Stelpro WFA1502 User manual

INSWFA0617
WFA SERIES
ALUMINUM WALL FAN HEATER
S
Y
S
T
È
M
E
Q
U
A
L
I
T
É
C
E
R
T
I
F
I
É
-
R
E
G
I
S
T
E
R
E
D
Q
U
A
L
I
T
Y
S
Y
S
T
E
M
complies
with CSA
standards
USER’S GUIDE
Before installing and operating this product, the user and/or installer must read, understand and follow these instructions and keep them handy for future
reference. If these instructions are not followed, the warranty will be considered null and void and the manufacturer deems no further responsibility for this
product.
This product must be installed by a qualied person and connected by a certied electrician, according to the electrical and building codes
effective in your region.
The following instructions must be adhered to in order to avoid personal injuries or property damages, serious injuries and potentially fatal electric shocks.
Protect the heating unit with the appropriate circuit breaker or fuse, in accordance with the nameplate.
Make sure the line voltage (volt) is consistent with that indicated on the unit’s nameplate.
This unit must be grounded.
Switch off the power at the circuit breaker/fuse before installing, repairing and cleaning the unit.
Make sure the unit is appropriate for the intended use (if needed, refer to the product catalog or a representative).
RECOMMENDED HEATING CAPACITY: 1.25 W/cubic foot (0.03 m³)
It corresponds to 10 W/square foot (0.09 m²) based on a standard ceiling height of 8 feet (2.44 m). The recommended capacity is usually sufcient
for normal heating needs. Please note that the insulation quality of walls and windows are some of the factors that inuence heat losses, which modify the
required capacity to heat a room. If needed, refer to a specialist (industrial and commercial buildings) who will be able to calculate these heat losses and
optimize the required capacity or consult the “Online heating calculation” section of the Stelpro Design Web site (residential buildings). To heat a large room
and to increase your comfort, it is recommended to install several units instead of one. For example, 2 X 1000 W rather than 1 X 2000 W.
WARNING
For further information or to consult this guide online, please visit our website at www.stelpro.com
REPLACEMENT COMPONENT LIST INCLUDED

2INSWFA0617
WARNING
Do not install the unit where objects or pieces of furniture could be heat damaged.
If the unit capacity is insufcient for the size of the room, it will be in operation continuously, and may become defective earlier and turn yellow.
Respect distances and positions indicated in the installation section.
If the installer or the user modies the unit, he will be held responsible for any damage resulting from this modication, and the CSA certication could be void.
This unit must not come into contact with a water source and must be protected from splashes. Do not use it if any part has been immersed.
When mounting the unit, make sure that the anchorage used can support the total weight of the unit with the mounting brackets.
When cutting or drilling into a wall or a ceiling, do not damage electrical wiring and other hidden utilities.
When starting up the unit for the rst time or after a long period, it is normal that it produces some temporary odours and whitish smoke.
Because this unit is hot when in use, it may pose risks even in normal operation. Therefore, be careful and responsible when using it. To avoid burns, do
not let bare skin touch hot surfaces. The unit must cool down for few minutes since it will stay warm for some time after shut-down.
This unit must be installed at least 6 inches (15.2 cm) from the walls and 8 inches (20.32 cm) from the oor. However, make sure objects or pieces
of furniture do not come into contact with the unit and keep them at least 24 inches (60 cm) from the unit since they are more ammable than walls and
oors. Failure to comply with this warning could lead to a re. Some materials are more heat-sensitive than others, so make sure those near the unit can
withstand heat.
Never block unit air vents. This obstruction could lead to overheating, which could result in a re.
Do not insert or allow foreign objects to enter any air vent as this may cause electric shocks, res, or damages to the unit.
This unit has hot and arcing or sparking parts inside. It is not designed to be used or stored in wet areas or areas containing ammable liquids, combustible
materials or corrosive, abrasive, chemical, explosive and ammable substances such as, but not limited to, gasoline, paint, chlorine, sawdust and cleaning
products.
Some areas are dustier than others. Thus, it is the user’s responsibility to evaluate if the unit must be cleaned based on the amount of dirt accumulated on
and inside air vents. Accumulated dirt can lead to a component malfunction or discoloration (yellow). It may cause a re hazard if not installed and maintained
in accordance with these instructions.
