STAR TRAC E-TBT TOTAL BODY TRAINER OWNER’S MANUAL 7
ASSEMBLY AND SETUP
UNPACKING
NOTE: Do not remove the base from the shipping carton at this time.
Remove the top cover from the shipping carton. Remove all parts and shipping supports (except the base) from the carton, and verify
that the following parts are included in your shipment:
Description Qty
Base 1
Display Weldment 1
Upper Body Arms 2
End Caps 2
Bolt, Allen Head, M8 x 16 mm 4
Description Qty
Bolt, Hex Head, M8 x 20 8
Screw, Phillips Head 8
Flat Washer, M8 4
Set Screw, M8 x 65 mm 1
Lock Washer, M8 8
Note: If you ordered a PVS kit or an Embedded Display, please refer to the assembly and operating
instructions included with those products for proper setup and operation.
TOOLS REQUIRED
Your STAR TRAC E-TBT TOTAL BODY TRAINER can be assembled using the following tools:
Metric Hex Key Wrenches
Metric Open-End Wrenches
Metric Ratchet Socket Wrench Set
Torque Wrench
Phillips Head Screwdriver
Your STAR TRAC E-TBT TOTAL BODY TRAINER includes a hex key set and combination open-end wrench.
ASSEMBLY
1. Unpack and Position the Base
CAUTION: The rear end of the base is very heavy. Two people are needed to
lift this end when moving the base.
Cut the long edge of the shipping carton base at both ends. Fold the flap down
to make a ramp.
With the aid of a helper, lift the rear end of the base, and roll the base off of the
shipping carton platform. Place the base on the floor in the location where the
unit will be used. Be sure the chosen location is level.
2. Install the Display Weldment
NOTE: You will need someone to assist you to install the display weldment.
Have the person who is assisting you hold the display weldment while you route
the display cables and connect the neck.
Have your helper hold the display close the neck on the base, route the main
I/O cable, auxiliary power and coaxial cable up the full length of the display
neck before seating the display unit on the base.
NOTE: Depending on the display configuration, not all the cables may be used.
Step 1
Step 2a

8 STAR TRAC E-TBT TOTAL BODY TRAINER OWNER’S MANUAL
Gently push the display cables down into the neck, and slide the display into the
base. Be sure the display is fully seated. Secure the display to the base with
four M8 allen head bolts and four M8 flat washers. Use two bolts in the front side
of the neck, and two in the rear side. Tighten the screws securely to a torque of
8-10 lbs-ft.
Install the set screw into the left side of the neck and tighten to a torque of 8-10
lbs-ft.
3. Install the Upper Body Arms
NOTE: Take care not to install the upper body arms backwards. Be sure the
arms are positioned as shown when installed.
Place one upper body arm on the right-side hub. Be sure the pin in the arm
bracket engages the unthreaded hole on the hub. Secure the upper body arm to
the hub with four hex head bolts and four lock washers. Tighten the bolts
securely to a torque of 19-21 lbs-ft.
Repeat for the left-side upper body arm.
4. Install the End Caps
NOTE: Be sure the holes in each end cap face the rear of the unit.
Separate the two parts of the right-side end cap. Place the end cap around the hub.
Use a piece of tape to temporarily hold the end cap together if necessary.
Secure the end caps together with four Phillips head screws. Tighten the screws firmly.
Repeat for the left-side end cap.
5. Install Rear DisplayCover
Open the separately packaged display and remove the M4 screws from the back
plastics, set these aside for additional use. Attach the rear display cover to the
display weldment with four M4 screws and four M4 washers included with the
display.
Make note of the location of the Quick Disconnect Tab as this is referenced in
the next assembly step.
Step 3
Step 4
Step 2b
Step 5
Quick Disconnect Tab

STAR TRAC E-TBT TOTAL BODY TRAINER OWNER’S MANUAL 9
6. Connecting the Display Assembly
Note: This step assumes that you are connecting an
LED display assembly.
The following display connections will need to be made.
A. Connect the main display cable with a white 9 pin
connector to the J4 connector on the display PCB.
B. Connect the contact heart rate cable to the heart
rate board
C. Ground wire from the heart rate board must be
connected to the quick disconnect tab on the
display weldment (the location of the quick
disconnect tab is shown in Step 5.)
7. Final Display Assembly
With the electrical connections made you can now attach the display. For the TBT console
you will need to first remove the two plastic tabs from the bottom of the display console.
Simply flex the plastic back and forth several times and the tabs will break off or carefully
remove with cutters.
Next you will need to attach the front of the display to the weldment. First guide the bottom
of the display under the front tabs of the weldment and then second you will need to pivot
the display forward around the tabs to mate front display plastic to the rear plastic that is
attached to the weldment.
Once in place attach the plastics with the M4 screws included with the display. There are 8
M4 screws that attach around the perimeter of the display.
8. Final Setup
Be sure all bolts and screws are tightened securely.
Operate the unit to check for proper operation. The LED display should power up after
the first few strides and the console should turn on.
Move the unit to its final place of operation and check to see if the unit is level. If
needed, use the four leveling feet to properly level the unit. To do this, loosen the lock
nuts on the adjusters. Rotate the adjusters until the unit is stabilized, then retighten the
lock nuts.
You have now completed the assembly of your Star Trac E-TBT Total Body Trainer.
