Star SOM7R1E User manual

1
OMELET
MAKER
MODEL
SOM7R1E
Installation and
Operation
Instructions
2M-Z17244 Rev. - 8/12/2013
SOM7R1E

2M-Z17244; Owners Manual Omelet Maker
2
2
These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual
accompanying the appliance.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE
Using any part other than genuine Star factory supplied parts relieves the
manufacturer of all liability.
Star reserves the right to change specications and product design without
notice. Such revisions do not entitle the buyer to corresponding changes,
improvements, additions or replacements for previously purchased
equipment.
Due to periodic changes in designs, methods, procedures, policies and
regulations, the specications contained in this sheet are subject to change
without notice. While Star International Holdings Inc., Company exercises
good faith efforts to provide information that is accurate, we are not
responsible for errors or omissions in information provided or conclusions
reached as a result of using the specications. By using the information
provided, the user assumes all risks in connection with such use.
MAINTENANCE AND REPAIRS
Contact your local authorized service agent for service or required maintenance.
Please record the model number, serial number, voltage and purchase date in the area below and have it ready when
you call to ensure a faster service.
SAFETY SYMBOL
Model No.
Serial No.
Voltage
Purchase Date
Business 8:00 am to 4:30 p.m. Central Standard Time
Hours:
Telephone: [phone]
Fax: [phone]
E-mail [email protected]
[email protected]
W[email protected]
Website: www.star-mfg.com
Service Help Desk
Authorized Service Agent Listing
Reference the listing provided with the unit
or
for an updated listing go to:
Website: www.star-mfg.com
E-mail [email protected]
Mailing Address: Star International Holdings Inc., Company
10 Sunnen Drive
St. Louis, MO 63143
U.S.A

2M-Z17244; Owners Manual Omelet Maker
3
SPECIFICATIONS
Model Voltage Amps Watts Plug Weight
SOM7R1E 120V 7.5 900 NEMA5-15P
IL2677
10”
9.5”
22”
GENERAL OPERATION
This equipment is designed and sold for commercial use only by personnel trained and experienced in its
operation and is not sold for consumer use in and around the home nor for use directly by the general public in
food service locations.
INSTALLATION
For your protection, we recommend that a qualied electrician install this appliance. The electrician should be
familiar with electrical installations and your local electrical requirements. Proper connections and power supply
are essential for efcient performance. The supply circuit should be properly fused as required by electrical
code. Plug the unit into a proper A.C. voltage wall outlet only. A three-prong plug is provided with the unit. If an
adapter is used be sure a good ground is provided.
LOAD
The rated load is on the nameplate. The line in the wall outlet must be heavy enough to carry this load, or the
wafe baker will be slow in performance.
DO NOT CONNECT TO DIRECT CURRENT (DC).
NON-STICK COATED PLATENS
DO NOT USE METAL UTENSILS TO REMOVE OMELET FROM THE COATED
PLATENS. THIS WILL VOID THE WARRANTY.
DO NOT CLEAN NON-STICK PLATENS WITH ABRASIVES.
THIS WILL VOID THE WARRANTY.
CAUTION
WARNING
CAUTION
CAUTION

