Stratco HT-6666 User manual

THANK YOU FOR PURCHASING YOUR 2 DOOR METAL LOCKER UNIT.
Please carefully read and follow these instructions to assemble your cabinet.
ENSURE PROTECTIVE EYEWEAR AND GLOVES ARE WORN WHEN ASSEMBLING THIS UNIT.
Step 1
JUN 2022
HT-6666
1
FOR INTERNAL USE ONLY
2 DOOR METAL
LOCKER UNIT
FITTING SIDE
PANELS TO
BACK PANEL
FITTING FRONT
DOOR PANEL
TO SIDE PANELS
Step 2
Slot front door panel into one
side then into the other.
Note: Ensure the front door
panel is flush with the side
panels. This is easier to do with
the doors open.
Top View
Bottom View
Screw together
back panel and
right hand side
panel at locations
indicated by the
arrows.
Screw together
back panel and
left hand side
panel at locations
indicated by the
arrows.
A
B
C

2JUN 2022
FOR INTERNAL USE ONLY
HT-6666
2 DOOR METAL
LOCKER UNIT
Step 3
FITTING THE
BOTTOM PANEL
TO THE CABINET
Step 4
FITTING THE
LOCKER BASE PANEL
Step 5
Push the floor panel down
inside the cabinet ensuring
the sides of the floor slide
into the slots on the side
and back panels.
Ensure that the tab on the
bottom panel fits over the
lip on the front panel and
clips into place.
Ensure that the tab on the
locker base panel fits over
the lip on the front panel
and clips into place.
Finished size:
1850 x 380 x 450mm
Insert the locker base panels
from the inside of the cabinet.
F G
I
H
FITTING THE
TOP PANEL
EScrew the top panel to the
inside of the cabinet as
indicated by the arrows.
DSlide the top panel inside the
cabinet and push up until
flush with the top of panels.
