Star SWCBE User manual

1
WAFFLE
BAKERS
MODEL
SWCBE
SWB7R1E
SWB7R2E
SWB7RBE
SWB8SQE
SWB8RBLE
Installation and
Operation
Instructions
2M-Z7728 Rev. H 11/26/2014
SWB7R2E

2
2
These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual
accompanying the appliance.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE
Using any part other than genuine Star factory supplied parts relieves the
manufacturer of all liability.
Star reserves the right to change specications and product design without
notice. Such revisions do not entitle the buyer to corresponding changes,
improvements, additions or replacements for previously purchased
equipment.
Due to periodic changes in designs, methods, procedures, policies and
regulations, the specications contained in this sheet are subject to change
without notice. While Star International Holdings Inc., Company exercises
good faith efforts to provide information that is accurate, we are not
responsible for errors or omissions in information provided or conclusions
reached as a result of using the specications. By using the information
provided, the user assumes all risks in connection with such use.
MAINTENANCE AND REPAIRS
Contact your local authorized service agent for service or required maintenance.
Please record the model number, serial number, voltage and purchase date in the area below and have it
ready when you call to ensure a faster service.
SAFETY SYMBOL
Model No.
Serial No.
Voltage
Purchase Date
Business 8:00 am to 4:30 p.m. Central Standard Time
Hours:
Telephone: [phone]
Fax: [phone]
E-mail [email protected]
Website: www.star-mfg.com
Service Help Desk
Authorized Service Agent Listing
Reference the listing provided with the unit
or
for an updated listing go to:
Website: www.star-mfg.com
E-mail [email protected]
Mailing Address: Star International Holdings Inc., Company
10 Sunnen Drive
St. Louis, MO 63143
U.S.A

2M-Z7728; Owners Manual Wafe Baker
A
Electrical
B
D
C
IL2937
MODEL SPECIFICATION
Model Specications
Wafe Type Model Voltage Watts Amps Cord
Weight Dimensions
Installed Shipping A B C D
Cone SWCBE
120V 1,320 11.0 NEMA 5-15P
29lb
(13kg)
32lb
(14.5 kg)
10”
(25.5 cm)
18 1/4”
(46.3 cm)
12 1/2”
(31.7 cm)
25 1/2”
(64.7 cm)
208V 990 4.8 NEMA 6-15P
230V 1,210 5.3 CEE7-7
240V 1,320 5.5 NEMA 6-15P
Standard SWB7R1E
120V 900 7.5 NEMA 5-15P
20lb
(9kg)
23lb
(10.5kg)
10”
(25.5 cm)
15 3/4”
(40 cm)
9 1/2”
(24.1 cm)
22”
(55.9 cm)
208V 676 3.3 NEMA 6-15P
230V 825 3.5 CEE7-7
240V 900 3.8 NEMA 6-15P
Standard SWB7R2E
120V 1,800 15.0 NEMA 5-15P
37lb
(17kg)
41lb
(18.7kg)
20”
(50.8 cm)
15 3/4”
(40 cm)
9 1/2”
(24.1 cm)
22”
(55.9 cm)
208V 1,352 6.5 NEMA 6-15P
230V 1,650 7.2 CEE7-7
240V 1,800 7.5 NEMA 6-15P
Square SWB8SQE
120V 1,645 13.7 NEMA 5-15P
33lb
(15kg)
36lb
(16.5kg)
10”
(25.5 cm)
18 1/4”
(40 cm)
12 1/2”
(31.7 cm)
27”
(68.6 cm)
208V 1,235 6.0 NEMA 6-15P
230V 1,510 6.6 CEE7-7
240V 1,645 6.8 NEMA 6-15P
Belgian SWB7RBE
120V 1,000 8.3 NEMA 5-15P
25lb
(11kg)
28lb
(13kg)
10”
(25.5 cm)
18 1/4”
(40 cm)
14”
(35.5 cm)
25 1/2”
(64.7 cm)
208V 751 3.6 NEMA 6-15P
230V 920 4.0 CEE7-7
240V 1,000 4.2 NEMA 6-15P
Belgian SWB8RBLE
120V 1,320 11.0 NEMA 5-15P
28lb
(12.7kg)
31lb
(14kg)
10”
(25.5 cm)
18 1/4”
(40 cm)
14”
(35.5 cm)
26 1/2”
(67.3 cm)
208V 990 4.8 NEMA 6-15P
230V 1,210 5.3 CEE7-7
240V 1,320 4.8 NEMA 6-15P

