Starkey SurfLink Assembly instructions

QuickTIPS
SURFLINK MEDIA
PRODUCT AVAILABILITY: Picasso, Muse iQ, SoundLens Synergy iQ, Muse, SoundLens Synergy,
Z Series Wireless, and 3 Series Wireless Devices
Launch Inspire®X, then connect hearing devices. Refer to the Initial Fit
Protocol QuickTIPs for information on getting started.
SETUP IN INSPIRE X
1. In Inspire X, select the Accessories tab from the left navigation bar.
2. Select the check box next to Media.
3. Select which memories will automatically accept a streamed
signal by selecting the boxes adjacent to the memory name under
Media Streaming and select Hearing Aid Microphone Setting While
Streaming for each memory, if desired.
4. If using the Advanced SurfLink Remote Control or the SurfLink
Mobile along with the SurfLink Media:
» Select the check box next to the SurfLink Remote Control or
SurfLink Mobile.
» Ensure the Favorite Button is configured to Stop/Start Audio.
NOTE: Stream Boost is the default streaming memory. Stream
Boost may be adjusted in the QuickFit or Fine Tuning screens as
needed, or de-selected to disable Stream Boost.
POWER AND CABLE CONNECTIONS
1. Insert A/V connection cables into the appropriate jacks on the back
of the SurfLink Media:
» Standard: RCA jacks insert in outlet (2) and Power cable inserts in
outlet (5).
» Optional: Microphone, S/PDIF, Optical TOSLINK (insert in outlets 1,
3, and 4).
2. Select the appropriate Monaural/Binaural switch:
» Select Monaural if the patient is fit with one hearing device or
using the CROS/BiCROS system.
» Select Binaural if the patient is fit with two hearing devices.
3. Connect power supply. A micro-USB cable is provided. Insert the
micro-USB connector into the Power port on the SurfLink Media
(outlet 5) and connect the opposite end to a power outlet.
SurfLink Media is designed to stream
audio from electronic audio sources
directly to the wireless hearing devices.
It can be connected to many electronic
audio sources, including televisions,
radios, computers, MP3 players, and
cable boxes.
Setup in Inspire X
Rear Panel View

USER CONTROLS
1. Select Power (the Power button will illuminate blue when power is
on).
2. Adjust the Streaming Activation Range by sliding the blue light left/
right, setting the distance for initiating a streamed signal to the
hearing aids.
3. Set the Volume Control of the audio device (such as the TV) to a
comfortable level for the non-hearing device user or other users in
the household.
4. Set the Volume Control of the SurfLink Media to a comfortable level
for the hearing device user by sliding the blue light left/right.
5. Adjust the volume level as needed using the controls on the SurfLink
Media, via the SurfLink Remote Control/Mobile, or via the volume
controls on the hearing device.
6. For Synergy devices, ensure the Audio Fidelity switch on the back
of the SurfLink Media is set to the up position to access high fidelity
audio streaming.
NOTE: If streaming to a Z Series device or older, ensure the Audio
Fidelity switch is set to the down position for standard fidelity.
7. The LED on the back of the SurfLink Media should be illuminated in
green when set up correctly, indicating a secure audio connection. If
the LED is not illuminated, check the audio cables and power supply.
Front Panel View
Audio Fidelity Switch
©2019 Starkey. All Rights Reserved. 5/19 FLYR3627-00-EE-ST
