Storz & Bickel GMBH Crafty User manual

STORZ & BICKEL GMBH & CO. KG
INSTRUCTIONS FOR USE
Read carefully before using the device
and save these instructions.

3
Table of Contents .......................................................... page
1. Product overview, Scope of delivery ................................... 5
2. Explanation of Symbols,
Safety Recommendations .................................................... 7
3. Intended Use ........................................................................... 11
4. Overview of Plants ............................................................... 12
5. Factors inuencing Vaporization ...................................... 13
6. The CRAFTY Vaporizer ...................................................... 13
7. Commissioning and Operation .......................................... 16
7.1. Charging the Battery ................................................ 16
7.2. Heating up ................................................................. 18
7.3. Temperature Setting ............................................... 18
7.4. Reset to Default Settings ....................................... 18
8. Filling the Filling Chamber ................................................... 19
8.1. Filling Aid .................................................................... 20
8.2. Filling the Filling Chamber
Using the Filling Aid .................................................. 21
9. Application ............................................................................. 22
10. Disassembling, Cleaning and Assembling ..................... 23
10.1. Disassembling and Reassembling
the CRAFTY Cooling Unit ...................................... 24
10.2. Cleaning the CRAFTY Cooling Unit .................... 26
10.3. Removal of the Lower Filling
Chamber Screen ...................................................... 26
INSTRUCTIONS FOR USE ENGLISH

Power
Adapter with
USB Cable
Herb Mill
Filling AidCleaning Brush
3 pcs. Spare Screens
1 Set of Spare Seal
Rings (one Seal Ring
each)
CRAFTY
Vaporizer
Dosing Capsule Liquid Pad
Instructions
for Use
54
1. PRODUCT OVERVIEW CRAFTY VAPORIZER
Scope of delivery:
(optional accessory: 12 Volt Car Charger)
Please check whether all components have been included. If not, please inform
the Storz & Bickel Service Center.
In the case of technical problems, questions about the device, warranty claims
and disposal of the device, customers in the US and Canada should contact the
following address:
Storz & Bickel America, Inc.
1078 60th Street, Suite A · Oakland, CA 94608
All other customers should contact this address:
Storz & Bickel GmbH & Co. KG
In Grubenäcker 5-9 · 78532 Tuttlingen, Germany
INSTRUCTIONS FOR USE ENGLISH
Table of Contents .......................................................... page
11. CRAFTY App ......................................................................... 27
11.1. Default Settings ........................................................ 27
11.2. Connecting the CRAFTY Vaporizer
with a Smartphone .................................................. 27
11.3. The Menu Items of
the CRAFTY App ..................................................... 28
11.4. Setting Temperature with
the CRAFTY App ..................................................... 29
11.5. Further Individual Settings .................................... 30
11.6. Menu Items for Device and Information.............. 31
12. Accessories ........................................................................... 32
12.1. Dosing Capsules and Magazine ........................... 32
12.2. Disposable Lip Piece for Hygienic Use ............... 35
13. Technical Specications ..................................................... 36
14. CE Declaration of Conformity ............................................ 36
15. Warranty, Liability ................................................................. 37

Type Label
(on the underside)
Charging Socket
(behind the Filling
Chamber Tool)
Filling Chamber Tool
ON/OFF Switch
LED-Display
Filling Chamber Mouthpiece
Cooling Unit
CRAFTY Vaporizer functional elements:
76
Explanation of symbols
Please follow these instructions carefully!
Safety recommendations!
In order to avoid injuries to persons and damage to the equipment,
it is mandatory to observe instructions marked with this symbol.
Note/Tip!
This symbol always gives you technical information or useful tips
regarding the Vaporizer.
The device was introduced after 13 August 2005. It may not be
disposed of in normal household waste.The X on the trash can
indicates the necessity of disposing of this device separately. The
device contains a built-in rechargeable lithium-ion battery that must
be discharged before disposal.
Symbol for the manufacturer - the manufacturer‘s name and
address are next to the symbol
2. SAFETY RECOMMENDATIONS
Read the following safety
recommendations thorough-
ly and carefully before using
the device.
These Instructions for Use are a
signicant part of the Vaporizer and
power adapter and must be provided
to the user.
The instructions given in these In-
structions for Use must be strictly
observed as they are extremely im-
portant to ensure safety during in-
stallation, use and maintenance of
the Vaporizer and power adapter.
Please keep this brochure in a safe
place for future reference.
You may download the current In-
structions for Use for the CRAFTY
on www.storz-bickel.com.
1. PRODUCT OVERVIEW CRAFTY VAPORIZER

