Storz & Bickel GMBH Plenty User manual

INSTRUCTIONS FOR USE
Read carefully before using the device
and save these instructions.
STORZ & BICKEL GMBH & C O. K G

3
Table of Contents ................................................. Page
1. Product Overview, Service ............................................4
2. Explanation of Symbols, Safety Recommendations.....6
3. Intended Use ................................................................10
4. Overview of Plants....................................................... 11
5. Factors Influencing Vaporization .................................12
6. The Hot Air Generator P LENTY ...................................12
7. Commissioning and Operation....................................14
7.1. Heating Up..........................................................15
7.2 . Temperature Setting...........................................16
8. Filling the Filling Chamber ...........................................18
9. Application....................................................................23
10. Disassembling, Cleaning and Assembling..................25
10.1. Disassembling and Reassembling
the PLENTY Vaporization Unit ........................25
10.2. Disassembling the Mouthpiece.......................26
10.3. Disassembling the Filling Chamber Cap.........27
10.3.1. Cleaning the Cooling Coil ..................27
10.4. Disassembling the Filling Chamber ................28
10.5. Assembling the Filling Chamber .....................28
11. Technical Specifications ..............................................29
12. CE Declaration of Conformity ......................................29
13. Warranty, Liability, Repair Service ..............................30
INSTRUCTIONS FOR USE

54
1. PRODUCT OVERVIEW PLENTY VAPORIZATION UNIT1. PRODUCT OVERVIEW PLENTY HOT AIR GENERATOR
Mouthpiece
Thermometer
Filling Chamber Threading
Vaporization Unit, comprising:
Auto off Release Handle
Power Switch
Temperature Adjustment Wheel
Ventilation Slots
Control Lamp
Cooling Coil
Filling Chamber Cap
Filling Chamber

76
Safety tested and production monitored by TUEV SUED Germany
Caution! Hot surfaces!
Do not touch metal parts!
Keep away from sunlight.
Protect against moisture and humidity.
Explanation of Symbols
Please follow these instructions carefully!
Safety recommendations!
In order to avoid injuries to persons and damage to the equipment,
it is mandatory to observe instructions marked with this symbol.
Note/Tip!
This symbol always gives you technical information or useful tips
regarding the Vaporizer.
EU conformity symbol:
The manufacturer confirms with this symbol the compliance of the
product with the applicable European directives and standards.
Nationally Recognized Testing Laboratory:
additional requirements of UL 499 and CAN/CSA-C22.2 No. 64
have been tested on the basis of EN 60335-1.
The device was introduced after 13 August 2005. It may not be
disposed of in normal household waste. The X on the trash can
indicates the necessity of disposing of this product separately.
2. SAFETY RECOMMENDATIONS 2. SAFETY RECOMMENDATIONS
Read the following safety
recommendations thor-
oughly and carefully before
using the device.
These Instructions for Use are a
significant part of the Vaporizer
and must be provided to the user.
The instructions given in these In-
structions for Use must be strictly
observed as they are extremely
important to ensure safety during
installation, use and maintenance
of the Vaporizer.
Please keep this brochure in a safe
place for future reference.
You may download the current In-
structions for Use for the PLENTY
on www.storz-bickel.com.
Please check whether all components have been included. If not, please
inform the Storz & Bickel Service Center.
In case of technical problems, questions about the device, repairs, war-
ranty claims and disposal of the device, customers in the US and Canada
should contact the following address:
Storz & Bickel America, Inc.
1078 60th Street, Suite A • Oakland, CA 94608
All other customers should contact the following address:
Storz & Bickel GmbH & Co. KG
In Grubenäcker 5-9 • 78532 Tuttlingen, Germany

