StarTech.com SDOCKU33BV User manual

Manual Revision: 08/31/2016
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
SDOCKU33BV
USB 3.0 to 2.5/3.5in SATA Hard Drive
Dock w/UASP
*actual product may vary from photos

Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction Manual
i
Table of Contents
Introduction............................................................................................1
Package Contents ..................................................................................................................................... 1
Product Overview ..................................................................................1
Rear View...................................................................................................................................................... 1
Disk Installation......................................................................................2
SATA Drive Removal...............................................................................2
Initializing the Hard Drive.....................................................................3
Specications..........................................................................................4
Technical Support ..................................................................................5
Warranty Information............................................................................5

Instruction Manual
1
Introduction
Package Contents
• 1 x USB 3.0 SATA hard drive docking station
• 1 x USB cable
• 1 x universal power adapter (NA/JP, EU, UK, ANZ)
• 1 x instruction manual
Rear View
DC Power Adapter
On/O
Switch
USB 3.0
Port
Product Overview

Instruction Manual
2
Disk Installation
1. Connect the Dock to an available power outlet, using the provided power adapter.
2. Connect the Dock to the (powered) Host Computer, using the provided
USB 3.0 cable.
3. Insert the 2.5”or 3.5”SATA drive you wish to install, such that the SATA power
and data connectors at the back of the drive are properly aligned with the
corresponding connectors inside the Dock.
4. Switch the power switch to “ON”position.
Once the drive has been inserted, the operating system will detect that it has been
connected and automatically update the drivers for proper operation.
SATA Drive Removal
When removing the installed drive from the Dock, please ensure that you have
followed the appropriate steps (dependant on the operating system) to disconnect
removable storage. In Windows for example, click on the Safe Remove icon located in
the taskbar. Select the drive from the menu provided, then click Stop. Select the device
to disconnect, and click OK.
In Mac OSX®, click on the USB storage icon on the desktop, and drag it to the Trash Can
icon on the desktop.

Instruction Manual
3
Initializing the Hard Drive
1. If the SATA Hard Drive is blank it may need to be initialized and formatted before
use. From the main Windows desktop, right-click on “My Computer” (“Computer” in
Vista/ 7 / 8), then select Manage. In the new Computer Management window, select
Disk Management from the left window panel.
2. A dialog window should automatically appear, asking you to initialize the drive.
Depending on the version of Windows, it will give you the option of either creating
an “MBR” or “GPT”disk. GPT (GUID partition) is not compatible with some older
operating systems, while MBR is supported by newer and older operating systems.
3. Once initialized, locate the Disk that says it is “Unallocated” (check the listed hard
drive capacity to conrm it’s the correct hard drive) and then right-click in the
section that says “Unallocated” and select“New Partition”.
Follow the on screen prompts to initialize the drive in the format of your choice.

Instruction Manual
4
Specications
Internal
Connectors
1 x SATA Power 15-Pin Female
1 x SATA Data 7-Pin Female
External
Connectors
1 x USB 3.0 type B w/ UASP Female
1 x DC Power Adapter
Drive
Compatibility 2.5/3.5”SATA Hard Drives
OS Support Windows 2000/2003/XP/Vista/7/8 x64/x86, Mac OS
10.0 and up, Linux
Power Adapter 12V 2.0A

Instruction Manual
5
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase.
During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
