INSTALLATION INSTRUCTIONS
ABDUCTOR / ADDUCTOR
IP-S1316

Page 2
Copyright 2009. Star Trac by Unisen, Inc. All rights reserved, including those to reproduce this book or
parts thereof in any form without first obtaining written permission from Star Trac.
Every effort has been made to keep this information current; however, periodically, changes are made to
the information herein, and these changes will be incorporated into new editions of this publication. All
product names and logos are trademarks of their respective owners. Printed in the USA.

Page 3
INSTALLATION INSTRUCTIONS
1• TORQUE WRENCH
••••••••••••••••••••••••••••••••••••••••
1• 8MM HEX KEY SOCKET
•••••••••••••••••••••••••••••••••
• #2 CROSS-HEAD (PHILLIPS) SCREWDRIVER
•••••••••
11• 6MM HEX KEY SOCKET
•••••••••••••••••••••••••••••••••
1• 13MM SOCKET
•••••••••••••••••••••••••••••••••••••••••••••
1• 5MM HEX KEY SOCKET
•••••••••••••••••••••••••••••••••
1• 19MM OPEN-END WRENCH
•••••••••••••••••••••••••••••
1• 4MM HEX KEY SOCKET
•••••••••••••••••••••••••••••••••
1• 17MM OPEN-END WRENCH
•••••••••••••••••••••••••••••
1• 3MM HEX KEY SOCKET
•••••••••••••••••••••••••••••••••
2• 13MM OPEN-END WRENCH
••••••••••••••••••••••••••••
1• 2.5MM HEX KEY SOCKET
•••••••••••••••••••••••••••••••
REQUIRED TOOLS:
GENERAL NOTES:
• Unless otherwise noted Loctite 242/243 or equivalent thread locker must be used on all threaded fasteners. (Do not
use thread locker when a Nyloc nut is used.)
• All Star Trac Strength equipment MUST be secured to the floor using either 10mm or 3/8in. (grade 5 minimum) bolts.
To accommodate this there are four mounting points inside the weight stack and one in either of the small feet.
• This Installation Instructions Manual must be used in conjunction with the equipment’s Owner’s Manual. The Owner’s
manual describes equipment setup and instructs members on how to use it correctly and safely.
• The Ab/Ad Machine weighs approximately 322 Kg (710 lbs) when fully assembled and occupies an area 140 cm wide
by 151 cm deep. Star Trac recommends the addition of 1-2 people during assembly, and when moving the
equipment to its designated point of use.
Should any component not be present or if you have any operational questions, please refer to your owner’s manual or on
the web @ www.startrac.com . Specifically refer to your Inspiration serial number and model number labeled on your
equipment.
THREAD LOCKER APPLICATION: Clean all threads and holes, apply no more than 3-4 drops per bolt.
Thru Holes Blind Holes
PACKAGING REMOVAL:
Carefully remove all packaging materials that wrap the equipment. DO NOT USE A KNIFE OR BOX
CUTTER AS YOU MAY DAMAGE THE EQUIPMENT. At this time remove any sub-components
from the pallet and set aside for later assembly.
• Torque all hardware to values as specified above, unless noted otherwise.
• See Page 13 of this manual for fastener sizing information; for reference only.
• Note: All torque values are in N-m unless otherwise stated.
26 to 30 (35 to 40)1.75
10mm
9.5 to 12 (13 to 16)1.258mm
4.5 to 6 (6 to 8)1.25
6mm
Torque, N-m (lbs-ft)Thread PitchBolt Size
Metric Steel Bolts Torque Specifications

Page 4
2. Gripping the top of the outside SHROUD lift
and remove it from the weight stack.
Carefully store the SHROUD for later use.
Now repeat with the inside SHROUD.
REMOVE THE SHROUDS:
1. Using a 4MM hex key remove the
(M6,30MM,Button Head Bolt) from the
rear of the weight stack. Save this bolt
as you will need it to re-install later. After
the bolt has been removed rotate the
black TOP BUMPER towards the front of
the weight stack then lift it off and set
aside.
REMOVE FROM PALLET:
1. With the shrouds removed, locate and
remove the two bolts that secure the
equipment to the pallet. There will also be
a bolt through each of the equipment’s
feet.
2. Once all bolts fastening the equipment to
the pallet have been removed, carefully
remove equipment off of the pallet and
place in desired location.
PROTECTIVE FEET:
1. Your equipment shipped with a set of
PROTECTIVE FEET. Tilt the equipment
towards the weight stack and slip the
small PROTECTIVE FEET on and set
the equipment back down.
2. Lift the weight stack and install the large
PROTECTIVE FOOT and set the
equipment back down. NOTE: The
weight stack frame is very heavy and will
require additional people to assist during
the foot installation.

Page 5
INSTALLING THE CROSS SUPPORT
FRAME
1. Tilt back the SEAT FRAME.
2. Install the CROSS SUPPORT FRAME
using two (M8, 25MM, Button Head
Screw) and two (M8, Washer) with a
5MM hex key. Do not tighten yet.
3. Set the SEAT FRAME back down and
install the two upper screws and
washers.
4. Tighten all screws per torque specs.
Left Shroud w/
Center Cap
Right Shroud
Seat Frame
Support
Frame
REMOVE THE SEAT FRAME
SHROUD:
1. Remove the CAM SHROUDS
underneath the SEAT. Use a 4MM hex
key to remove the (M6, 16MM, Button
Head Screws) and (M6, Washers) and
retain for later use.