98
2. SAFETY RECOMMENDATIONS
Safety Recommendations
The packaging material (plastic
bags, boxes etc.) must be kept out
of the reach of children as it is a
potential source of danger.
People who require assistance must
be supervised constantly during ap-
plictaion. Such persons often under-
estimate the hazards involved (e.g.
strangulation with the USB cable of
the power adapter), so resulting in
injury.
The device contains small parts
which can block the respiratory tract
and lead to choking. Therefore, make
sure that you always keep the Vapor-
izer and accessories out of the reach
of babies and infants.
When charging the battery, only use
the power adapter supplied with the
Vaporizer or the 12 Volt car charger
available as an accessory from Storz
& Bickel. The use of products from
other sources can damage the bat-
tery.
If you have any concerns, ask a spe-
cialist to check whether the electrical
system is in accordance with the
local safety regulations.
If there are any problems during
operation, immediately pull out the
power adapter from the socket.
The USB cable of the power adapter
must be unwound over its entire
length (avoid rolling up and laying the
coils over each other). It must not be
exposed to any impacts and must
be kept out of the reach of children.
Also, it must not be kept near liquids
or sources of heat and must not be
damaged. Do not wind the USB cable
of the power adapter tightly, nor pull
it over sharp edges and never crush
or kink it. If the mains USB cable is
damaged, please contact our Service
Center to have it replaced. Never try
to repair a power adapter USB cable
yourself!
The use of multiple sockets and/or
extension cables is not recommend-
ed. However, if this is absolutely
The China Compulsory Certicate (CCC) is a certication system
that applies in China.
The lightning ash with arrowhead symbol within an equilateral
triangle alerts the user to the presence of uninsulated, dangerous
voltage within the system enclosure that may be of sucient
magnitude to constitute a risk of electrical shock.
Equipment with this symbol may only be used in the house (dry
surroundings).
EU conformity symbol:
The manufacturer conrms with this symbol the compliance of the
product with the applicable European directives and standards.
Safety Category II device
DC (direct current)
Caution! Hot surfaces!
Do not touch metal parts!
Protect from direct sunlight.
Protect against moisture and humidity.
UL Recognized Component Mark: This symbol indicates that the
corresponding devices are listed by UL.
UL - Underwriters Laboratories: This symbol indicates that the
corresponding devices are listed by UL.
Restriction on the use of certain hazardous substances in electrical
and electronic equipment
Symbol for FCC declaration of conformity
(electromagnetic interference approval in the USA)
Eciency Level 5
Eciency of power adapter
2. SAFETY RECOMMENDATIONS
The following symbols relate to the power adapter:
Safety tested and production monitored by TUEV SUED according
to EN 60335-1, UL 499 and CAN/CSA-22.2 No. 64-M91.

1110
The manufacturer is not re-
sponsible for any damage or
personal injury caused by in-
appropriate, incorrect or irresponsi-
ble use.
Never operate the Vaporizer or power
adapter when it is wet or damp. If the
Vaporizer or the power adapter gets
wet, it must be checked by our Ser-
vice Center for damage to electrical
components.
Do not use in an atmosphere with risk
of explosion or ignition.
Never allow the Vaporizer or the
power adapter to be used by children
or unqualified persons.
Only use original Storz & Bickel acces-
sories and spare parts.
2. SAFETY RECOMMENDATIONS
3. INTENDED USE
The CRAFTY Vaporizer releases fra-
grances or aromas from the herbs
and other plant materials listed below.
These aromatic substances are re-
leased through vaporization by heated
air, and may be directly inhaled.
The device may only be used with the
recommended vaporizing media. The
use of other substances can present a
health risk.
The CRAFTY Vaporizer is not intended
for medical/therapeutic purposes.
2. SAFETY RECOMMENDATIONS
necessary, only products with a qual-
ity certificate (such as UL, IMQ, VDE,
+S etc.) may be used, provided the
specified power exceeds the power
required (A=Ampere) by the devices
that are connected.
After use, the Vaporizer must be
placed on a stable, flat surface. To
be used only at a sufficient distance
away from heat sources (ovens,
stoves, fireplaces), and in locations
where the ambient temperature can-
not drop below +5°C (+41°F). Store
the Vaporizer and power adapter in
a dry place protected against the ef-
fects of weather and out of the reach
of children or unqualified persons.
It cannot be used in damp locations
(such as bathrooms etc.).
Do not operate the Vaporizer close to
flammable objects such as curtains,
tablecloths, or paper.
Keep the Vaporizer and power adapt-
er away from pets (e.g. hamsters,
mice) and other animals which could
damage the insulation of the power
adapter USB cable.
The Vaporizer and power adapter
may not be repaired by the customer.
Incorrectly performed repairs with-
out the use of original spare parts
can prove dangerous to the user.
Danger to life when opening the
power adapter as live components
and connections are exposed.
The Vaporizer must never be
repaired or transported when the
power adapter is plugged in.
The Vaporizer and power adapter
must never be operated when the
power adapter USB cable is faulty.
Do not put any objects into the open-
ings of the device.
Do not leave the Vaporizer unat-
tended while it is being operated.
After use, switch off the heater.
The ventilation slots and the hot air
outlet of the Vaporizer may not be
closed, obstructed, or blocked while
the device is being used, nor while it
is cooling down.
Caution! Hot surfaces!
The Filling Chamber is made of metal;
do not touch it when it is hot.
Before cleaning, disconnect the
power adapter from the socket. The
Vaporizer and the power adapter
should be cleaned only with a dry
cloth - or a damp cloth if absolutely
necessary. Never immerse the Vapor-
izer or the power adapter in water
or any other liquid, nor clean it with
direct jets of water or steam.
The Vaporizer and the power adapter
must not be used in damp or wet
conditions.
Do not expose the Vaporizer or the
power adapter to rain. Do not use in
the bathroom or above water.
Never touch the Vaporizer or power
adapter with wet or damp parts of the
body.

