Streamline Arcisan Synergii SY02930 Operation manual

SYNERGII SHOWER PANEL
- RETROFITTABLE -
RIGHT HAND OPERATION
SY02930
INSTALLATION AND CARE INSTRUCTIONS
Important Information
• Hot and cold water inlet pressures should be equal.
• Operating static pressure is 300—500kpa. If pressure exceeds this, then an
approved pressure limiting valve must be fitted.
• Pipework must be flushed out prior to installation of the shower panel. Damage
caused to the shower panel by debris coming through the pipework is not
covered under warranty.
• Installation should comply to AS/NZS3500.1 2003 or the relevant local
requirements.
• Maximum hot water temperature is 75°C.
• Not suitable for gravity feed applications.
Maintenance and care
• Using a soft cloth with a mild detergent or soap is all that is required to clean
surfaces.
• Do not use abrasive cream cleaners or citrus based cleaning products. These will
damage the surface.
• The spray channel of overhead shower is protected by a self-cleaning system. If
scale deposits are noticed in the spray channel, turn water on lightly and rub the
spray channels with a finger or sponge.
WARRANTY
Guarantee
Arcisan shower panels are covered by a 7 year conditional residential warranty subject to
the terms below.
> 7 year product or parts warranty against manufacturing defects. (Hoses and hand sprays
on kitchen mixers are 2 years).
> 1 year replacement product or parts and labour warranty.
Streamline reserves the right to assess, fix, replace or service warranty claims as they see fit.
The warranty period applies from date of purchase or date of handover for new buildings. If
this is not available, the manufacturing date stamp on the product will be used.
Warranty claims should first be directed through the point of purchase. It is mandatory that
the purchaser provide proof of purchase and the warranty is valid for the original purchaser
only and is not transferable.
Exclusions
The warranty does not apply to the following cases:
• Blocked or damaged aerators are not covered under the warranty. Other damage caused
by not flushing the system before connection or use.
• Damage caused by improper installation, abuse, accident and misuse. Also previous repair
or alteration without the company’s or agent’s permission.
• Warranty only applies to items purchased through an authorised re-seller within Australia.
• Tapware used in a commercial setting. This is subject to a 1 year parts and labour warranty.
• General wear and tear from normal use of the product, including scratching from cleaning.
• Water temperature or pressure exceeds the stated maximums. The maximum water
pressure is 500kpa and maximum temperature is 75 degrees Celsius.
Consequential Damages
Streamline Products will not liable for damage to other items (floor coverings, walls, lights
and other fittings) or any other type of consequential losses caused by a defect in the
product, except when the failure amounts to a major failure under your statutory rights.
Statutory Rights
Our goods come with guarantees that cannot be excluded in the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
Contact
This warranty is provided by Streamline Products P/L
Phone: [phone]
Email: [e-mail]

INSTALLATION INSTALLATION
IMPORTANT INFORMATION
We recommend that mounting brackets are secured into stud
work. If unable, prior to installation make sure the wall can
support a load of 12kg.
Prior to installation of shower panel please familarise yourself with the
Height Setup page for dimensions.
Note: There are two options for installing the retrofittable Synergii shower panel.
Option 1: External water connection | Option 2: Concealed water connection
Step 1
Attach mounting brackets to the
finished wall. Use a level to be sure that
the bracket is fixed straight.
Ensure correct hardware is used to fix
bracket to wall.
For mounting position, refer to Height
Setup page and/or Concealed water
point diagram.
Step 2 - Concealed water connection
Screw flexible hose from back of shower
panel onto wall connection. Do not over
tighten the nut .
Once the connections are made, turn on
mains water to check for leaks.
Step 3
Carefully hang the shower panel onto
the mounting brackets, ensuring that
both top and bottom brackets are
resting in the correct location on the
back of the panel.
Once the panel is in place, run a line of
silicone down each side of the shower
panel to fix it in place.
Step 4
Finally, connect the handshower to
the bottom water outlet on the side of
shower panel.
Do not overtighten the nut.
Silicone
Step 2 - External water connection
Connect braided hose to the water
inlet hose on the back of the shower
panel. Make sure connection is secure
but do not over tighten the nut.
Connect braided hose to external water
connection.
Once the connections are made, turn
on mains water to check for leaks.

Dimensions are in millimeters and are subject to manufacturing variations. Streamline reserves the right to vary specications at any time without notice. Information provided within this specication sheet is correct at the date of printing. Please conrm all particulars with your sales consultant prior to purchase. Version: 1.0 - May 2017
www.streamlineproducts.com.au | Ph: 1300 735 352
Height set-up for Synergii Shower Panel (Right Hand Operation) SY02930
1530
X
Mounting
bracket
110
200
400
600
520

Dimensions are in millimeters and are subject to manufacturing variations. Streamline reserves the right to vary specications at any time without notice. Information provided within this specication sheet is correct at the date of printing. Please conrm all particulars with your sales consultant prior to purchase. Version: 1.0 - May 2017
www.streamlineproducts.com.au | Ph: 1300 735 352
Concealed water point installation for Synergii Shower Panel Retrofittable SY02930
X
Mounting
bracket
Mounting
bracket
565
30-50
Water inlet zone
is between
Xand X-400
Water inlet 1/2” BSP
