Stratco SS-10433 User manual

Finished size:
1850mm high x
900mm wide x
450mm deep.
C
M
Y
CM
MY
CY
CMY
K
Finished size:
1850mm high x
900mm wide x
450mm deep.
C
M
Y
CM
MY
CY
CMY
K
Slide Front Panel into the two sides and click into place.
FITTING FRONT
PANEL TO SIDE
PANELS
Step 3 A B
Each shelf can hold a maximum load of 45kg. Please carefully read and follow these
instructions to assemble your cabinet.
ENSURE PROTECTIVE EYEWEAR AND GLOVES ARE WORN WHEN ASSEMBLING THIS UNIT.
CHECK PARTS LIST
1 x Front Panel (Doors & Frame)
2 x Plastic Covers
10 x Screws
16 x Shelf Supports
2 x Keys
2 x Side Panel
4 x Shelves
(have folded edge)
1 x Floor Panel
1 x Top Panel
1 x Rear Wall
(install this way up & face
detail towards inside of cabinet)
FITTING AND
SECURING
TOP PANEL
Step 1
Step 4 A B
Position the Right Side Panel
next to the Rear Wall.
Locate the Top Panel - the front has the ‘push-through’ slots.
Lift the Top Panel into place from the inside.
Fasten to the Back Panel with 3 x screws. Then, use a screwdriver to
push the ‘push-through’ slots shown at ‘A’ into the Front Panel.
View from above of
how they slot together.
Secure with screws to hold
side and rear together. Repeat with other side.
FITTING AND
SECURING REAR
WALL TO SIDES
Step 2 A B C D
SS-10 433
1
EXTRA LARGE
METAL CABINET
FOR INTERNAL USE ONLY
TOOLS REQUIRED:
• Rubber Mallet
• Phillips Head
Screwdriver
OCTOBER 2023
WARNING: SERIOUS INJURY CAN BE CAUSED BY TOPPLING FURNITURE. To help
prevent tip-over, we recommend you anchor this product to a wall or other suitable surface. Check anchors regularly.

EXTRA LARGE
METAL CABINET
FITTING AND
SECURING THE
FLOOR PANEL
FITTING THE
SHELVES
FINISHING
OFF
Step 5
Step 6
Step 7
A
A
C D
A
B
B
B
C
2
Place the Floor Panel into position
with the cutouts facing the front.
Ensure the front lip goes over
the top of the Front Panel.
Turn the cabinet on its side and fasten the floor panel with 1 screw
and then use a screwdriver to push the “push-through” slots.
Turn the cabinet upright and place the
Shelf Supports into the side rails of the
cabinet - 4 per shelf at the same height.
Place the Shelves onto the supports and
ensure that they are locked into place.
The doors have a spring loaded hinge
to allow removal at any time. A cover
is supplied for these access points.
Simply push into place.
Your cabinet is now finished
and supplied with 2 x keys.
FOR INTERNAL USE ONLY
SS-10 433
OCTOBER 2023
