InstructionManual
OriginalInstruction





SmallerDiameterNeoBolt®Fasteners
InstallationEquipment(3/16”1/4”5/16”3/8”)
NoseEquipment,PlacingToolsandToolPowerUnits


2
SafetyInstructions


Thistechnicaldatasheetmustbereadwithparticularattentiontothesafetyrulesandoperatinginstructionslistedin
theGenesis®nG3LB,73200and07287ToolInstructionManuals,byanypersonfittingoroperatingtheNeoBoltInstallation
Equipment.

AVDEL®RECOMMENDSTHATONLYAVDEL®HYDRAULICPOWERUNITSBEUSEDTODRIVEAVDEL®07287
INSTALLATIONTOOLS,ASOTHERMAKESOFHYDRAULICPOWERUNITSANDTOOLINGMAYNOTOPERATEAT
THESAFEDESIGNEDWORKINGPRESSURES.

ENSURETHATTHEREISADEQUATECLEARANCEFORTHETOOLOPERATOR'SHANDSBEFOREPROCEEDING.

DONOTABUSETHETOOLBYDROPPINGORUSINGITASAHAMMER.

AVOIDCONTAMINATIONOFTHENOSEEQUIPMENTASTHISMAYCAUSEACCELERATEDWEARORCLOGGING
WHICHMAYJAMTHETOOL.



3

Specification
IntentofUse

TheNeoBoltInstallationEquipment,comprisingNeoBoltnoseequipment,andeithernG3LB,73200or07287tools,is
designedforplacingthesmallerfourdiametersofAvdel®NeoBoltstructuralfastenersonly.

Thisdocumentisconcernedwiththespecification,set‐upandoperatinginstructionsspecifictothesmalldiameterNeoBolt
InstallationEquipment.TheInstructionManualsforthenG3LB,73200or07287toolsmustbereferredtoforfulldetailsofthe
placingtoolspecification,operatinginstructions,servicingandroutinemaintenance.

ThecorrectplacingtoolandnoseassemblymustbeselectedforeachNeoBoltfastenersize.Thetablebelowprovidesafull
listofnoseassembliesandplacingtoolsrequiredandshouldbeusedtoselectthecorrectplacingequipment.


NEOBOLTNOSEASSEMBLYPLACINGTOOL
SIZEPARTNUMBERDIM.'A'DIM.'B'MODELPARTNUMBERINSTRUCTIONMANUAL(S)
3/16"71213‐0550060.930.5nG3LB71256‐0200007900‐01067&07900‐00930
1/4"71213‐0680060.930.5nG3LB71256‐0200007900‐01067&07900‐00930
5/16"73200‐05000101.526.97320073200‐0200007900‐01033
3/8"73200‐05100100.540.00728707287‐0020007900‐00918


Refertotheillustrationonpage4fortheidentificationofthenoseassemblydimensions‘A’and‘B’.




IMPORTANT‐THENOSEASSEMBLIES,HANDTOOLSANDPOWERUNITSMUSTBEUSEDINACCORDANCEWITH
THESAFETYRULESANDOPERATINGINSTRUCTIONSCONTAINEDWITHINTHISDOCUMENTANDINTHEHANDTOOL
ANDPOWERUNITINSTRUCTIONMANUALS.

THEPLACINGOFFASTENERSNOTINCLUDEDINTHISDATASHEETCOULDHAVEADETRIMENTALIMPACTONTHE
WORKINGLIFEOFTHETOOL,POWERUNITANDNOSEASSEMBLIESANDCOULDINVALIDATETHEWARRANTY.














4





     71256‐02000toolfor3/16”and¼”NeoBolt 










 

 73200‐02000toolfor5/16”NeoBolt   07287‐00200toolfor3/8”NeoBolt




Refertothetableonpage3forthenoseassemblydimensions‘A’and‘B’.

5

NoseEquipment


IMPORTANT–ENSURETHEHANDTOOLORPOWERUNITCOMPRESSEDAIRSUPPLYISDISCONNECTEDBEFORE
FITTINGORREMOVINGTHENOSEASSEMBLY

DetailsofthecomponentswithineachNeoBoltnoseassemblyareprovidedinthetablesandillustrationsbelow.

ForNeoBoltfastenersizes3/16”and1/4”



NEOBOLT
SIZE
NOSE
ASSEMBLY
123
ANVILCOLLETADAPTOR
PARTNUMBERPARTNO.QTYPARTNO.QTYPARTNO.QTY
3/16"71213‐0550071213‐05501171213‐05502171233‐202011
1/4"71213‐0680071213‐06801171213‐06802171233‐202011






FittingInstructions
Itemnumbersinboldrefertonoseassemblycomponentsinthetablesandillustrationabove.Noseassembliesshouldonly
befittedtonG3LBtools(PartNo.71256‐02000).

