Strong tivu on! tivusat SRT 7840 User manual

tivùsat
LA TV
SATELLITARE
4K ULTRA HD
GRATUITA
Ricevitore satellitare
tivùsat UHD SRT 7840
08 Feb 2019 13:37
Supplied by STRONG Austria
Represented by
STRONG Ges.m.b.H.
Franz-Josefs-Kai 1
1010 Vienna
Austria
Email: [email protected]

SAT IN
13/18 V
400 mA max.
USB: 5 V
500 mA max. 24 W max.
12 V 2 A,
ETHERNET
HDMI USB 3.0
TV SCART S/PDIF
optical
IR
DOLBYAUDIO E IL SIMBOLO DELLA DOPPIA D SONO MARCHI REGISTRAT IDI DOLBY LABORATORIES.
Modello: Ricevitore Satellitare tivùsat UHD SRT 7840
Supplied by STRONGAustria
SAT IN
13/18 V
400 mA max.
USB: 5 V
500 mA max. 24 W max.
12 V 2 A,
ETHERNET
HDMI USB 3.0
TV SCART S/PDIF
optical
IR
DOLBYAUDIO E IL SIMBOLO DELLA DOPPIA D SONO MARCHI REGISTRAT IDI DOLBY LABORATORIES.
Modello: Ricevitore Satellitare tivùsat UHD SRT 7840
Supplied by STRONGAustria
SAT IN
13/18 V
400 mA max.
USB: 5 V
500 mA max. 24 W max.
12 V 2 A,
ETHERNET
HDMI USB 3.0
TV SCART S/PDIF
optical
IR
DOLBYAUDIO E IL SIMBOLO DELLA DOPPIA D SONO MARCHI REGISTRAT IDI DOLBY LABORATORIES.
Modello: Ricevitore Satellitare tivùsat UHD SRT 7840
Supplied by STRONGAustria
HDMI cableSCART cable
DiSEqC 1.0
Coaxial
cable
Coaxial cable
Satellite
Dish
Fig. 5Fig. 6Fig. 7
Fig. 8
Fig. 9
Fig. 10
AUDIO
MENU
INFO
BACK
TV/R
SUB TEXT FAVMEDIA
EPG
EXIT
P- P+ LIST
Audio Amplifier
Provider Router
Ethernet cable
100-240V~
/12V
AUDIO
MENU
INFO
BACK
TV/R
SUB TEXT FAV MEDIA
EPG
EXIT
P- P+ LIST
26
25 27
1
3
7
11
15
13
13
16
18
23
8
4
20
30
29
2
6
10
15
17
21
24
32
28
22
12
9
5
19
31
34
33 36
35
14
Fig. 1
Fig. 3
Fig. 4
Fig. 2
SAT IN
13/18 V
400 mA max.
USB: 5 V
500 mA max. 24 W max.
12 V 2 A,
ETHERNET
HDMI USB 3.0
TV SCART S/PDIF
optical
IR
DOLBY AUDIO E IL SIMBOLO DELLA DOPPIA D SONO MARCHI REGISTRATI DI DOLBY LABORATORIES.
Modello: Ricevitore Satellitare tivùsat UHD SRT 7840
Supplied by STRONG Austria
1
1
2
12
3
1 2 3 4 5 6 7 8