The thermal protection activation indicates that the unit has been subjected to abnormal operating conditions. If the thermal protection remains activated or
activates and deactivates repeatedly, it is recommended that a qualied electrician or a certied repair centre examine the unit in order to make sure it is not
damaged. (Refer to the limited warranty)
If the unit is damaged or defective, cut off power supply at circuit breaker and call a certied repair centre. (Refer to the limited warranty)
Make sure that all the electrical connections have been secured and made properly. Pull each wire to ensure it is not loose in the connector or the terminal
board as this may cause a re.
If an option must be added, make sure it has been approved by Stelpro. This way, it will ensure that it has been tested in accordance with our safety rules and
that an appropriate installation has been planned into the unit.
SPECIFICATIONS
Note: When a part of the product specication must be changed to improve operability or other functions, priority is given to the product specication itself. In such
instances, the instruction manual may not entirely match all the functions of the actual product. Therefore, the actual product and packaging, as well as the name
and illustration, may differ from the manual.
WFA SERIES – WITHOUT CONTROL
UNIT TYPE WATTS VOLTS KG LB
SINGLE WFA1502 1500 240 10 22
SINGLE WFA2002 2000 240 10 22
SINGLE WFA3002 3000 240 10 22
SINGLE WFA4002 4000 240 10 22
SINGLE WFA4802 4800 240 10 22
SINGLE WFA1508 1500 208 10 22
SINGLE WFA2008 2000 208 10 22
SINGLE WFA3008 3000 208 10 22
SINGLE WFA4008 4000 208 10 22
SINGLE WFA4808 4800 208 10 22
SINGLE WFA1507 1500 277 10 22
SINGLE WFA2007 2000 277 10 22
SINGLE WFA3007 3000 277 10 22
SINGLE WFA4007 4000 277 10 22
SINGLE WFA4807 4800 277 10 22
SINGLE WFA1502T 1500 240 10 22
SINGLE WFA2002T 2000 240 10 22
SINGLE WFA3002T 3000 240 10 22
SINGLE WFA4002T 4000 240 10 22
SINGLE WFA4802T 4800 240 10 22
SINGLE WFA1508T 1500 208 10 22
SINGLE WFA2008T 2000 208 10 22
SINGLE WFA3008T 3000 208 10 22
WFA SERIES – WITHOUT CONTROL
UNIT TYPE WATTS VOLTS KG LB
SINGLE WFA4008T 4000 208 10 22
SINGLE WFA4808T 4800 208 10 22
SINGLE WFA1507T 1500 277 10 22
SINGLE WFA2007T 2000 277 10 22
SINGLE WFA3007T 3000 277 10 22
SINGLE WFA4007T 4000 277 10 22
SINGLE WFA4807T 4800 277 10 22
SINGLE WFA1503T 1500 347 10 22
SINGLE WFA2003T 2000 347 10 22
SINGLE WFA3003T 3000 347 10 22
SINGLE WFA4003T 4000 347 10 22
SINGLE WFA4803T 4800 347 10 22
SINGLE WFA1505T 1500 480 10 22
SINGLE WFA2005T 2000 480 10 22
SINGLE WFA3005T 3000 480 10 22
SINGLE WFA4005T 4000 480 10 22
SINGLE WFA4805T 4800 480 10 22
SINGLE WFA1506T 1500 600 10 22
SINGLE WFA2006T 2000 600 10 22
SINGLE WFA3006T 3000 600 10 22
SINGLE WFA4006T 4000 600 10 22
SINGLE WFA4806T 4800 600 10 22
Several other models with control are available in higher voltages and wattages.
For a complete model list, consult our online product catalog at www.stelpro.com

3INSWFA0617
TECHNICAL DRAWINGS
SINGLE UNIT
DOUBLE UNIT
TRIPLE UNIT
K.O. 7/
8
(22mm)
ARRIÈRE/ BACK
26.6mm
1 1/16"
5"
127mm
1 9/16"
40.2mm
16 3/8"
416.3mm
23 1/4"
590.6mm
MUR/
WALL
20 1/2"
521.4mm
2"
51.5mm1 1/4"
32.5mm
1 5/8"
40.7mm
DESSUS/ TOP
EDIS/ÉTOCTNORF/TNAVED
MU
R
WALL
1 9/16"
39.3mm
5"
127mm
1 7/8"
47.8mm
3 13/16"
96.3mm
2"
50.8mm
359.6mm
14 3/16"1 1/8"
28.4mm
K.O. 7/8
(22mm)
ARRIÈRE/ BACK
5"
127mm
TYP. 7 9/16"
192.4mm
23 3/16"
589.6mm
1 1/8"
27.9mm
1 1/16"
26.6mm
DESSUS/ TOP
MUR
WALL
5"
127mm
TYP.
