StarTech.com S2510BU3PWPS User manual

Manual Revision: 02/03/2014
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
S2510BU3PWPS
USB 3.0 to 2.5” SATA HDD Enclosure
with Encryption
*actual product may vary from photos

Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction Manual
i
Table of Contents
Introduction............................................................................................1
Packaging Contents ................................................................................................................................. 1
System Requirements.............................................................................................................................. 1
Product Diagrams ..................................................................................2
Top View ....................................................................................................................................................... 2
Front View .................................................................................................................................................... 2
Hardware Installation............................................................................3
How to Use ..............................................................................................5
Specications..........................................................................................7
Technical Support ..................................................................................8
Warranty Information............................................................................8

Instruction Manual
1
Introduction
Packaging Contents
• 1x USB 3.0 to 2.5” SATA HDD Enclosure w/ Encryption
• 1x Carrying Pouch
• 1x USB 3.0 Cable
• 1x Instruction Manual
System Requirements
• Computer system with available USB 3.0 port (5 Gbit/s) or USB 2.0 port (480Mbps)
• 2.5” SATA hard drive or solid state drive (9.5mm height)
• Microsoft® Windows® 2000/XP/Server 2003/Vista/Server 2008 R2/7/8 (32/64-bit), or
Apple® Mac® OS 9.x/10, or Linux®
It is recommended that the enclosure act as a backup to important les, and
not as additional storage (unless also regularly backed up), as lost passwords or
hardware failure (SATA drive or enclosure) will result in the stored data
being unrecoverable.

Instruction Manual
2
Product Diagrams
Top View
Front View
Operation LEDs
USB Port
Keypad

Instruction Manual
3
Hardware Installation
WARNING! Hard drives and storage enclosures require careful handling, especially
when being transported. If you are not careful with your hard disk, lost data may
result. Always handle your hard drive and storage device with caution. Be sure that
you are properly grounded by wearing an anti-static strap when handling computer
components or discharge yourself of any static electricity build-up by touching a large
grounded metal surface (such as the computer case) for several seconds.
NOTE: To use encryption, the SATA drive must be initialized and formatted after setup.
This will erase all data on the drive.
1. Open the enclosure by locating the thumb ridges. Pressing down slightly, slide the
back pane away from the top edge.
2. Connect the the 2.5” SATA Hard Drive

Instruction Manual
4
3. Slide the back pane back into place.
4. With the enclosure fully assembled, connect the USB 3.0 cable from the enclosure to
a USB port on the host computer system using the included cable.

Instruction Manual
5
How to Use
Initial Setup
1. When connected to a host computer for the rst time, the“2_Input new password,
and then press `Enter`” LED will prompt. If no password is used, the enclosure will
function as a standard external hard drive enclosure without any encryption.
2. Enter your own Password (1~8 digit PIN setting) and press the ‘Enter’ button.
3. After pressing the `Enter` button, the “3_input password and then press ‘Enter’
button” LED will turn on. Re-enter the same password you entered in the previous
step and press the‘Enter’ button to apply it. (If you enter the incorrect password,
you cannot go to the next step. You must go back to the previous step.) Password
is now set.
4. Once the password has been setup, the SATA drive must be initialized and formatted
before use. From the main Windows desktop, right-click on “My Computer”
(“Computer” in Vista/ 7 / 8), then select Manage. In the new Computer Management
window, select Disk Management from the left window panel.
5. A dialog window should automatically appear, asking you to initialize the drive.
Depending on the version of Windows, it will give you the option of either creating
an “MBR” or“GPT” disk. GPT (GUID partition) is not compatible with some older
operating systems, while MBR is supported by newer and older operating systems.

Instruction Manual
6
6. Once initialized, locate the Disk that says it is “Unallocated” (check the listed hard
drive capacity to conrm it’s the correct hard drive) and then right-click in the
section that says “Unallocated” and select “New Partition”.
WARNING! Losing the password or hardware failure (the SATA drive or enclosure)
will result in the data stored in the enclosure becoming unrecoverable. Removing
the drive from the enclosure or placing it into another S2510BU3PWPS enclosure
will not allow access to the data. It is recommended that all data stored on the
enclosure also be backed up to another location regularly to prevent any chance
of losing your data.
Menu Options
Certain key codes will allow access to additional options for the enclosure. The features
of these Options are outlined below.
Change Password
Change the password set in Initial Setup. Once selected follow steps “2 and 3” of
initial setup.
HDD Initialization
Initial the Hard Drive, without using computer disk management software.
NOTE: the drive will still need to be partitioned using disk management software.
Press <Lock> Button <0> Button <Enter>
Press <Lock> Button <9> Button <Enter>

Instruction Manual
7
HDD Connection / Disconnection (Smart Mount/Un-mount function)
Press <Lock> Button over 2 seconds
Safely un-mounts the hard drive from your computer, to help prevent in data loss and
drive damage.
NOTE: Ensure there are no active data transfers prior to performing procedure.
Specications
Host Interface USB 3.0
Chipset ID Fujitsu MB86C311
External Connectors 1 x USB 3.0 female
Encryption Type AES-256bit
Power Adapter USB Powered
Enclosure Material Plastic
Maximum Data Transfer Rate USB 3.0: 5 Gbit/s
Operating Temperature 0°C ~ 60°C (32°F ~ 140°F)
Storage Temperature -20°C ~ 60°C (-4°F ~ 76°F)
Humidity > 70% RH
Dimensions 135mmx78mmx16mm
Weight 75g
Compatible Operating Systems
Windows 2000/XP/Server 2003/Vista/
Server 2008 R2/7/8 (32/64-bit), Mac OS
9/10, Linux
