Strong SRT 4922B+ User manual

1
USER’S MANUAL
High Definition Digital Satellite Television Receiver
and Recorder

2
Contents
1. Introduction
-------------------------------------------------------3
1.1 Overview --------------------------------------------------------
3
1.2 Main Features ---------------------------------------------------
3
2. Safety Precautions -----------------------------------------------4
2.1 safety
------------------------------------------------------------ 4
2.2 Precautions
----------------------------------------------------- 5
3. Points to Check before Use --------------------------------------6
3.1 Accessories ------------------------------------------------------
6
4. Controls/Functions -----------------------------------------------7
4.1 Front Panel
------------------------------------------------------ 7
4.2 Rear Panel
------------------------------------------------------ 8
4.3 Remote Controller ----------------------------------------------
9
5. How to Connect --------------------------------------------------11
6. Operation ---------------------------------------------------------12
6.1 Getting Started
------------------------------------------------- 12
6.2 System Setting -------------------------------------------------
23
6.3 Channels
------------------------------------------------------- 32
6.4 Electronic Program Guide -------------------------------------- 39
6.5 Entertainment
--------------------------------------------------- 41
6.6 External Device
------------------------------------------------- 44
6.7 System Information ---------------------------------------------
50

3
6.8 Conditional Access System ------------------------------------- 51
6.9 DVR ------------------------------------------------------------
53
7. Troubleshooting ---------------------------------------------------60
8. Specifications
-----------------------------------------------------61
9. Warranty Information----------------63

4
1. Introduction
h 1.1 Overview
This satellite receiver is designed for the reception of
free-to-air and encrypted channels. Depending on your
location, enjoy the rich choice of different channels
broadcasting a large range of programs: culture, sports,
cinema, news, events, etc. This receiver is assembled with
highly qualified electronic parts.
1.2 Main Features
▪Video Resolution : 1080p / 1080i / 720p / 576p / 576i
▪DVR Ready via USB External Mass Data Storage Device
▪Time Shift, Record & Playback
▪USB 2.0 Host for MP3 Playback, JPEG Viewing & Firmware Update
▪10,000 Programmable Channels
▪DVB-S, DVB-S2 Compliant
▪HDMI Output
▪On-screen display with true color full resolution
▪Advanced Blind Scan
▪Auto & Manual Channel Search
▪Dolby Digital Output
▪Channel Sorting by Alphabet, Transponder or CAS
▪16 Favorite Channel Groups
▪OSD in 12 Languages
▪Multi Picture Display and Zoom
▪16:9 Full Screen, 4:3 Letterbox & Full Screen
▪DiSEqC 1.2 and USALS Compatible
▪Data Transfer Between Units
▪Extended Electronic Program Guide (EPG) and program reservation
through EPG
▪Teletext by OSD/VBI (Vertical Blanking Interval)

5
▪Auto Voltage (AC 100 - 250V) SMPS
▪High speed software upgrade via USB 2.0
▪Parental Lock/ Installation Lock / Receiver Lock / Channel Lock / Lock
Channel Confirm
▪Video color adjustment function. Manufactured under license from Dolby
Laboratorie “Dolby”and the double-D Symbol are trademarks
of Dolby Laboratories.
✽ DiSEqC is a trademark of EUTELSAT

6
2. Safety Precautions
2.1 Safety
l
D
o not touch the power cord with
w
et hands as it may cause electric
shock.
lBe sure to read this manual
before starting the operation of
the unit.
lNever open the cover. It is very
dangerous to touch the inside of
the unit due to possible electric
shock.
lWhen you do not use this unit
for a long time, make sure that
power cord is pulled out
f
rom the
outlet. Also do not use a damaged
power cord as it may cause fire or
electric shock.
l
Place the unit in a well
ventilated and
cool environment.
l
A
professional installation is
required.
If reception is interrupted,
contact
your local service centre

7
2. Safety Precautions
2.2 Precautions
When installing the unit
lDo not leave the unit where the
water drops or splashes.
lInstall the unit horizontally.
An uneven
installation may cause the unit
to be damaged.
l
D
o not put heavy items such as
a
TV set on the unit. That may
damage the unit.
lDo not install the unit:
▪Where it is subject to
vibrations
▪Where it is exposed to direct
sunlight
▪Where there is humidity
▪Where the temperature is too high
or too low
▪Where there is no ventilation
l
D
o not put water holding items
such as vases on the unit.

8
l
M
oving the unit to a hot area
from a cold one will cause
c
ondensation. Do not operate the
u
nit for one or two hours or until
it has dried completely.

9
3. Points to Check before Use
3.1 Accessories
The accessories below are included with this receiver:
3.2 The Satellite dish
Your dish should be properly installed and azimuth and elevation must
be precisely set up
✽ This unit supports DiSEqC 1.2 and can work with a compatible
antenna positioner. Ask your dealer for information.

10
4. Controls/Functions
❶ ❸ ❷ ❹ ❻ ❺ h
4.1 Front Panel
❶ Standby/Power on Indications Lamp: Flashes red light in ‘Standby’
mode and shows no light in ‘Power ON’ mode.
❷ Power: Switches the receiver between ‘Standby’ and ‘Power
ON’ modes. ❸ -❹ CH. (▲/▼): To switch channels or change the
cursor position on the application screen.
❺ USB: To connect USB devices such as Memory stick or external
Hard Disk Drive.
❻ Smart Card Reader: Insert smart card for encrypted channel
access.