98
2. SAFETY RECOMMENDATIONS 2. SAFETY RECOMMENDATIONS
children or unqualified persons. It
must not be installed in damp lo-
cations (such as bathrooms, etc.).
�Do not operate the Hot Air Gen-
erator close to flammable objects
such as curtains, tablecloths, or
paper.
�Keep the Hot Air Generator away
from from pets (e.g. hamsters,
mice) and other animals which
could damage the insulation of the
power cord.
�The Hot Air Generator may only
be repaired by our Service Cent-
er. Incorrectly performed repairs
without the use of original spare
parts can prove dangerous to the
user.
�Danger to life when opening the
Hot Air Generator as live com-
ponents and connections are ex-
posed.
�The Hot Air Generator must never
be repaired or transported when
the power plug is plugged in.
�To pull the power plug from the
socket, pull the power plug direct-
ly, never pull the power cord.
�The Hot Air Generator must never
be operated when the power cord
is faulty.
�Do not put any objects into the
openings of the device.
�Do not leave the Vaporizer unat-
tended while it is being operated.
After use, switch off the heater.
�The ventilation slots and the hot
air outlet of the Hot Air Generator
may not be closed, obstructed, or
blocked while the device is being
used, nor while it is cooling down.
Caution! Hot surfaces!
�When they are hot, do not touch
the exposed heat exchanger within
the Filling Chamber Threading nor
the metal Filling Chamber Cylin-
der.
�Before cleaning, remove the power
plug from the socket. The Hot Air
Generator should be cleaned only
with a dry cloth - or a damp cloth
if absolutely necessary. Never im-
merse the Hot Air Generator in wa-
ter or any other liquid, nor clean it
with direct jets of water or steam.
�The Hot Air Generator must not be
used in damp or wet conditions.
�Do not expose the Hot Air Genera-
tor to rain. Do not use in the bath-
room or above water.
�Never touch the Hot Air Generator
with wet or damp parts of the body.
�Never operate the Hot Air Genera-
tor when it is wet or damp. If the
Hot Air Generator gets wet, it must
be checked by our Service Center
for damage to electrical compo-
nents.
�Do not use in an atmosphere with
risk of explosion or ignition.
�Never allow the Vaporizer to be
used by children or unqualified
persons.
cident prevention measure is not
taken.
�The power cord must be unwound
over its entire length (avoid roll-
ing up and overlapping the power
cord). It must not be exposed to
any impacts and be kept out of the
reach of children. Also, it must not
be kept near liquids or sources of
heat and must not be damaged.
Do not wind the power cord tight-
ly, nor pull it over sharp edges and
never crush or kink it. If the power
cord is damaged, please contact
our Service Center to have it re-
placed. Never try to repair a power
cord yourself!
�The use of multiple sockets and/
or extension cables is not recom-
mended. However, if this is abso-
lutely necessary, only products
with a quality certificate (such as
UL, IMQ, VDE, +S etc.) may be
used, provided the specified pow-
er exceeds the power required
(A=Ampere) by the devices that
are connected.
�After use, the Hot Air Genertor
must be placed on a stable, flat
surface. To be used only at a suf-
ficient distance away from heat
sources (ovens, stoves, fireplac-
es), and in locations where the
ambient temperature cannot drop
below +5°C (+41°F). Store the
Hot Air Generator in a dry place
protected against the effects of
weather and out of the reach of
Safety Recommendations
�The packaging material (plastic
bags, styrofoam material, boxes
etc.) must be kept out of the reach
of children as it is a potential
source of danger.
�People who require assistance
must be supervised constantly
during application. Such persons
often underestimate the hazards
involved (e.g. strangulation with
the power cord), thus resulting in
a risk of injury.
�The device contains small parts
which can block the respiratory
tract and lead to choking. There-
fore, make sure that you always
keep the Hot Air Generator and
accessories out of the reach of
babies and infants.
�Before connecting the Hot Air Ge-
nerator, make sure that the infor-
mation given on the type label on
the back side of the Hot Air Gen-
erator corresponds to the mains
supply at the place of installation.
�If you have any concerns, ask a
specialist to check whether the
electrical system is in accordance
with the local safety regulations.
�If there are any problems during
operation, immediately pull out
the power plug from the socket.
�It is mandatory to electrically
ground the Hot Air Generator. The
manufacturer will not bear any re-
sponsibility whatsoever if this ac-

