Stanley K1200 User manual

1
Pellet Stove
Instruction Manual
K1200- K1700- K2300
Wood Pellet Boiler Stoves
Read these instructions carefully before installing, using and servicing the unit.
Please read this manual carefully and retain it for future reference.

2
Table of Contents
1. CO DITIO S OF WARRA TY ............................................................................................................................4
2. Package content .............................................................................................................................................5
3. Safety precautions .................................................................................................................................5
4. Advice on action in the event of a fire in a chimney (includes equipment) ..............................................................6
5. Technical specifications ....................................................................................................................................7
6. Installing the free-standing pellet fire .............................................................................................................. 10
7. Hydraulic Installation .................................................................................................................................... 14
8. Fuel ............................................................................................................................................................ 14
9. Using the Free-Standing Pellet Fire ................................................................................................................. 15
10. Control Tiemme ............................................................................................................................................ 16
11. Alarm / Failure / Recommendation List – Tiemme Control .................................................................................. 32
12. Operating the unit ........................................................................................................................................ 34
13. Instruction for installing the casings ................................................................................................................ 34
14. Installation and operation with the remote control (chrono-thermostat) – not included in free standing units ........... 40
15. Maintenance ................................................................................................................................................ 41
16. Maintenance Plan and Log ............................................................................................................................. 46
17. Maintenance Guide Level ............................................................................................................................... 47
18. Spare Parts Lists & Exploded Views. ................................................................................................................ 48
19. Installation Diagrams .................................................................................................................................... 55
20. Electrical diagram of the Free-Standing Pellet Fire unit ...................................................................................... 57
21. Hydraulic Pumps ........................................................................................................................................... 58
22. Life Cycle of a Free-Standing Fire Unit ............................................................................................................. 65
23. Sustainability ............................................................................................................................................... 65
24. Commissiioning ............................................................................................................................................ 65
25. Flow Charts Ignition/ Shutdown ...................................................................................................................... 65

3
This Pellet Burning Free Standing Fires is designed according to E 14785:2008
WATERFORD STA LEY disclaims any responsibility for damages to the unit if installed by non-qualified personnel;
WATERFORD STA LEY is not responsible for any damage to units installed incorrectly or not used in compliance to the instructions
included in this manual;
All local regulations, including but not limited to national and European standards, must be observed when installing, operating
and servicing the unit;
For assistance, please contact your unit's supplier or installer. You must have the wood pellet stove serial number located on the
identification plate on unit's back panel ready;
The stove can be commissioned free of charge please contact your place of purchase to arrange, the first commissioning visit is
free of charge.
If you need more information about the electronics applied in the WATERFORD STA LEY pellet stoves you may find some helpful
videos on the Waterford Stanley You tube channel. https://www.youtube.com/@WaterfordStanley
Contacts for technical support:
service@Waterford Stanley.com
Waterford Stanley
Unit 401-403
IDA Industrial Estate,
Cork Rd,
Waterford
Ireland.
Setting the Language for the first time.
To set the Language to English on the controller.
Press the menu button until “ set” is displayed beside the menu button.
Press the “ +” button 4 times , display shows “configura.......”.
Press the set button twice until abbreviation for languages in the top and centre of the screen.
Press the “ +” button until abbreviation “E ” is displayed.
Press the Menu button to set the language to English.

