Stark 67001 User manual

PORTABLE ELECTRIC CEMENT MIXER BARROW MACHINE
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
ITEM: 67001
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: [phone] MON-FRI 9AM TO 3PM PST
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: [phone] MON-FRI 9AM TO 3PM PST

IMPORTANT SAFETY INFORMATION
GENERAL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to follow the warnings and instructions
may result in electric shock, re and/or serious injury. Save all warnings and instructions for
future reference.
SAFETY
The warnings, precautions, and instructions discussed in this instruction manual cannot cover
all possible conditions and situations that may occur. It must be understood by the operator that
common sense and caution are factors which cannot be built into this product, but must be supplied
by the operator. Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS
before operating. Failure to follow the safety rules and other basic safety precautions may result in
serious personal injury.
Stay alert, watch what you are doing, and use common sense when operating the tool. DO NOT use the
tool while you are tired or under the inuence of drugs, alcohol, or medication.
Dress properly. DO NOT wear loose clothing, dangling objects, or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery, or long hair can be caught in moving parts.
Air vents on the tool often cover moving parts and should be avoided.
Wear the proper personal protective equipment when necessary. Use ANSI Z87.1 compliant safety
goggles (not safety glasses) with side shields, or when needed, a face shield. Use a dust mask in dusty
work conditions. Also use non-skid safety shoes, hard-hat, gloves, dust collection systems, and hearing
protection when appropriate. This applies to all persons in the work area.
1
Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
DO NOT allow persons to operate or assemble the product until they have read this manual and have
developed a thorough understanding of how it works.
DO NOT modify this product in any way. Unauthorized modication may impair the function and/or
safety and could affect the life of the product. There are specic applications for which the product
was designed.
Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit.
Cluttered, wet, or dark work areas can result in injury. Using the product in conned work areas
may put you dangerously close to cutting tools and rotating parts.
DO NOT use the product where there is a risk of causing a re or an explosion; e.g., in the
presence of ammable liquids, gases, or dust. The product can create sparks, which may ignite the
ammable liquids, gases, or dust.
Keep children and bystanders away from the work area while operating the tool. DO NOT allow
children to handle the product.

IMPORTANT SAFETY INFORMATION
DO NOT overreach. Keep proper footing and balance at all times.
2
Remove adjusting tools, shovels, hand trowels etc. Make sure all adjusting tools and equipment
are removed from the mixer prior to turning it on.
Check for damaged parts before each use. Carefully check that the product will operate properly and
perform its intended function. Replace damaged or worn parts immediately. Never operate the
product with a damaged part.
Keep a safe clearance around the Cement Mixer. Keep all people a minimum of six feet away from
the mixer during operation.
NEVER stick your hands and/or tools into the drum assembly while the mixer is in operation.
Use only accessories that are recommended by the manufacturer for use with your product.
Accessories that may be suitable for one product may create a risk of injury when used with another tool.
Never use an accessory that has a lower operating speed or operating pressure than the tool itself.
DO NOT leave the tool running unattended.
DO NOT overload the mixer. Capacity is 270lbs. An overload may damage the equipment.
DO NOT move the mixer during operation. The mixer could tip over and damage the engine.
Prolonged exposure to noise levels above 85 dBA is hazardous to hearing. Always wear ANSI
approved hearing protection when operating or working near the cement mixer. ANSI approved
hearing protectors are highly recommended.
People with pacemakers should consult with their physician before using this product. Operation
of equipment in close proximity to a heart pacemaker could cause interference or failure of the
pacemaker.
Always operate the cement mixer on a at surface. Operating at an angle could cause the
machine to roll or tip over during operation.
NEVER operate the mixer if it is sitting in water. Never attempt to plug in the mixer if the plug is
wet.
Always use the proper extension cord. The motor will draw a maximum of 8 amps under start
up load. Base your wire gauge on 8 amps and the length of the cord required.
SAVE THESE WARNINGS

3
ASSEMBLY
1. Insert the rear leg of the stand into the front frame
using the only nut and bolt supplied. Tighten the
bolt using the wrench that is supplied. The rear leg
is also used as a tongue to pull the mixer to another
location.
2. Slide the wheels onto the front frame axle and
insert the cotter pin into the hole in the axle to hold
the wheels in place.
3. Attach the drum rotation base to the motor gear
box assembly frame using the heavy duty anchor
pin. After you connect the motor frame and rotation
base with the anchor pin insert the cotter pin to hold
the anchor pin in place.
4. Slide the rotation base, motor frame assembly
onto the shaft of the cement mixer frame.

4
ASSEMBLY
5. Mount the cement mixer drum onto the gear box
shaft. Align the guide notch with the pin on the
gear box shaft. Secure the drum in place using the
washer and T-Handle bolt.
6. Mount the mixing paddles inside the drum using
the large Phillips head screws and bolts. The screw
head is on the outside of the drum and the bolt on
the inside. Then, insert the tilting handle through
the hole in the motor gear box frame. It goes in at a
slight angle. The notch goes in rst and aligns with
the side of the frame. Secure it with the cotter pin
provided.
OPERATING INSTRUCTIONS
1. Set your mixer up on a at surface.
2. Use at least a 14 gauge, 3-prong grounded extension cord to plug in your cement mixer. A heavier
gauge may be required of you need a cord longer than 50 feet.
3. Load the mixer with concrete mix, sand and water while it is running. Be careful not to get water on
the motor or electrical parts.
4. Pour the mixed concrete by lifting the dump handle while the machine is running. Be sure to pour the
mix slowly and smoothly, avoid tilting the mixer over.
5. If the motor overheats it will shut off. It has a thermal protection switch. Unplug the machine for at least
15 minutes then plug it back in and press the start switch. If it does not start check your circuit breaker
and extension cord. If a problem still exists, contact your distributor.
6. To move your mixer lift it and pull it with the rear leg of the stand while holding the dump handle. Never
try to move it when it is loaded. It may be too heavy and tip over.

MAINTENANCE
5
Clean your mixer after each use. When washing the mixer do not get water in the motor. Be sure the
machine is unplugged.
Keep all moving parts lightly greased.
Change the gear box oil every 3000 hours of operation. Use SAE-40 oil.
Make sure the breather openings on the end of the motor are open and clean of debris. If they are
blocked, the motor oil will overheat and the machine will shut down.
TO MOVE THE MIXER: Disconnect the power cord. Make sure the
mixer is empty before you move it. Lift the mixer with the rear support
handle of the frame and hold the dump handle. Pull the machine to
the desired location.
Do not apply water in or around the motor base cover.
Periodically recheck all nuts, bolts and screws for tightness.
When not in use, put the mixer in a safe, secure area that has no child accessibility.
CAUTION: NEVER leave the mixer running while unattended. Do not turn the mixer off while full
of cement.

6
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available individually
as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