2M-Z17244; Owners Manual Omelet Maker
4
CORD, PLUG AND GROUND INSTRUCTIONS
For your protection, this appliance is equipped with a 3-conductor power cord, having a grounding type plug. It
should only be used with a properly grounded 3-prong receptacle. Do not modify. If you use an adapter be sure
your system is grounded. Connect the green wire to a mounting screw of the receptacle. For ungrounded electrical
systems, connect the green wire of the adapter to a known permanent ground.
RELEASE AGENT CAUTION
If you nd it necessary to use a release agent to keep omelets from sticking, spray it on sparingly. Spraying may
oversaturate the platens and the excess has the possibility of building up inside the baker and causing damage.
SEASONING PLATENS
(Not applicable to non-stick coated grids)
GRIDSANDCUPSHAVEVERYHIGHTEMPERATURES. DO NOT COME IN DIRECT
CONTACT WITH THESE PARTS WHEN THE WAFFLE BAKER IS IN OPERATION.
DO NOT ALLOW THE CORD TO COME INTO CONTACT WITH HOT GRIDS
MAKING OMELET
Turn the unit on and allow to pre-heat for 15 minutes with the platens closed. Once the baker has reached proper
temperature you can proceed as follows:
1. Apply releasing agent, if needed
2. Lift the lid, pour in mix and close.
3. Start timer by pressing the start/stop pad.
4. When timer beeps, depress the start/ stop pad.
5. Remove omelet. (Do not use metal utensils on coated platens.)
6. For next omelet repeat steps 1 through 6.
SETTING THE TIME:
If necessary, the factory pre-set timer can be adjusted to satisfy individual preferences.
To increase time, Press & hold the “UP” button, then press the “Start/Stop” button the
amount you wish to increase the cooking time.
To decrease time, Press & hold the “DOWN” button, then press the “Start/Stop” button
the amount you wish to decrease the cooking time.
SETTING THE TEMPERATURE
If necessary, the factory pre-set temperature can be changed: To view the temperature, depress and hold “TEMP”
button and press “START/STOP” button. Hold both buttons for 3 seconds for the pre-set temperature to be
displayed.
To increase the temperature press “+” button; to decrease press “-“ button.
To lock the temperature press the “START/STOP” button.
Changing the displayed temperature from “F” (Fahrenheit) to “C” (Celsius) -
Hold “TEMP” button and turn “OFF” and then “ON” the lighted switch on the front panel. To change back from “C”
to “F”, repeat the same procedure. Setting the temperature is available in both modes “F” and “C”.
Omelet Tips
1. Don't use more than two (2) eggs or the equivalent amount of egg substitute per omelet.
2. Overloading the omelet with toppings such as ham, onions, mushrooms, etc.., may result in
inconsistant cooking.
3. Add cheese after the omelet is removed from the omelet maker.
CAUTION

2M-Z17244; Owners Manual Omelet Maker
5
CLEANING
Clean all surfaces of the unit every day that it is in use, using a damp cloth and mild detergent.
Wipe the cooking surfaces with damp cloth & mild deterent, rinse with a damp cloth.
DO NOT CLEAN USING A WATER JET OR SIMILAR DEVICE FOR CLEANING.
DO NOT IMMERSE IN WATER AT ANY TIME.
DO NOT CLEAN NON-STICK GRIDS WITH ABRASIVES. THIS WILL VOID THE WARRANTY.
For cleaning the baker outside use only a soft cloth and mild soap to keep the exterior surfaces bright and shining. Do
not use detergents, strong abrasives or metal scouring pads on the exterior surfaces of the wafe baker.
CAUTION
CAUTION
TERMINAL
BOTTOM ELEMENT
SWITCH
E
RTD PROBE
A
C
B
TOP ELEMENT
G
WIRE ASSEMBLY
WIRE ASSEMBLY
WIRE ASSEMBLY
WIRE ASSEMBLY
WIRE ASSEMBLY
WIRE ASSEMBLY
WIRE ASSEMBLY
CORD ASSY
120V 15A
GREEN
GROUND
F
G
E
C
D
B
A
ELEMENT
TRANSFORMER SWITCH
RELAY
TERMINAL BLOCK
GROUND
ELEMENT
D
ELECTRICAL SCHEMATIC
*
*
F
TIME/TEMP TIME/TEMP
GROUND
C
D
G
E
BLOCK
TRANSFORMER
WIRE ASSEMBLY
J
CONTROL
J
CONTROLLER
RELAY
(on controller)
WIRING DIAGRAM SWB7R1E, SOM7R1E
FUSE (2)
SK1607
SEE NOTE 1
NOTES:
1. USE FUSES ON 230V CE MODELS
ONLY.
240V 7.5A
230V CE
REV. F 3/29/2005
A
D
(BACK VIEW)
SWITCH
C
B
N
L
(BLUE)
WHITE
BLACK
(BROWN)
2. RELAY MAY BE ON THE CONTROL
BOARD IN SOME CASES.
3. 2 H WIRES ARE NOT NECESSARY
IF RELAY IS ON THE CONTROL
BOARD.