4
1. CONDITIONS O WARRANTY
Your Stanley pellet stove is guaranteed against any part that fails (under normal operating conditions) as detailed in the
following table with timelines specified from the date of installation of the appliance. If the stove is not installed within six
months of date of purchase, the warranty will commence six months from the date of purchase.
Warranty
Period
Parts Covered (Parts & Labour unless Stated)
Up to 1
Year
•Refractory materials (supply only)
•Rope seals, glass seals and cement seals.
•Surface Finish on Seno models.
•Grates and fire bars.
•Ceramic glass is covered for Thermal breakage (supply
only).
•Rust (if reported before installation)
•Aesthetic Damage (provided reported on date of receipt)
• Electrical components under normal operation.
Up to 2
Years
•All external casings & enamel finishes (excluding impact
damage or damage caused by overfiring). Pictures of
damage must be submitted to WS Service Department.
Up to 3
Years
•Boiler - A Leaking Boiler Report must be conducted by an
Authorised Stanley Service Engineer and submitted to
WS Service Department for review.
All warranty claims must be reported to the Waterford Stanley Service Department and must be
submitted with the product serial number (located on the data plaque at the rear of the product), date
of purchase, proof of purchase (if requested) and details of the specific nature of the problem.
The warranty is given only to the original consumer/purchaser only and is non- transferable. The
appliance must be installed by a suitable qualified person and installed as per the requirements of the
manual. Failure to comply with the Installation requirements or Building Regulations will void your
warranty. Waterford Stanley reserve the right to replace any part due to manufacturing defect that
fails within the warranty period under the terms of the warranty. The stove must be used for normal
domestic purposes only and in accordance with manufacturer's operation instructions.
LIMITS OF LIABILITY
The warranty does not cover:
•Special, incidental or consequential damages, injury to persons or Property, or any other
consequential loss.
•Any issue caused by negligence, misuse, abuse or circumstances beyond Waterford Stanley’s
control.
•Any issue with wear and tear, modification, alteration, or servicing by anyone other than an
authorized service engineer.
•Installation and operational related problems such as draught related issues external to the
stove, inadequate venting or ventilation, excessive flue offsets, negative air pressure caused by
insufficient burning of improper fuel.
•Damage caused to the stove while in transit.
•Discolouration due to over firing, damage caused by impact, damage to baffles caused by over
firing and fading of surface finish on casting.
•Stress fractures on bricks.
•Rust on cast iron parts unless reported prior to stove being installed.
•Aesthetic damage, rust & missing parts on stoves purchased off display.
•Electrical components where voltage variations are in excess of 10% of nominal 230V
•
ote: Adequate clearance must be maintained around the appliance to ensure the ease of part
removal in the possible event of their damage/failure. Waterford Stanley are not responsible for any
costs incurred in the removal of items installed in the vicinity of the appliance that must be moved to
facilitate a part replacement.

5
2. Package content
Waterford Stanley ships the unit with the following components:
- Free standing pellet fire model K1200 kW, K1700 kW or K2300 kW;
- Access to the brochure of the online manual;
- Power cable.
2.1. Unpacking the unit
When unpacking the unit, please refer to the illustrations below. First remove the retractable bag containing the cardboard box.
Then pull the cardboard box out (Figure 1-a) by lifting it and remove the bag containing the free-standing fire unit and the
Styrofoam plates. Finally, unscrew the four parts securing the unit to the wood pallet (Figure 1-b and Figure 1-c).
a) b)
Figure 1 - Unpacking the free-standing fire unit
3. Safety precautions
Waterford Stanley is not liable for any damages to the unit if the specified precautions, warnings and operating procedures are
not followed.
Units manufactured by Waterford Stanley are easy to operate and special attention was given to their components in order to
protect users and installers against accidental damages.
The units must only be installed by an authorised engineer, who should supply the client with a relevant statement of conformity
and who shall be liable for the final installation and consequent product good operating conditions.
This unit must be used according to its intended use as specified by the manufacturer. The manufacturer is excluded from all
liability, by contract or by tort, caused by injury to people, animals or property arising from misuse or faulty installation or servicing.
After removing the packaging, verify the contents to check their integrity and completeness. If the content of the package fails to
correspond to that indicated in point 1, contact the salesperson from whom you purchased the unit.
All the unit's components guarantee its operation and energy efficiency and should only be replaced with original parts provided
by an authorised technical assistance centre.
The unit must be serviced at least once a year by the installation engineer.
This manual is provided with the product. Please keep it close to the unit.
3.1. or your safety, we recommend that:
Make sure you fully read and understand this instruction manual before using the free-standing pellet fire as a biomass heating
unit;
•Make sure that the hydraulic circuit was correctly assembled and connected to the water supply before turning on the free-
standing pellet fire;
•The free-standing pellet fire is not intended for use by children or persons with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they are under supervision or have been instructed concerning the use of the unit;