1 7/8"
47.8mm
3 13/16"
96.3mm
2"
50.8mm
29 13/16"
756.8mm
7 9/16"
192.4mm
1 1/8"
28.2mm
10 5/8"
270.2mm
DEVANT/ FRONT
32"
813.2mm
23 1/4"
590.6mm
MUR/
WALL
COTÉ/ SIDE
1 1/4"
32.5mm
20 1/2"
521.4mm
1 5/8"
40.7mm
2"
51.5mm
MUR
WALL
1 1/4"
32.5mm
20 1/2"
521.4mm
2"
51.5mm
ARRIÈRE/ BACKCOTÉ/ SIDEDEVANT/ FRONT
DESSUS/ TOP
23 1/4"
590.6mm
47 3/4"
1213.2mm
MUR
WALL
3 13/16"
96.3mm
1 7/8"
47.8mm
5"
127mm
TYP.
2"
50.8mm
45 7/16"
1154mm
1 9/16"
40.2mm
1 3/16"
29.6mm 10 5/8"
270.2mm
10 5/8"
270.2mm
K.O. 7/8
(22mm)
5"
127mm
TYP.
38 7/8"
986.9mm
23 3/16"
589.6mm
7 9/16"
192.4mm
1 1/16"
26.6mm

4INSWFA0617
N.B. Cut off power supply at circuit breaker/fuse before proceeding to the installation and wiring connections.This product must
be connected by a certied electrician, according to the electrical and building codes effective in your region.
When the unit is recessed, the anged shoulders must rest on the nished surface of the wall.
WARNINGS
1. Recessed and surface installations must meet the minimum distances for single and double units (see gures 1 and 2). Note: 4800 W single units should
be installed with a minimum distance of 8 inches (203 mm) from the oor.
2. Triple units must meet a minimum distance of 12 inches (305 mm) from the wall and 8 inch (203 mm) from the oor. For the opening of recessed
installation of triple units, see gure 3.
3. Recessed structure requirement on outside walls must be the same as a window structure (refer to applicable building codes effective in your area).
4. For surface installation, put a wooden plate at the back of gypsum in order to x the product to the wall securely. For the wooden plate dimensions, refer
to the opening for the recessed application (see gures 2 and 3).
INSTALLATION
FRONT
SURFACE INSTALLATION
SINGLE AND DOUBLE UNIT
REQUIRE (SURFACE ADAPTOR)
OPENING
RECESSED INSTALLATION
SINGLE AND DOUBLE UNIT
OPENING
RECESSED INSTALLATION
TRIPLE UNIT
FIG. 1 FIG. 2 FIG. 3
SURFACE INSTALLATION
1. Make sure you use the proper sleeve surface adaptor depending on the
device you are installing: WFASA1 (single units), WFASA2 (double units),
WFASA3 (triple units).
2. Unscrewed the two (2) screws holding the grid (see gure 4). Raise the
bottom and gently pull up to release the grille (see gure 5).
3. Using the screws included with the sleeve adaptor, attach the sleeve
adaptor to the frame (see gure 6).
4. Remove the inlet of the frame (see gure 6) by unscrewing the four (4)
screws.
5. Open the KO to be used and insert the wire with connector into it.
6. Place the frame against the wall, level it and tighten it with four (4) wood
screws (not included) into the holes provided for this purpose (see gure
7).
7. Replace the inlet, make the required electrical connections and replace
the grille.
RECESSED INSTALLATION
1. The opening in the wall must rst be made in accordance with acceptable
standards (see gures 2 and 3, and Warning).
2. Unscrew the two (2) screws holding the grid (see gure 4). Raise the
bottom and pull up to release the grille (see gure 5).
3. Remove the inlet of the frame (see gure 6) by unscrewing the four (4)
screws.
4. Open the KO to be used and insert the wire with connector into it.
5. Insert the frame into the opening, press the ap against the wall. Screw in
wood screws (not included) in the left and the right studs, through holes
provided for this purpose (see gure 8).
6. Replace the inlet, make the required electrical connections and replace
the grille.
6"
152mm
MIN.
20 3/4"
527mm
7 1/8"
181mm
MIN.