LightlycoattheoutersurfaceoftheCollet2jawsandtheAnvil1borewithMolyLithiumgrease.

ScrewAdaptor3ontotheplacingtoolpistonroduntilitreachestheendofthepistonrodthread.

ScrewCollet2fullyontotheplacingtoolpistonroduntilitcontactstheendfaceofthetoolpiston.

UnscrewAdaptor3untilitcontactstheendfaceoftheCollet2andthentightenthetwotogetherusingspannersonthe
flatsofeachpart.

SlideAnvil1overCollet2andpushtheexpandedendoftheColletintotheAnvilBore.Someforcewillberequiredtodo
thisandsocareshouldbetakentopreventpinchingofhands–ideallywearprotectiveglovesorcovertheAnvilwitha
thickrag.OncetheColletiswithintheAnvil,screwthethreadedendoftheAnvil2intotheplacingtoolheadandtighten
withaspanner.

RemovaloftheAnvil1andCollet2isthereverseprocedure.



6


ForNeoBoltfastenersizes5/16”



NEOBOLT
SIZE
NOSE
ASSEMBLY
12
ANVILCOLLET
PARTNUMBERPARTNO.QTYPARTNO.QTY
5/16"73200‐0500073200‐05001173200‐050021










FittingInstructions
Itemnumbersinboldrefertonoseassemblycomponentsinthetablesandillustrationabove.NotethattheRetainingNut3
(PartNo.73200‐02042)andAdaptorRing4(PartNo.73200‐02043)arepartsoftheplacingtool5&6(PartNo.73200‐02000).

ForoptimumadjustmentofthecolletpositioningOptionalSpacerRings(PartNo.73200‐05003and73200‐05004)are
providedwitheachnoseassembly.Itisrecommendedthatthe2mmthickring(PartNo.73200‐05004)isusedfortheinitial
assembly,howevermoreorlessspacingmayberequiredtosuittheparticulartool.

OptionalSpacerRings
maybefittedhere.
73200‐05003(1mm)and
73200‐05004(2mm).

7


LightlycoattheoutersurfaceoftheCollet2jawsandtheAnvil1borewithMolyLithiumgrease.

CleanthethreadedendofthetoolpistonrodandapplytwodropsofLoctite®243threadlocktothemiddleofthe
threadedregion.

FitappropriateOptionalSpacerRing(s)overplacingtoolpistonrod.

ScrewCollet2fullyontotheplacingtoolpistonrodandlightlytightenusingaspannerontheflatsofCollet2.

SlideAnvil1overCollet2andpushtheexpandedendoftheColletintotheAnvilbore.Someforcewillberequiredtodo
thisandsocareshouldbetakentopreventpinchingofhands–ideallywearprotectiveglovesorcovertheAnvilwitha
thickrag.

OncethelugsoftheAnvil1arerestingagainsttheendofthetoolhead,slidetheAdaptorRing4,withitscut‐outsfacing
thetool,overtheAnvil1andalignsothattheColletlugsengagewiththecut‐outsintheAdaptorRing4.

ScrewtheRetainingNut3ontothethreadedendoftheplacingtoolheadandtightenwithaspanner.

CheckthatCollet2ispositionedcorrectlywithintheAnvil1.TheopeninginthecentreoftheColletshouldbeslightly
largerthantheNeoBoltpinpullingtaildiameterandasaguidetheColletshouldprotrudebyabout4mmfromthefront
faceoftheAnvil.(ExcessiveColletprotrusionwillreducetheavailabletoolstrokewheninstallingNeoBoltfasteners
closetominimumgripcondition.)IftheColletopeningistoosmall,additionalspacingisrequired.IftheCollet
protrusionistoogreat,reducethespacerthickness.

RemovaloftheAnvil1andCollet2isthereverseprocedure.



ForNeoBoltfastenersizes3/8”



NEOBOLT
SIZE
NOSE
ASSEMBLY
12
ANVILCOLLET
PARTNUMBERPARTNO.QTYPARTNO.QTY
3/8"73200‐0510073200‐05101173200‐051021















8









FittingInstructions
Itemnumbersinboldrefertonoseassemblycomponentsinthetablesandillustrationabove.NotethattheHeadExtension
assembly3(PartNo.07220‐01500)ispartoftheplacingtool(PartNo.07287‐00200).

ForoptimumadjustmentofthecolletpositioningOptionalSpacerRings(PartNo.73200‐05003and73200‐05004)are
providedwitheachnoseassembly.Itisrecommendedthatthe1mmthickring(PartNo.73200‐05003)isusedfortheinitial
assembly,howevermoreorlessspacingmayberequiredtosuittheparticulartool.


