STAUFF SPG-DIGI User manual

Contents
Contents ................................................................................................................ 1
1Introduction...................................................................................................... 1
1.1 Notes on Safety / Product Selection................................................................................. 1
1.2 Device Versions and Range of Delivery...........................................................................1
2Commissioning................................................................................................ 2
2.1 Replacing the Batteries ....................................................................................................2
3Functions and keys ......................................................................................... 3
3.1 Display Mode ...................................................................................................................4
3.2 Menu Functions................................................................................................................4
4Connection to the Hydraulics......................................................................... 5
5Operating the SPG-DIGI .................................................................................. 6
5.1 Turning on (ON) ...............................................................................................................6
5.2 Turn off (OFF) ..................................................................................................................7
5.3 Turn on backlight..............................................................................................................7
5.4 MIN/MAX Display ............................................................................................................. 7
5.5 FS Full Scale Display .......................................................................................................7
5.6 Erasing MIN/MAX Values................................................................................................. 7
5.7 OFL Display .....................................................................................................................7
5.8 Zero Point Correction (ZERO).......................................................................................... 8
5.9 Resetting Zero Point Correction.......................................................................................8
5.10 Automatic Power Off .....................................................................................................9
5.11 Changing the Unit .......................................................................................................10
5.12 Filter settings...............................................................................................................11
5.13 Display serial number..................................................................................................11
6Technical Data: .............................................................................................. 12

1 Introduction
The SPG-DIGI is a digital manometer featuring a MIN/MAX display function. Full scale (FS) accuracy is
± 0,5% based on the upper limit of the measurement range.
Dynamic pressure peaks are measured at a scanning rate of 10 ms (100 measurement values/second).
The MIN/MAX memory is continuously updated and rewritten.
1.1 Notes on Safety / Product Selection
The correct functioning of the SPG-DIGI can only be guaranteed when the specifications detailed in
these operation instructions are adhered to. In particular, specifications relating to the permitted upper
limit of the measurement range as well as the permissible temperature range must be observed.
Serious malfunctions leading to personal injury or damage to property can result from using the
chosen product in applications that do not comply with the specifications or from disregarding the
operation instructions. In particular, incorrect mounting of the manometer and the corresponding adapter
can cause the manometer to be torn out of the assembly.
For Service, Repair and Calibration of the measurement instruments please contact your STAUFF
sales branch.
1.2 Device Versions and Range of Delivery
Device Versions and scope of delivery
Pressure connection G 1/4 male thread
Without Connection adapter
Basic setting to unit "bar"
Pressure connection 7/16-20 UNF male
Without Connection adapter
Basic setting to unit "PSI"
Measurement
Range Part No. Measurement
Range Part No.
-1… 16 bar SPG-DIGI-B0016-B -14,5… 230 PSI SPG-DIGI-B0016-U
0… 100 bar SPG-DIGI-B0100-B 0 ... 1450 PSI SPG-DIGI-B0100-U
0… 400 bar SPG-DIGI-B0400-B 0… 5800 PSI SPG-DIGI-B0400-U
0… 600 bar SPG-DIGI-B0600-B 0… 8700 PSI SPG-DIGI-B0600-U
0…1000 bar SPG-DIGI-B1000-B
SPG-DIGI without Adapter
SPG-DIGI with Adapter
Page 1 of 13

2 Commissioning
The SPG-DIGI is supplied with batteries fitted.
The device is operational as soon as it is turned on.
Caution!
Turn off the device before replacing the
batteries. Open the battery compartment.
Insert the new batteries as depicted. Ensure
correct polarity of the batteries.
Batteries: 2 x 1,5 V (LR6 - AA)
2.1 Replacing the Batteries
When in continuous operation (without light), the service life of the batteries is 1.500 hours.
A battery symbol permanently displays the actual battery status.
The serial number is of the SPG-DIGI pressure
gauge is no longer displayed on a label under the
protective rubber cap but now in the SPG-DIGI
software menu.
Please press the button
MENU
ZERO and hold the button
for min. 2 s. The SPG-DIGI will switch through the
following menu points on every keystroke:
- Automatic Switch off (PO, 5.10)
- Changing the units (unit, 5.11)
- Filter settings (Filt, 5.12)
- Display serial number (5.13)
Page 2 of 13

3 Functions and keys
Display
• 4 ½ digit LCD with backlight
• Displays measurement values and menu
functions
- „Bar-graph“ with peak & hold
function
- Actual Value display (size 15mm)
- MIN/MAX or FullScale (FS)
(8 mm)
- Battery status
Keys
ON
OFF
MIN
MAX
FS
MENU
ZERO
RESET
OK
Key Function
ON
OFF
ON /OFF
Turns the device on / off.
Press for 2 s. Turns on the Back Light (stays on for 20 s.).
MIN
MAX
FS
MIN
MAX
FS
Select display unit: MIN, MAX or FS.
Minimum value,
Maximum value (=pressure peak)
Displays the upper limit (FS) of the scale (e.g.400 bar)
MENU
ZERO
MENU:
ZERO:
Press for 2 s.
Changes the unit.
Auto power off - on/off.
Zero point calibration.
RESET
OK
RESET:
OK:
Erases MIN and MAX values from the memory.
Confirms the MENU functions.
Page 3 of 13