1110
4. OVERVIEW OF PLANTS
Portion of the Temperature-
Plant name Botanical name plant used setting
Eucalyptus Eucalyptus globulus the leaves 1 / 130°C (266°F)
Hops Humulus lupulus the cones 3 / 154°C (309°F)
Chamomile Matriarca chamomilla the blossoms 6 / 190°C (374°F)
Lavender Lavandula angustifolia the blossoms 1 / 130°C (266°F)
Lemon balm Melissa officinalis the leaves 2 / 142°C (288°F)
Sage Salvia officinalis the leaves 6 / 190°C (374°F)
Thyme Thymus vulgaris the herb 6 / 190°C (374°F)
Below is an overview of the plants that
are suitable for vaporization in the
PLENTY Vaporizer.
The aromas and fragrances from the
plant materials listed below may be
vaporized.*
Any other use is inappropriate and po-
tentially dangerous.
Information and up to date news
about plants suitable for vaporization
will be published on www.storz-bick-
el.com.
2. SAFETY RECOMMENDATIONS
The PLENTY Vaporizer releases fra-
grances or aromas from the herbs
and other plant materials listed below.
These aromatic substances are re-
leased through vaporization by heated
air, and may be directly inhaled.
WARNING:
Please consult your doctor
or pharmacist if you have any
medical concerns. It is possible that
some plants may cause allergic reac-
tions for the user. If this occurs, it is
urgently recommended to refrain from
further use of such plants.
best possible way for your personal re-
quirements.
The PLENTY Vaporizer is not a medical
device and is not intended to diagnose,
treat, cure or prevent any disease.
*This statement has not been evalu-
ated by the FDA. The PLENTY Vapor-
izer is not a medical device and is not
intended to diagnose, treat, cure or
prevent any disease.
The device may only be used with the
recommended vaporizing media. The
use of other substances can present
a health risk.
The PLENTY Vaporizer is not intended
for medical/therapeutic purposes.
Only use the plant parts which are
found in this list and which have been
verified according to the regulations
of the European or any other pharma-
copoeia with regard to genuineness,
purity and pathogenic germs. You can
purchase such plants or plant parts in
pharmacies.*
It is important to observe the following
instructions in order to set the PLENTY
Vaporizer with the plant material in the
3. INTENDED USE
The heat exchanger inside
the Filling Chamber Thread-
ing and the Filling Chamber
Cylinder are made of metal and be-
come hot during operation. Do not
touch them when they are hot!
Caution! Hot surface!
The manufacturer is not re-
sponsible for any damage
or personal injury caused
by inappropriate, incorrect or irre-
sponsible use.
�Only use original Storz & Bickel ac-
cessories and spare parts.

1312
6. THE HOT AIR GENERATOR PLENTY
Unpacking
The box contains all components as
well as the Instructions for Use. Keep
the Instructions for Use for future ref-
erence.
Remove the Hot Air Generator and
the accessories from the box. Imme-
diately after unpacking, check wheth-
er the Hot Air Generator, the acces-
sories, the power cord and the power
plug are all included in the delivery
and work properly. If you notice any
defects, inform the seller or the deliv-
ery agent immediately.
Power Connection
Before connecting up the Hot Air
Generator, make sure that the infor-
mation given on the device‘s type la-
bel corresponds to the local power
supply voltage.
All parts of the electrical system must
comply with currently applicable offi-
cial regulations.
It is mandatory to electrically ground
the Hot Air Generator. The manufac-
turer will not bear any responsibility
whatsoever if this accident preven-
tion measure is not taken.
Place the heated Vaporizer only on a
hard, stable surface, and not on any
soft or heat-sensitive material.
Take care that the power cord cannot
be damaged through kinking, crush-
ing or pulling.
Improper installation may
lead to personal injury or ma-
terial damages, for which the
manufacturer cannot be held respon-
sible.
Application and Operation
This Vaporizer was devel-
oped for vaporizing the plant
materials listed in the plant
overview. Any other use is inappropri-
ate and potentially dangerous.
The user should always follow the in-
structions listed here for use and
maintenance; the device should only
be used in a sitting position.
5. FACTORS INFLUENCING VAPORIZATION
If you have any concerns, or if there
are any problems immediately switch
off the Hot Air Generator and pull out
the power plug from the socket. Do
not try to remedy the defect yourself.
Contact our Service Center directly.
After using the device, allow it to cool
down before placing it in storage.
Storage
Store the Hot Air Generator in a dry
place protected against the effects
of weather and out of the reach of
children or unqualified persons.
In Case of Problems
Immediately unplug the power cord
and ensure that no one can connect
the Hot Air Generator to the mains
supply again without this being no-
ticed.
Before any maintenance work is done,
the device has to be switched off and
the power plug unplugged from the
power supply.
Put the Hot Air Generator in the origi-
nal packaging, or pack it properly in
other packing material, and send it to
our Service Center.
Troubleshooting
Please make sure that the current is
on and that the fuse (in the mains fuse
box) is switched on and is not defec-
tive.
The packing material (plas-
tic bags, styrofoam materi-
al, boxes etc.) must be kept
out of the reach of children as it is a
potential source of danger.
Please dispose of the packing ma-
terial in a proper and environmen-
tally friendly manner.
We recommend keeping the origi-
nal packaging in case it is required
later (transport, Storz & Bickel Ser-
vice Center etc.).
Please note: Increasing the tempera-
ture should be the last resort, because
plant material tastes more roasted
when using higher temperature.
Since the plant ingredients are re-
leased in a gentle manner, the vapori-
zation cycle may be repeated with the
same contents in the Filling Chamber.
Depending on the four factors de-
scribed above, the Filling Chamber
contents may be reused multiple times
until the aromas and fragrances are
released completely.
If no more vapor is produced at the
highest temperature, then the vapori-
zation material is completely exhaust-
ed and must be replaced with new
material. However, for the best aroma
results it is advisable to replace the
vaporization material before this point.
The amount of aromas and fragrances
released can be influenced by the fol-
lowing factors:
1. Quality: The amount of aroma or
fragrance contained in the respec-
tive plant material that can be va-
porized.
2. Quantity: The amount of vaporiza-
tion material in the Filling Cham-
ber.
3. Surface: The finer the plant is
ground, the greater the surface
and the more aromas and fra-
grances can be released during
the vaporization cycle.
4. Temperature: The higher the tem-
peratures, the more aromas and
fragrances will be released at
once.
6. THE HOT AIR GENERATOR PLENTY

