StarTech.com USB3S2SAT3CB User manual

SATA to USB Cable with UASP
Product ID: USB3S2SAT3CB
This SATA to USB cable is an external drive adapter that gives you quick and easy access to a SATA drive through
the USB-A port on a laptop.
This SATA solid-state (SSD) or hard drive (HDD) adapter lets you upgrade to an external 2.5" SATA SSD or HDD.
The cable lets you:
• Add drive space
• Perform backups
• Create disk images
• Implement data recovery
• Transfer content between the drive and the laptop
The cable supports USB 3.0 data transfer speeds of 5Gbps. But, you can experience transfer speeds up to 70%
faster than conventional USB 3.0, when connected to a computer that also supports UASP. With UASP you can
utilize the full potential of a SATA III SSD or HDD. UASP is supported in Windows 8, Mac OS X (10.8 or above), and
Linux.
In testing, UASP performs with a 70% faster read speed and 40% faster write speed over traditional USB 3.0 at peak
performance.
At the same peak in testing, UASP also shows an 80% reduction in required processor resources.
The SATA to USB cable is a portable solution that tucks away nicely in a laptop bag -- no external power is required.
The cable lets you easily swap between drives with no need to install the drive inside an enclosure. It's plug-and-play
and doesn't require drivers.
Note: This product is not compatible with 3.5 in. hard drives. For 3.5 in. drive support, please see our USB to SATA

Cable with Supplemental Power (USB312SAT3).
USB3S2SAT3CB is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Certifications, Reports and Compatibility
Applications
• Back up important data to an external storage device
• Back up important data to an external storage device
• Retrieve data from an old SATA drive
• Perform a data migration or clone a drive
• Take advantage of USB 3.0 laptops or desktops with UASP for faster transfer speeds
• Upgrade your laptop HDD to an SSD via USB 3.0
Features
• Access a SATA SSD or HDD from your laptop with this SATA to USB cable
• Experience 70% faster read speed and 40% fast write speeds with UASP support
• Connect to external drives anywhere with this SATA to USB adapter -- no power adapter required
• Save setup time with plug-and-play installation
• Supports USB 3.0 data transfer speeds of 5Gbps and is backward compatible with USB 2.0
Hardware
Warranty
2 Years
Fan(s)
No
Interface
USB 3.0
Bus Type
USB 3.0
Number of Drives
1
Drive Size
2.5in
Compatible Drive Types
SATA

Chipset ID
ASMedia - ASM225CM
Performance
Type and Rate
USB 3.0 - 5 Gbit/s
UASP Support
Yes
TRIM Support
Yes
4Kn Support
Yes
Type and Rate
SATA III (6 Gbps)
Hardware Raid Supported
No
Max Drive Capacity
Currently tested with up to 2TB 5900 RPM hard drives
General Specifications
Max power of the attached drive is 900 mA
MTBF
1,609,297 Hours
Connector(s)
Drive Connectors
SATA Data & Power Combo (7+15 pin)
SATA Power (15 pin)
Host Connectors
USB Type-A (9 pin) USB 3.0 (5 Gbps)
Software
OS Compatibility
OS independent; No software or drivers required
Special Notes /
Requirements
Note
Cable will work only with 2.5" SATA drives
3.5"/5.25" drives are not supported
Windows 7 and earlier Windows versions do not support TRIM
with USB to SATA devices.
Power
Power Source
USB-Powered
Environmental
Operating Temperature
0C to 60C (32F to 140F)
Storage Temperature
-10C to 70C (14F to 158F)

Humidity
40%-85%RH
Physical
Characteristics
Color
Black
Product Length
19.7 in [50.0 cm]
Product Width
1.9 in [49.0 mm]
Product Height
0.4 in [9.0 mm]
Weight of Product
1.5 oz [42.5 g]
Packaging
Information
Package Length
7.8 in [19.8 cm]
Package Width
8.7 in [22.0 cm]
Package Height
0.4 in [10.0 mm]
Shipping (Package)
Weight
2.2 oz [61.0 g]
What's in the Box
Included in Package
USB 3.0 to SATA 2.5" HDD Adapter Cable
Instruction Manual
*Product appearance and specifications are subject to change without notice.
