Strata Furniture Addison User manual

Parts in the Arm Box:
1A
Parts in the Body Box:
1B
S t r a t a F u r n i t u r e
Page 1 of 8
Assembly Instructions for all sizes.
A d d i s o n ADD 0404
Arm- inside viewArm- outside view Corbels x 4
Back Deck x 1 Seat Deck x 1
with the Feet attached Back Panel x 1
Stretcher x 1 Foot Connector Bar x 1 Advance Arms
x 2
Back Panel Corbel
x 1

Hardware in this Box:
2A
Fit the Wooden Dowels into the Stretcher.
2B
S t r a t a F u r n i t u r e
Page 2 of 8
Assembly Instructions for all sizes.
A d d i s o n ADD 0504
Long Allen Key
x 1
Locking Pins
x 4
Short Clevis Pins
x 2
Bungies x 2
Screw
x 4
Bolts (60mm) x 6
For the Advance Arms
and the Foot Connector Bar
Sleeve x 2
Long Bolts (80mm) x 10
For the Stretcher and Back Panel Bolts (50mm) x 4 For the Arm Corbels
Barrel Nuts
x 10 Wooden Dowel x 4
Washers
x 6
Long Clevis Pins
x 2
Plastic Runner
x 2
Short Bolts (30mm) x 2
For the Back Panel
Corbels
Strap x 1
Wooden
Dowels
End of Stretcher

Assemble the Back Panel between the Arms.
3A A d d i s o n
S t r a t a F u r n i t u r e
Page 3 of 8
Assembly Instructions for all sizes.
ADD 0404
Use 2 People!
Please Note:
Bolt the parts together with using the long Bolts (80mm) and
Barrel Nuts as shown in the drawing. It is helpful to keep the frame
squared. Be patient, it can be tricky to start the bolts in the nuts - A
screw driver will help you line up the Barrel Nut with the Bolt.
Drive the Bolts in until they just catch the Nuts.
Attach the Back Panel Corbel to the Back Panel using the
Short Bolts (30mm).
1.
2.
Long Bolt
(80mm) JCB
Back Panel
Wooden
Dowels
Wooden
Dowels
Wooden
Dowels
Wooden
Dowels
Barrel
Nuts
Barrel Nut
Barrel Nuts
Barrel Nut
Back Panel Corbel
Short (30mm) Bolts
Long Bolts
(80mm) JCB
Long Bolt
(80mm) JCB

Fit the Stretcher, with the Barrel Nut holes on
the inside, to the inside edge of the Arms.
Bolt the parts together with four long Bolts (80mm)
and Barrel Nuts.
Drive the Bolts in until they just catch the Nuts.
Assemble the Stretcher between the Arms.
4A
S t r a t a F u r n i t u r e
Page 4 of 8
Assembly Instructions for all sizes.
A d d i s o n ADD 0404
Barrel Nuts
Wooden
Dowels
Stretcher
Back Panel
Long Bolts
(80mm) JCB
Wooden
Dowels
Barrel Nuts
Long Bolts
(80mm) JCB

Join the Seat and Back Deck together.
5A
Lay both Decks out flat on the
floor with the stickers facing upwards.
The Seat Deck fits inside the Back
Deck as shown. Slip the Long Clevis
Pin through the small end of the Plastic
Runner, through the hole in the Back
Deck and the corresponding hole in
the Seat Deck. Secure with a Washer
and Locking Pin.
S t r a t a F u r n i t u r e
Page 5 of 8
Assembly Instructions for all sizes.
A d d i s o n ADD 0404
Rotate the Back Deck upright.
Attach the Advance Arms
on the inside using the short
Clevis Pins. Secure with a
Washer and Locking Pin.
Fit the Advance Arms
to the Back Deck.
5B
Long Clevis Pin
Sticker
- facing upwards
Plastic
Runner
Long
Clevis Pin
Plastic
Runner
Back Deck
Seat Deck
Sticker- facing upwards
Sticker
Sticker
Lock the Clevis
Pin with a washer
and Locking Pin
Seat Deck
Back Deck
Short
Clevis Pin
Short Clevis Pin
Slot end outwards!
Advance Arm
Advance Arm - Slot end outwards!

Attach the Connector Bar to the Legs.
6A
Assembly Instructions for all sizes.
Lift the Seat Deck so it resting on the Back Deck.
The feet should be pointing downwards.
Line up the holes between the Connector Bar and the
Legs. Make sure the recess for the head of the Bolt is
facing outwards.
Use four Bolts (60mm) and bolt it in place.
Screw the Bungies to the side of the two inner
rails. Fix the lower end of the Bungie chord first,
then stretch the Bungie over the Connector Bar.
Fix the top end.
Assemble the Bungies under the Seat Deck.
6B
S t r a t a F u r n i t u r e
Page 6 of 8
A d d i s o n ADD 0404
60mm
Bolts
Foot Connector Bar
Foot
60mm Bolts
Foot
Back Deck
Seat Deck
Screw
Bungie
Inner Rail
Screw
Screw
Screw
Inner Rail
Back Deck
Seat Deck

Fit the Seat and Back Decks to the Frame.
7A
Insert the decks into the partially completed
frame. This is where a helper may be useful.
When the guides are in the grooves in the
Arms, slide the assembly to the back of the
frame.
Tighten all Stretcher and Back Panel Bolts.
Use 2 People!
Please Note:
All joints must
be left loose.
S t r a t a F u r n i t u r e
Page 7 of 8
Assembly Instructions for all sizes.
All joints must
be left loose.
Connect the Advance Arms
to the Arms.
7B
A d d i s o n ADD 0404
7C Fit the Strap to the
Back Deck.
60mm
Bolt
Sleeve
Washer
Advance Arm

To convert into couch position:
Attach the Corbels to the Arms.
8A
S t r a t a F u r n i t u r e
Page 8 of 8
Assembly Instructions for all sizes.
Note:
Never lift the frame by the arm caps -
Always lift from the bottom of the arms.
To convert into bed position:
Secure with a short Bolt (50mm) from the inside
of the Arm at the bottom. Tighten until the
Corbel is snug.
Fit the dowel at the top of the Corbel into the hole
on the underside of the Arm,and then fit the other
dowel into the side of the Arm.
To convert into couch position:
Lift up the seat deck into a vertical position.
Resting seat deck on your hip, rotate the foot connector
towards you until the feet are fully extended.
Set the frame down gently.
Operating Instructions:
To convert into bed position:Operating Instructions:
•
•
•
Correct Foot position
A d d i s o n ADD 0404
Remove any pillows and other obstructions. Reach to
the back and lay the strap on top of the mattress.
Lift up the seat deck into a vertical position.
Resting seat deck on your hip,
push the foot connector down all
the way so that the foot connector
touches the side rail -
It is Very Important that the feet are
in proper position - see diagram.
With one hand lightly push the seat
deck down and with other hand
pull the back using the Strap, making
sure that the matress clears back rail.
Push the seat deck in all the way.
•
•
•
•
•
DO NOT FORCE - the frame should operate easily.
50mm Bolt Corbel
Arm