1514
Do not leave the device unat-
tended during operation.
Place the PLENTY Vaporizer
only on a hard, heat-resistant, flat, sta-
ble surface, never on soft surfaces or
flammable material. Check whether
the power supply voltage corresponds
to the voltage rating listed on the de-
vice. The power cord and plug must be
in perfect condition. Connect the de-
vice only to a properly installed (elec-
trically grounded) socket.
7.1. Heating Up
Turn the device on with the
orange power switch (it is rec-
ommended to fill and attach
the Filling Chamber and Cooling Coil
before warming up the Hot Air Gener-
ator).
The power switch lights up to show
that the heater is operative. If the auto
off release handle has already been
activated, then the heating process
begins automatically.
Otherwise the heating process must
be started by pressing the orange
auto off release handle.
The heating process is in progress
when the orange control lamp is
lit. The desired temperature may be
set with the temperature adjustment
wheel. Warming up the heat exchang-
er may take up to 4 minutes, depend-
ing on the temperature set.
Press the auto off release handle to activate
the heating process
7. COMMISSIONING AND OPERATION6. THE HOT AIR GENERATOR PLENTY
Vaporization temperature scale
130°C
266°F
142°C
288°F
154°C
310°F
166°C
331°F
178°C
352°C
190°C
374°F
202°C
396°F
7. COMMISSIONING AND OPERATION
If the preceding tips do not
yield the desired results, or
for any other defects or prob-
lems not mentioned here, please un-
plug the power plug and contact our
Service Center immediately.
Do not open the Hot Air Gen-
erator! Without special tools
and specialized knowledge,
any attempt to open the device will
cause damage to it. Such an attempt
will invalidate the warranty claim.
Do not try to remedy the defect your-
self. Contact our Service Center di-
rectly.
Disposal
If the Hot Air Generator is irreparably
damaged, please do not simply throw
it away. As it is made of high qual-
ity, completely recyclable component
parts, it should be brought to a mate-
rial recycling center in your town or
sent to our Service Center for disposal.
The manufacturer will not bear any
responsibility whatsoever if this acci-
dent prevention measure is not taken.
Please unplug from the mains socket
to completely disconnect from the
mains power supply.

