Starkey OtoLens User manual

IIC (Invisible-In-The-Canal)
OPERATIONS MANUAL

Table of Contents
Overview
Features, Controls and Identification. . . . . . . . . . . . . 3
Preparation
Batteries................................... 4
BatteryIndicators............................ 6
InsertionandRemoval........................ 7
Operation
On&Off .................................. 10
Multimemory Settings . . . . . . . . . . . . . . . . . . . . . . . . 11
T2(touch-tone) Function . . . . . . . . . . . . . . . . . . . . . . 12
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . 13
TelephoneUse.............................. 14
Reminder.................................. 17
SummaryofSettings......................... 18
InstrumentCare............................. 19
Hearing System Care
ServiceandRepair........................... 21
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . 21
Tips for Better Communication
ForYou.................................... 22
For Your Family and Friends . . . . . . . . . . . . . . . . . . . 23
FDA Information
RequiredInformation......................... 24

3
2
Features, Controls and Identification
Your hearing system controls include:
1. Microphone opening
2. Sound outlet (receiver)
3. Battery compartment (on/off control)
4. Removal handle
5. Vent (optional)
Your hearing system can be identified by the
whiteR for the right ear and L for the left ear
and the serial number:
6. Location of serial number
IIC Overview
1
3
5
4
6

4
Preparation
Batteries
Your hearing system uses a battery as its power
source. This battery size can be identified by the
yellow (10) color code on the packaging.
To insert or replace the battery:
1. Use the nail grip on the battery door.
2. Open the battery door gently and remove
the old battery.
3. Remove the tab from the new battery.
4. Line up the battery’s “+” sign (flat side of the
battery) with the “+” on the battery door.
5. Close the battery door.
Warnings
Batteries are dangerous if swallowed. To help
prevent the accidental ingestion of batteries:
Keep out of reach of children and pets
Check your medications before taking them –
batteries have been mistaken for pills
Never put batteries in your mouth, as they can
easily be swallowed
National Button Battery Ingestion Hotline:
202-625-3333

5
Preparation
1 2
3 4
5

6
Preparation
Battery Indicator Tones
An indicator will sound when the battery voltage is
low. You have approximately 5 minutes* to replace
the battery. An indicator will sound just before the
battery stops working.
* Actual time between low battery indicator and
shut down will vary depending on environmental
noise levels and brand of battery used.
Helpful Hints
• NEVERFORCETHEBATTERYDOORSHUT;
thiscouldresultinseriousdamage;ifthedoorwill
not close securely, check that the battery is
inserted correctly.
• Donotopenthebatterydoortoofarordamageis
likely to occur.
• Becauseoftheirsize,it’sagoodideatochange
and replace batteries above a table or desk to
reduce the risk of dropping the instrument or
battery.
• Disposeofusedbatteriesimmediatelyinthe
proper waste or recycling container.
• Because batteries can vary in size and
performance, your hearing care professional is your
best source for lifespan estimates and verification
that you are using the proper size and type.

7
Preparation
Insertion and Removal
It is very important that you work closely with your
hearing professional to develop an insertion
technique that is specific for the shape and
contours of your ear. Improper insertion will
result in unsatisfactory performance and comfort.
To insert the hearing instrument:
1)DetermineLeftorRightbylocatingtheside
marker on the hearing instrument.
2)Holdtheinstrumentinthesamesidehandwith
the dot marker on top.
3) Lift the device to the ear and place at the opening
of the ear canal.
4) Push the device into place in the ear, using the
end of the removal cord as indication that the
device is inserted all the way.

8
Preparation
To remove the hearing instrument:
Grasp the removal handle found at the bottom
of the ear canal and gently remove the hearing
instrument from the ear.

9
Preparation
Helpful Hints
• Itisnotunusualforthehearingaidtofeelquite
foreign in the ear canal initially, but very natural
over time as your ear adapts. It may be necessary
to adopt a wearing schedule that gradually
increases the time that you wear your hearing aids.
Work with your hearing professional to develop a
wearing schedule appropriate for your needs.
• Minor irritation and inflammation may occur as your
earbecomesaccustomedtohavinganobjectinit;
if so, please contact your hearing care professional.
• Ifanactualallergi c reaction occurs, alternative
materialsareavailable;contactyourhearing
care professional.
• Severeswelling,dischargefromtheear,excessive
wax, or other unusual conditions warrant
immediate consultation with a physician.
• Ifdesired,applyasmallamountofOto-Easetothe
outside of the hearing instrument being careful to
not get any in the receiver/sound opening.
• Itmaybehelpfultolifttheexternalearwithyour
opposite hand to straighten the ear canal during
insertion. You will know the hearing instrument is
in position when it sits firmly and comfortably in
the ear.
• Verifyproperinsertionvisuallywithastationary
hand mirror reflecting the opening of the ear
canal, and finally adjust the position of the removal
strand as directed by your hearing professional.

10
Operation
Insert a battery and
completely close the
battery door.
To turn OFF:
Open the battery door until
the battery is no longer touching
the battery contacts.
Some hearing instruments are programmed to
have a Power-On delay. Your hearing professional
will place a check in the box below if your hearing
instruments have this feature.
The Power-On delay means that your instruments
will take several seconds to power up once they
have been turned on. This feature allows you to
get the hearing instruments in your ear before they
start to amplify sound. You may hear a tone series
indicating that your device is fully powered on.
On & Off
To turn ON:
My hearing instrument has a Power-On delay.
