STEINWAY LYNGDORF P200 Use and maintenance manual

MODEL P200
SURROUND SOUND PROCESSOR
EXTERNAL CONTROL MANUAL
December 9, 2015

2
TABLE OF CONTENTS
INTRODUCTION.....................................................................................................................................4
HOME AUTOMATION SYSTEM INTEGRATION...................................................................................4
CONTROL VIA NETWORK ....................................................................................................................4
CONTROL VIA SERIAL PORT...............................................................................................................5
CONTROL PROTOCOL .........................................................................................................................6
Commands.........................................................................................................................................................6
Responses and feedback level...........................................................................................................................6
COMMANDS...........................................................................................................................................7
STATUS REQUESTS.............................................................................................................................9
CONTROL PROTOCOL USAGE..........................................................................................................11
Controlling power .............................................................................................................................................11
Controlling volume............................................................................................................................................11
Controlling sources...........................................................................................................................................12
Controlling processing modes ..........................................................................................................................13
Controlling focus positions ...............................................................................................................................14
Controlling voicings ..........................................................................................................................................14
Controlling lipsync ............................................................................................................................................15
Getting main zone video and audio status .......................................................................................................15
Getting zone 2 audio status..............................................................................................................................16
Controlling feedback level ................................................................................................................................16
Controlling OSD and OSD menu......................................................................................................................16
Direct controlling of HDMI outputs....................................................................................................................16
Control of main HDMI output............................................................................................................................16
Controlling multiview ........................................................................................................................................17
AUDIO INPUTS.....................................................................................................................................18
VIDEO INPUTS.....................................................................................................................................18
VIDEO OUTPUTS.................................................................................................................................19
IR CODES.............................................................................................................................................20
RS232 pinout diagram ..........................................................................................................................21

3
DOCUMENT HISTORY
Date
Author
Comments
October 16 2015
PKL / CJN
First draft
October 21 2015
PKL / CJN
Second draft
October 21 2015
PKL / CJN
Document ready for release
November 11 2015
PKL
Added IR Codes
November 20 2015
PKL
Added text to “Control via Serial Port”
November 30 2015
CJN
Added commands and chapter on controlling Multiview
December 9, 2015
PKL
Added RS232 pinout diagram
December 9, 2015
PKL
Fixed IR codes

4
INTRODUCTION
The purpose of this document is to describe how the external control interface of the device works.
HOME AUTOMATION SYSTEM INTEGRATION
The Model P200 is compatible with home automation systems via the RS232 and network connectors
on the rear socket panel. The P200’s IR and trigger connections can also be programmed for use in a
home automation system.
CONTROL VIA NETWORK
Open a TCP connection on port 84 and use the control protocol as described in this document. For
control from a PC, use Telnet, Putty, or similar programs to open the TCP connection.
If you do not know the IP address of the Model P200 on your local network, the Model P200 supports
Apple´s Bonjour Discovery service, which must be on the computer you want to set up the Model
P200 with. The software is built-in as part of the Apple OS X operating system. For Windows
operating systems, the software can be found at http://www.apple.com/support/bonjour/
The control protocol is announced via bonjour as the service “_slactrl”.
Pressing the “OK” button on the remote and toggling through the “Info” of the unit will also display the
current IP address of the unit.
The P200 can also be controlled via the network by accessing http://p200.localin your browser.

5
CONTROL VIA SERIAL PORT
The serial port on the P200 is wired as a DTE, so for communication with a PC or similar, you will
need a null modem adapter and gender changer.
The port settings should always be 8 data bits, no parity, one stop bit and no hardware handshake.
The baud rate is 115200 bits per second. All commands and responses are in ASCII form.
When controlling the P200 via the serial port, it is able to wake up even when the standby mode has
been set to “deep sleep”. However, the P200 will miss the first one or two characters transmitted
when in deep sleep, because it needs to wake up first. So in order to make sure the P200 is ready for
the command, send a few extra characters before an ON-command. Sending for instance
“!!!POWERONMAIN” to turn on the P200 will guarantee that the command is always received, even if
it is in deep sleep.