1716
7. COMMISSIONING AND OPERATION
The PLENTY Hot Air Genera-
tor is equipped with a temper-
ature safety regulator.
When the auto off release handle is
first activated and the set temperature
is reached, the heating process is ter-
minated and the heater is turned off.
If the auto off release handle is pressed
while the PLENTY is held in the hand
during operation, then the set tempera-
ture level will be automatically retained.
Once the temperature of the heat ex-
changer cools off, an automatic reheat-
ing will not occur; instead the cooling
process continues until the orange
auto off release handle is pressed
again.
As soon as the orange control lamp
turns off, the set temperature has been
reached, and the heat exchanger’s
warming process is complete. Once
the desired preset temperature has
been reached, the vaporization cycle
can begin.
The current temperature can be read
from the thermometer.
If the temperature falls during vapori-
zation, then it is necessary to press the
auto off release handle again to restart
heating.
For technical reasons it is not
possible to measure the tem-
perature in the Filling Cham-
ber during the inhalation process. The
thermometer measures the tempera-
ture of the heat exchanger, and a cor-
responding calibration displays the
respective temperature in the Filling
Chamber during inhalation.
The auto off release handle
may not be fixed in the activa-
tion position (such as by tap-
ing or glueing it down). The manufac-
turer cannot accept any liability
whatsoever for damages caused by
alterations to the device or fixation of
the auto off release handle.
In case you prefer to keep the
PLENTY standing up instead
of laying it on its side, you can
use the Cleaning Brush as a support,
by inserting the wooden handle in the
screwhole next to the rubber foot, as
shown.
Standing up the PLENTY Hot Air Generator
7.2. Temperature Setting
The vaporization temperature may
fluctuate by up to ±3% in comparison
to the stated values because of the
heating and cooling processes in the
heat exchanger.
Select the desired temperature with
the adjustment wheel of the tempera-
ture safety regulator.
Choose temperature
7. COMMISSIONING AND OPERATION

1918
8. FILLING THE FILLING CHAMBER
Turn the Filling Chamber Cap coun-
terclockwise in order to remove it from
the Filling Chamber.
Removal of the Filling
Chamber Cap with Cooling Coil
Always fill the Filling Chamber completely up
to the upper edge
Remove the Filling Chamber Cap with
Cooling Coil and Mouthpiece from the
Filling Chamber.
Always fill the Filling Chamber com-
pletely with finely crushed or ground
plant material.
Always fill the Filling Chamber
completely up to the upper
edge. This prevents the va-
porization material from shifting when
the Hot Air Generator is not held up-
right, which would make efficient va-
porization impossible, since the hot air
could then bypass the vaporization
material.
8. FILLING THE FILLING CHAMBER
Completely filled FIlling Chamber
The Filling Chamber must always be
filled completely, so that the vaporiza-
tion material cannot shift around, no
matter how the Hot Air Generator is
held.
correct
vapor
Uniform flow through the
vaporization material

2120
Filling Chamber only partially filled
Hot air only; no steam
If the Filling Chamber is only partially
filled, then the vaporization material
may shift around; the hot air then by-
passes the vaporization material, so
that no vaporization can occur.
wrong
8. FILLING THE FILLING CHAMBER
hot air
8. FILLING THE FILLING CHAMBER
If the Filling Chamber is not to be
filled completely, it is recommended to
place the included Liquid Pad over the
herbs, and then screw the cap with the
Cooling Coil onto the Filling Chamber.
Filling Chamber only partially filled,
with Liquid Pad placed on top
Uniform flow through the
vaporization material
correct
vapor
This prevents the vaporization mate-
rial from shifting even when the Filling
Chamber is only partially filled, ena-
bling efficient vaporization.

2322
Take care never to screw the
black Filling Chamber Cap di-
rectly onto the heat exchanger.
Only the orange Filling Chamber is in-
tended to be screwed onto the heat ex-
changer.
If this warning is disregarded, the Fill-
ing Chamber Cap may become de-
formed.
Take care that the Screens
are not obstructed with plant
material. To guarantee opti-
mal results, we recommend cleaning
the Screens after each vaporization
cycle with the enclosed Cleaning
Brush.
Afterwards, screw the Filling Chamber
Cap with the Cooling Coil back onto
the Filling Chamber.
8. FILLING THE FILLING CHAMBER
Heating the PLENTY Hot Air Generator
Screw the Filling Chamber with Cool-
ing Coil and Mouthpiece onto the Hot
Air Generator and heat it up. This
ensures that both the Filling Cham-
ber and the vaporization material are
preheated and the vaporizing can be-
gin as soon as the heating process is
completed.
If the auto off release handle is
not activated or pressed after
heating, then the Hot Air Gen-
erator will cool down again after the set
temperature is reached.
Caution! Hot surface!
After using the PLENTY Va-
porizer, do not touch any com-
ponents of the Filling Cham-
ber until they have cooled down again,
except for the textured surface and the
handles provided for this purpose.
Once the Hot Air Generator has
reached the set temperature (the or-
ange control lamp turns off, or the
thermometer displays the desired
temperature), the inhaling process
can then begin.
9. APPLICATION