1312
The amount of aromas and fragrances
released can be inuenced by the fol-
lowing factors:
1. Quality: The amount of aroma or
fragrance contained in the respec-
tive plant material that can be va-
porized.
2. Quantity: The amount of vaporiza-
tion material in the Filling Chamber.
3. Surface: The ner the plant is
ground, the greater the surface and
the more aromas and fragrances
can be released during the vapori-
zation cycle.
4. Temperature: The higher the tem-
peratures, the more aromas and
fragrances will be released at once.
Please note: Increasing the tempera-
ture should be the last resort, because
plant material tastes more roasted
when using higher temperature.
Since the plant ingredients are released
in a gentle manner, the vaporization
cycle may be repeated with the same
contents in the Filling Chamber. De-
pending on the four factors described
above, the Filling Chamber contents
may be reused multiple times until the
aromas and fragrances are released
completely.
If no more vapor is produced at the
highest temperature, then the vapori-
zation material is completely exhaust-
ed and must be replaced with new
material. However, for the best aroma
results it is advisable to replace the
vaporization material before this point.
5. FACTORS INFLUENCING VAPORIZATION
6. THE CRAFTY VAPORIZER
Unpacking
The box contains all components as
well as the Instructions for Use. Keep
the Instructions for Use for future ref-
erence.
Remove the Vaporizer and the acces-
sories from the box. Immediately after
unpacking, check whether the Vaporiz-
er, the accessories, the power adapter
and the device plug are all included in
the delivery and work properly. If you
notice any defects, inform the seller or
the delivery agent immediately.
The packing material (plastic
bags, boxes etc.) must be kept
out of the reach of children as
it is a potential source of danger.
Please dispose of the packing mate-
rial in a proper and environmentally
friendly manner.
We recommend keeping the original
packaging in case it is required later
(transpor t, Storz & Bickel Service Cent-
er etc.).
4. OVERVIEW OF PLANTS
Portion of the Temperature-
Plant name Botanical name plant used setting
Eucalyptus Eucalyptus globulus the leaves 130°C (266°F)
Hops Humulus lupulus the cones 154°C (309°F)
Chamomile Matriarca chamomilla the blossoms 190°C (374°F)
Lavender Lavandula angustifolia the blossoms 130°C (266°F)
Lemon balm Melissa ocinalis the leaves 142°C (288°F)
Sage Salvia ocinalis the leaves 190°C (374°F)
Thyme Thymus vulgaris the herb 190°C (374°F)
Below is an overview of the plants that
are suitable for vaporization in the
CRAFTY Vaporizer.
The aromas and fragrances from the
plant materials listed below may be
vaporized.*
Any other use is inappropriate and po-
tentially dangerous.
It is important to observe the follow-
ing instructions in order to set the
CRAFTY
Vaporizer with the plant material in the
best possible way for your personal re-
quirements.
*This statement has not been evalu-
ated by the FDA. The CRAFTY Vapor-
izer is not a medical device and is not
intended to diagnose, treat, cure or pre-
vent any disease.
WARNING:
Please consult your doctor
or pharmacist if you have any
medical concerns. It is possible that
some plants may cause allergic reac-
tions for the user. If this occurs, it is
urgently recommended to refrain from
further use of such plants.
Only use the plant parts which are
found in this list and which have been
veried according to the regulations
of the European or any other pharma-
copoeia with regard to genuineness,
purity and pathogenic germs. You can
purchase such plants or plant parts in
pharmacies.*

1514
If the preceding tips do not
yield the desired results, or for
any other defects or problems
not mentioned here, please unplug the
power adapter and contact our Service
Center immediately.
Do not open the Vaporizer or
the power adapter! Without
special tools and specialized
knowledge, any attempt to open either
of these devices will cause damage to
them. Such an attempt will invalidate
the warranty claim.
6. THE CRAFTY VAPORIZER
Do not try to remedy the defect your-
self. Contact our Service Center di-
rectly.
Disposal
If the Vaporizer or the power adapter
has been irreparably damaged after
the warranty period, please do not sim-
ply throw them away. As they are made
of high quality, completely recycla-
ble component parts, they should be
brought to a material recycling center
in your town or sent to our Service
Center for disposal.
Possible faults / Troubleshooting
Problem Possible cause/remedy
CRAFTY cannot be
switched on.
Please ensure that the CRAFTY’s battery is
charged.
If the Vaporizer still does not work, then the device is
faulty. In this case, get in touch immediately with our
Service Center.
The LED display of
CRAFTY ashes alter-
nately red/blue.
Battery temperature is either too high or too low.
Allow the hot Vaporizer to cool down or the cold
Vaporizer to warm up.
The LED display of
CRAFTY ashes blue.
Battery is completely discharged. Please connect
the charger.
The LED display of
CRAFTY ashes alter-
nately red/green.
The power adapter or the USB cable is not suitable.
Please use an original Storz & Bickel power adapter
and USB cable or 12 Volt car charger.
The LED display of
CRAFTY ashes alter-
nately red/orange.
The Vaporizer is faulty. In this case, disconnect from
the mains without delay and get in touch immedi-
ately with our Service Center.
6. THE CRAFTY VAPORIZER
Power Connection
Before connecting up the Vaporizer,
make sure that the information given
on the power adapter type label cor-
responds to the local power supply
voltage.
All parts of the electrical system must
comply with currently applicable o-
cial regulations.
Place the heated Vaporizer only on a
hard, stable surface, and not on any
soft or heat-sensitive material.
Take care that the power adapter USB
cable cannot be damaged through
kinking, crushing or pulling.
Improper installation may lead
to personal injury or material
damages, for which the manu-
facturer cannot be held responsible.
Application and Operation
This Vaporizer was developed
for vaporizing the plant materi-
als listed in the plant overview.
Any other use is inappropriate and po-
tentially dangerous.
The user should always follow the in-
structions listed here for use and main-
tenance.
If you have any concerns, or if there are
any problems immediately switch off
the Vaporizer and pull the power adapt-
er cord, if used, from the socket. Do not
try to remedy the defect yourself. Con-
tact our Service Center directly.
After using the Vaporizer and power
adapter, allow them to cool down be-
fore placing them in storage.
Storage
Store the Vaporizer and the power
adapter in a dry place protected
against the effects of weather and out
of the reach of children or unqualied
persons.
In Case of Problems
If the power adapter has been in use,
unplug it at the socket and ensure that
no one can connect the Vaporizer to
the mains supply again without this
being noticed.
Before any maintenance work is done,
the Vaporizer has to be switched off
and the power adapter unplugged
from the power supply.
Put the Vaporizer in the original pack-
aging, or pack it properly in other pack-
ing material, and send it to our Service
Center.

