StarTech.com ICUSB232V2 User manual

Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 11/14/2019
For the most up-to-date information, please visit: www.startech.com
Package contents
• 1 x USB to RS232 Adapter
• 1 x Instruction Manual
ICUSB232V2
USB to RS232 DB9 Serial Adapter Cable - M/M
Pin 1 DCD
Pin 2 RXD
Pin 3 TXD
Pin 4 DTR
Pin 5 GND
Pin 6 DSR
Pin 7 RTS
Pin 8 CTS
Pin 9 RI
Pinout
Installation
Windows
1. In a web browser, navigate to www.startech.com/ICUSB232V2.
2. Click the Support tab.
3. Under Driver(s), download the Prolic_PL2303.zip le.
4. When the le is downloaded, right-click the le and extract the
contents.
5. Browse to the Windows folder and run the PL2303_Prolic_
DriverInstaller application.
6. Follow the on-screen instructions to complete the installation.
7. Connect the USB to RS232 adapter to an available USB port.
Mac OS
1. In a web browser, navigate to www.startech.com/ICUSB232V2.
2. Click the Support tab.
3. Under Driver(s), download the Prolic_PL2303.zip le.
4. When the le is downloaded, right-click the le and extract
the contents.
5. Browse to the Mac folder, and select the appropriate folder for the
version of OS that you’re running.
6. Run the PL2303_x.dmg application, and follow the on-screen
instructions to complete the installation.
7. Connect the USB to RS232 adapter to an available USB port.
Verify the installation
Windows
1. Navigate to Device Manager.
2. Expand the Ports (COM & LPT) section.
3. Conrm that Prolic USB-to-Serial Comm Port (COMx) appears in
the list with no exclamation points or question marks.
Mac OS
1. Navigate to the System Proler.
2. Expand the Hardware section, and click USB.
3. Conrm that USB-Serial Controller D appears in the list.
15
69
System requirements
• USB port
• Any of the following operating systems:
• Windows® 10 / 8.1 / 8 / 7
• Windows Server® 2003 / 2008 R2 / 2012 / 2012 R2 / 2016
• Mac OS® 9.x, 8.x, 10.6 to 10.12
• Linux 2.4.31 to 4.4.x LTS versions only