14 1/2 (368mm) SINGLE
30 1/8 (765mm) DOUBLE
6"
152mm
MIN
7 5/8"
194mm
MIN.
20 3/4"
527mm
9 5/8"
244mm
MIN.
13 1/8"
333mm
MIN.
45 7/8 (1165mm) TRIPLE
6"
152mm
MIN.
WALL
FLOOR FLOOR
WALL
WALL
FLOOR
WALL
20 1/2"
521mm
1 5/8"
41mm
3 13/16"
97mm
2 1/16"
52mm

5INSWFA0617
When purchasing a product with a thermostat (e.g. WFA4802T), two
options are available:
OPTION A) TAMPER PROOF
Function: Prevents children from changing the room temperature.
Before installing the grille, insert the tamper proof button onto the shaft of
the thermostat. Check the alignment between the tamper proof knob and
the hole on the grille. Adjust, if necessary, using the thermostat support
grooves.
OPTION B) THERMOSTAT KNOB
After installation of the grille, insert the knob onto the shaft of the
thermostat.
INSTALLATION OF THERMOSTAT KNOBS
THERMOSTAT
GRILLE
TAMPER-PROOF
THERMOSTAT SUPPORT
TAMPER-PROOF
THERMOSTAT
GRILLE
ANTI-VANDALE
SUPPORT THERMOSTAT
ANTI-VANDALE
FIG. 5 FIG. 6FIG. 4
FIG. 7 FIG. 8
SCREW
1
2
FRAME
ADAPTOR
INLET
SCREW
SCREW
SCREW
SCREW
SCREW
SCREW
FLAP
FLAP
SCREW
SCREW
SCREW
SCREW
SCREW
SCREW
FLAP
FLAP
Note: If you ordered the grille without the thermostat hole by mistake,
consult the diagram shown here for the dimensions to manually drill the
hole. 2 3/16"
55mm
5/8"
16mm
3 11/16"
93mm

6INSWFA0617
TROUBLESHOOTING
N.B. If you do not solve the problem after checking these points, cut off the power supply at the main electrical panel and contact our customer service (see the
“Limited warranty” section to obtain the phone numbers).
PROBLEM DEFECTIVE PART OR PART TO CHECK
The unit does not work
• The circuit breaker is in the OFF position or removed fuse
• Defective thermostat or wrong thermostat setting
• Activated thermal protection
• Faulty connections
The unit runs continuously • Defective thermostat or wrong thermostat setting
• Heat losses higher than the unit capacity
The enclosure is extremely hot • Defective thermal protection
• Blocked air vents
The desired ambient temperature can never be reached
• One or more elements are defective
• Defective thermostat or wrong thermostat setting
• Voltage lower than that written on the nameplate
• Heat losses higher than the unit capacity
Overheating • Defective thermostat or wrong thermostat setting
The unit cycles under control of the thermal protection
(overheat indicator)
• Blocked air vents
• Defective motor
The breaker trips when the heater is turned on • Faulty connections
• Voltage higher than that written on the nameplate
N.B. In order for the warranty to be valid, the unit must be
cleaned regularly.
Switch off the main breaker in the electrical panel before cleaning the unit.
Use a soft rag for dusting. When cleaning, use only a damp rag and non-
abrasive dish soap. If you use a cleaning product, always wipe the product
off properly to avoid the discoloration of the unit. Do not use abrasive or
chemical cleaners because they may damage the nishing. If the unit is
used in a very dusty location, use a vacuum brush to remove dust and
other foreign objects from the grilles. If needed, vacuum out the dust inside
the unit. Note that cigarette smoke could yellow the discharge grille and
that the best way to prevent it is to clean the unit on a regular basis.
