Stil-fit ERGOMETER PURE User manual

Instruction Manual
ERGOMETER PURE

Assembling the Cockpit
The STIL-FIT ergometer is delivered almost fully
assembled. You only have to connect one cable,
tighten one screw at the front post and assemble the
handle bar.
Step 1
Slip the wooden tube onto the front tube. Connect
the cable. Pay attention to the arking. Check if the
connection is fixed well. Then stick the unit into the
frame.
Step 2
Assemble the handle bar. We recommend to align
the handle bar parallel to the cockpit as shown in the
picture.
Both parts are packed each in one box.

Adjustment of the quick release
To adjust the quick release, open the lever and
tighten the screw until the desired result is achieved.
When the quick release is fastened the saddle should
not turn. Attention: The saddle tube has a mark
-max-. This indicates the maximum possible height
of the saddle.
Adjustment of the saddle
The saddle can be adjusted horizontally and vertically.
To adjust the saddle, loose the screws at the bottom
and adjust the angle. Fix the saddle at the desired
position and tighten the screws again very strong.
Both parts are packed each in one box.
Step 3
Slide the wooden tube upwards. At the front you will see a hole with a headless
screw inside. Use the Allen key and turn the tool clockwise firmly to fix the front
tube in the frame.
Never remove the screw. Pay attention that the front unit is aligned straight.
Take the rubber grommet and stick it into the hole. Then slide the wooden tube
downwards. The rubber grommet will keep the tube in position.
2

Assembling of the transportation wheels
The transportation wheels can be mounted optionally
at the back of the frame.
Adjustable feet
The STIL-FIT Ergometer comes with four adjustable
feet to guarantee a firm stand.
Special equipment
You can equip the Ergometer with dierent acces-
sories. These components can be purchased from
the bicycle retail market. Please note the following
specifications.
Pedals
all types with standard thread
Seat
all standard types
Seat tube
tube size 31,8 mm

TRAININGS COMPUTER:
The Ergometer is controlled by a 4,3” touch screen monitor.
The operation is very easy and self-explanatory. Start imme-
diately with the quick start or register a user and select a
program.
By starting to pedal the training computer is activated. It turns
PROGRAMS:
Quick Start 1-32 resistance levels
Manuel 1-32 resistance level with pre
selection of time
Beginner 115 minutes, level 6-10
Beginner 2 30 minutes, level 6-10
Advanced 1 20 minutes, level 8-14
Advanced 2 30 minutes, level 10-14
Advanced 3 45 minutes, level 10-16
Watt Constant Adjustable in steps of 5 Watt
Cardio Fitness 75% of the maximum pulse
Cardio Fatburner 65% of the maximum pulse
Data storage:
The training computer stores data for up to five people.
Pulse control
The pulse signal is transferred via BLuetooth smart. We
recommend the heart rate sensor Verity Sense from Polar
Language
German and English are available.

Step 2
Assemble the handle bar. We recommend to align
the handle bar parallel to the cockpit as shown in the
picture.
The user interface is self-explanatory and easy to use
with a clearly arranged operator guidance system.
Using the "Quick start" you start immediately with
your workout. You can find our other preselected
programs in the ‚program selection’. The trainings
computer gives you the opportunity to store the
training-data for up to four users.
Training Screen
RPM
km/h
25
Pulse
WATT
Distance/ km
CAL
130
850
62
120
Level
30 min
12
2.0
12:20 +
-
Heart rate
RPM
Adjustment level
Back
Remaining time
Training level
Distance
Power
Calories
Speed
Home

Start Screen
Screen: Program selection
Quick Start allows you to
start immeditely with
program Manual
RPM
km/h
25
Pulse
WATT
Distance/ km
CAL
130
850
62
120
Level
30 min
12
2.0
12:20 +
-
RPM
Back
Speed

Screen: Pre-selection
Screen: Data Base

The ergometer has an induction brake system with a
built in generator. There is no external power supply
necessary. At the bottom of the housing there is a
battery rack for 10 Mignon AA rechargeable cells.
They keep the training computer activated in case
you stop pedaling.
If you should not be using the Ergometer for a longer
period of time the battery might be discharged.
Please use the enclosed power supply in order to
recharge the battery. You will find the socket at the
backside of the housing. If the batteries are defect
they can be replaced. Unscrew the battery rack and
replace the batteries.
Technical Data
Ergometer PURE
Commercial induction brake system with built-in generator
50 - 400 watt
4,3“ touch screen monitor
2 cardio programs
Manual mode - adjustable in 32 levels
Watt program - adjustable in steps of 5 watt
5 hill programs
POLAR pulse receiver Bluetooth smart
Data storage for 5 users
Languages: German, English
No external power supply necessary
Weight 38 kg
Transportation rollers - optional installation
L/W/H: 115 x 50 x 120 cm
Virtual tours
The app Kinomap can be used with the STIL-FIT Ergometer
PURE.
www.kinomap.com