6
CONTROL PROTOCOL
Commands
Every command starts with ‘!’ character and ends with carriage return (ascii 0x0D, referred to in this
document as <CR>). There are two types of commands, commands and status requests. Commands
are used to emulate remote key presses or to set a certain volume etc. Status requests are used to
query the current state of the controller (volume, current source etc.). Commands with invalid format
are simply ignored. For example, sending a command !VOL(100)garbage!MUTEON<CR> will only
result in volume being muted, because volume command is not terminated properly.
Responses and feedback level
There are three levels of responsiveness, called feedback levels. Each level adds something new on
top of the previous level. Feedback level can be set from the control interface with command
“!VERB(X)<CR>” (X can be 0, 1 or 2). All responses start either with ‘!’ (status messages) or ‘#’ (echo
messages) and end with <CR>.
Feedback level 0: Data is only sent when data is requested by status request command. For example
command “!VOL?<CR>” would return “!VOL(XXX)<CR>”, where “XXX” would be current volume.
Feedback level 1: Data is sent whenever any of the statuses listed below changes. The data format is
the same as for responses to status request commands.
Feedback level 2: Each command is also echoed back with the ‘#’ in front of the command instead of
‘!’ character. For example command “!VOL?<CR>” would return “#VOL?<CR>!VOL(XXX)<CR>”.
Status
Related status request command
Audio input
!AUDIN?<CR>
Audio processing mode
!AUDMODE?<CR>
Audio type
!AUDTYPE?<CR>
Mute
!MUTE?<CR>
Power
!POWER?<CR>
RP Focus Position
!RPFOC?<CR>
Voicing
!RPVOI?<CR>
Source
!SRC?<CR>
Video input
!VIDIN?<CR>
Video type
!VIDTYPE?<CR>
Volume
!VOL?<CR>
Multiview layout
!MVIEW?<CR>
Multivew active window
!MVIEWACTIVE?<CR>
Multiview sources
!MVIEWSRC?<CR>
Zone power
!POWERZONE2?<CR>
Zone audio input
!ZAUDIN?<CR>
Zone source
!ZSRC?<CR>
Zone user mute
!ZMUTE?<CR>
Zone volume
!ZVOL?<CR>
Table 1 Automatic status messages

7
COMMANDS
This chapter introduces all the different control protocol commands.
Command
Values
Description
!AUDMODE-
Audio processing mode down button.
!AUDMODE(X)
See list returned by
!AUDMODEL?
Set audio processing mode.
!AUDMODE+
Audio processing mode up button.
!BACK
Back button.
!DIM-
Reduce brightness of front display.
!DIM(X)
0=100%, 1=75%, 2=50%, 3=25%
Set brightness of front display.
!DIM+
Increase brightness of front display.
!DIRD
Direction Down button.
!DIRL
Direction Left button.
!DIRR
Direction Right button.
!DIRU
Direction Up button.
!ENTER
Enter button.
!EXIT
Exit button.
!HDMIMAINOUT(X)
X is the number of the HDMI
output (See list)
Selects which HDMI output to use for
main out.
!HDMIOUT1(X)
X is the number of the HDMI-input
to be used, see list.
Route HDMI input X video to HDMI
output 1. Will not work for the main
HDMI output.
!HDMIOUT2(X)
X is the number of the HDMI-input
to be used, see list.
Route HDMI input X video to HDMI
output 2. Will not work for the main
HDMI output.
!HDMIOUT3(X)
X is the number of the HDMI-input
to be used, see list.
Route HDMI input X video to HDMI
output 3. Will not work for the main
HDMI output.
!HDMIOUT4(X)
X is the number of the HDMI-input
to be used, see list.
Route HDMI input X video to HDMI
output 4. Will not work for the main
HDMI output.
!HDMIOUT5(X)
X is the number of the HDMI-input
to be used, see list.
Route HDMI input X video to HDMI
output 5. Will not work for the main
HDMI output.
!INFO
Info button.
!LIPSYNC-
Reduces the lipsync value. (-5ms)
!LIPSYNC(X)
Lipsync value in ms. See range
returned by !LIPSYNCRANGE?
Sets the lipsync value to X.
!LIPSYNC+
Increases the lipsync value. (+5ms)
!LOUDNESS(X)
0 (off) or 1 (on)
Sets loudness status.
!MENU
Menu button.
!MULTIVIEW
Multiview button.
!MUTE
Mute toggle button.
!MUTEOFF
Mute off.
!MUTEON
Mute on.
!MVIEW(X)
0 to 5 (0 = Off, 1 to 5 = Layout)
Select multiview layout. If X is 0,
multiview is turned off. If X is not 0 and
multiview is off, multiview is turned on.
!MVIEWACTIVE(X)
1 to 4
Select active multiview window.
!NUM(X)
0 to 9
Numeric buttons 0-9.
!POWEROFFMAIN
Power off.

