Stealth Cam QV Series User manual

Page 1
QV Series
Instruction Manual
R0

Page 2
To ensure the product is being utilized to its full potential, we recommend checking
our website for new product updates. If your camera is having an issue, please check
our website to determine you are using the latest rmware or software version.
Notice
TECHNICAL SUPPORT
EMAIL:
[email protected]
Please allow 48 hours for email
response.
GSM, LLC
P.O. Box 535189
Grand Prairie, TX 75053-9504
CUSTOMER SERVICE
CONTACT & HOURS
Toll Free: 877-269-8490
CALL CENTER HOURS
Mon – Fri / 8 AM – 5 PM (CST)
WEBSITE
www.stealthcam.com
Contact Us
QS20NGK

Page 3
Table of Contents
About Your Camera 4
Quick Setup Guide 5
Camera Overview 6
Camera Setup 8
Camera Conguration 9
Viewing and Deleting Images 12
Frequently Asked Questions 13
Camera Care 14
FCC COMPLIANCE 15
Limited Warranty Information 16

Page 4
About Your Camera
Water Resistant Design
Your camera is safe against the elements with a sturdy waterproof housing.
Quick Set Options
Set up in seconds with pre-programmed options.
Burst Rapid-Fire Mode
Rapid-re Burst Mode, multiple exposures per triggering.
No Glow IR LEDs
Perfectly illuminate your nighttime photos with 24 IR LED lights.
Expandable Storage Space
Expand your storage space with an SC memory card up to 32 GB.
Energy E󰀩cient Design
Completely re-energized to optimize energy e󰀩ciency.

Page 5
Quick Setup Guide
Insert Batteries and SD Card
Install 8 AA batteries and a class 10 SD card into camera.
Mount Camera
Mount the camera at the desired location using the strap
mount, Python Lock cable, Articulating Ball Joint Mount, or
other desired mounting mechanism. Position the camera so
that it does not face East or West directly as the rising and
setting of the sun can cause false positive triggers.
Activate Camera
Set camera to “On” position and place in desired vantage
point to start capturing photos of game.

Page 6
Camera Overview

Page 7
Python Cable
Lock Hole
Strap
Mounts
Universal
¼ - 20 thread

Page 8
Camera Setup
Battery Installation
To remove batteries from unit, simply open the
camera and slide the battery release switch to the
left. Once the battery compartment is open, insert
batteries into camera, being careful to match the
orientation marked on your camera. After batteries
are inserted, close the battery compartment and
secure the battery release switch.
SD Card Installation
SD card slot is located on the bottom of the
camera, above the battery compartment.
Insert SD card with the label facing back of
camera. Only minimal resistance should be
felt as card is inserted and a click when the
card is fully inserted. Battery Release Switch
SD Card Slot

Page 9
Camera Conguration
Name Type Quality Timeout
Delay Detail
QSET 1 Photo Medium 30 sec 1 Photos
QSET 2 Video Medium 30 sec 10 sec Video
Cycle between camera modes by pressing the UP and DOWN arrows. The
camera mode will be displayed on the left side of the LCD Screen. This camera
comes equipped with two Quick Sets (QSET) containing some of our most
popular congurations. QSET 1 and 2 are dened in the table below. For alternate
congurations, press the UP or DOWN arrows until CUSTOM is displayed on the
left of the LCD screen and press ENTER.
Continue to next page for more information regarding each setting.

Page 10
OPERATION MODE: The operation mode setting is accessible immediately after the Time setting.
The screen will be blank with either Video or Photo displayed on the right side of screen.
Press Enter to change between Photo and Video mode.
DATE: This setting is used by the camera to display the correct date on the Info Bar of the image.
PHOTO BURST: This setting determines how many
photos are taken each time the camera is activated.
OPTIONS: 1 photo – 3 photos
PIR DELAY: This setting is used to determine how long
the camera will wait before restarting the PIR sensor
after taking a photo.
OPTIONS:
5 sec | 10 sec | 15 sec | 30 sec | 60 sec| 120 sec
RESOLUTION: This setting will determine the quality
of each image. A higher quality will result in better
photos and take more memory space.
OPTIONS: High | Med | Low
Note: This setting is only applicable in photo mode.
VIDEO LENGTH: This setting is used to determine
the length of time, in seconds, of a video recording
OPTIONS: 5 sec | 10 sec | 15 sec | 30 sec
Camera Conguration cont.
TIME: This setting is used by the camera to display the correct time of day on the Info Bar of the image.
PHOTO: In this mode the camera will
take a photo when trigger is activated. VIDEO: In this mode the camera will take a VIDEO when trigger is activated.
PIR DELAY: This setting is used to determine how long
the camera will wait before restarting the PIR sensor
after taking a video.
OPTIONS:
5 sec | 10 sec | 15 sec | 30 sec | 60 sec| 120 sec

Page 11
There are a few methods for viewing and deleting your les.
i. Using an SD Memory Card Reader/Viewer: You will simply
need to remove the SD card from the camera and insert it into
the reader to view the les; you can also delete them from this
device.
ii. Using your computer: This method requires an SD card slot to
be installed to your computer. Please refer to your computer’s
Owner’s Manual for the proper way of viewing the les.
iii. Obtain a mobile device adapter: This will allow you to plug one
end into the device, and, at the other end, insert the SD card.
Please refer to the vendor’s User Manual for the proper way of
viewing the les.
Viewing and Deleting Images

Page 12
Frequently Asked Questions
Q: Will I lose my images and settings if the batteries die?
A: You will lose your settings but not your images. The images are stored on your
external SD memory card so your images will be intact only on your card.
Q: Why is my camera taking pictures with nothing in front of it?
A: This camera is powered by motion activation. This can cause objects, like a tree
branch or moving water, within the camera frame to cause the camera to take a photo.
Q: Is there a warranty that comes with my camera or an extended warranty I can
purchase?
A: Your Stealth Cam Camera comes with a Limited 1-year warranty. Please contact
support at 1.877.269.8490 for more information.
Q: Can I mix batteries together?
A: No, you should never mix batteries. After your camera batteries die, always install
brand new batteries in your camera.
Q: Can I use rechargeable batteries in the camera?
A: Rechargeable batteries can be used but will cause battery percentage to be report-
ed incorrectly.

Page 13
Camera Care
Operating Conditions
This camera is designed to function in 14°F – 104°F (-10°C -
40°C) 20%-85% relative humidity, non-condensing.
Product Care
• When not in use, store camera in a cool, dust-free, environment.
• Handle camera with care.
• Camera is weather resistant only. Do not fully submerge camera in
water or other liquid. Doing so will void camera warranty.
• Only use same type of batteries to power camera. Do not mix old
and new batteries.
• Do not touch camera lens directly. Clean only with soft lens cloth.
• Use damp cloth to clean. DO NOT submerge camera.
• Remove batteries when camera is not in use for an extended time.
• Do not open camera housing to access internal parts. Doing so
could damage camera and void warranty.
Notice
Camera is an active electronic device. Attempting to service
internal parts may expose you to dangerous voltages and
other risks.