Do not use cleaning products identied with these symbols:
MAINTENANCE

7INSWFA0617
REPLACEMENT COMPONENT LIST
REF. # PART # DESCRIPTION
1BLA-003 FAN BLADE 8”
2BOUT-033W THERMOSTAT BUTTON, WHITE
2BOUT-033A THERMOSTAT BUTTON, WHITE
2BOUT-033BK THERMOSTAT BUTTON, BLACK
3 BOUT-026W TAMPER-PROOF, WHIITE
3 BOUT-026A TAMPER-PROOF, ALMOND
3 BOUT-026BK TAMPER-PROOF, BLACK
4 --- ---
5 ELF-WFA1502 ELEMENT ASSEMBLY WFA1502
5 ELF-WFA1503 ELEMENT ASSEMBLY WFA1503
5 ELF-WFA1506 ELEMENT ASSEMBLY WFA1506
5 ELF-WFA1507 ELEMENT ASSEMBLY WFA1507
5 ELF-WFA2002 ELEMENT ASSEMBLY WFA2002
5 ELF-WFA2003 ELEMENT ASSEMBLY WFA2003
5 ELF-WFA2006 ELEMENT ASSEMBLY WFA2006
5 ELF-WFA2007 ELEMENT ASSEMBLY WFA2007
5 ELF-WFA2008 ELEMENT ASSEMBLY WFA2008
5 ELF-WFA3002 ELEMENT ASSEMBLY WFA3002
5 ELF-WFA3003 ELEMENT ASSEMBLY WFA3003
5 ELF-WFA3006 ELEMENT ASSEMBLY WFA3006
5 ELF-WFA3007 ELEMENT ASSEMBLY WFA3007
5 ELF-WFA4002 ELEMENT ASSEMBLY WFA4002
5 ELF-WFA4003 ELEMENT ASSEMBLY WFA4003
5 ELF-WFA4006 ELEMENT ASSEMBLY WFA4006
5 ELF-WFA4007 ELEMENT ASSEMBLY WFA4007
5 ELF-WFA4008 ELEMENT ASSEMBLY WFA4008
5 ELF-WFA4802 ELEMENT ASSEMBLY WFA4802
5 ELF-WFA4803 ELEMENT ASSEMBLY WFA4803
5 ELF-WFA4805 ELEMENT ASSEMBLY WFA4805
5 ELF-WFA4806 ELEMENT ASSEMBLY WFA4806
5 ELF-WFA4807 ELEMENT ASSEMBLY WFA4807
5 ELF-WFA4808 ELEMENT ASSEMBLY WFA4808
6 PROT-006 THERMAL PROTECTION 1500-2000W
6 PROT-005 THERMAL PROTECTION 3000-12000W
7 ST-017 THERMOSTAT SP 120 TO 277V-22A, 600V-10A
7 ST-007 THERMOSTAT SP 120 TO 277V-25A, 600V-10A
7 ST-013 THERMOSTAT DP 120 TO 277V-25A, 600V-10A
REF. # PART # DESCRIPTION
CONTROL TRANSFORMER
8 TRF200040D TRANSFORMER 208-240/24/40VA CL.2
8 TRF700025 TRANSFORMER 277/24/25VA
8TRF720025 TRANSFORMER 277/240/25VA
8TRF300040 TRANSFORMER 347/24/40VA CLS 2
8TRF320025 TRANSFORMER 347/240/25VA
8TRF500025D TRANSFORMER 240-480/12-24/25VA
8TRF520025 TRANSFORMER 480/240/25VA
8TRF600040 TRANSFORMER 600/24/40VA CLS 2
8TRF620025 TRANSFORMER 600/240/25VA
CONTACTOR
9CONT-3002 CONTACTOR 2P/24V/30A RESISTIVE
9CONT-3503 CONTACTOR 3P/24V/35A RESISTIVE
9CONT-5002 CONTACTOR 2P/24V/50A RESISTIVE
9CONT-3022 CONTACTOR 2P/240-208V/30A RESISTIVE
9CONT-4023 CONTACTOR 3P/240-208V/40A RESISTIVE
9CONT-5023 CONTACTOR 3P/240-208V/50A RESISTIVE
MOTOR TRANSFORMER
10 TRF720100 TRANSFORMER 277/240/100VA
10 TRF520100 TRANSFORMER 480/240/100VA
10 TRF620100 TRANSFORMER 600/240/100VA
11 MO-016 MOTOR 208/240V 50/60HZ 0.4A
12 M-WFA100Z* GRILL ASSY WFA-1
12 M-WFA100TZ* GRILL ASSY WFA-1, THERMOSTAT
12 M-WFA200Z* GRILL ASSY WFA-2
12 M-WFA200TZ* GRILL ASSY WFA-2, THERMOSTAT
12 M-WFA300Z* GRILL ASSY WFA-3
12 M-WFA300TZ* GRILL ASSY WFA-3, THERMOSTAT
13 SWI-027 MOTOR SWITCH 600V/30A, 2 POLES
13 SWI-028 DISCON. SWITCH 600V/40A 2POLES/3POLES
13 SWI-029 DISCON. SWITCH 600V/60A 2POLES/3POLES
13
1
11
78
9
10
5
3
2
12
* Add Wfor white, SW for silica white, Afor almond, Sfor silver, BK for black,
CHAR for textured charcoal, NIC for nickel, CHA for champagne, LB for light
bronze, BR for dark brown or CAP for clear anodized (paint)

8INSWFA0617
STELPRO DESIGN INC. | Saint-Bruno-de-Montarville | Québec | J3V 6L7
This limited warranty is offered by Stelpro Design inc. (“Stelpro”) and applies to the following products made by Stelpro: WFA model. Please read
this limited warranty carefully. Subject to the terms of this warranty, Stelpro warrants its products and their components against
defects in workmanship and/or materials for the following periods from the date of purchase: 3 years. This warranty applies only to the original
purchaser; it is non-transferable and cannot be extended.