8
!POWEROFFZONE2
Zone 2 power off.
!POWERONMAIN
Power on.
!POWERONZONE2
Zone 2 power on.
!RPFOC-
Previous RoomPerfect position button.
!RPFOC(X)
0 = bypass
1-8 = focus1 – focus8
9 = global
Select RoomPerfect position X.
!RPFOC+
Next Roomperfect position button.
!RPVOI-
Previous voicing button.
!RPVOI(X)
See list returned by RPVOIS?
Select voicing X.
!RPVOI+
Next voicing button.
!SETUP
Setup button.
!SRC-
Previous source button.
!SRC(X)
See list returned by SRCS?
Select source X.
!SRC+
Next source button.
!SRCBTN
SRC button.
!SRCOFF-
Decrease source volume offset.
!SRCOFF(X)
-100 (-10dB) to
100 (+10dB)
Set new source volume offset for
current source to X.
!SRCOFF+
Increase source volume offset
!VERB(X)
0 to 2
Set verbosity level of active interface.
!VOL-
Decrease volume. (-0.5dB)
!VOL-(X)
1 to 999 (-0.1dB to -99.9 dB)
Decrease volume by X.
!VOL(X)
-999 to 200 (-99.9dB to +20.0dB)
Set volume to X.
!VOL+
Increase volume. (+0.5dB)
!VOL+(X)
1 to 999 (+0.1dB to +99.9 dB)
Increase volume by X.
!ZMUTE
Toggle Zone 2 mute.
!ZMUTEOFF
Zone 2 mute off.
!ZMUTEON
Zone 2 mute on.
!ZSRC-
Previous zone 2 source button.
!ZSRC(X)
See list returned by ZSRCS?
Select zone 2 source X.
!ZSRC+
Next zone 2 source button.
!ZVOL-
Decrease zone 2 volume. (-0.5dB)
!ZVOL-(X)
1 to 999 (-0.1dB to -99.9 dB)
Decrease zone 2 volume by X.
!ZVOL(X)
-999 to 200 (-99.9dB to +20.0dB)
Set zone 2 volume.
!ZVOL+
Increase zone 2 volume. (+0.5dB)
!ZVOL+(X)
1 to 999 (+0.1dB to +99.9 dB)
Increase zone 2 volume by X.

