Stratco TITANIUM SS-10215 User manual

THANK YOU FOR PURCHASING YOUR 2 DOOR METAL UTILITY CABINET.
Each shelf can hold a maximum load of 45kg.
Please carefully read and follow these instructions to assemble your cabinet.
ENSURE PROTECTIVE EYEWEAR AND GLOVES ARE WORN WHEN ASSEMBLING THIS UNIT.
1
Slot front door panel into
one side then into the other.
Note: Ensure the front door
panel is flush with the side
panels. This is easier to do
with the doors open.
Screw together
back panel
and right hand
side panel
at locations
indicated by
the arrows.
Screw together
back panel
and left hand
side panel
at locations
indicated by
the arrows.
FITTING SIDE
PANELS TO
BACK PANEL
FITTING FRONT
DOOR PANELS
TO SIDE PANEL
Step 1
Step 2
FITTING THE
TOP PANEL
Step 3
A
C
B
EScrew the top panel to
the inside of the cabinet
as indicated by the arrows.
DSlide the top panel inside
the cabinet until flush
with the top of panels.
SS-1021 5
JUN 2022
UTILITY METAL CABINET
TITANIUM

Finished size:
1850mm high x
900mm wide x
450mm deep.
C
M
Y
CM
MY
CY
CMY
K
2
SS-1021 5
Finished size:
1850mm High
1000mm Wide
450mm Deep
FITTING THE
BOTTOM PANEL
TO THE CABINET
Step 4
FITTING THE MIDDLE
DIVIDER PANEL
Step 5
FITTING SHELVES
RHS SIDE
Step 6
Push the floor panel down
inside the cabinet ensuring
the sides of the floor slide
into the slots on the side
and back panels.
Place shelf inside cabinet,
ensure it slides into slots
in panels.
Fit coat hanger rod as shown.
Insert the
middle
divider
panel and
ensure
both top
and bottom
edges
slide into
slots in top
and floor
panels.
Secure the
panel with
screws as
indicated.
F
H
J K L
M
I
G
FITTING
SHELVES
LHS SIDE
Step 7
To fit a shelf, four shelf supports need to be placed at equal
heights around the inside of the cabinet. The shelf supports
fit in as shown in Figure J, K and L.
Place shelves on
pre-positioned
shelf supports.
JUN 2022
UTILITY METAL CABINET
TITANIUM