2M-Z17244; Owners Manual Omelet Maker
6
SK2676, REV. -, 8/06/13
MODEL: SOM7RIE; OMELET MAKER
1
2
3
4
10
11
37
12
18
17
12
10
14
15
16
3
2
19
31
32
33
34
35
36
36
30
25
29
26
27
28
20
21 22 23 24
13
589
6
7
39
40
41
42
38
38
43
44
42
41
40
45

2M-Z17244; Owners Manual Omelet Maker
7
PARTS LIST August 12, 2013, Rev -
Model: SOM7R1E, OMELET MAKER
Fig No. Part Number Quantity Description
1 2P-Z1735 2 PLUG CAP 3/4
2 2C-Z2670 4 NUT 1/4-20 W/LOCKWASHER
3 2C-Z1674 2 STUD 1/4-20 X 2 1/4
4 2D-Z2016 1 TOP CUP 7” STANDARD
5 B9-73044 1 CUP SUPPORT HINGEASSY
6 2A-Z2606 1 SPACER SWB7R
7 2R-09-WB-0027 1 HANDLE-BLK 3/8-16
8 2A-Z3728 1 HINGE PIN
9 2C-08-07-0040 2 NUT 1/4-20ACHD STL NP
10 B9-Z8773 2 PLATE-ELEMENT
11 2E-Z1837 1 RTD PROBE 2000 OHM
12 2N-Z2843 1 ELEMENT, BTM, 475W 120V
2N-Z2040 1 ELEMENT, TOP, 425W 120V
13 2F-Z17129 2 PLATEN COATED - SOM
14 2C-8833 2 SCREW 8-18X1/2 HEX STLNP
15 B9-04-WB-0046 1 CLAMP WIRE SUPPORT
16 2V-Z1799 1 7” CUP SUPPORT
17 B9-04-WB-0231 1 WIRE COVER
18 B9-Z2008 1 WIRE CHANNEL
19 2E-Z5375 1 TERMINAL BLOCK-3 POLE
20 B9-Z1925 1 BRACKET-TERMINAL
21 2K-Z1971 8 SPACER .257X.75X.25 NYLON
22 2J-Z17245 1 TIMER/TEMP CONTROL PROGRAMMED
23 B9-Z2612 1 BRACKET-TRANSFORMER
24 2E-05-07-0351 1 TRANSFORMER 115/10V 6VA
25 B9-Z1926 1 BOTTOM SINGLE
26 2I-Z0057 4 FOOT, RUBBER
27 2P-9564 4 PLUG-RUBBER
28 2K-Y3240 1 BUSHING HEYCO SR 17-2
29 2C-1646 12 SCREW #8X3/8 AB THP STL
30 2C-08-07-0207 2 NUT 10-24 HEX STLNP
31 2D-Z7611 1 BOTTOM CUP-STANDARD WB
32 B9-73074 1 BODYASSY SGL WAFFLE BKR
33 2E-Z1858 1 SWITCH-LIGHTED
34 2M-Z2623 1 WAFFLE BAKER OVERLAY
35 B9-Z1853 1 DRIP TRAY SINGLE
36 2C-Z1675 1 ROLL PIN 3/16 X 2
37 B9-Z17243 1 BRACKET - PROBE
38 B9-73065 1 MICAASSY SINGLE/DOUBLE
39 2C-08-07-0137 2 SCREW 8-32 x 3/4 HEXHD
40 2C-H8670 4 WASHER, SS #8 INT
41 2C-08-07-0221 4 WASHER 7/16OD/3/16ID18GA
42 Z1-06-07-0004 2 MICA1.50 x 1.75
43 2C-08-07-0025 2 WASHER .072THK CERAMIC
44 B9-Z3821 1 HOLDER-MICA
45 2C-2556 2 NUT 8-32 HEX STLNP
NI 2E-Z3385 1 CORD SET 14/3 120V 15A
NI 2I-09-WB-0002 2 INSULATION 7” CIRCLE