6
•Do not touch the free-standing fire when barefoot or if any part of your body is wet or humid;
•Do not tamper with safety or adjustment features without the manufacturer's authorization;
•Do not cover or reduce the size of the vents at the installation area;
•The free-standing pellet fire requires a clear space around the unit for proper combustion, so possible air tightness of the
location or any existing air extraction sources in the room may prevent the unit proper operation;
•The existence of vents is a requisite for proper combustion;
•Do not leave the packing materials near children;
•During normal operation, Free Standing Fire unit's door must not be opened;
•Some parts of the unit may overheat during normal operation, so avoid direct contact with parts such as the door handle and
glass;
•Check the existence of any obstructions on the fume duct before turning on the unit after a long period of inactivity;
•This free-standing pellet fire unit is intended for residential use in protected areas. Safety systems may turn off the unit. If
this occurs, contact the technical assistance. In any circumstances should you attempt to interfere with the safety systems;
•The free-standing pellet fire is a biomass heating unit equipped with an electric fume extractor. The occurrence of any power
failure during its use may prevent fume extraction and the room will be filled with smoke. For this reason, you should have a
natural fume extraction system, like a chimney, available;
•Waterford Stanley offers you an optional safety system which allows the Free-Standing Fire unit to be connected to a UPS so
that during any power failure the fume extractor will still operate until complete extraction of all the fumes;
•If you intend to use the Free-Standing Fire unit while you are away from home or unattended, you should use the safety
system specified above for total safety during any power failure;
•During operation, EVER turn off the free-standing fire unit by disconnecting the electric plug. The fume extractor on the free-
standing pellet fire unit is electric so disconnecting the power plug will prevent the extraction of combustion fumes;
•Your unit must be disconnected from the mains for servicing. Before doing this, the unit must be totally cooled down (if
operating before);
•ever touch the interior of the unit without disconnecting it from the power mains;
•On back boiler models, the maximum temperature of the water that can be set by the user (water set-point temperature) is
85°C. In the event of a temperature of 90ºC being reached, the free-standing pellet fire unit automatically disconnects and the
respective alarm is activated.
4. Advice on action in the event of a fire in a chimney (includes equipment)
Try to extinguish the fire without putting your life at risk.
•If within a minute you cannot extinguish the fire, you should call the fire department.
•Close the doors and windows or partition where the fire has flared.
•Disconnect the electric current and close the gas before leaving your home.
•Once outside, you must wait for the firefighters and be ready to give you the following information: location of the fire, possible
materials that are burning and what they can do to prevent the progression of fire.

7
5. Technical specifications
eatures K1200 K1700 K2300 Units
Weight 185 202 219 kg
Height 1110 1192 1255 mm
Width 617 W W mm
Depth 707 710 767 mm
Diameter of the fume discharge pipe 80 100 100 mm
Reservoir capacity 30 36 55 kg
Maximum heating capacity 295 380 502 m³
Maximum overall thermal power (water/air) 11,5 / 1,5 14,5 / 2,2 18,8 / 3,3 kW
Minimum thermal power (water/air) 3,8 / 1,2 4,3 / 0,8 4,3 / 0,8 kW
Minimum fuel consumption 1,1 1,1 1,1 kg/h
Maximum fuel consumption 3,0 3,9 5,1 kg/h
Rated electric power 43 134 134 W
Electric power at start-up (<10 min.) 406 434 434 W
Rated voltage 230 230 230 V
ominal frequency 50 50 50 Hz
Thermal yield at rated thermal power 92,0 90,9 89,2 %
Thermal yield at reduced thermal power 95,0 93,8 93,8 %
Combustion gas flow (max.) 21,0 6,9 6,9 g/s
Combustion gas flow (min.) 44,0 33,7 18,8 g/s
Max. gas temperature 108 126,5 153,4 ºC
Min. gas temperature 62 66 66 ºC
CO emissions at rated thermal power 0,0136 0,0162 0,0200 %
CO emissions at reduced thermal power 0,0256 0,0200 0,0200 %
Draught in the chimney 12 12 12 Pa
Unit water volume 19 22 22 L
Rated electric power 49,1 49,1 49,1 dB(A)