11
4. Controls/Functions
4.2 Rear Panel
Name Connector Function
❶ LNB INPUT IEC 169-24 FEMALE IF input from LNB to
digital tuner
❷ LOOP OUT IEC 169-24 FEMALE IF loop-
t
hrough outpu
t
from digital tuner
❸ VIDEO RCA cinch
C
omposite video outpu
t
❹ AUDIO L RCA cinch Left audio output
❺ AUDIO R RCA cinch Right audio output
❻ S/PDIF RCA cinch Digital audio output
❼ LAN RJ-45 10/100Mbps Ethernet
❽ HDMI HDMI Digital Video/Audio
Output
❾ USB 1USB A -type USB2.0
❿ RF OUT UHF
21-69 IEC 169-2 MALE Output to TV
 TV ANT IN IEC 169-2 FEMALE
I
nput from terrestria
l
antenna

12
4. Controls/Functions
4.3 Remote Controller
English
❶ POWER: To turn the receiver
On/Off ❷ STAND BY: Just turn the
receiver off ❸ TEXT: To show the
teletext contents if
teletext is transmitted
❹ SUBTITLE: To turn closed captions
on or off ❺ AUDIO: To show the
Multi-language
audio track, the stereo-mono
mode and subtitle information
❻ MUTE: To turn the sound On/Off
❼ Numeric Keys (0-9): To enter
numerical settings (such as
channel numbers) directly
❽ TV/RADIO: To switch between TV and
Radio ❾ SLEEP: To set the STB off after
minutes
❿ GUIDE: To show the TV/Radio program
guide
 INFO: To show information about the current
program. Press twice to show detail
 RECALL: To move to the previous channel
Used for special functions in menu mode
 ASPECT: To select a TV aspect ratio
with Pan Scan or Letter-Box(4:3) (Full screen or pillar box(16:9)
 MENU: To enter or exit the main menu

13
 EXIT: To exit from the present menu and
move to the previous menu
 Up & Down: To switch channels in non-menu mode and move the cursor up/down in
menu mode

14
4.3 Remote
Controller
❶ Vol Up & Down: To change the volume
level
in non-menu mode
❷ OK: To show the Channel List in
nonmenu mode and select an item or
confirm in menu mode
❸ Vol Up & Down: To change the volume
level
in non-menu mode
❹ Double arrow Up/Down: To move to the
next or previous page when many pages
are available
❺ FILELIST: To display the filelist
❻ GROUP: To change the channel groups
(Satellites or favorite groups)
❼ Color Key: Select the option such
as View List,
Select Disk, Rename
❽ REW: Playback in rewind
mode
❾ Time Shift: Play
Content
❿ PLAY: Play Content
 FWD: Playback in forward mode
 REC: Start recording
 STOP: Stop Playback
 SLOW: Playback in slow mode
 ADVANCE: Go to live channel

15
 MOSAIC: To display multiple pictures
 FREEZE: To pause the video. Press again to resume the video
 ZOOM: To zoom In/Out
 V.FORMAT: To switch the resolution of video output
 F1~F4: Reserved button for new function

16
5. How to Connect
English
When Connecting the Receiver to a TV
1. Connect the TV antenna to TV ANT IN
2. Connect the Video and Audio of the TV to Video and Audio: connect
the red and white connectors to Audio R and Audio L, and the yellow
connector to Video
3. Connect your satellite dish

17
6. Operation
6.1 Getting Started
After your receiver is powered on, proceed with installation as
follows :
➊ Menu Language Setting
1. Turn on your TV and receiver.
2. The wizard menu for language selection will appear.<Figure
6.1.1> Select one language and press to proceed.

18
6.1 Getting Started
➋Antenna Setup
1. Press the MENU button to display the main menu.
2. Use and to move in the menu.
3. 3. Press OK on ‘Dish Setting’. The following window will appear.
<Figure 6.1.2> If you have a motorized dish, press OK on ‘Motorized
Setting’. < Figure 6.1.3>
✽ Note: Enter a 4-Digit password if need arises. The default password
is ‘0000’.
4. Select the item that you want to edit, and set its parameters as
desired. <Dish Setting>
▪ LNB Power: Select among ON/OFF/13V/18V.
▪ LNB Type: Select among Single/Universal/OCS/SaTCR.
▪ LNB Freq: Set the frequency of the LNB oscillator.
▪ 22KHz: When not AUTO, set the signal path from LNB or switch by selecting
a control signal among 0/22KHz.
▪ DiSEqC 1.0: Select DiSEqC 1.0 Port
▪ DiSEqC 1.1: Select DiSEqC 1.1 Port
5. Select the item that you want to edit and set its parameters as
desired. <Motorized Setting>
▪ Frequency: If the default TP frequency is not appropriate, you can
select another TP frequency at which to check
for signal.

19
▪ DiSEqC Motor: Select DiSEqC protocol among OFF/1.2/USALS as
appropriate for your Motor.

20
6.1 Getting Started
(When the DiSEqC Motor parameter is set as 1.2 <Figure 6.1.4>)
▪ Satellite: Select any satellite by pressing buttons.
▪ Frequency: Displays the current TP value of the selected
satellite.
▪ Move: Move the dish position to west/east by pressing buttons.
▪ Move Fine: Move the dish position 1 step at a time to west/east
by pressing buttons.
▪ Motor Control: Control motor by press OK button on the remote.
▫ Recalcuate: Recalculate the position of all other saved satellites relative
to the known position.
▫ Reset System: Reset the position of all saved satellites.
▫ Goto Reference: Move the dish to the 0 position.
▫ Disable Limit: Disable east and west limit.
▫ Enable Limit: Enable the saved east and west limit.
▫ Set East Limit: Edit & Save east limit by pressing or OK buttons
▫ Set West Limit: Edit & Save limit by
pressing or OK buttons
▪ Go To: Go to the position of the
saved satellite.
▪ Save: Save the current setting
of DiSEqC 1.2 system.