2524
Take the Mouthpiece between the
lips, and inhale slowly and evenly for
several seconds.
Please note the following about vapor
generation: the more intense the va-
pors, the greater the impairment of
the flavor.
A very high intensity (density)
of the vapor can lead to irrita-
tion of the respiratory pas-
sages from the concentration of the
aromas and fragrances.
In this case, the temperature should
be lowered, so that the intensity of the
vapors is reduced.
The PLENTY Vaporizer is intended to
be used while seated.
The device is not to be used,
if the user has respiratory
tract or lung conditions. De-
pending on the density, the vapor
could irritate respiratory tracts or
lungs, which can lead to coughing.
Inhale only half the amount of
air you can normally manage.
Hold your breath for a few sec-
onds and then exhale slowly. It is advis-
able to deliberately concentrate on your
breathing process.
After vaporization, turn off the PLEN -
TY Hot Air Generator, unplug the
power cord, and let it cool down be-
fore putting the device away.
9. APPLICATION 10. DISASSEMBLING, CLEANING AND ASSEMBLING
Mouthpiece
Upper Tubing
Section (long)
Cooling Coil
Lower Tubing
Section (short)
Filling Chamber Cap
Upper Screen
Lower Screen
Filling Chamber
Cylinder
Filling Chamber
Housing
10.1. Disassembling and Re-
assembling the PLENTY
Vaporization Unit
Manual cleaning with alcohol (min. 90%) or
dishwashing soap. Replacement Cooling
Coils may also be purchased.
PLENTY Vaporization Unit
Please allow the Vaporization Unit to
cool down before disassembling it.
The component parts of the Filling
Chamber, including the Cooling Coil
and the Mouthpiece must be thor-
oughly cleaned on a regular basis to
guarantee proper operation and pure
flavor.
For hygienic reasons, it is also neces-
sary to clean these components when
the device is to be used by a different
person.
Paper or cotton towels may be used
for manual cleaning; use alcohol (eth-
anol) for metal components (Filling
Chamber Cylinder, Screens, Cooling
Coil), and warm water with wash-up
liquid for plastic components (Filling
Chamber Housing, Mouthpiece, Tub-
ing Sections).

2726
10. DISASSEMBLING, CLEANING AND ASSEMBLING
Pull the Mouthpiece away from the Cooling
Coil
The Vaporization Unit may be eas-
ily disassembled and reassembled
for cleaning in a few seconds. The
Mouthpiece, Filling Chamber, and cap
components may also be cleaned in a
dishwasher.
However, the Screens, Mouthpiece,
and Tubing Sections are very small,
and may be lost if placed in a dish-
washer.
Do not immerse any plastic
components in ethanol or al-
cohol for longer than an hour.
Extended contact with ethanol or al-
cohol may lead to discoloration or em-
brittlement of plastic parts.
After cleaning, check all component
parts for surface damage, tears, sof-
tening or hardening, impurities, dis-
tortion and discoloration and set dam-
aged component parts aside.
10.2. Disassembling the
Mouthpiece
1. Pull the Mouthpiece and the Tubing
Section off of the Cooling Coil with
a gentle twist.
2. Pull the Tubing Section off of the
Mouthpiece with a gentle twist.
Reassemble in reverse order.
Before assembling allow all compo-
nent parts to dry properly.
Mouthpiece
Upper Tubing
Section (long)
Cooling Coil
Cooling Coil
Filling
Chamber Cap
Upper Screen
Lower Tubing
Section (short)
10. DISASSEMBLING, CLEANING AND ASSEMBLING
10.3. Disassembling the Filling
Chamber Cap
Push out the upper Screen with help of the
Cleaning Brush
Pull the Cooling Coil out of the Filling
Chamber Cap
Pull the Cooling Coil out of the Filling
Chamber Cap with a gentle twist, and
then remove the Tubing Section from
the Cooling Coil.
Push the upper Screen out of the Fill-
ing Chamber Cap from above, by us-
ing (for example) the handle of the
included Cleaning Brush.
Reassemble in reverse order.
The upper Screen must be inserted
carefully into the groove provided.
Disregarding this may allow plant
particles to enter the Cooling Coil, so
blocking this or be inhaled.
10.3.1. Cleaning the Cooling Coil
Place the Cooling Coil in a glass and
immerse it completely in alcohol (eth-
anol), cover the glass, and let it soak
overnight.
Repeat this process until the inside of
the Cooling Coil is completely clean,
then rinse it carefully with water.
Warning! Alcohol is flamma-
ble and may easily ignite.
Sets of new Cooling Coils may
be ordered from www.storz-
bickel.com.