8
Table 1 - Technical specifications
Tests performed using wood pellets with a heating capacity of 4,9 kWh/kg.
The above information was obtained during product homologation tests performed at independent laboratories accredited for pellet unit tests.
Front Side Rear Top
Figure 2 - Dimensions of the free-standing pellet fire unit K1200
Front Side Rear Top
Figure 3 - Dimensions of the free-standing pellet fire unit K1700 Table 2 - Dimensions of the free-standing pellet fire unit K1700
Front Side Rear Top
Figure - Dimensions of the free-standing pellet fire unit K2300
Model lat Curved
Dimension “W” (mm) 626 704
Model lat K2
Dimension “W” (mm) 644 746

9
Figure 5 - Hydraulic connections of the free-standing pellet fire unit K1200
Figure 6 - Hydraulic connections of the free-standing pellet fire unit K1700 (Flat)

10
Figure 7 - Hydraulic connections of the free-standing pellet fire unit K2300 (curved)
6. Installing the free-standing pellet fire
Before installing, please perform the following steps:
•Upon receipt, check the product is complete and determine there is no sign of any damage. Any damages or defects should be
checked before the unit is installed;
•The unit is equipped with four adjustable height feet at the base which allow for a simple regulation when installed on a non-
flat surface;
Figure 8 - Adjustable feet
•Remove the instruction manual from the package and hand it over to the client;
•Connect an 80mm wide (K1200) or 100mm wide (K1700 or K2300) duct between the combustion gas output and the outgoing
fume extraction duct of the building (e.g., chimney) – check diagrams point 5;
•If a tube is used for combustion air inlet from the outside, it shall be no longer than 60cm horizontally or present offsets (such
as bends);
•Perform the hydraulic installation;
•Connect the 230VAC power cable to a grounded socket;
•The surface of the unit where the hot air outlet is located must be facing the area to be heated;
•As an option, a conventional external programmer may be used (not included) to automatically setup the unit's operating
periods. This should be connected through cable to the optional 230VAC programmer plug (not provided).
6.1. Installation requirements
The minimum distance between the free-standing pellet fire unit and particularly flammable surfaces is specified in Figure 9. The
top of the unit must be at least 100cm separated from the ceiling, especially in rooms with ceilings consisting of flammable

11
materials. The base supporting the unit cannot be made of combustible material (e.g., carpet), so make sure you use an adequate
protection.
a) b)
Figure 9 - Minimum distances from all surfaces: a) upper view of the unit's installation; b) side view of the unit's installation
WARNING!
Keep combustible and flammable materials at a safe distance.
6.2. Installation of ducts and fume extraction systems
• The exhaust pipe must have been designed for this purpose, in compliance to the location requirements and in accordance with
any applicable regulations.
• Important! An inspection-T with an airtight lid must be attached to the exhaust pipe of the unit to allow the regular
inspection of the system or discharge of heavy dust and condensates.
• As indicated in Figure 9, the exhaust pipe must be assembled so as to allow cleaning and maintenance of the pipe by inserting
inspection points.
• In the K1700 model, if you want the flue to go up vertically behind the stove it is necessary to install a straight section of 25cm
(Figure 10) before the cleaning "T". This ensures a minimum distance to the protection box of the auger loading motor.
Figure 10 - 25 cm stainless steel tube
• Under normal operating conditions, the combustion gas flow should create a draught of 12 Pa one meter above the chimney
neck.
• The unit must not share the chimney with other equipment.
• Pipes outside the operating area must have double stainless-steel insulation and an internal diameter of 80 mm (K1200) or 100
mm (K1700 and K2300).
• The fume exhaust pipe may generate condensation, so we recommend that the appropriate systems for collecting
condensates should be installed.
6.3. Installation without a chimney
The installation of the free-standing pellet fire without a chimney should be performed as illustrated in Figure 11, equipped with
an exhaust pipe (with a minimum diameter of 80 mm for the K1200 and 100 mm for the K1700 and K2300 model) directly
outside and terminate over the the roof level by at least 600mm. The termination should be in accordance with building regs to
avoid any high pressure zones.