9
STATUS REQUESTS
Command
Return format
Values
Description
!AUDIN?
!AUDIN(X)
Index of active audio
input. (See list)
Currently selected
audio input.
!AUDMODE?
!AUDMODE(X) "Name"
Index and name of
active audio mode.
Current audio
processing mode.
!AUDMODEL?
!AUDMODECOUNT(N)
!AUDMODE(0)”Name”
…
!AUDMODE(N-1)”Name”
N is the total number
of available modes.
List of audio
processing modes.
Returns a count of
modes plus index and
name of each mode.
!AUDTYPE?
!AUDTYPE(typestring)
String describing the
audio signal.
Audio input signal
type.
!DEVICE?
!DEVICE(P200)
Name of the device.
!DIM?
!DIM(X)
0 = 100%, 1 = 75%,
2 = 50%, 3 = 25%
Brightness of the VFD
display.
!HDMIMAINOUT?
!HDMIMAINOUT(X)
See list of video
outputs.
Active main HDMI
oputput.
!INTERFACE?
!INTERFACE(IP) or
!INTERFACE(SERIAL)
Interface for active
session.
!LIPSYNC?
!LIPSYNC(X)
X is in the range
returned by
!LIPSYNCRANGE?
Current lipsync value.
!LIPSYNCRANGE?
!LIPSYNCRANGE(min,max)
Min and max values
in ms.
Valid range for lipsync
values.
!LOUDNESS?
!LOUDNESS(X)
0 (off) or 1 (on)
Loudness status.
!MUTE?
!MUTEON or
!MUTEOFF
Mute status.
!MVIEW?
!MVIEW(X)
0 to 5 (0 = Off,
1 to 5 = Layout)
Multiview layout.
!MVIEWACTIVE?
!MVIEWACTIVE(X)
1 to 4
Active multiview
window.
!MVIEWSRC?
!MVIEWSRC(A,B,C,D)
Numbers of the 4
sources.
Multiview sources.
!PING?
!PONG
Ping.
!POWER?
!POWER(X)
0 (standby) or 1 (on)
Power status.
!POWERZONE2?
!POWERZONE2(X)
0 (off) or 1 (on)
Zone 2 power status.
!RPFOC?
!RPFOC(X)"Name"
0=bypass
1-8=focus1 – focus8
9=global
Current RoomPerfect
position.
!RPFOCS?
!RPFOCCOUNT(N)
!RPFOC(index)”Name”
…
!RPFOC(index)”Name”
N is the number of
available positions.
Index-values are not
consecutive!
List of RoomPerfect-
positions.
Returns a count of
positions plus index
and name of each
position.
!RPVOI?
!RPVOI(X)"Name"
X is from the list
returned by
RPVOIS?
Active voicing.
!RPVOIS?
!RPVOICOUNT(N)
!RPVOI(0)”Name”
…
!RPVOI(N-1)”Name”
N is the total number
of available voicings.
List of available
voicings.
Returns a count of
voicings plus index
and name of each
voicing.

10
!SRC?
!SRC(X)”Name”
Number and name
of source.
Active source.
!SRC(X)?
!SRC(X)”Name”
Name of source X.
Info for source X.
!SRCOFF?
!SRCOFF(X)
-100 (-10dB) to
100 (+10dB)
Source volume offset
for current source.
!SRCS?
!SRCCOUNT(N)
!SRC(0)”Name”
…
!SRC(N-1)”Name”
N is the number of
available sources.
List of available
sources. Returns a
count of sources plus
index and name of
each source.
!VERB?
!VERB(X)
0 to 2
Verbosity level of
active interface.
!VIDIN?
!VIDIN(X)
Index of active video
input. (See list)
Currently selected
videoinput.
!VIDTYPE?
!VIDTYPE(typestring)
String describing the
video signal.
Video input signal
type.
!VOL?
!VOL(X)
-999 to 200 (-99.9dB
to +20.0dB)
Current volume.
!ZAUDIN?
!ZAUDIN(X)
Index of active audio
input. (See list)
Currently selected
zone 2 audio input.
!ZMUTE?
!ZMUTEON or
!ZMUTEOFF
Zone 2 mute status.
!ZSRC?
!ZSRC(X)”Name”
Number and name
of source.
Active zone 2 source.
!ZSRC(X)?
!ZSRC(X)”Name”
Name of source X.
Info about zone 2
source X
!ZSRCS?
!ZSRCCOUNT(N)
!ZSRC(X)”Name”
Repeated for all zone B
sources
N is the number of
available sources.
List of available Zone
2 sources. Returns a
count of sources plus
index and name of
each source.
!ZVOL?
!ZVOL(X)
-999 to 200 (-99.9dB
to +20.0dB)
Current zone 2
volume.