2928
10. DISASSEMBLING, CLEANING AND ASSEMBLING
Push out the Filling Chamber Cylinder
Push out the lower Screen
Put in the Screen into the Filling Cham-
ber from the topside.
Screw the Filling Chamber Cap with
Cooling Coil and Mouthpiece onto the
Filling Chamber.
Filling Chamber Cylinder, Filling Chamber
Housing, Positioning Surfaces
10.4. Disassembling the
Filling Chamber
Push the lower Screen upwards out of
the Filling Chamber Cylinder.
10.5. Assembling the Filling
Chamber
Place the Filling Chamber Cylinder into
the Filling Chamber Housing from above,
and turn it so that the flattened position-
ing surfaces are located in the intended
orientation within the Filling Chamber
Housing. Push the Filling Chamber Cyl-
inder in until it latches into the Filling
Chamber Housing. Make sure the posi-
tioning surfaces are oriented correctly, as
shown in the detailed illustration.
Lower Screen
Filling Chamber
Cylinder
Filling Chamber
Housing
Push the Filling Chamber Cylinder
upwards out of the Filling Chamber
Housing.
Voltage:
220 - 240 V / 50 - 60 Hz
or 100 - 120 V / 50 -60 Hz
The voltage specification is located on
the type label of the PLENTY Hot Air
Generator.
Power required by PLENTY: 110 W
Vaporization temperature:
adjustable between approx.
130°C- 202°C / 266°F - 396°F
Dimensions: 20.0 x 15.5 x 6.0 cm
(7.9 x 6.1 x 2.4 inch)
Weight: approx. 0.7 kg (1.5 lbs)
Safety category I (electrically
grounded)
Please unplug to disconnect from the
mains current.
Subject to technical changes.
Patents: EP 2 599 512, US 9,272,103
Manufacturer
Storz & Bickel GmbH & Co. KG
In Grubenäcker 5-9
78532 Tuttlingen, Germany
11. TECHNICAL SPECIFICATIONS
12. DECLARATION OF CONFORMITY
The devices comply with the following
EC Directives:
�Low Voltage Directive
73/23/EWG
�Electromagnetic Compatibility
89/336/EWG

