Specification
Input: 5.0V-2.0A
Output: 5.0V-1.0A
Frequency: 110-205kHz
Charging Distance: ≤10mm
Conversion: ≥72%
Mounting of wireless
car charger
Place the ball end of the adjustable
socket (A) into the holder on the
back of the wireless car charger (B).
Tighten securing nut (C) to fasten
the holder to the charger.
To mount to the dash, select a
suitable flat area to mount the
Wireless Charger (it must be FREE
from grease, dust or moisture),
remove the protective layers from the double sided adhesive base (D) attach one side to
the base of the adjustable bracket and then adhere it to the dash (pressing firmly for a
strong mount).
To secure to a window, simply moisten the suction pad and push on to a window in a
suitable position and close leaver (E) to secure.
To adjust the charger, undo screw adjustment (C) and adjust, then tighten to secure in
correct position.To adjust the angle of the charger, undo screw adjustment (C) to adjust,
then tighten to secure in correct position.
Safety Advice
DO NOT place the wireless charger in a position that may cause interference with the
drivers view of the road.
DO NOT place in water or near fire, The are no serviceable parts DO NOT dismantle.
DO NOT use wireless charger in high temperature or humid conditions this may
damage the circuits.
DO NOT place too close to any magnetic strips or chips on bank cards.
Please keep a minimum distance of 20cm between any implantable medical devices
(such as Pacemakers and Cochlear implants) to avoid any potential interference with
the devices.
It is advised to keep the chargers out of the reach of children.
Charging for mobile phones
(with Qi Technology)
Insert the 12V USB cable into the socket on the
charger (G).
Insert the other end of the USB cable into a suitable
12V plug adaptor and connect this to the vehicle
12V power socket.
Press button (F) to open the arms of the holder (will
fit devices from 60mm to 84mm). Squeeze arms together to grip the mobile phone
for a stong secure fit of the device.
Ensure the Qi-technology is enabled on the mobile phone to begin charging (this will
be indicated by the mobile phone showing the charging symbol).
AB
C
D
G
F
Plus a double sided adhesive plastic pad for dash mounting.
E