2M-Z7728; Owners Manual Wafe Baker
GENERAL INFORMATION
This equipment is designed and sold for commercial use only by personnel trained and experienced in
its operation and is not sold for consumer use in and around the home nor for use directly by the general
public in food service locations.
INSTALLATION
For your protection, we recommend that a qualied electrician install this appliance. The electrician
should be familiar with electrical installations and your local electrical requirements. Proper connections
and power supply are essential for efcient performance. The supply circuit should be properly fused as
required by electrical code. Plug the unit into a proper A.C. voltage wall outlet only. A three-prong plug is
provided with the unit. If an adapter is used be sure a good ground is provided.
LOAD
The rated load is on the nameplate. The line in the wall outlet must be heavy enough to carry this load, or
the wafe baker will be slow in performance.
DO NOT CONNECT TO DIRECT CURRENT (DC).
TEFLON®COATED WAFFLE BAKERS
DO NOT USE METAL UTENSILS TO REMOVE WAFFLE FROM THE TEFLON®COATED
WAFFLE BAKER. THIS WILL VOID THE WARRANTY.
DO NOT CLEAN TEFLON®GRIDS WITH ABRASIVES. THIS WILL VOID THE
WARRANTY.
CORD, PLUG AND GROUND INSTRUCTIONS
For your protection, this appliance is equipped with a 3-conductor load cord, having a grounding type plug.
It should only be used with a properly grounded 3-prong receptacle. Do not modify. If you use an adapter
be sure your system is grounded. Connect the green wire to a mounting screw of the receptacle. For
ungrounded electrical systems, connect the green wire of the adapter to a known permanent ground.
RELEASE AGENT CAUTION
If you nd it necessary to use a release agent to keep wafes from sticking, you should brush it on.
Spraying may oversaturate the grids and the excess has the possibility of building up inside the baker and
causing damage. If you only have a spray type release agent, try spraying it into a container and using
the contents with a pastry brush.
SEASONING WAFFLE GRIDS
(Not applicable to Teon ® coated grids)
With a pastry brush, apply vegetable oil, butter, or grid release agent on both grids. Turn power on and
allow to preheat for twenty minutes. Lift the lid and re-apply vegetable oil, or grid release agent. Allow the
unit to heat for ve more minutes. The baker is now ready for use.
GRIDS AND CUPS HAVE VERY HIGH TEMPERATURES. DO NOT COME IN DIRECT
CONTACT WITH THESE PARTS WHEN THE WAFFLE BAKER IS IN OPERATION.
DO NOT ALLOW THE CORD TO COME INTO CONTACT WITH HOT GRIDS.
CAUTION
WARNING
CAUTION
CAUTION
CAUTION

2M-Z7728; Owners Manual Wafe Baker
OPERATION
MAKING WAFFLES
Turn the unit on and allow to pre-heat for 15 minutes with the grids closed. Once the baker has reached proper
temperature you can proceed as follows:
1. Brush on releasing agent, if needed
2. Lift the lid, pour in mix and close. (Belgian units wait 10 seconds)
3. Start timer by pressing the start/stop pad.
4. Rotate grids 180o. (Belgian units only)
5. When timer beeps, depress the start/ stop pad.
6. Rotate grids 180o (Belgian units only)
7. Remove wafe. (Do not use metal utensils on teon coated wafe bakers.)
8. For next wafe repeat steps 1 through 7.
Setting the Time:
If necessary, the factory pre-set timer can be adjusted to satisfy individual preferences.
To increase time, Press & hold the “UP” button, then press the “Start/Stop” button the
amount you wish to increase the cooking time.
To decrease time,Press & hold the “DOWN” button, then press the “Start/Stop” button
the amount you wish to decrease the cooking time.
SETTING THE TEMPERATURE
If necessary, the factory pre-set temperature can be changed: To view the temperature, depress and hold
“TEMP” button and press “START/STOP” button. Hold both buttons for 3 seconds for the pre-set temperature
to be displayed.
To increase the temperature press “+” button; to decrease press “-“ button.
To lock the temperature press the “START/STOP” button.
Changing the displayed temperature from “F” (Fahrenheit) to “C” (Celsius) -
Hold “TEMP” button and turn “OFF” and then “ON” the lighted switch on the front panel. To change back from
“C” to “F”, repeat the same procedure. Setting the temperature is available in both modes “F” and “C”.
HELPFUL HINTS
1. During long slack periods of the day, turn off the baker. During short slack periods, leave unit on with
the grids closed. This will help minimize carbon buildup.
2. Do not store batter in the refrigerator and expect the same speed in baking. Cold batter will take
longer to bake.
3. For proper release of wafes it is important that the batter contain the proper amount of shortening.

2M-Z7728; Owners Manual Wafe Baker
CLEANING
For non-coated grids: Clean outside of baker every day that it is in use. Do not clean grids unless a buildup
of carbon forms. In order to remove carbon from grids, unplug the unit, use a carbon releasing agent that
is safe for aluminum, and is approved by your corporate ofce. Follow the instructions with the releasing
agent.
A nylon brush may then be used to remove the carbon buildup, DO NOT use a wire brush on the grid
surface, it will scratch the surface and will lead to faster buildup of carbon.
Note: When carbon buildup on the grids is removed, they will need to be reseasoned.
See "Seasoning Wafe Grids"
DO NOT CLEAN USING A WATER JET OR SIMILAR DEVICE FOR CLEANING.
DO NOT IMMERSE IN WATER AT ANY TIME.
DO NOT CLEAN TEFLON®GRIDS WITH ABRASIVES. THIS WILL VOID THE WARRANTY.
For cleaning the baker outside use only a soft cloth and mild soap to keep the exterior surfaces bright
and shining. Do not use detergents, strong abrasives or metal scouring pads on the exterior surfaces of
the wafe baker.
CAUTION
CAUTION