13. WARRANTY, LIABILITY, REPAIR SERVICE
3130
Manufacturer’s Representations
and Warranties
These representations and warranties
are applicable to all end-customers
(the “Customers” and each, individu-
ally, a “Customer”) purchasing prod-
ucts (the “Products”) sold by Storz
& Bickel GmbH & Co. KG or Storz &
Bickel America Inc. (the “Company”).
Warranty and Limitations
Company warrants solely to the origi-
nal purchaser of the Products that
for the warranty period (as defined
below), the Products will be free from
defects in materials and workmanship
under normal use, and will conform to
Company’s published specifications
of the Products. Notwithstanding the
foregoing, Company retains its right to
deviate from its published specifica-
tions due to the latest innovations and
improvements in function and design
of the Products. The foregoing war-
ranty is subject to the proper storage,
transportation and use of the Prod-
ucts, and does not include defects
due to normal wear and tear or dete-
rioration, including, but not limited to,
defects in Screens and similar parts
subject to wear and tear.
Upon delivery, Customer shall imme-
diately inspect the Products for con-
formity and visible defects. Customer
shall give Company immediate written
notice of any non-conformities or vis-
ible defects regarding the Products
and contact Company in writing con-
cerning return or repair, as the case
may be.
Warranty
Customer shall notify Company in
writing of any defects of the Products.
Company’s sole obligation under the
foregoing warranty is, at Company’s
option, to repair or correct any such
covered defect or to replace or ex-
change the Product, provided Cus-
tomer has returned the Products
with a copy of the original invoice to
the Company or one of its author-
ized repair shops at his own cost.
Any repaired, corrected, replaced or
exchanged Products shall be subject
to the warranty set forth in section
“Warranty and limitations”, follow-
ing their repair, correction, replace-
ment or exchange. If Company has
received notification from Customer,
and no defects of the Product could
be discovered, Customer shall bear
the costs that Company incurred as a
result of the notice.
The warranty period for the PLENTY
Hot Air Generator begins on the date
when the Product is physically deliv-
ered to the Customer’s site, and is val-
id for thirty-six (36) months thereafter.
Company does not authorize any per-
son or party to assume or create for it
any other obligation or liability in con-
nection with the Products except as
set forth herein.
All requests and notices from U.S. and
Canadian Customers under this war-
ranty shall be directed to:
Storz & Bickel America, Inc.
1078 60th Street, Suite A
Oakland, CA 94608
All requests and notices from all other
Customers under this warranty shall
be directed to:
Storz & Bickel GmbH & Co. KG
In Grubenäcker 5-9
78532 Tuttlingen, Germany
The warranty set forth in section
“Warranty and limitations” is made
in lieu of all other warranties (whether
express or implied), rights or condi-
tions, and Customer acknowledges
that except for such limited warranty,
the Products are provided “as is.”
Company specifically disclaims, with-
out limitation, all other warranties, ex-
press or implied, of any kind, including,
without limitation, the implied warran-
ties of merchantability and fitness for a
particular purpose, non-infringement,
and those warranties arising from a
course of performance, a course of
dealing or trade usage.
Liability
Handling of these Products is to be as
stated in the Instructions for Use. The
user accepts full liability for improper
handling and usage of these Products.
The intended application only refers to
the plants named by us.
Repair of this Product is only to be done
by us or one of our authorized customer
services.
Only original Storz & Bickel parts are to
be used.
Failure to comply with any of the points
mentioned in these Instructions for
Use release Storz & Bickel GmbH &
Co. KG from any and all liability.
Limitation of Liability
In no event shall Company be liable
for any indirect, incidental, punitive,
special or consequential damages,
including but not limited to, damages
for loss of profits, revenue, goodwill or
use, incurred by Customer or any third
party, whether in an action in contract,
tort, strict liability, or imposed by stat-
ute, or otherwise, even if advised of the
possibility of such damages.
Company’s liability for damages aris-
ing out of or in connection with this
agreement shall in no event exceed
the purchase price of the Products. It
is agreed and acknowledged that the
provisions of this agreement allocate
the risks between Company and Cus-
tomer, that Company’s pricing reflects
13. WARRANTY, LIABILITY, REPAIR SERVICE

3332
13. WARRANTY, LIABILITY, REPAIR SERVICE
Repair Service
After the warranty period has expired,
or if there are any defects which are
not covered under warranty, our ser-
vice department will repair the defect
after providing the Customer with an
estimate and receiving the payment.
Copyright
No part of this document may be repro-
duced in any form (by printing, photo-
copying or other means) or processed,
duplicated or circulated electronically
without the prior written approval of
Storz & Bickel GmbH & Co. KG.
this allocation of risk, and but for this
allocation and limitation of liability,
Company would not have entered into
this agreement.
In jurisdictions that limit the scope of
or preclude limitations or exclusion of
remedies or damages, or of liability,
such as liability for gross negligence
or willful misconduct or do not allow
implied warranties to be excluded,
the limitation or exclusion of warran-
ties, remedies, damages or liability set
forth above are intended to apply to
the maximum extent permitted by ap-
plicable law. Customer may also have
other rights that vary by state, country
or other jurisdiction.
The information contained in these
Instructions for Use are based on our
experience and is current and com-
plete to the best of our knowledge and
ability at the time of printing. Storz &
Bickel GmbH & Co. KG does not ac-
cept responsibility for errors, omis-
sions or incorrect interpretations of
the contents or any information herein.
Users are advised that all applications
and uses of the Products described
must conform to applicable local laws,
ordinances and codes and users of
the Products are advised that they are
solely responsible for determining and
assuring the suitability of any Product
for the intended application.

©by STORZ & BICKEL GmbH & Co. KG · PAL-30-202-E 09-2016 · Subject to alterations · All rights reserved
STORZ & BICKEL GMBH & C O. K G
In Grubenäcker 5-9 · 78532 Tuttlingen/Germany
STORZ & BICKEL AMERICA INC.
1078 60th Street Suite A · Oakland, CA 94608
