  9. Stratco HW-13318 User manual

Stratco HW-13318 User manual

There may be minor variations in the
appearance of some parts from
illustrations due to continued
product improvements.
2 x Side Panels
Top
2 x Middle Shelf
Bottom Shelf
1 x Rear Wall
(install this way up & face
detail towards inside of cabinet)
2 x Keys
Finished size:
1850mm high x
900mm wide x
450mm deep.
C
M
Y
CM
MY
CY
CMY
K
10 x Screws
Finished size:
1850mm high x
900mm wide x
450mm deep.
C
M
Y
CM
MY
CY
CMY
K
Stand the back and right
hand side upright.
Step 2
Insert the cupboard door section
from the inside of the unit.
Step 5
Screw in top and middle screws
to secure Back and RH Side.
Step 3
Fit bottom shelf making sure side slots line up
and that the front of the shelf sits on the lip.
Step 6
Repeat for LH Side.
Step 4
• Get your components ready ahead of the next procedure.
• Use care when using an electric screwdriver not to strip the thread on the screwholes.
TIP
THANK YOU FOR PURCHASING YOUR 2 DOOR METAL STORAGE CABINET.
Each shelf can hold a maximum load of 45kg. Please carefully read and follow these
instructions to assemble your cabinet.
ENSURE PROTECTIVE EYEWEAR AND GLOVES ARE WORN WHEN ASSEMBLING THIS UNIT.
Step 1
JUNE 2022
HW-13318
1
STORAGE UNIT
2 DOOR METAL
8 x Shelf Supports
CHECK PARTS LIST
TOOLS REQUIRED:
• Phillips Head
Screwdriver
Step 7
Lay unit on it’s back and x
bottom screw in lower shelf.
Finished size:
1850mm high x
900mm wide x
450mm deep.
C
M
Y
CM
MY
CY
CMY
K
2 x Plastic Covers
1 x Front Panel
(Doors & Frame)
Step 10Step 8
Step 11
Step 9
Step 12 Step 13
Shown above with only one shelf installed.
Finished size: 900mm high x 900mm wide x 450mm deep Accessories not included.
Make sure the top is tted
on all four corners.
Insert shelf supports in the four
corners of the unit at same height.
Please remove doors to place
the top on the unit, front rst.
Rest shelf on supports. Press in plastic covers.
Screw top down with 2 screws
either side as shown.
2
HW-13318
STORAGE UNIT
2 DOOR METAL
JUNE 2022
Finished size:
1850mm high x
900mm wide x
450mm deep.
C
M
Y
CM
MY
CY
CMY
K