3.1 Display Mode
The actual pressure (ACT) is indicated in the display mode. The ACT measured value is displayed
in the corresponding unit. The MIN, MAX or FS values is indicated in the lower oart of the display.
Display Description
bar-graph Graphic indication of the actual pressure.
A pressure peak is indicated by means of a pixel (graduation mark).
The indicated value is refreshed at intervals of 50 ms (20
measurements /s).
ACT Indicates the actual pressure.
The indicated value is refreshed at intervals of 300 ms (3 times /s).
MIN/MAX Indicates the MIN-, MAX- or FS value according to setting.
The indicated value is refreshed at intervals of 300 ms (3 times /s).
FS Upper limit of the scale (e.g. 400 bar).
Units Indicates the chosen unit.
Battery
Indicates the battery status (5 segments).
x10 Indicated value (actual indication and MIN/MAX indication) x10
3.2 Menu Functions
The following settings can be made
in the MENU function:
• Auto Power Off – on or off
• Unit selection
(bar/mbar/PSI/kPa/Mpa.)
Press the MENU key for 2 seconds to
activate the functions menu.
Press the MENU key again to select
the next function.
Press the OK key to save the function setting.
The device then switches to the display mode.
Page 4 of 13

4 Connection to the Hydraulics
The SPG-DIGI is available with male thread G ¼ (BSPP) or 7/16-UNF for the corresponding versions
(bar / psi). Several adapters for other pressure connections can be supplied also.
Please make sure that the device is properly mounted to avoid malfunctions.
Please do not assemble while the SPG-DIGI is pressurized
Connection Designation Adapter
G1/4 to M16x2 SDA20-G1/4
G1/4 to M16x1,5 SDA15-G1/4
G1/4 to S12,65x1,5 SDA12-G1/4
Adapter SAD only in conjunction with Adapter SDA20-G1/4
M16x2 to M16x1.5 SAD20/15-P
M16x2 to S12,65x1.5 SAD20/12-P
M16x2 to Plug SAD20/10-P
(Other adapters on request available.)
Observe specified torques when fitting the SPG-DIGI:
The spanner size of the pressure connection is 27 mm
Pressure connection Torque
¼ BSPP 25 Nm
7/16-20 UNF 35 Nm
When fitting directly, please ensure the SPG-DIGI can be rotated freely.
Safety instructions for using the 1.000 bar operating range:
Please note that special connection adapters are available which are approved for
a nominal working pressure of 1.000 bar.
Please pay attention to built in test points acc. to rated nominal pressure and
specified safety factors.
Page 5 of 13

5 Operating the SPG-DIGI
5.1 Turning on (ON)
MIN FS
MAX
REC
x10
A self-test procedure is carried out
ON
OFF Press
FS
The measuring range is indicated
(FS)
Unit (bar) SPG-DIGI-…-B
Unit (PSI) SPG-DIGI-…-U
Auto Power Off function is active.
Power off activates automatically
after 5 min. This function can be
altered in MENU.
MAX
Display mode.
ACT value displayed
MAX pressure peak
Page 6 of 13

5.2 Turn off (OFF)
ON
OFF Press once (briefly)
5.3 Turn on backlight
ON
OFF Press for 2 s
The backlight turns off automatically after 20 seconds.
5.4 MIN/MAX Display
Use this key to toggle the required value.
The key function is sequential; the values are indicated in the display in sequence.
The MIN/MAX function is used to measure pressure peaks. The respective lowest (MIN) and highest
(MAX) measured values are stored in the MIN/MAX memory. Values in the MIN/MAX memory are
erased when the device is turned off. If different pressure tests are to be carried out in succession, the
MIN/MAX memory must be erased after each measurement.
MIN
MAX
FS
MIN / MAX and FS value is indicated in the display
5.5 FS Full Scale Display
Displaying the upper limit of the scale (FS) is designed to increase readability of the bar graph function.
The upper limit of the measurement range is indicated numerically.
FS is indicated in sequence after MIN and MAX
MAX
FS
MIN
FS is displayed.
5.6 Erasing MIN/MAX Values
RESET
OK
Erases MIN/MAX values.
5.7 OFL Display
This indicates that the applied pressure is outside given full scale
range (at appr. 20% overload from FS).
If the message will remain displayed, while the SPG-DIGI is
pressure less, please consult your local STAUFF office.
Page 7 of 13

