Stanley AUTOMATIVE STMT78401-8 User manual

IT IS ADVISABLE TO:
CAREFULLY READ THE INSTRUCTIONS BEFORE USING THE PNEUMATIC TOOLS
WEAR SAFETY GOGGLES AND HEARING PROTECTION
3/8"AIR RATCHET
Manual size: 145W x 210H mm
Spread size: 290W x 210H mm
OUTSIDE
3/8"AIR RATCHET
STMT78401-8
Serial Number Parts Number Description Q'ty
A
B
C
D
E
F
G
H
I
J
K
L
1
1
1
1
1
1
1
1
1
1
1
1
K45021
45015
K15014
15012
45013
K15014
75020
45055
K75001
75018
K66024
75003
Ratchet Housing repair kit
Locking Nut
Gear repair kit
Thread Ring Gear
Washer
Cylinder repair kit
Exhaust Deflector
O-Ring
Housing repair kit
Housing grip
Air Inlet repair kit
Trigger
A
D
E
F
G
H
I
J
K
L
B
C

INSIDE
Take note of the air supply system and air tube connection
Keep the tube from bursting by checking the air pressure before operating the tool.
Avoid intertwining or running over the tube.
Ensure that the air supply is clean and dry before use.
Regularly clean the air compressor and tube to optimize the life span of the tool.
More Than 1/100 Slope
Auto Drain Valve
Air Tool
Filter Regulator
Lubricator
Stop Valve
Branch Line =2 Times
Tool Inlet/hose Size
Main Line =3 Times
Tool Inlet/hose Size
Auto Drain
Valve
Stop Valve
Air Compressor
Maintenance Notifications:
Use the specified lubricant to lubricate the tool.
Make use of the filler while conducting lubrication and limit the flow to two (2) drops per minute.
If the filler is unavailable, lubrication should be conducted whilst rotating the tool every one (1) to two (2)
minutes until it is complete.
The life span and performance of the tool will be greatly improved if the aforementioned steps are taken.
Thoroughly read and understand the user manual before attempting to operate
the tool.
Any attempt to alter the structural design and mechanics of the tool may result in
grievous bodily harm.
Do not directly point the tool at any living object.
Consistently wear protective gear, such as safety goggles, ear plugs, and mask, while
operating the tool. The use of protective gear is also advisable while repairing or
changing the tool’s spare parts.
Long hair must be tied back and it is advisable to remove all adornments including,
but not limited to scarves, neckties, and clothing with loose sleeves, to avoid any
interference with the tool.
Do not make direct contact with any part of the transmission while the tool is
in operation.
Only purchase and use original Stanley spare parts in order to maintain the precision
and accuracy of the tool.
Operating the air tool will deliver strong back throw; please stabilize yourself with
equal strength
During repair and maintenance or when not in use, turn off the air compressor and
remove the tool from the air source.
Ensure that the air tube is not placed in an area with high foot traffic.
Should bodily irritation, numbness, or fatigue occur at any time during the operation
of the tool, seek immediate medical attention.
STANLEY®PNEUMATIC TOOL USER GUIDE
The tool must be used accurately to comply with the design parameters and usage range.
Care for the tool by conducting regular inspections.
Safety precautions must be taken into account during usage, removal and storage of the tool.
Take note of potential hazards in the surrounding environment, such as people and objects, while
operating the tool.
Use the appropriate tool based on the working application and capacity.
This tool has been designed to drive fasteners with specific impact sockets;
using standard sockets could cause injuries to the operator.
NEVER USE STANDARD SOCKETS ON IMPACT TOOLS
Forward 1
30
STMT78401-8
Technical Notifications:
Torque ft-lb
Forward 2
48
Torque ft-lb
Forward 3
60 180
Torque ft-lb RPM
85
RPM
107
RPM