1716
7. COMMISSIONING AND OPERATION
Connecting the Vaporizer using the power
adapter or 12 volt Car Charger
Once the charging operation is com-
plete, rst disconnect the power adapt-
er from the mains socket and then un-
plug from the Vaporizer.
The CRAFTY cannot be oper-
ated while plugged in. It can
only be turned on again if it has
been partially charged beforehand.
The battery can also be
charged via the optional 12
volt Car Charger. Connect the
12 volt Car Charger to the power sock-
et of the Vaporizer using the USB cable
and then plug the Car Charger into the
socket in the car for the cigarette light-
er, or any other suitable 12 V socket.
Charge and complete the operation in
the same way as with the power adapt-
er (see Chapter 7.1. “Charging the Bat-
tery”, page 16).
Batteries are specially assem-
bled consumable items that
can only be replaced by Storz
& Bickel when the CRAFTY Vaporizer
is sent in to them.
Any attempt by the customer to re-
place the battery by him/herself is po-
tentially dangerous and leads to loss of
any claims under the warranty and ex-
empts Storz & Bickel from any liability.
Automatic Switching Off
The automatic switching off is used to
save battery capacity so that the Va-
porizer can be used as long as possible
without charging.
The device switches off automatically
one minute after the last press of a but-
ton or the last application. The switch-
ing off of the Vaporizer is indicated by
a short vibration and by displaying the
charged state.
A short press of the ON/OFF
switch during operation can
reset the automatic switching-
off to one minute.
7. COMMISSIONING AND OPERATION
Do not leave the device unat-
tended during operation.
Place the CRAFTY Vaporizer
only on a hard, heat-resistant, at, sta-
ble surface, never on soft surfaces or
ammable material. Check whether
the power supply voltage corresponds
to the voltage rating listed on the pow-
er adapter. The power adapter and USB
cable must be in perfect condition.
Connect the power adapter only to a
properly installed socket.
The manufacturer will not bear any
responsibility whatsoever if this acci-
dent prevention measure is not taken.
Please unplug the power adapter from
the mains socket to completely discon-
nect from the mains power supply.
7.1. Charging the Battery
The battery charge status is signaled
by the blue light on the LED display.
Explanations on the battery display
during the charging operation:
Steady blue light:
the battery is fully charged.
Blue, slow-ashing light: the battery
is between 61 and 96% charged
Blue, rapidly ashing light: the battery
is between 31 and 60% charged
Blue ashing: the battery is up to 30%
charged
Explanations of the battery display fol-
lowing switch off:
Steady blue light: the battery is
between 64 and 100% charged
Blue, slow-ashing: the battery is
between 32 and 64% charged
Blue, rapidly ashing: the battery is
between 1 and 32% charged
Blue ashing: battery is completely
discharged
Check the housings of the Va-
porizer and the power adapter
for signs of damage each time
before using or charging. The Vaporiz-
er may not be charged and neither Va-
porizer nor power adapter used if these
are damaged.
The battery charge of the new product
has a level of up to 80%. Fully charge
before using for the rst time.
The charging time for the battery de-
pends on how old it is and how high
the charge is on starting; it takes about
two hours if the battery is completely
discharged.
Connect the USB cable to the charg-
ing socket of the Vaporizer and to the
power adapter. Then plug the power
adapter into a suitable power socket.
Note: When the power adapter is
plugged into the mains, the LED dis-
play lights up in green/red/blue for a
moment and the Vaporizer vibrates
briey. This serves as a functional
check and indicates that the charging
operation has started.
The LED lights up and starts to ash,
i.e. the battery is being charged. As
soon as the battery is fully charged,
the charge indicator lamp stops ash-
ing and shows a steady blue light.

1918
Turn the Cooling Unit with a 90° rota-
tion counterclockwise in order to re-
move it from the Vaporizer.
Always ll the Filling Chamber com-
pletely up to the plastic rim with ground
plant material. Do not compress the
Removal of Cooling Unit (with Mouthpiece)
Filling Chamber properly lled
Filling Chamber partially lled, with Liquid
Pad placed on top
plant material too much so that the
airow is not unnecessarily impeded.
Remove any excess plant material left
around the lling aperture so that it is
clean and allows the Cooling Unit to be
tted.
If the Filling Chamber is only
partially lled, then the vapori-
zation material may shift
around; the hot air then bypasses the
vaporization material, so that no va-
porization can occur.
If the Filling Chamber is not to be lled
completely, it is recommended to
place the included Liquid Pad over the
herbs, and then mount the Cooling Unit
on the Vaporizer.
8. FILLING THE FILLING CHAMBER7. COMMISSIONING AND OPERATION
7.2. Heating Up
The CRAFTY Vaporizer provides two
temperature levels that are set in the
factory: The basic temperature at
180°C (356°F) and the booster tem-
perature at 195°C (383°F).
Both the basic and booster
temperatures can be altered
using a smartphone and the
CRAFTY App (see Chapter 11.4. “Set-
ting Temperature with the CRAFTY
App”, page 29).
Switch on the device (heating up the
Vaporizer with full Filling Chamber and
Cooling Unit mounted is recommend-
ed). To do this, press the orange ON/
OFF switch for at least half a second.
The Vaporizer responds with a short
vibration. The vibration does not take
place if there is a fault.
The LED display indicates the heating
operation up to the basic temperature
by a steady red light. Heating up the
heat exchanger can take up to two min-
utes, depending on the temperature
setting and battery charge level. Once
the basic temperature is reached, this
is signaled by a short double vibration
and a steady green light.
If the basic temperature can no longer
provide adequate evaporation, the
booster temperature can be activated
by means of a double-click on the
orange-colored ON/OFF switch. The
LED displays the heating-up operation
for the booster temperature by a red
ashing signal. Once the booster tem-
perature is reached, this is signaled by
a short double vibration and a green
ashing signal.
7.3. Temperature Setting
The levels for the basic and booster
temperatures can be altered with the
aid of a smartphone and the CRAFTY
App. See Chapter 11. “CRAFTY App”,
page 27.
7.4. Reset to Default Settings
It is possible to reset settings (see
Chaper 11.1. “Default Settings”, page
27) which were changed using the
CRAFTY App. The reset is made by
pressing the ON/OFF button for ten
seconds while the CRAFTY Vaporizer
is switched on.
If the ON/OFF button has been
pressed for ten seconds, the signaling
of the reset is made by the following
running lights sequence: red/green/
blue/red/green/blue/red/green/blue.
The CRAFTY Vaporizer also vibrates
while the lights sequence is running.

