Operating Instructions
STRION
®
STRION
®
LED
99 Washington Street
Melrose, MA 02176
Phone [phone]
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com

ENGLISH
OPERATING INSTRUCTIONS FOR THE STREAMLIGHT
STRION
®
AND STRION
®
LED
Thank you for selecting the Strion®/Strion®LED, a new concept in portable lights. As
with any fine tool, reasonable care and maintenance of this product will provide years
of dependable service.
Please read this manual before using your Strion®/Strion®LED. It includes important
safety and operating instructions and should be saved. Flashlight must be fully charged
before first use.
USING THE LIGHT
The Strion®features a tactical push button tailcap switch.
Press tailcap button for momentary operation.•
With one hand, rotate tailcap clockwise with thumb and forefinger for steady on.•
Rotate tailcap counterclockwise two (2) turns for storage.•
Rotate facecap to adjust focus to desired beam.•
The Strion®LED incorporates a digital multifunction tail mounted switch.
Lightly press the tailcap button for momentary operation.•
Fully press the pushbutton switch once to turn the light on at full intensity.•
Press and hold the switch to cycle through brightness levels. Release at desired•
level.
A quick double-click of the switch will activate the rapid flash function.•
A single press of the switch from any "on" mode will turn the flashlight off.•
SAFETY
While eye damage from the StrionA. ®LED is unlikely, it is a Class 2 LED product and
YOU SHOULD NOT STARE INTO THE BEAM.
CAUTION: LED RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 2 LED PRODUCT
Maximum LED output<60 mW per IEC 60825-1. Edition 1.2 2001-08
The StrionB. ®/Strion®LED is not approved for use in hazardous atmospheres.
SAVE THESE INSTRUCTIONS.C. This manual contains important safety,
operating and maintenance information for your flashlight and charger.
CAUTION:D. To reduce risk of fire, electrical shock, or personal injury, do not
attempt to use the charger to recharge any other product. Likewise, do not attempt
to charge the Strion®/Strion®LED with any other charger.

Do not abuse the cord. Never carry the charger by the cord or yank the cord toE. disconnect it from a receptacle. Do not use a damaged charger.
Plug AC charger directly into an electrical outlet. Do not use an extension cord.F.
Do not put any metal objects onto the charging terminals located in the chargeG. holder.
Do not try to repair the unit or charger yourself. Take it to a qualified service facilityH. or return it to the factory.
Use only battery #74175 (see parts list). The contact arrangement in the flashlightI. precludes the use of other batteries. Recycle worn out or damaged batteries
properly. Do not attempt to incinerate the battery as it may explode in a fire.
Handle the battery carefully and never allow it to short circuit.
Use of this product for other than a lighting device is not recommended.J. Streamlight
specifically disclaims liability for other than recommended use.K.
CHARGER FACTS
CHARGER MOUNTING
The charger should never be mounted against any heat sensitive surface.•
The most secure mounting position is with the Strion• ®/Strion®LED vertical and
head up.
Before drilling any holes, make sure there is room to insert and remove the•
flashlight.
Two (2) self-tapping screws are included to mount the charger.•
Use a 1/8th" drill bit.
LED CHARGE INDICATOR
With the Strion• ®/Strion®LED inserted properly the LED on the charger should light,
indicating a proper charge path. It may take a second or two for the LED to light
when the Strion®/Strion®LED is first inserted.
Charging…LED is steady.•
Charged…LED pulses shortly every second.•
Charge time is approximately 2.5 hours for Strion• ®and 3hrs for the Strion®LED.
IMPORTANT: Charging temperature is between 20°F and 115°F. A safety circuit
prevents charge outside that range.
Temperatures outside this range may also cause the charge indicator to temporarily•
function abnormally.
It is normal for the indicator to switch between steady and blink as the battery is•
“topped off”.

There is no danger of overcharge. The Strion• ®/Strion®LED is designed to be in the
charger continuously when not in use.
INSTALLATION IN VEHICLES
A 12VDC power cord (#22051) is equipped with a cigarette plug and is available for
mounting a Streamlight charger in a vehicle. The plug can be removed and the wires
can be attached directly to a power source for a more permanent installation. (A two
amp fuse must be used on the positive lead.)
IMPORTANT: Before making electrical connections in a vehicle, keep in mind that a
shorted auto battery can easily start a fire. Make all connections with insulated lugs
or other connectors intended for such use. Be sure that your installation is fused. The
striped power lead is positive and the unmarked lead is negative. The charger body is
electrically isolated from the charge circuit and allows positive ground installations.
The charger is diode protected and if connected in reverse polarity simply won’t
operate until connected properly.
Streamlight recommends connecting chargers to an unswitched source of power
to ensure the flashlight is always fully charged. If the vehicle will not be driven for
several days, the flashlight should be removed from the charger to avoid vehicle
battery drain.
BATTERY REPLACEMENT
Simply unscrew the tailcap and slide the battery from the flashlight. Replace the
battery inserting the contact end first and reattach the tailcap.
MAINTENANCE
Keep all threads and o-rings lubed with silicon grease.•
Keep flashlight charger contacts clean at all times. Poor contact can cause charger•
malfunction. An abrasive pencil eraser works well to clean the contacts.
REPLACEMENT PARTS
BATTERY P/N 74175
LAMP P/N 74914 (Incandescent Model Only)
IMPORTANT – Be sure to use genuine Streamlight®replacement parts.
Go to www.streamlight.com for additional information about replacement parts and
the location of an authorized Streamlight repair center near you.
