INSTALLATION OF SS-2000 SERIES STOPPER® STATION
All specifications and information shown were current as of publication, and are subject to change without notice. 1027IS MAY2011
Safety Technology International, Inc.
2306 Airport Road • Waterford, Michigan 48327-1209
Phone: 248-673-9898 • Fax: 248-673-1246
Toll Free: 800-888-4784 • E-mail: [email protected]
Web: www.sti-usa.com
Safety Technology International (Europe) Ltd.
Unit 49G Pipers Road • Park Farm Industrial Estate • Redditch
Worcestershire • B98 0HU • England • Tel: 44 (0) 1527 520 999
Fax: 44 (0) 1527 501 999 • Freephone: 0800 085 1678 (UK only)
E-mail: [email protected]om • Web: www.sti-europe.com
#7 BUTT
#9
#
#9
#
#7 BUTT
#9
#
EXISTING STANDARD
SINGLE GANGBOX
HOUSING INDEXING SLOTS
BACKPLATE ASSEMBLY
(SEE REVERSE SIDE)
102722 SPACER RED, GREEN,
YELLOW, WHITE AND BLUE.
STI RECOMMENDS THE USE OF THIS
SPACER FOR SWITCH CLEARANCE
ON STANDARD SINGLE GANG BOXES.
ASSIGNED A 5VA FLAMMABILITY RATING.
SEE NOTE IN PRODUCT DIMENSION VIEW.
10274 OCTAGON SHELL
RED, GREEN, YELLOW, WHITE AND BLUE
10105 MOMENTARY BUTTON (#4)*KEYS
(2) PROVIDED
10271 STATION HOUSING
RED, GREEN, YELLOW, WHITE AND BLUE
10100 PUSH/TURN RESET BUTTON (#1)
10104 KEY BUTTON (#3)
KEY REQUIRED TO ACTIVATE - IN
ACTIVATE MODE KEY CAN BE REMOVED
19001 SCREW
(1) PROVIDED
STATION LABEL
KEYS
(2) PROVIDED
10102 KEY RESET SWITCH
OCTAGON KEY RESET BUTTON (#0)
RED, GREEN, YELLOW, WHITE
AND BLUE
02050
T
PUSH
PUSH
HERE
NOTE: TO PROVIDE ADEQUATE CLEARANCE FOR INSTALLATION,
MAY REQUIRE: SUB-102722 SPACER, OR RACO #660
W/1/2" K.O. AND RACO #653 EXTENSION RING.
ALSO RACO #696 MASONRY BOX.
P
3.25 in.
(82mm)
4.87 in.
(124mm)
1.62 in.
(41mm) 2.25 in.
(57mm)
*
#7 BUTT
PROD CT DIMENSIONS
*SS-2**4 and LT1-UL NOTES: For access control nstallat ons, power for the LT-1UL T mer must be suppl ed by a power
source l sted to UL294. When used for access control, th s dev ce shall be used as part of an access controlled egress door
system. It s up to the local AHJ to allow use of th s dev ce n place of an automat c sensor. For h gher secur ty nstallat ons,
lower t me l m ts should be used. For SS-2**4 and LT1-UL the enclosed t mer s to be used and nstalled per the enclosed
LT-1UL nstallat on sheet. *SS-2**4 and LT1-UL max mum rat ng 30 VDC 3A. Electronic warranty form at www.sti-usa.com/wc14
#7 BUTT
#7 BUTT
#9
#
STRIP 1/4 in. OF WIRE INSULATION
INSERT IN TERMINAL (AS SHOWN) THEN
USING A PHILLIPS SCREWDRIVER TURN
CLOCKWISE UNTIL TIGHT.
INSTALLATION OF SS-2000 SERIES STOPPER® STATION
All specifications and information shown were current as of publication, and are subject to change without notice. 1027IS MAY2011
Safety Technology International, Inc.
2306 Airport Road • Waterford, Michigan 48327-1209
Phone: 248-673-9898 • Fax: 248-673-1246
Toll Free: 800-888-4784 • E-mail: [email protected]
Web: www.sti-usa.com
Safety Technology International (Europe) Ltd.
Unit 49G Pipers Road • Park Farm Industrial Estate • Redditch
Worcestershire • B98 0HU • England • Tel: 44 (0) 1527 520 999
Fax: 44 (0) 1527 501 999 • Freephone: 0800 085 1678 (UK only)
E-mail: [email protected]om • Web: www.sti-europe.com
VIEW IN DIRECTION OF ARROW A
INSTALLATION OF ELECTRICAL
WIRE INTO TERMINAL BLOCK
VIEW IN DIRECTION OF ARROW A
INSTALLATION AND REMOVAL OF TERMINAL BLOCKS AND
TERMINAL BLOCK ASSEMBLY FROM B TTON ASSEMBLY
#7 BUTT
#9
#
#9
#
#7 BUTT
#9
#
TERMINAL BLOCK 10196 NO (1) PROVIDED
10198 NC (1) PROVIDED
SEE VIEW IN DIRECTION OF ARROW
FOR CONTACT INDENTIFIER LOCATIONS
UP TO (3) TERMINALS MAY BE USED FOR EACH
STATION ASSEMBLY.
OUTGOING
INCOMING
19010 SCREWS #6-32 x 1
OUTLET BOX (2) PROVIDED.
SCREWS #6-32 x 1.50 WHEN
USING 102722 SPACER
(SEE REVERS SIDE).
19021 GROUND LUG
(1) PROVIDED
BUTTON LOCK NUT
10272 BACKPLATE
GREEN, YELLOW, WHITE AND BLUE
A
#7 BUTT
#7 BUTT
#9
#
NC
NO1
2
3
4
SEPARATION OF TERMINAL ASSEMBLY.
FROM BUTTON ASSEMBLY IS AS FOLLOWS:
GRASP TERMINAL HOUSING AND USING THUMB
APPLY PRESSURE DOWNWARD, REMOVE TERMINAL.
REMOVAL OF TERMINAL BLOCK
FROM TERMINAL HOUSING: INSERT
SMALL SCREWDRIVER (AS SHOWN)
AND PRY UPWARD, REMOVE TERMINAL.
#7 BUTT
#7 BUTT
#9
#
TERMINAL BLOCK
RELEASE LEVER
MUST FACE UPWARD
AS SHOWN FOR SWITCH
TO FUNCTION CORRECTLY.
ELECTRICAL TERMINAL BLOCK
UP TO 3 TERMINALS MAY BE USED
INSERT NOTCH, AS SHOWN
THEN ROTATE UPWARD
VOLTAGE
250 VDC
600 VAC
RATED AVERAGE C RRENT
1 AMP
3 AMP
ALL TERMINALS ACCEPT TWO 12 TO 18 (AWG)
NO — NORMALLY OPEN
NC — NORMALLY CLOSED
C — COMMON
TERMINAL BLOCK LEGEND
NOTE: SS-2XX4/LT CONTACTS ON FORM C TIMER RATED: 120 VAC, 3A
28 VDC, 3A