LightlycoattheoutersurfaceoftheCollet2jawsandtheAnvil1borewithMolyLithiumgrease.

CleanthethreadedendofthetoolpistonrodandapplytwodropsofLoctite®243threadlocktothemiddleofthe
threadedregion.

FitappropriateOptionalSpacerRing(s)overplacingtoolpistonrod.

ScrewCollet2ontotheplacingtoolpistonroduntilitreachestheendofthepistonrodthreadandlightlytightenusinga
spannerontheflatsofCollet2.

PullandthenrotatethesprungoutersleeveoftheHeadExtensionassembly3sothatitrevealstwoopencut‐outs.

SlideAnvil1overCollet2andpushtheexpandedendoftheColletintotheAnvilbore.Someforcewillberequiredtodo
thisandsocareshouldbetakentopreventpinchingofhands–ideallywearprotectiveglovesorcovertheAnvilwitha
thickrag.

AlignthelugsoftheAnvil1withthecut‐outsintheHeadExtensionassembly3andpushintowardsthetooltofully
engagethelugsinthecut‐outs.ThenrotatetheAnvil1byapproximatelyhalfaturn.

RotatetheoutersleeveoftheHeadExtensionassembly3sothatitspringsbackintotheclosedpositiontoretainthe
Anvil1andcoversthecut‐outs.



OptionalSpacerRings
maybefittedhere.
73200‐05003(1mm)and
73200‐05004(2mm).

9

CheckthatCollet2ispositionedcorrectlywithintheAnvil1.TheopeninginthecentreoftheColletshouldbeslightly
largerthantheNeoBoltpinpullingtaildiameterandasaguidetheColletshouldprotrudebyabout5mmfromthefront
faceoftheAnvil.(ExcessiveColletprotrusionwillreducetheavailabletoolstrokewheninstallingNeoBoltfasteners
closetominimumgripcondition.)IftheColletopeningistoosmall,additionalspacingisrequired.IftheCollet
protrusionistoogreat,reducethespacerthickness.

RemovaloftheAnvil1andCollet2isthereverseprocedure.






ServicingInstructions

Noseassembliesshouldbeservicedatweeklyintervals.Youshouldholdsomestockofallinternalcomponentsofthe
noseassemblyastheywillneedregularreplacement.

Removethenoseassemblyusingthereverseproceduretothe‘FittingInstructions’.

Anywornordamagedpartshouldbereplaced.

CleanandcheckwearontheCollet2jawsandtheAnvil1bore.

Cleanandinspectcomponents,renewingwornordamageditems.

Re‐assembleaccordingtothe‘FittingInstructions’.



10

PuttingIntoService
PreparationforUse

IMPORTANT–READTHEAPPROPRIATEPLACINGTOOLMANUALCAREFULLYBEFOREPUTTINGINTOSERVICE.
PERSONALINJURYORDAMAGETOEQUIPMENTMAYOCCURWITHOUTCORRECTAIRINLETPRESSURES.THE
REGULATEDAIRPRESSURESMUSTNOTEXCEEDTHOSEPRESSURESLISTEDINTHEPLACINGTOOL
SPECIFICATIONFORTHESPECIFICSIZEOFFASTENER.
IMPORTANT–BEFOREPUTTINGTHETOOLINTOSERVICE:

(nG3LBand73200tools)ENSURETHATASUITABLEAIRPRESSUREREGULATORISFITTEDIN‐LINEWITHTHE
PLACINGTOOL,THATTHEPRESSUREADJUSTMENTISREADILYACCESSIBLE,ANDTHATAPRESSUREDIAL
GAUGEORREADOUTISCLEARLYVISIBLEFORSETTING.

(07287tools)ENSURETHATTHEINTERNALAIRPRESSUREREGULATORISSETTOTHERECOMMENDED
PRESSUREANDTHATTHEAIRSUPPLYCANDELIVERSUFFICIENTFLOWRATETOTHETOOL.




PressureSettings
CAUTION‐CORRECTAIRPRESSURESAREIMPORTANTFORPROPERFUNCTIONOFTHEINSTALLATIONTOOLAND
FORCORRECTINSTALLATIONOFTHENeoBoltFASTENER.

ForcorrectinstallationofNeoBoltfastenerstheairpressureforthespecifiedplacingtoolmustbesetasstatedinthetable
below.


NEOBOLTPLACINGTOOLAIRPRESSURE
SETTING(bar)
SIZEMODELPARTNUMBER
3/16"nG3LB71256‐020003.0
1/4"nG3LB71256‐020005.2
5/16"7320073200‐020003.6
3/8"0728707287‐002004.0


AIRPRESSURESETTINGSLOWERTHANTHOSESTATEDABOVEWILLNOTFULLYSWAGETHENEOBOLTCOLLAR,
LEADINGTOLOWERTHANSPECIFIEDPERFORMANCEFORTHEFASTENER.