12
Double-walled stainless steel insulated pipes must be used and properly fastened to avoid condensation.
A T-tube must be installed at the base of the pipe to allow periodic inspections and annual maintenance, as illustrated in Figure
11.
Figure 11 - Side view of the installation without a chimney, illustrating the inspection point
Error! Reference source not found. specifies the basic requirements for installing the chimney to the unit.
a)
Failure to comply with these requirements may prevent the correct operation of the unit. Follow all the instructions presented
on the diagrams.
The Hidro units operate with the combustion chamber in vacuum, so it is absolutely necessary to have a fume exhaust pipe
to extract combustion gases properly.
ume duct material: The tubing must consist of 0,5 mm thick rigid stainless steel, with fastening joints attaching the different
sections and accessories.
Inspection

13
Insulation: The fume ducts must be double-walled and insulated to make sure that fumes do not cool down going outwards,
which would cause an inadequate circulation and condensation that may damage the unit.
Where the flue draught is excessive it may be necessary to insert a “T-tube” with a regulator to regulate the flue draught.
Windproof terminal: A windproof terminal must always be installed to avoid the backflow of fumes.
Draught in the chimney: The figures below show three standard diagrams, specifying adequate lengths and diameters. Any
other type of installation must guarantee a draught of 12 Pa (0,12 mbars) measured when hot and at the maximum power.
Ventilation: To get the optimum operation of the unit it is necessary that the installation location has an air inlet with a
minimum section of 100 cm
2
, preferably near the back panel of the unit. The free-standing pellet fire unit has a circular
pipe ( ∅ 50mm) that may be connected to the exterior of the house.
If the residence has an air exhaust system installed (e.g., kitchen extractor fan), then ventilation of a required cross
sectional area to accommodate the different air exhaust units/systems must be installed.
The installation of the unit on locations near kitchen exhaust fans or fume extractors may prevent the unit from
operating properly.
6.4. Installation with a chimney
As shown in Figure 12, where the unit is installed with an exhaust pipe (∅80 mm for the K1200; ∅100 mm for the K1700 and
K2300) through the existing chimney, the chimney will be too large and must be lined with a flexible flue liner of appropriate
diameter, for 80 mm exhaust outlet increase to 100mm flexible flue, for 100mm exhaust outlet increase to125mm flexible flue.
A T-tube must be attached to the base of the pipe to allow for periodic inspection and annual maintenance, as illustrated in Figure
12.
Figure 12 - Side view of the installation with a chimney, showing the inspection point
We do not recommend that you use the unit in rough weather conditions that may seriously impact the draught (particularly with
very strong winds).
If you do not use the unit for a long time, check it to make sure that the flue pipes are clear before lighting the fire.
Inspection

