STI E2610VA110 User manual

(1)
PART.No E2610VA110
FUJI HEAVY INDUSTRIES, LTD. 131220
00
Ø10 mm
Ø9.5 mm
Ø6 mm
Ø3 mm 8 mm
STI SIDE UNDER SPOILER
(1) (2) (3) (4) (5) (6)
Small bag
( 7 ) Pattern set
Pattern RH
Detergent
APattern LHA Pattern RHB Pattern LHB Pattern LHCPattern RHC Pattern LHDPattern RHD
Pattern LHGPattern RHGPattern LH
FPattern RHFPattern LHE
Pattern RHE
Pattern LH
HPattern RHH Pattern LHIPattern RHI Pattern LHJPattern RHJ Pattern LHKPattern RHK
INSTALLATION INSTRUCTION
GUIDE D'INSTALLATION
EINBAUANLEITUNG
MANUALE D'INSTALLAZIONE
MANUAL DE INSTALACION
Applicable: LEVORG
(2016MY ~ )
(R)×1
(L)×1
× 20 × 20 × 20 × 2 × 2

(2)
CAUTION
(1) Perform installation properly according to the procedures indicated in the instruction manual.Improper installation
can result in damage to your vehicle or serious injury.
(2) Be careful when driving after installing this product as ground clearance at the side sill spoiler is decreased by
approximately 20mm (0.8 inches).
(3) Never use gasoline, thinner, acid, alkaline or other organic solvent to clean this product.
(4) This product can become deformed if exposed to high heat.
(5) Always keep this instruction manual in your vehicle.
(1) Procédez à la repose correctement conformément aux procédures indiquées dans le manuel d’instructions.
Toute repose incorrecte peut endommager sérieusement votre véhicule ou provoquer des blessures graves.
(2) Faites attention à la conduite du véhicule après la repose de ce produit, la garde au sol au niveau de la moulure de
marchepied étant réduite d’environ 20 mm (0,8 pouce).
(3) N’utilisez jamais d’essence, de diluant, de solvant acide, alcalin ou tout autre solvant organique pour nettoyer ce
produit.
(4) Ce produit peut se déformer s’il est soumis à des températures élevées.
(5) Conservez toujours le présent manuel d’instructions dans votre véhicule.
(1) Führen Sie die Installation exakt nach den Verfahren durch, die in der Bedienungsanleitung beschrieben sind.
Unsachgemäße Installation kann zu Schäden an Ihrem Fahrzeug oder zu schweren Verletzungen führen.
(2) Fahren Sie nach der Installation dieses Produkts vorsichtig, da die Bewegungsfreiheit am Seitenspoiler um ca. 20 mm (0,8 Zoll)
reduziert ist.
(3) Verwenden Sie niemals Benzin, Verdünner, Säuren, Laugen oder andere organische Lösungsmittel zur Reinigung dieses Produkts.
(4) Dieses Produkt kann sich bei starker Hitze verformen.
(5) Bewahren Sie diese Bedienungsanleitung immer in Ihrem Fahrzeug auf.
(1) Esegui l'installazione correttamente in base alle procedure indicate nel manuale di istruzioni.
Una errata installazione può causare danni al veicolo o lesioni gravi.
(2) Prestare attenzione durante la guida dopo l'installazione di questo prodotto in quanto è stata ridotta la distanza da
terra sullo spoiler del longherone laterale di circa 20 mm (0,8 pollici).
(3) Non usare benzina, solventi, acidi, alcalini o altri solventi organici per pulire questo prodotto.
(4) Questo prodotto potrebbe deformarsi se esposto a calore eccessivo.
(5) Conservare sempre questo manuale di istruzioni all'interno del veicolo.
(1) Выполните установку в соответствии с инструкциями в руководстве.
Неправильная установка может привести к повреждению вашего автомобиля или серьезной травме.
(2) Будьте осторожны при вождении автомобиля после установки данного изделия, поскольку клиренс спойлера
бокового порога уменьшается приблизительно на 20 мм (0,8 дюйма).
(3) Ни в коем случае не используйте для чистки данного изделия бензин, растворитель, кислоту, щелочь или
другие органические растворители.
(4) Под воздействием высокой температуры данное изделие может деформироваться.
(5) Всегда держите данное руководство в вашем автомобиле.
（１） 请根据安装指导说明书中所述的步骤正确进行安装。
安装不当会导致车辆损坏或严重伤害事故。
（２） 安装本产品后请小心驾驶，因为侧梁扰流板的离地间隙减少了约 20 mm (0.8 inch)。
（３） 切勿使用汽油、稀释剂、酸、碱或其他有机溶剂清洁本产品。
（４） 本产品处于高温状态下可能会变形。
（５） 请始终将本安装指导说明书存放在您车中。
(1) Realice la instalación correctamente según los procedimientos que se indican en el manual de instrucciones.
La instalación incorrecta puede provocar daños en su vehículo o lesiones graves.
(2) Tenga cuidado cuando conduzca después de instalar este producto, debido a que la distancia libre al suelo en el faldón o estribo
lateral disminuye aproximadamente 20 mm (0,8 pulgadas).
(3) No utilice nunca gasolina, diluyente, ácido, productos alcalinos u otros disolventes orgánicos para limpiar este producto.
(4) Este producto puede deformarse si se expone a una fuente de calor elevado.
(5) Guarde este manual de instrucciones en su vehículo en todo momento.

(3)
1
2
3
NOTE:
• Do not wash the vehicle for 24 hours following installation of this product.
• If this product requires cleaning after installation, wipe with a soft cloth or sponge with mild detergent and wipe thoroughly with a dry cloth.
Do not use gasoline, thinner, acid, alkaline or other solvent based products.
• The recommended adhesive surface temperature range is 77 F - 104 F (25° - 40°).
• If the surface temperature is below 60 F (15°), heat the double sided tape and bumper surface to a temperature of 77 F - 104 F (25° - 40°).
Detergent

(4)
4
5
(7) Pattern A
(7) Pattern E (7) Pattern F
(7) Pattern B (7) Pattern C (7) Pattern D
(7) Pattern I
(7) Pattern J
(7) Pattern K
3 mm → 6 mm →
10 mm 3 mm → 6 mm →
9.5mm (10 mm)
10 mm (a)9.5 mm
(7) Pattern G
(7) Pattern H

(5)
6
7
8
3 mm → 6 mm
(3)
Insert ( 3) into the 10 × Ø9.5 mm holes.
( The marking point of pattern K )
Detergent

(6)
9
11
10
(1)
( 5 ) 10 Ø
( 6 ) 6 Ø
Peel 20 to 50 mm of the tape liner,
and seal with tape on the outside of
the Side under spoiler.
(4)
(2)
Tighten the screws temporarily.

(7)
12
14
13
( 1 ) SIDE UNDER SPOILER
( 2 )
(1.0 ±0.5 N •m )
（0.8 ± 0.3 lb-ft）
Re-install the OE side sill spoiler.
Tighten the screws completely.
(1)
4.5 kg
(10 lbs) 10 sec
( 1 ) SIDE UNDER SPOILER
SIDE SILL SPOILER
(1)
Align with a concave shape of
the side sill spoiler.
Convex shape of
side sill spoiler
A
OK NG