2M-4497-2 6/1312
The foregoing warranty is in lieu of any and all other warranties expressed or implied and constitutes the entire warranty.
FOR ASSISTANCE
Should you need any assistance regarding the Operation or Maintenance of any Star equipment; write, phone, fax or email our Service Department.
In all correspondence mention the Model number and the Serial number of your unit, and the voltage or type of gas you are using.
ALL:
*Pop-Up Toasters
*Butter Dispensers
*Pretzel Merchandisers
(Model 16PD-A Only)
*Pastry Display Cabinets
*Nacho Chip Merchandisers
*Accessories of any kind
*Sneeze Guards
*Pizza Ovens
(Model PO12 Only)
*Heat Lamps
*Pumps-Manual
Visit our Website at: www.star-mfg.com Email: [email protected]
THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL
This unit has been tested for proper operation before leaving our plant to insure delivery of your unit in perfect condition. However, there are instances in which
the unit may be damaged in transit. In the event you discover any type of damage to your product upon receipt, you must immediately contact the transportation
company who delivered the item to you and initiate your claim with same. If this procedure is not followed, it may affect the warranty status of the unit.
LIMITED EQUIPMENT WARRANTY
All workmanship and material in Star products have a one (1) year limited warranty on parts & labor in the United States and Canada. Such warranty is limited
to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited to the repair
of defects without charge, by the factory authorized service agency or one of its sub-agencies. Models that are considered portable (see below) should be taken
to the closest Star service agency, transportation prepaid.
>Star will not assume any responsibility for loss of revenue.
>On all shipments outside the United States and Canada, see International Warranty.
*The warranty period for the Ultra-Max, Hot Plates, Griddles, Charbroilers is (3) years parts & labor.
*The warranty period for the Star-Max, Charbroilers, Griddles, Hot Plates, Fryers & Finishing Oven is (2) years parts & labor.
*The warranty period for the JetStar six (6) ounce & Super JetStar eight (8) ounce series popcorn machines is two (2) years.
*The warranty period for the Chrome-Max Griddles is ve (5) years on the griddle surface. See detailed warranty provided with unit.
*The warranty period for Teon/Dura-Tec coatings is one year under normal use and reasonable care. This warranty does not apply if damage occurs to
Teon/Dura-Tec coatings from improper cleaning, maintenance, use of metallic utensils, or abrasive cleaners, abrasive pads, product identiers and
point-of-sale attachments, or any other non-food object tha comes in continuous contact with the roller coating. This warranty does not apply to the
“non-stick” properties of such materials.
>This warranty does not apply to "Special Products" but to regular catalog items only. Star's warranty on "Special Products" is six (6) months on parts
and ninety (90) days on labor.
>This warranty does not apply to any item that is disassembled or tampered with for any purpose other than repair by a Star Authorized Service Center or
the Service Center's sub-agency.
>This warranty does not apply if damage occurs from improper installation, misuse, wrong voltage, wrong gas or operated contrary to the Installation and
Operating instructions.
>This warranty is not valid on Conveyor Ovens unless a "start-up/check-out" has been performed by a Factory Authorized Technician.
PARTS WARRANTY
Parts that are sold to repair out of warranty equipment are warranted for ninety (90) days. The part only is warranted, the labor to replace the part is NOT warranted.
SERVICES NOT COVERED BY WARRANTY
PORTABLE EQUIPMENT
Star will not honor service bills that include travel time and mileage charges for servicing any products considered "Portable" including items listed below.
These products should be taken to the Service Agency for repair:
1. Travel time and mileage rendered beyond the 50 mile radius limit
2. Mileage and travel time on portable equipment (see below)
3. Labor to replace such items that can be replaced easily during a daily cleaning
routine, ie; removable kettles on fryers, knobs, grease drawers on griddles, etc.
4. Installation of equipment
5. Damages due to improper installation
6. Damages from abuse or misuse
7. Operated contrary to the Operating and Installation Instructions
8. Cleaning of equipment
9. Seasoning of griddle plates
10. Voltage conversions
11. Gas conversions
12. Pilot light adjustment
13. Miscellaneous adjustments
14. Thermostat calibration and by-pass adjustment
15. Resetting of circuit breakers or safety controls or reset buttons
16. Replacement of bulbs
17. Replacement of fuses
18. Repair of damage created during transit, delivery, &
installation OR created by acts of God
*The Model 510FD, 510FF Fryer.
*The Model 526TOAToaster Oven.
*The Model J4R, 4 oz. Popcorn Machine.
*The Model 518CMA & 526CMA Cheese Melter.
*The Model 12MC & 15MC & 18MCP Hot Food Merchandisers.
*The Model 12NCPW & 15NCPW Nacho Chip/Popcorn Warmer.
*All Hot Dog Equipment except Roller Grills & Drawer Bun Warmers.
*All Nacho Cheese Warmers except Model 11WLA Series Nacho Cheese Warmer.
*All Condiment Dispensers except the Model HPD & SPD Series Dispenser.
*All Specialty Food Warmers except Model 130R, 11RW Series, and 11WSA Series.
*All QCS/RCS Series Toasters except Model QCS3 & RCS3 Series.
*All Fast Steamer Models except Direct Connect Series.
