Stanley SLL360 User manual

Please read these instructions before operating the product.
SLL360
360° Self-Levelling Multi-Line Laser
77-137
GB
D
F
I
E
PT
NL
DK
SE
FIN
NO
PL
GR
CZ
RU
HU
SK
SI
BG
RO
EE
LV
LT
HR
TR

277-137
A
2
4
3
1
6
5
7
(-)
(+)
8
(-)
(+)
(-)
(+) B
5

9
77-137
Notes

10 77-137
Contents
• Safety
• Product Overview
• Applications
• Keypad, Modes, and LED
• Batteries and Power
• Set Up
• Operation
• Accuracy Check and Calibration
• Specications
User Safety
WARNING:
• Carefully read the Safety Instructions and
Product Manual before using this product.
The person responsible for the instrument must
ensure that all users understand and adhere to
these instructions.
CAUTION:
• While the laser tool is in operation, be careful
not to expose your eyes to the emitting laser
beam (red light source). Exposure to a laser
beam for an extended time may be hazardous
to your eyes.
CAUTION:
• Glasses may be supplied in some of the laser
tool kits. These are NOT certied safety glasses.
These glasses are ONLY used to enhance the
visibility of the beam in brighter environments or
at greater distances from laser source.
Retain all sections of the manual for future reference.
WARNING:
• The following labels are placed on your laser tool
to inform of the laser class for your convenience
and safety. (Text has been translated here for
your convenience)
IEC/ EN 60825-1
LASER RADIATION - DO NOT
STARE INTO THE BEAM
CLASS 1 LASER PRODUCT
Max Output ≤ 1 mW @ 630 - 670 nm
Product Overview
Figure A - Laser Tool
1. Window for Front Horizontal and Vertical Beams
2. Pendulum / Transport Lock
3. Windows for 360° Horizontal Coverage Beams
4. Keypad
5. Battery Cover
6. 5/8 - 11 Threaded Mount
7. 1/4 - 20 Threaded Mount
Figure B - Laser Tool Battery Location
5. Battery Cover
8. Batteries - 3 x “AA” (Included)
Figure C - Pendulum / Transport Lock Positions
Figure D - Keypad
Figure E - Laser Modes
Figure F - Manual Mode
Figure G - Level Beam Accuracy
Figure H - Level Beam Accuracy (Without Vertical Beam)
Figure J- Horizontal Beam Accuracy
