S32M2NGFFPEX
SATA to M.2 NGFF SSD Adapter with
Expansion Slot Mounting
*actual product may vary from photos

Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Changes or modications not expressly approved by StarTech.com could void the user’s
authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction Manual
i
Table of Contents
Introduction............................................................................................1
System Requirements.............................................................................................................................. 1
What’s in the Box....................................................................................................................................... 1
Product Diagram ....................................................................................2
Front View .................................................................................................................................................... 2
Rear View...................................................................................................................................................... 2
M.2 NGFF SSD Installation ....................................................................3
System Installation Preparation ..........................................................7
System Installation ................................................................................10
Hard Drive Initialization........................................................................11
Technical Support ..................................................................................12
Warranty Information............................................................................12

Instruction Manual
1
Introduction
System Requirements
• M.2 NGFF SSD Drive
• Computer System with:
-Available Low prole or full prole Expansion slot (PCI or PCI Express)
-Available SATA port on the motherboard
-Available SATA Power connector on the power supply
What’s in the Box
• 1 x SATA to M.2 NGFF SSD Adapter
• 1 x Full prole bracket (pre-installed)
• 1 x Low prole bracket
• 2 x SSD Installation screws
• 2 x PCI slot standos

Instruction Manual
2
Product Diagram
Front View
1. Mounting Bracket (Full prole pictured)
Rear View
1. M.2 NGFF connector
2. SSD Mounting holes
3. SSD stando and installation screw
4. SATA Power Port
5. SATA Data Port
45
2
1
1
3

Instruction Manual
3
M.2 NGFF SSD Installation
WARNING:
SSD Drives and storage adapters require careful handling. If you are not careful
with your SSD Drive, lost data may result. Always handle your drive with caution. Be
sure that you are properly grounded by wearing an anti-static strap when handling
computer components or discharge yourself of any static electricity build-up by
touching a large grounded metal surface (such as the computer case) for several
seconds.
1. Determine if the SSD installation screw and stando requires relocating by
assessing your drive length. The board is labeled with the respective drive types for
length but if your drive type is unknown, place your SSD next to the M.2 (NGFF) SSD
connector, note which drive installation hole matches the height of your SSD. If the
screw and stando are already installed in the correct position please proceed to step 4.

Instruction Manual
4
2. (Only required if the drive installation screw and stando requires relocating)
Remove the nut holding the SSD stando in place on the reverse side using a small
5mm wrench/nut driver, or needle nosed players (not included).
3. (Only required if the drive installation screw and stando requires relocating)
Remove the SSD installation stando, and reseat it into the drive installation hole
that matches your SSD. Replace the nut on the reverse side and secure it into place
using a 5mm wrech/nut driver or small set of needle nosed plyers.

Instruction Manual
5
4. Using the included Phillips head screw driver. Remove the SSD screw located in the
front of the SSD installation stando.
5. Slide the M.2 connector on the SSD into the M.2 receprical connector on the
S32M2NGFFPEX.
Note: The connector on your M.2 SSD is keyed so the drive will only t one way.

Instruction Manual
6
6. Press the drive down toward the SSD stando, and drive the removed screw
through the mounting hole on your SSD drive and into the SSD stando using the
included Philips head screw driver.
7. The SSD has now been installed, and is ready for system installation.

Instruction Manual
7
System Installation Preparation
The S32M2NGFFPEX can be mounted in both low prole and full prole computer
systems. Select the bracket that corresponds with your type of computer system.
(See Bracket Installation)
The S32M2NGFFPEX can be installed in an available PCI slot, or a PCI Express slot. If you
intent to install the adapter into a PCI slot, the PCI standos must be used.
(See PCI Stando installation)
Bracket Installation
1. Remove the undesired bracket by unscrewing the bracket screws from the top of
the S32M2NGFFPEX board using a Phillips head screw driver (not included, included
screw driver is too small).