2120
8.2. Filling the Filling Chamber using
the Filling Aid
Remove the Cooling Unit from the Va-
porizer and remove any residues that
may be in the Filling Chamber. The
Filling Chamber Tool can be a help in
doing this.
Remove the lower cap of the Filling Aid
by turning counterclockwise. Place the
Filling Aid on the Vaporizer and attach
by turning it clockwise. Remove the
upper cap from the Filling Aid. Pull the
plug and use it to ll a portion of plant
material through the central opening
into the Filling Chamber.
Make sure that the Filling
Chamber is not overlled (see
Chapter 8. “Filling the Filling
Chamber”, page 19).
Fill the Filling Aid to the lower rim (see
the two following drawings)!
Overlling leads to clogging of the
Screens and can make inhaling more
dicult.
Then re-insert the plug into the central
opening and screw on the upper cap of
the Filling Aid. Unscrew the Filling Aid
with a 90° rotation and screw on the
lower cap again. Then re-mount the
Cooling Unit by rotating it clockwise
through 90°.
Filling the Filling Chamber with the Filling Aid
The lower rim of the Filling Aid must be
above the top level of the plant material
8. FILLING THE FILLING CHAMBER
Take care that the Screens are
not obstructed with plant ma-
terial. To guarantee optimal
results, we recommend cleaning the
Screens after each vaporization cycle
with the enclosed Cleaning Brush.
The upper Screen especially can be-
come clogged with plant material and
so make inhaling dicult. In this case,
remove the Screen as in Chapter 10.
“Disassembling, Cleaning and Assem-
bling”, page 23 and clean or insert a
new Screen.
Then re-mount the Cooling Unit by ro-
tating it clockwise through 90°.
As soon as the lower Filling Chamber
Screen is clogged or shows depos-
its, a cleaning of the Filling Chamber
is needed. For that, please rstly re-
move the lower Screen as described
in Chapter 10.3. “Removal of the lower
Filling Chamber Screen”, page 26
and clean the Filling Chamber with
a cotton stick that has been soaked
in alcohol. Please make sure that no
alcohol drops into the inner of the de-
vice. After cleaning, a new screen is to
be inserted.
8.1. Filling Aid
The Filling Aid supplied with the unit
makes lling the Filling Chamber an
easy and clean operation and serves
as a magazine for transporting and
storing plant material already ground
in the Herb Mill.
To ll the Filling Aid, remove the up-
per cap and ll the bowl incl. plug with
ground plant material. Replace the up-
per cap and close it.
Filled Filling Aid (upper cap removed)
Upper
Cap
Plug
Lower
Cap
Bowl
8. FILLING THE FILLING CHAMBER

Cap Lock
Mouthpiece
Cooling Unit Cap
Base Seal Ring
(small)
Base Seal Ring
(large)
Upper Screen
(coarse mesh width)
Cooling Unit Base
Mouthpiece Seal Ring
2322
When the vapors are cooled, it is in-
evitable that a small fraction is con-
densed on the internal surfaces of the
Cooling Unit.
The component parts of the Cooling
Unit, including the Mouthpiece must
be thoroughly cleaned on a regular ba-
sis to guarantee proper operation and
pure avor.
For hygienic reasons, it is also neces-
sary to clean these components when
the Vaporizer is to be used by a differ-
ent person.
The condensate can be sticky.
The Cooling Unit can be dis-
mantled more easily when it
rst warmed up.
Product Overview of the CRAFTY Cooling Unit
The Cooling Unit consists of:
10. DISASSEMBLING, CLEANING AND ASSEMBLING9. APPLICATION
Using the CRAFTY Vaporizer
Mount the Cooling Unit on the Vaporiz-
er and heat up. This ensures that both
the Filling Chamber and the material
to be vaporized are preheated and the
vaporizing can begin as soon as the
heating process is completed.
Caution! Hot surface!
After using the CRAFTY Va-
porizer, do not touch the Fill-
ing Chamber until it has cooled down
again.
Once the Vaporizer has reached the set
temperature (steady green light for the
basic temperature and ashing green
for the booster temperature, each also
accompanied by a short double vibra-
tion) and the Mouthpiece is folded out,
then the inhaling process may begin.
Take the Mouthpiece between the lips,
and inhale slowly and evenly for sev-
eral seconds.
Please note the following about va-
por generation: the more intense the
vapors, the greater the impairment of
the flavor.
A very high intensity (or densi-
ty) of the vapor can lead to irri-
tation of the respiratory pas-
sages from the concentration of the
aromas and fragrances.
In this case, the temperature should
be lowered, so that the intensity of
the vapors is reduced (see Chapter
11.4. “Setting Temperature with the
CRAFTY App”, page 29).
The device is not to be used, if
the user has respiratory tract
or lung conditions. Depending
on the density, the vapor could irritate
respiratory tracts or lungs, which can
lead to coughing.
Inhale only half the amount of
air you can normally manage.
Hold your breath for a few sec-
onds and exhale slowly. It is advisable
to deliberately concentrate on your
breathing process.
After vaporization, turn off the
CRAFTY Vaporizer. To do this, press
the orange ON/OFF switch for at least
half a second. The Vaporizer acknowl-
edges the switching off with a short
vibration.
Allow the Vaporizer to cool down be-
fore it is packed away.