5.8 Zero Point Correction (ZERO)
The zero point can be corrected manually should undesired deviations occur when no system pressure
is being applied (atmospheric pressure).
ON
OFF
Caution! The zero point correction sets the current ACT value to zero.
In order exclude erroneous measurements; ensure no system pressure is
being applied when carrying out this function.
Press ZERO (quick)
MENU
ZERO
RESET
OK
This initiates the zero point correction..
The ACT (actual) value is indicated in the display as 0.0 bar.
This correction remains active until the device is turned off.
OFL / ZEro is displayed for 3 s if the measured pressure is
greater than 5% of the measurement range.
Zero point correction cannot be carried out.
Please ensure that no system pressure is being applied.
5.9 Resetting Zero Point Correction
Turn off the device.
Zero point correction is no longer active when the device is turned off and on again.
Page 8 of 13

5.10 Automatic Power Off
Press for 2 s
Depending on the device configuration, two different displays are possible:
MENU
ZERO
Auto Power off Continuous operations
PO ON
Press
RESET
OK . Auto Power off is activated
after 5 minutes.
PO OFF
Press
RESET
OK . The device must be
turned off manually.
The settings Auto Power Off or Continuous operations remain stored
and are active when the device is turned off and on again.
Page 9 of 13

5.11 Changing the Unit
Press for 2 s.
MENU
ZERO
⇔
Press.
MENU
ZERO
MENU
ZERO Press once (briefly)
The next unit is indicated
RESET
OK Confirm unit selection
Page 10 of 13

5.12 Filter settings
The filter prevents little fluctuations of the displayed values (has the same function as a glycerin filling in
a analog pressure gauge that prevents a shivering indicator because of small system fluctuations).
NU
ZERO
ME
NUME
Press.
ZERO
NUME
ZERO
RESET
OK
Confirm filter configuration
MENU
ZERO
RESET
OK
Press for 2 s.
MENU
ZERO
⇔
Press
Press once (briefly)
Filter selection is indicated
5.13 Display serial number
Press
Display of serial number (1.line)
Display of software version (2.line)
Page 11 of 13

6 Technical Data:
Version - Digital pressure gauge with ACT - MIN and MAX Display
- Bar graph display (33 segments) with peak and hold
function
- 4 ½ digit LC display (15 mm) with back light illumination
- Battery powered with low power electronic system
- Life time cycle 1.500 h (No back light function)
- Pressure port stainless steel 1.4404
- ¼" BSPP (ISO 1179-2) or
- 7/16 – 20 UNF (ISO 11926-2/3)
Input: - Ceramic sensor cell (relative) –1. . 16 bar
- Strain gauge cell (absolute) 0. . 100/400/600/1000 bar
- Scan rate 10 ms
- Resolution 12 bit = 4.096 steps.
- Accuracy ±0,25%FS (Full Scale) typ.,
± 0,5 %FS max.
Housing - Ø79 mm,
- T=33 mm,
- Zinc die cast with rubber protection TPE
Sealing - NBR sealed (standard)
- FKM (Viton®) or EPDM on request
Weight - 540 g
Power supply - Battery 2 x1,5 VDC AA (LR6 –AA) Alkaline (Mignon)
Parts in contact with media - Stainless steel 1.4404
- NBR
- Ceramics
Ambient conditions - Operating temperature:
- Fluid temperature:
- Storage temperature:
- Rel. humidity:
- Protection:
- Vibration:
- Shock:
- Reliability cycles (106):
-10. . 50 °C
-20. . +80°C
-20. . +60°C
< 85%
EN 60529 (IP 67)
IEC 60068-2-6, (5g)
IEC 60068-2-27 (25g)
100
Page 12 of 13

Digital Pressure Gauge SPG-DIGI
Range
bar
Display
bar
Display
PSI
Display
mbar
Display
kPa
Display
MPa
-1 … 16 -1,0...16,0 -14,5...200,0 -999...16000 -100...1600 -
0 … 100 0...100,0 0...1500 - 0...10000 0...10,0
0 … 400 0...400,0 0...6000 - 0...4000 (x10) 0...40,0
0 … 600 0...600,0 0...9000 - 0...6000 (x10) 0...60,0
0 …1000 0…1000 0…15000 - - 0…100,0
Range (bar) -1 . . 16 0 . . 100 0 . . 400 0 . . 600 0…1000
Overload Pmax (bar) 40 200 800 1200 1500
Burst Pressure (bar) 50 800 1700 2200 2500
Range (PSI) -14,5 . . 230 0 . . 1450 0 . . 5800 0 . . 8700 14500
Overload Pmax (PSI) 580 2900 11600 17400 21750
Burst Pressure (PSI) 725 11600 24650 31900 36250
Burst pressures are based on data without assembled adapters.
Exceeding the maximum overload values (Pmax) can lead to malfunctions and
result in the SPG-DIGI being destroyed.
The SPG-DIGI meets the guidelines of the European Community (EU).
It is confirmed that this product is approved acc. to following standards:
DIN / EN 61000-6-2
DIN / EN 61000-6-3
Technical subject to change November 2006
Other manuals for SPG-DIGI
2
Table of contents
Other STAUFF Measuring Instrument manuals