AIRPRESSURESETTINGSHIGHERTHANTHOSESTATEDABOVEMAYCAUSEFAILUREOFTHENEOBOLTPIN
DURINGINSTALLATIONANDWILLALSOREDUCEDTHELIFEOFTHENOSEEQUIPMENT.

EnsureOperatorswhohaveaccesstothepressureregulationarefamiliarwiththecorrectsettings.








11


PuttingIntoService
OperatingInstructions


CheckingtheJointsforNeoBoltfasteners

Measureandensurethatthetotaljointthicknesses(thecombinationofthethicknessofallthelayersinalljointsto
befastened)fallwithinthegriprangespecifiedfortheNeoBoltfastener.RefertotheNeoBoltdatasheetorSales
Drawing.Tohelpwithidentification,eachNeoBoltpinhasthegriplengthcodeembossedonthepinhead.

Checkapplicationandremoveexcessivegapsbetweenthelayersofthejoint.Gapsmaybeduetojointlayersbeing
bentordistorted.Thegapisexcessiveifitisnotpossibletoscrewthecollarfit‐uptabontothepinfit‐upthreadby
atleasthalfaturn.Additionalclampingofthejointmaybenecessarytoavoidexcessivegaps.

Measureandensurethattheholediametersfallwithinthespecifiedrange.Ensurethatholesarealignedinthe
differentlayers.Donotforcepinsintopoorlyalignedholesasthiscandamagethepinsurfaceandfit‐upthread.If
necessaryincreaseholesizesuptothemaximumspecifieddiametertoeasepininsertion.



ToInstallNeoBoltfasteners

PutNeoBoltpintailintoholeandpushfullythroughthejointlayers.

FitNeoBoltcollaroverthepintail(theflangedendofthecollarmustbeclosesttotheworkpiece)androtate
clockwisetoengagethecollarontothepinfit‐upthreadbyatleasthalfaturn.

PushtheColletfullyoverthepinpullingtailuntilColletfullycoversthepullinggrooveontheNeoBoltpin.The
placingtoolmustbeheldperpendicular(90°)totheworkpiecesurface.

Depressandholdthetooltriggerswitchtostarttheinstallationcycle.TheColletwillgriptheNeoBoltpintailand
pulltheAnvilupagainstthecollar.

ContinuetoholdthetriggerdownuntilthecollarisfullyswagedandtheforwardmotionoftheAnvilstopsagainst
thecollarflange.

Releasethetrigger.TheplacingtoolpistonandColletwillthenreturntopushtheAnvilofftheinstalledcollarand
releasethepintailfromtheCollet.

OncetheinstalledfastenerhasbeenejectedfromtheAnvil,theplacingtool,noseassemblyandpumpunitare
readyforthenextinstallation.



CAUTION–DONOTRELEASETHETRIGGERUNTILTHEPLACINGTOOLPULLCYCLEISCOMPLETE.RELEASINGTHE
TRIGGERBEFORETHISPOINTWILLRESULTINANINCORRECTLYPLACEDANDPARTIALLYINSTALLEDNEOBOLT
FASTENER.










12


VisualInspectionofInstalledNeoBoltfasteners

TheraisedradialbarsontheinstalledNeoBoltcollarflangeshouldshownsignsofhavingbeenflattenedbythe
frontfaceoftheswagingAnvil(seebelow).

Thepintailshouldnotbegreatlydistorted,breakorshearoff.Someminormarkingofthebearingsurfaceinthe
pullgrooveishowevernormal.






 



GeneralAdviceforInstallingNeoBoltfasteners

WheninstallingmultipleNeoBoltfasteners,fitallthecollarsontothepinspriortousingtheplacingtool.

Avoiddroppingthetoolastheimpactcandamagetheendofthecolletorallowdirtandgrittoclogandwearout
thenoseequipmentprematurely.






13





FindyourclosestSTANLEYEngineeredFasteninglocationonwww.StanleyEngineeredFastening.com/contact

Foranauthorizeddistributornearbypleasecheckwww.StanleyEngineeredFastening.com/econtact/distributors
Manual No. Issue Change Note No.
07900-01071 A 15/076


www.StanleyEngineeredFastening.com
© 2015 Stanley Black & Decker, Inc., Rev. 04.2015
Avdel®, Genesis®, and NeoBolt®are registered trademarks of Avdel UK Limited.
The names and logos of other companies mentioned herein may be trademarks of their respective owners.
This document is for informational purposes only. Avdel UK Limited makes no warranties, expressed or implied, in this document.
Data shown is subject to change without prior notice as a result of continuous product development and improvement policy.
Your local Stanley Engineered Fastening representative is at your disposal should you need to confirm latest information.