2524
Removal of the large base Seal Ring
Pressing out the upper Screen
Remove the large and small base Seal
Rings. Lever out the large Seal Ring
from the recess in the notch using the
Filling Chamber Tool.
Reassemble in reverse order.
When assembling, make sure
that Seal Rings are properly
seated. The Mouthpiece Seal
Ring, especially, must sit completely in
the Cap and be no longer visible.
The upper Screen must be inserted
carefully into the groove provided. Dis-
regarding this may allow plant parti-
cles to enter the Cooling Unit, so block-
ing this or be inhaled.
Push the upper Screen downwards out
of the Filling Chamber Cap from above
by using the Filling Chamber Tool sup-
plied.
10. DISASSEMBLING, CLEANING AND ASSEMBLING
Pull the Cooling Unit
Cap from the Cooling Unit Base
10.1. Disassembling and Reassem-
bling the CRAFTY Cooling Unit
Turn the Cooling Unit with a 90° rota-
tion counterclockwise in order to re-
move it from the Vaporizer.
Pull out the Mouthpiece from the Cool-
ing Unit Cap, rotate slightly back and
forth while doing this, and pull off the
Mouthpiece Seal Ring.
Pulling the Mouthpiece from the Cooling Unit
Cap
Removal of the Cap Lock
Opening the Cap Lock
Open the Cap Lock by pulling it rear-
wards.
Remove the Cap Lock from the Cap by
pulling up at one side.
If the Cooling Unit must be im-
mersed into alcohol (ethanol)
the Cap Lock only has to be
removed from the Cooling Unit. Ex-
tended contact with alcohol can lead
to whitening of the Cap Lock Label or
disintegration of the glue.
Separate the Cooling Unit Cap from
the Cooling Unit Base by pulling off the
cap upwards.
10. DISASSEMBLING, CLEANING AND ASSEMBLING

2726
11. CRAFTY APP
General
The CRAFTY App is not necessary
for operating the CRAFTY Vaporizer,
does however allow individual settings
to be made and allows the readout
of additional information when the
CRAFTY Vaporizer is in operation.
As the CRAFTY Vaporizer has too little
space for a display, the Vaporizer can
be connected to an iPhone or Android
smartphone via Bluetooth and the
smartphone’s display used.
Minimum requirement for this is iOS6
for the iPhone or Android 4.3.
The CRAFTY App can be downloaded
from the App Store or Google Play
Store.
11.1. Default settings
Basic temperature: 180°C (356°F)
Booster temperature:
additional 15°C (27°F)
so corresponding to 195°C (383°F)
LED indicator
brightness CRAFTY: 100%
Charge Indicator Lamp CRAFTY: ON
Vibration CRAFTY: ON
Vibration smartphone: OFF
Smartphone alarm tone: OFF
11.2. Connecting the CRAFTY Va-
porizer with a Smartphone
Switch on the smartphone and down-
load the CRAFTY App. Ensure that
the Bluetooth function is switched
on and this is not blocked by another
Bluetooth device. Then switch on the
CRAFTY Vaporizer and, after that, the
CRAFTY App.
You will now be requested to enter
the serial number (= alphanumeric
sequence of six numbers printed on
the bottom label of the device) of your
CRAFTY Vaporizer.
It is sucient to enter the serial num-
ber once. Calling the CRAFTY App au-
tomatically connects the two devices.
If another CRAFTY Vaporizer is to be
controlled by the same smartphone,
the previous connection is to be dis-
connected by use of the “Disconnect“
button and the serial number of the
other CRAFTY Vaporizer entered.
Manual cleaning of the disassembled Cooling
Unit
Do not immerse any plastic
components for longer than
an hour in alcohol or ethanol.
Extended contact with alcohol or etha-
nol can lead to discoloration or embrit-
tlement of plastic parts.
Before assembling allow all compo-
nent parts to dry properly.
After cleaning, check all component
parts for surface damage, tears, sof-
tening or hardening, impurities, distor-
tion and discoloration and set dam-
aged component parts aside.
Warning! Alcohol (ethanol) is
ammable and may easily ig-
nite.
Sets of new Cooling Units may
be ordered from www.storz-
bickel.com.
10.3. Removal of the Lower Filling
Chamber Screen
Remove the lower Filling Chamber
Screen using the Filling Chamber
Tool by pushing in along the indenta-
tion of the Filling Chamber. In this way
the Screen arches and detaches itself
from the notch.
Insert a new Screen while taking care
that the edges of the Screen seat into
the groove at the bottom of the Filling
Chamber.
10.2. Cleaning the CRAFTY
Cooling Unit
The Cooling Unit can be disassem-
bled for cleaning purposes and then
assembled again (see Chapter 10.1.
“Disassembling and Reassembling the
CRAFTY Cooling Unit”, page 24).
The Cleaning Brush, cotton swabs and
paper or cotton towels may be used for
cleaning. As solvent, we recommend
alcohol (ethanol) or warm water with
wash-up liquid.
For optimal airow, please ensure the
Cooling Unit and Mouthpiece are clean
and free from debris blockage.
10. DISASSEMBLING, CLEANING AND ASSEMBLING

