.Your cool-down should include the stretches listed above and should be completed after
each strength-training session.
Lower Body Stretch
Place feet shoulder-width
apart and lean forward.
Keep this position for 30
seconds using the body as a
natural weight to stretch the
backs of the legs.
DONOT BOUNCE!
When the pull on the back of
the legs lessen, try a lower
position gradually.
Floor Stretch
While sitting on the floor,
open the legs as wide as
possible. Stretch the upper
body toward the knee on the
right leg by using your arms
to pull your chest to your
thighs. Hold this stretch 10
to 30 seconds.
DONOT BOUNCE!
Do this stretch 10 times.
Repeat the stretch with the
left leg.
Bent Over Leg Stretch
Stand with feet shoulder-
width apart and lean forward
as illustrated. Using the
arms, gently pull the upper
body towards the right leg.
Let the head hang down.
DONOT BOUNCE!
Hold the position a minimum
of 10 seconds. Repeat
pulling the upper body to the
left leg. Do this stretch
several times slowly.
Bent Torso Pulls
While sitting on the floor,
have legs apart one leg
straight and one knee bent.
Pull the chest down to touch
the thigh on the leg that is
bent and twist at the waist.
Hold this position at least 10
seconds. Repeat 10 times
on each side.

PRODUCT PARTS DRAWING
BACK
FRONT
16
Strap
Strap

17
PARTS LIST
DIAGRAM# PART NAME QTY
1 Main Frame 1
2 Front Stabilizer 1
3 Rear Stabilizer 1
4 Left Pedal Arm 1
5 Right Pedal Arm 1
6 Upright 1
7 Handrail 1
8 Pulley and Axle 1
9 Bearing (6003Z) 2
10 Bearing Washer (M17) 1
11 C Ring (17mm) 1
12 V Belt 1
13 Flywheel 1
14 Bearing (6900Z) 2
15 FlywheelAxle 1
16 Eyebolt 2
17 Tension Bracket 2
18 Tension Spring 1
19 Tension Strap 1
20 Buckle 1
21 Tension Cable 1
22 Tension Knob 1
23 Meter 1
24 Sensor Wire 1
25 Magnet 1
26 Foam Pad 2
27 Left Cover 1
28 Right Cover 1
29 Crank Disk 2
30 Disk Cap 2
31 Left Crank 1
32 Right Crank 1
33 Flange Bolt (M8 x 1.25 x 25mm) 2
34 Left Pedal Shaft (9/16" - 20, Left Hand Threads) 1
35 Right Pedal Shaft (9/16" - 20, Right Hand Threads) 1
36 Pedal Arm Bushing 4
37 Axle Washer (M8) 2
38 Left Pedal Cap 1
39 Right Pedal Cap 1
40 Roller 2
41 Spacer 4
42 Ring Cap 1
43 Foam Grip 1
44 Leveling Cap (45mm) 2
45 Endcap (45mm) 2
46 Round Plug (22mm) 2
47 Round Plug (32mm) 2

PARTS LIST
DIAGRAM# PART NAME QTY
18
48 Bolt, Button Head (M8 x 1.25 x 20mm) 2
49 Bolt, Button Head (M8 x 1.25 x 57mm) 2
50 Bolt, Button Head (M8 x 1.25 x 60mm) 4
51 Bolt, Button Head (M8 x 1.25 x 100mm) 2
52 Bolt, Button Head (M10 x 1.5 x 50mm) 2
53 Bolt, Round Head (M6 x 1 x 43mm) 4
54 Screw, Round Head (M4 x 25mm) 6
55 Screw, Round Head (M5 x 15mm) 4
56 Screw, Flat Head (M5 x 12mm) 1
57 Screw, Flat Head (M5 x 15mm) 1
58 Screw, Round Head (M5 x 0.8 x 15mm) 4
59 Nut (M6 x 1) 2
60 Nylock Nut (M8 x 1.25) 2
61 Nylock Nut (M10 x 1.5) 2
62 Thin Nut (3/8" - 26 x 0.16" thick) 2
63 Nut (3/8" - 26 x 0.28" thick) 2
64 Acorn Nut (M8 x 1.25) 6
65 Arc Washer (M8) 8
66 Lock Washer (M8) 8
67 Wave Washer (ø16.5 x ø22.5 x 0.4mm Thick) 4
68 Screw, Round Head (M5 x 15mm) 1
69 Warning Label 1
70 Wrench 1
71 Allen Wrench (6mm) 1
72 Manual 1