CLAIM PROCEDURE
If at any time during the warranty period the unit becomes defective, you must cut off the power supply at the main electrical panel and contact 1) your
installer or distributor, 2) your service center or 3) Stelpro’s customer service department. In all cases, you must have a copy of the invoice and
provide the information written on the product nameplate. Stelpro reserves the right to examine or to ask one of its representatives to
examine the product itself or any part of it before honoring the warranty. Stelpro reserves the right to replace the entire unit, refund its purchase
price or repair a defective part. Please note that repairs made within the warranty period must be authorized in advance in writing by Stelpro and
carried out by persons authorized by Stelpro.
Before returning a product to Stelpro, you must have a Stelpro authorization number (RMA). To obtain it, call the customer service department at:
1-800-363-3414 (electricians and distributors - French), 1-800-343-1022 (electricians and distributors - English), or 1-866-766-6020
(consumers). The authorization number must be clearly written on the parcel or it will be refused.
CONDITIONS, EXCLUSIONS AND DISCLAIMER OF LIABILITY
This warranty is exclusive and in lieu of all other representations and warranties (except of title), expressed or implied, and Stelpro expressly disclaims
and excludes any implied warranty of merchantability or implied warranty of tness for a particular purpose.
Stelpro’s liability with respect to products is limited as provided above. Stelpro shall not be subject to any other obligations or liabilities whatsoever,
whether based on contract, tort or other theories of law, with respect to goods or services furnished by it, or any undertakings, acts or omissions
relating thereto. Without limiting the generality of the foregoing, Stelpro expressly disclaims any liability for property or personal injury damages,
penalties, special or punitive damages, damages for lost prots, loss of use of equipment, cost of capital, cost of substitute products, facilities or
services, shutdowns, slowdowns, or for other types of economic loss or for claims of a dealer’s customers or any third party for such damages. Stelpro
specically disclaims all consequential, incidental and contingent damages whatsoever.
This warranty does not cover any damages or failures resulting from: 1) a faulty installation or improper storage; 2) an abusive or abnormal use, lack
of maintenance, improper maintenance (other than that prescribed by Stelpro) or a use other than that for which the unit was designed; 3) a natural
disaster or an event out of Stelpro’s control, including, but not limited to, hurricanes, tornadoes, earthquakes, terrorist attacks, wars, overvoltage,
ooding, water damages, etc. This warranty does not cover any accidental or intentional losses or damages nor does it cover damages caused by
negligence of the user or owner of the product. Moreover, it does not cover the cost of disconnection, transport, and installation.
The warranty is limited to the repair or the replacement of the unit or the refund of its purchase price, at the discretion of Stelpro. Any parts
replaced or repaired within the warranty period with the written authorization of Stelpro will be warranted for the remainder of the original warranty
period. This warranty will be considered null and void and Stelpro will have the right to refuse any claims if products have been altered without
the written authorization of Stelpro and if the nameplate numbers have been removed or modied. This warranty does not cover scratches, dents,
corrosion or discoloration caused by excessive heat, chemical cleaning products and abrasive agents. It does not cover any damage that occurred
during the shipping.
Some states and provinces do not allow the exclusion or limitation of incidental or consequential damages and some of them do not allow limitations
on how long an implied warranty lasts, so these exclusions or limitations may not apply to you. This warranty gives you specic legal rights and you
may have other rights which vary from state to state or from province to province.
LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY
LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY
LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY
LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY
LIMITED WARRANTY