14
7. Hydraulic Installation
• The chapter 19 (installation diagrams) contains the optional connection diagrams for central heating installations, with or
without water heating for household use;
• The free-standing pellet fire unit is equipped with a circulating pump, an expansion vessel (6 litre volume (in the K1200 and
17 model) or 10 litre volume (in the K2300 model) and pre-charge of 1 bar) and a 3-bar safety valve;
• Operating pressure is between 0,8 and 1,2 bar (for K1200) and 1 and 1,5 bar (for K1700 and K2300);
• To empty the unit, attach a “T-tube” with a tap to the outlet (connected to the drain); the safety valve (3 bar) outlet must also
be connected to the drain;
• The heating fluid must consist of water with an anti-rust, non-toxic product added in the quantity recommended by the
manufacturer. If the unit installation or the fluid pipes are installed are likely to freeze, the installation engineer must add to the
circulating fluid the amount of antifreeze product recommended by the manufacturer, to avoid freezing at the estimated minimum
temperature.
7.1. Operating mode for radiator/buffer tank
IMPORTA T! The boiler is programmed to work directly for radiators, in case you want to install the boiler with a buffer or
AQS tank, we recommend changing the temperature “OFF” of the circulation pump by placing the same temperature as the deposit
or 1 °C higher than this temperature, should disable the “hYDRO Menu” modes “Modulating Pump” and “hydro independent” and
switch the mode display “Auto” to “Manual” mode and select the power 5 (Fire 5).
You must change the smoke temperatures (“Toff” and “Ton”) in the “Activation” menu. For these changes is necessary to access
the “Installer Menu” on the display, please request a password manufacture.
8. uel
The Free-Standing Pellet Fire operates exclusively with pellets. o other fuel sources are allowed to be used.
Only use pellets certified by standard E 14961-2 grade A1 with a diameter of 6mm and a length of 10-30mm.
The pellets may have a maximum humidity of 8% their weight. To guarantee a good combustion, the pellets must maintain these
characteristics so it is recommended that they should be stored in a dry place.
The use of different pellets will reduce the efficiency of the unit and cause deficient combustion.
Only certified pellets should be used and a sample must be tested before buying large bulks.
The physicochemical properties of the pellets (namely, calibre, friction, density and chemical composition) may vary within specific
tolerances and across manufacturers. Please note that this may cause changes to the feeding process and, consequently, the need
for different doses (more or less pellet quantity).
The unit allows for an adjustment of +15%/-33% the pellet dosage at the start-up phase and at each power level
(please see section 9.2.7 of this manual) .
WARNING!
This unit may OT be used as an incinerator.

15
9. Using the ree-Standing Pellet ire
The pellet stoves must be serviced as described in point 3.6, page 110 (Warranty). In order to adjust the operating
parameters of the stove (pellet stove), the dosing must be adjusted as described in section 7 of this manual. The pellet dose must
be adjusted according to the gas temperature and pellet consumption of the appliance at the rated power described in Table 1,
page 5, in order to ensure that the appliance delivers the correct power.
Recommendations
Before starting up the unit, please check the following:
•Ensure the unit is properly connected to the power mains using the 230V AC power cable.
Figure 13 - Electric power plug
Check if the pellet reservoir is supplied with pellets. Inside the pellet reservoir is a safety grid to prevent users from reaching the
worm screw.
•Ensure that before each ignition the burner is clear.
The unit’s combustion chamber and panel door are made of iron plate painted with high temperature resistant
paint which releases fumes during the initial burn due to the paint’s curing process. Avoid touching the unit during
its first burn to prevent leaving permanent marks on the paint. The paint goes through a more plastic phase during
the curing process. The curing of the paint occurs at approximately 300ºC for 30 minutes.
Please make sure the room where the unit is installed has adequate air circulation; otherwise, the unit will not work properly. For
this reason, it is important to check if there are any other air-consuming heating appliances present in the room (e.g., gas units,
braziers, extractors, etc.); these should not be used simultaneously with the unit.
This Free-Standing Pellet Fire unit has a probe for measuring the room temperature. This probe is attached to the grid at the rear
panel (Figure 14). For a good reading of the room temperature, avoid the contact between the end of the probe and the unit
surfaces. You may also attach the probe to the wall beside the unit.