BOOSTER TEMPERATURE
TEMPERATURE
Temperature Settings InformationCRAFTY
Disconnect
Vibration
Vibration
Alarmtones
Charge Indicator
Bluetooth permanently on
180
Smartphone
LED Brightness
Automatic Shutoff in seconds
SETTINGS
Temperature Settings InformationCRAFTY
Temperature Settings InformationCRAFTY
Minus
temperature
button
Plus
temperature
button
Actual
temperature
Set
temperature
Charge
indicator lamp
Booster
temperature
display
2928
11. CRAFTY APP
When you press the plus button, the
set value is increased, and when you
press the minus button, the set value
is decreased. When you briey tap
on the plus or minus button, the set
values are increased or decreased
respectively in 1-degree increments.
11.4. Setting Temperature with the CRAFTY App
The temperature can be set between 40°C and 210°C (104°F and 410°F) (see
Chapter 4. “Overview of Plants”, page 12).
If you keep the plus or minus button
pressed, the set values start running
continuously in the corresponding di-
rection.
The current actual temperature can be
read from the upper line of the display.
Functional elements Menu item Temperature
11. CRAFTY APP
Making the connection
11.3. The Menu Items of the CRAF-
TY App
Temperature:
Here you can read off the set and ac-
tual temperatures and carry out the
temperature settings. You will also nd
here the charge indicator lamp of the
CRAFTY Vaporizer.
Settings:
You can also make further individual
settings here.
Device:
Here you nd the device-related infor-
mation, such as operating hours, soft-
ware versions etc.
Information:
Here you nd further information such
as lists of plants and prices, but also di-
rect links to the Storz & Bickel website
or to the online shop.
Enter the serial number of your
CRAFTY.
Connect to a known CRAFTY.
Cancel
CY
CY000010
------
CY040521

Disconnect
Reset Settings
Vibration
Vibration
Alarmtones
Charge Indicator
Smartphone
CRAFTY
LED Brightness
SETTINGS
Temperature Settings InformationCRAFTY
3130
Vibration Smartphone:
Here, in addition to the vibration of the
CRAFTY Vaporizer, the vibration of the
smartphone can also be switched on
and off here.
Smartphone Alarm Tone:
Any alarm tone of the smartphone can
also be switched on and off here in par-
allel with the vibration of the CRAFTY
Vaporizer.
11.6. Menu Items for Device and
Information
Device:
Here you nd device-related informa-
tion, such as operating hours, soft-
ware versions etc.
Information:
Here you nd further information such
as lists of plants and prices, but also di-
rect links to the Storz & Bickel website
or to the online shop.
the charging, the LED indication lights
up for a moment on red/green/blue
and the Vaporizer vibrates briey. This
serves as a functional check and indi-
cates that the charging operation has
started.
Vibration CRAFTY:
The vibration motor of the CRAFTY
Vaporizer can be switched on and off
here.
Reset to Default Settings:
The default settings (see Chapter 11.1.
“Default Settings”, page 27) can be
restored here.
The following settings / values are re-
stored to the default settings:
Set temperature
Booster temperature
LED brightness
Charge Indicator Lamp
Vibration CRAFTY
Vibration smartphone
Smartphone alarm tone
Connect to other CRAFTY:
If another CRAFTY Vaporizer is to be
controlled by the same smartphone,
the previous connection can be dis-
connected so that the serial number
of the other CRAFTY Vaporizer can be
entered.
11. CRAFTY APP11. CRAFTY APP
11.5. Further individual settingsThe booster temperature is always
added to the basic temperature. But
the total cannot exceed 210°C (410°F).
Fahrenheit/Celsius
If you simultaneously tap on the plus
button and the minus button, the dis-
play changes from degree Celsius to
degree Fahrenheit and vice versa.
Charge Indicator Lamp
The charge indicator lamp shows a
battery symbol with six elds indicat-
ing the charging status. If the battery is
almost discharged, the battery frame
to ash; if fully charged, the frame and
all six elds are visible.
The number of status elds visible
depends on the extent of the battery
charge.
During the charging of the CRAFTY
Vaporizer, the charge indicator lamp
ashes and shows the current level of
charging.
Settings
Charge Indicator Lamp
LED Brightness CRAFTY:
The brightness of the LED indica-
tor on the CRAFTY Vaporizer can be
dimmed using the slider control.
Charge Indicator Lamp CRAFTY:
Here, the blue lights of the LED indi-
cator can be switched on and off dur-
ing the charging operation. When the
power adapter is plugged in to start

3332
12. ACCESSORIES
Attaching the Magazine Cap
After ling the Dosing Capsules, attach
the Magazine Cap and close it by turn-
ing it clockwise.
Filling the Dosing Capsules with
aromatic Oils
The Dosing Capsules with inserted
Liquid Pad, which are available as ac-
cessories, can be lled with aromatic
oils and store them in the Magazine.
Dosing Capsule with removed cap and
inserted Liquid Pad
Please make sure to not over-
ll the Liquid Pad. It can con-
tain up to 5 drops.
Attach the cap onto the Dosing Cap-
sule. Repeat the lling process until the
desired amount of Dosing Capsules is
lled and insert them into the Maga-
zine. The Magazine can hold up to 8
Dosing Capsules.
Attaching the Magazine Cap
After ling the Dosing Capsules, attach
the Magazine Cap and close it by turn-
ing it clockwise.
12. ACCESSORIES
12.1. Dosing Capsules and Magazine
Dosing Capsules with Magazine
With the Dosing Capsules, which are
available as accessories, you can ll
ground plant material or aromatic oils
using the Liquid Pads into the Dosing
Capsules in advance and store them
in the Magazine. This facilitates the
handling.
Filling the Dosing Capsules with
ground Plant Material
The plant material has to be ground
with the included Herb Mill rst.
The Dosing Capsules can be lled with
ground plant material per Capsule and
be stored in the Magazine as a reserve.
Dosing Capsule with removed cap
Grind the plant material and ll the
Dosing Capsule by using the Magazine
Cap (funnel).
Dosing Capsule while being lled with
Magazine Cap (funnel)
Attach the cap onto the Dosing Cap-
sule. Repeat the lling process until the
desired amount of Dosing Capsules is
lled and insert them into the Maga-
zine. The Magazine can hold up to 8
Dosing Capsules.