LIMITED WARRANTY MODEL 55-1615
Stamina Products, Inc. warrants that this product will be free from defects in materials and workmanship
under normal use, service and proper operation for a period of 90 days on the parts and one year on the
frame from the date of the original purchase from an authorized retailer. THIS WARRANTY SHALL NOT
APPLY TO ANY PRODUCT WHICH HAS BEEN SUBJECT TO COMMERCIAL USE, ABUSE, MISUSE,
ALTERATION OF ANY TYPE OR CAUSE OR TO ANY DEFECT OR DAMAGE CAUSED BY REPAIR,
REPLACEMENT, SUBSTITUTION OR USEWITH PARTSOTHER THAN PARTSPROVIDED BYSTAMINA
PRODUCTS, INC. Commercial use includes use of the product in athletic clubs, health clubs, spas,
gymnasiums, exercise facilities, and other public or semipublic facilities whether or not the product's use is
in furtherance of a profit making enterprise, and all other use which is not for personal, family, or household
purposes.
To implement this limited warranty, send a written notice stating your name, date, and place of purchase and
abriefdescriptionofthedefectalongwithyourreceiptto StaminaProducts, Inc. P.O.Box 1071, Springfield
Missouri, USA, 65801-1071 or call us at 1 [phone]. If the defect is covered under this limited
warranty, you will be requested to return the product or part to us for free repair or replacement at our option.
NO ACTION FOR BREACH OF THIS LIMITED WARRANTY MAY BE COMMENCED MORE THAN ONE
(1) YEAR AFTER THE DATE THE ALLEGED BREACH WAS OR SHOULD HAVE BEEN DISCOVERED.
NO ACTION FOR BREACH OF ANY IMPLIED WARRANTY MAY BE COMMENCED MORE THAN ONE
(1) YEAR AFTER DELIVERY OF THE PRODUCT TO THE PURCHASER. This limited warranty is not
transferable. IF ANY PART OF THE PRODUCT IS NOT IN COMPLIANCE WITH THIS LIMITED
WARRANTY OR ANY IMPLIED WARRANTY, THE REMEDY OF REPAIR OR REPLACEMENT IS THE
EXCLUSIVE REMEDYAVAILABLE TO YOU. In the event that the purchaser makes any claim under this
limitedwarranty or anyimpliedwarranty,theWarrantor reservestherighttorequiretheproducttobereturned
for inspection, at the purchaser's expense, to the Warrantor's premises in Springfield, Missouri. Return of
the enclosed warranty registration card is not required for warranty coverage, but is merely a way of
establishing the date and place of purchase.
Stamina Products, Inc. SHALLNOT BE LIABLE FOR THE LOSS OF USE OFANY PRODUCT, LOSS OF
TIME, INCONVENIENCE, COMMERCIAL LOSS OR ANY OTHER INDIRECT, CONSEQUENTIAL,
SPECIALOR INCIDENTALDAMAGESDUE TO BREACHOF THEABOVEWARRANTYORANYIMPLIED
WARRANTY.
This limited warranty is the only written or express warranty given by Stamina Products, Inc. This warranty
gives you specific legal rights, and you may also have other legal rights which vary from state to state.
ANY OTHER RIGHT WHICH YOU MAY HAVE, INCLUDING ANY IMPLIED WARRANTY OR
MERCHANTABILITYOR FITNESS FORA PARTICULAR PURPOSE, IS LIMITED INDURATION TO THE
DURATION OF THIS WARRANTY.
The laws in some jurisdictions restrict the rights of manufacturers and distributors of consumer goods to
disclaim or limit implied warranties and consequential and incidental damages with respect thereto. If any
suchlaw is foundto be applicable,the foregoingdisclaimers andlimitationsof andon implied warrantiesand
consequential and incidental damages with respect thereto shall be disregarded and shall be deemed not to
have been made to the extent necessary to comply with such legal restriction.
WARRANTY
19

20
NOTES