16
Figure 1 - Room temperature probe
10. Control Tiemme
Waterford Stanley stoves may be equipped with Tiemme electronics, the Tiemme display is as shown below. To confirm if your
equipment is equipped with these electronics, please check the serial number of the equipment and refer to Table 3.
Tiemme Electronic Serial No. of equipment
K1200
≥ 01-21-00193
K1700
≥ 01-21-00243
K2300
≥ 01-21-00291
Table 3 - Serial No. with Tiemme electronic
10.1. Display
When connecting the equipment, the display indicates the “OFF” status of the stove, and can also indicate the chrono activation,
system errors, selected combustion power, selected ventilation power, current room temperature and selected room temperature
set-point.
In the Home Page by pressing the key:
•“P1” it’s possible to exit the menu/submenu;
•“P2” it’s possible to switch on the equipment, or, switch off the equipment. The same button allows the errors reset, by
pressing 3 seconds continuously, it also allows the activation of Chrono in the corresponding submenu;
•“P3” it’s possible to access the user menu 1, by pressing 3 seconds on the same button we can access the user menu 2 and
it also allows saving changes;
•“P4” it’s possible to enter the Combustion Power menu;
•“P5” it’s possible to enter the Information menu and also activate a Chrono time slot;
•“P6” it is possible to enter the Room Thermostat menu;
•“P3” + “P5” for 3 seconds it is possible to access the secondary information menu present in the service menu where it is
possible to check a set of variables.

17
Led
Meaning
D
W
WE
• When this Led is active it means that the Chrono is in
Daily Mode O , Weekly Mode O or Weekend Mode O .
• When this LED is active, it means that the required
room temperature has been reached.
• Summer
• Winter
THE STOVE MUST ALWAYS BE DEACTIVATED IN THE SAME WAY IT WAS ACTIVATED. THE EQUIPMENT MUST NEVER BE UNPLUGGED DURING THE
ACTIVATION PROCESS.
10.2. Settings Menu
10.2.1. Language
By pressing the P3 key for 3 seconds, you will display the Settings, Service, Display and System menus.
S YSTEM M ENU IS AN EXCLUSIVE ACCESS MENU OR THE TECHNICAL SERVICE AND REQUIRES A PASSWORD .
With the P4 and P6 keys you must select the required menu and then press P3 to validate your choice, in this case the Settings
menu.
Select the Language submenu with the P6 key and to validate the entry in this submenu the P3 key.
Within this submenu, with P4 and P6 select the required language and press P3 again to confirm.

18
To exit the Language menu, press the P1 key.
10.2.2. Time and Date
•Time
From the main screen, by pressing for 3 seconds the P3 key, you can access the Settings menu, by pressing again on P3 to enter
this menu.
Use the P3 key to select Date and Time.
In the Date and Time menu, select Time, with the P4 and P6 keys, and press the P3 key, the time will appear in editable mode,
flashing, with P4 and P6 select the correct time and press P3 to validate.
The same must be done for Minutes, with P6 select Minutes and press P3, the minutes will appear in editable mode, flashing, with
P4 and P6 select the correct minutes and press P3 to validate.

19
•Date
In the same menu, select Day with the P4 and P6 keys and press P3, the day will appear in editable mode, flashing, with P4 and
P6 select the correct day and press P3 to validate.
To edit the Month, you must use the P4 and P6 keys to select this information and then P3, the month will appear in editable
mode, with P4 and P6 select the desired month and then press P3 again to validate.
The Year follows the same procedure, press the P4 and P6 keys to move to the Year, use the P3 key to edit this field, the year will
appear in editable mode. With P4 and P6 select the desired year and press P3 to validate.
THE DAY O THE WEEK (SUNDAY TO SATURDAY) CHANGES ACCORDING TO THE DAY O THE WEEK SELECTED.
10.2.3. Summer-Winter (not applicable)
From the main screen, by pressing for 3 seconds the P3 key, you can access the Settings menu, by pressing again on P3 to enter
this menu.

20
Use the P6 key to select the Summer-Winter submenu and confirm the entry in this submenu with the P3 key.
By pressing the P4 and P6 buttons, you can choose between summer or winter mode, this menu allows you to modify the
functioning of the control unit according to the season. Use the P3 key to validate the choice.
10.3. Display Menu
By pressing the P3 key for 3 seconds, you will see the Settings, Service, Display and System menus. Use the P4 and P6 keys to
select the required menu and then press P3 to confirm the choice, in this case the Display menu.
In this menu there are the functions Contrast, Min Brightness, Screen Saver and Firmware Codes.