3534
12.2. Disposable Lip Piece for
Hygienic Use
The Lip Piece, which is available as an
accessory, will be delivered brand new
and in a low-germ, but not fully-sterile
state.
The Lip Piece is equipped with
a check valve. This check
valve reduces the danger of a
potential contamination inside the
Cooling Unit by preventing breathing
into the Cooling Unit.
Cooling Unit with Mouthpiece and Lip Piece
The Lip Piece is put on the folded out
Mouthpiece, slid until stop and is then
ready for operation.
The Cooling Unit with Mouthpiece and
the Lip Piece may be used by only one
person.
A Lip Piece may be used for max. 4
hours after initial operation if it is un-
damaged and clean. Afterwards, it
must be disposed of in the household
waste and a new Lip Piece must be
used due to hygienic reasons.
Every further use beyond this or the
use of damaged and/or contaminated
products respectively is the user‘s re-
sponsibility.
We assume no liability if this recom-
mendation is ignored.
Please note that damaged or
brittle Lip Pieces are not to be
used.
12. ACCESSORIES
Inserting the Dosing Capsules
Turn the Cooling Unit with a 90° rota-
tion counterclockwise in order to re-
move it from the CRAFTY Vaporizer.
Removal of Cooling Unit (with Mouthpiece)
The inserted Dosing Capsule
Insert the Dosing Capsule into the
Filling Chamber of the CRAFTY Va-
porizer.
Then re-mount the Cooling Unit by ro-
tating it clockwise through 90°.
The Filling Chamber of the CRAFTY
can be lled directly as well (without a
Dosing Capsule), see Chapter 8. “Fill-
ing the Filling Chamber”, page 19.
As soon as the lower Filling Chamber
Screen is clogged or shows deposits,
a cleaning of the Filling Chamber is
needed. For that, please rstly remove
the lower Screen as described in Chap-
ter 10.3. “Removal of the lower Filling
Chamber Screen”, page 26 and
clean the Filling Chamber with a cotton
stick that has been soaked in alcohol.
Please make sure that no alcohol
drops into the inner of the device. Af-
ter cleaning, a new Screen is to be in-
serted.
12. ACCESSORIES

3736
Warranty
Storz & Bickel GmbH & Co. KG and
Storz & Bickel America Inc. as seller
hereby guarantee the customer that
the product will be free from defects
in accordance with the specications
of German law, and pursuant to our
General Terms and Conditions (GTC),
upon which the purchasing agreement
are based. Of course, Storz & Bickel
will only be subject to a warranty ob-
ligation if the customer has purchased
the products directly from us. If prod-
ucts are purchased from third parties,
warranty claims may only be asserted
against these third parties, and Storz &
Bickel cannot provide any information
on the content of such claims.
In clarication, we would like to note
once again here that the warranty ex-
tends only to correcting such initial
defects that exist despite proper han-
dling of the product in consideration
of this Instructions for Use and further
information provided to users. Normal
wear or tear to the products is not con-
sidered a defect under warranty law. If
the customer has commissioned third
parties with completing maintenance
or repair of the product, or if the cus-
tomer uses external products, Storz &
Bickel’s warranty obligations will only
exist if the customer can prove that the
defect was not caused by use of the ex-
ternal service or external product.
Storz & Bickel will decide at its own
discretion whether to correct a defect
covered to warranty law through repair
or by delivering a new product to the
customer.
Any warranty claims must be directed
to Storz & Bickel GmbH, In Grubenäck-
er 5-9, 78532 Tuttlingen. American
and Canadian customers should di-
rect warranty claims to Storz & Bickel
America Inc., 1078 60th Street, Suite
A, Oakland, CA 94608. Please send the
complete defective item to us, not dis-
assembled, with invoice. Please use
external packaging that would prevent
any damage during transportation.
In order to avoid misunderstandings,
we would like to note that all informa-
tion on our products provided in this
Instructions for Use or elsewhere
does not represent any guarantee of
features or durability, unless we have
expressly referred to a guarantee for
such features or durability.
Liability
Storz & Bickel shall be liable for any
damages caused to the customer by
our products in accordance with Ger-
man law and pursuant to our GTC. Un-
der said provisions, we are only liable
for damages caused by intentional
action or gross negligence, unless
such damages involve death, personal
injury, or injury to health, or if the in-
jury is related to a cardinal contractual
obligation. In such cases, we will also
be liable to the customer for simple
negligence.
15. WARRANTY, LIABILITY
Power adapter:
Power consumption: 10 W
Supply voltage: 100-240 V / 50-60 Hz
Output voltage: 5 V DC
CRAFTY Vaporizer:
Supply voltage: 5 V DC
The voltage details are located on the respective type labels of the CRAFTY
Vaporizer and power adapter.
Power required by CRAFTY Vaporizer: 10 W max.
Operating temperature: 5°C - 40°C / 41°F - 104°F
Vaporization temperature:
adjustable between approx. 40°C - 210°C / 104°F - 410°F
Size:11.0 x 5.7 x 3.3 cm (4.3 x 2.2 x 1.3 inch)
Weight:approx. 135 g, (0.3 lb)
Please unplug the power adapter from the mains socket to completely disconnect
from the mains power supply.
Subject to technical changes.
Patents and designs: www.storz-bickel.com/patents
Manufacturer :
Storz & Bickel GmbH & Co. KG
In Grubenäcker 5-9
78532 Tuttlingen, Germany
13. TECHNICAL SPECIFICATIONS
The devices comply with the following EC Directives:
DIN EN 60 335
DIN EN 60 950
Electromagnetic Compatibility 2004/108/EG
14. CE DECLARATION OF CONFORMITY

38
15. WARRANTY, LIABILITY
Copyright
This document is copyright protected,
and may not be used either in whole or
in part pursuant to Sections 15 et seqq.
UrhG (German Copyright Act) without
prior written approval of Storz & Bickel.