SAT IN
13/18 V
400 mA max.
USB: 5 V
500 mA max. 24 W max.
12 V 2 A,
ETHERNET
HDMI USB 3.0
TV SCART S/PDIF
optical
IR
DOLBYAUDIO E IL SIMBOLO DELLA DOPPIA D SONO MARCHI REGISTRAT IDI DOLBY LABORATORIES.
Modello: Ricevitore Satellitare tivùsat UHD SRT 7840
Supplied by STRONGAustria
SAT IN
13/18 V
400 mA max.
USB: 5 V
500 mA max. 24 W max.
12 V 2 A,
ETHERNET
HDMI USB 3.0
TV SCART S/PDIF
optical
IR
DOLBYAUDIO E IL SIMBOLO DELLA DOPPIA D SONO MARCHI REGISTRAT IDI DOLBY LABORATORIES.
Modello: Ricevitore Satellitare tivùsat UHD SRT 7840
Supplied by STRONGAustria
SAT IN
13/18 V
400 mA max.
USB: 5 V
500 mA max. 24 W max.
12 V 2 A,
ETHERNET
HDMI USB 3.0
TV SCART S/PDIF
optical
IR
DOLBYAUDIO E IL SIMBOLO DELLA DOPPIA D SONO MARCHI REGISTRAT IDI DOLBY LABORATORIES.
Modello: Ricevitore Satellitare tivùsat UHD SRT 7840
Supplied by STRONGAustria
HDMI cableSCART cable
DiSEqC 1.0
Coaxial
cable
Coaxial cable
Satellite
Dish
Fig. 5Fig. 6Fig. 7
Fig. 8
Fig. 9
Fig. 10
AUDIO
MENU
INFO
BACK
TV/R
SUB TEXT FAVMEDIA
EPG
EXIT
P- P+ LIST
Audio Amplifier
Provider Router
Ethernet cable
100-240V~
/12V
AUDIO
MENU
INFO
BACK
TV/R
SUB TEXT FAV MEDIA
EPG
EXIT
P- P+ LIST
26
25 27
1
3
7
11
15
13
13
16
18
23
8
4
20
30
29
2
6
10
15
17
21
24
32
28
22
12
9
5
19
31
34
33 36
35
14

tivùsat
LA TV
SATELLITARE
4K ULTRA HD
GRATUITA
Ricevitore satellitare
tivùsat UHD SRT 7840
08 Feb 2019 13:37
Supplied by STRONG Austria
Represented by
STRONG Ges.m.b.H.
Franz-Josefs-Kai 1
1010 Vienna
Austria
Email: [email protected]

tivùsat
LA TV
SATELLITARE
4K ULTRA HD
GRATUITA
Ricevitore satellitare
tivùsat UHD SRT 7840
08 Feb 2019 13:37
Supplied by STRONG Austria
Represented by
STRONG Ges.m.b.H.
Franz-Josefs-Kai 1
1010 Vienna
Austria
Email: [email protected]

08 Feb 2019 13:47
1
English
English
Licenses
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND
NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD
(“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED
TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM
This product contains one or more programmes protected under international and U.S. copyright laws as
unpublished works. They are condential and proprietary to Dolby Laboratories. Their reproduction or
disclosure, in whole or in part, or the production of derivative works therefrom without the express permission
of Dolby Laboratories is prohibited. Copyright 2003-2009 by Dolby Laboratories. All rights reserved.
SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby, STRONG declares that the radio equipment type DVB-S2 receiver is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: https://www.strong.tv/en/doc
Subject to alterations. In consequence of continuous research and development technical specications, design and appearance of products
may change. ASTRA is a registered trademark of SES ASTRA. NagraVision is a trademark of Kudelski SA. Manufactured under license from Dolby
Laboratories. Dolby Audio, Dolby Digital, Dolby Digital Plus and the double-D symbol are trademarks of Dolby Laboratories.The terms HDMI and
HDMI High-Denition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc in
the United States and other countries. All product names are trademarks or registered trademarks of their respective owners.
© STRONG 2019. All rights reserved.

2
English
TABLE OF CONTENTS
1.0 INTRODUCTION 3
1.1 Safety Instructions 3
1.2 Storage 4
1.3 Equipment Set-up 4
1.4 Accessories 4
1.5 Usage of external USB devices 5
2.0 YOUR RECEIVER 5
2.1 DEFAULT PIN-CODE: 0000 5
2.2 Front Panel 5
2.3 Top cover 5
2.4 Side Panel 5
2.5 Rear Panel 5
2.6 Remote Control 6
2.7 Installing the batteries 7
2.8 Using the remote control 7
3.0 CONNECTIONS 7
3.1 Connecting the antenna and LNB (Low Noise Block) to the receiver 7
3.2 Connecting to a digital audio amplier 7
3.3 Basic connection using an HDMI cable 8
3.4 Basic connection using a SCART cable 8
3.5 Connecting to the Internet 8
3.6 Connection to main power supply 8
4.0 STARTING UP FOR THE FIRST TIME 8
4.1 Language, audio and video 8
4.2 PIN code creation 8
4.3 Internet Connection 8
4.4 Satellite System 9
4.5 Search Channel 9
5.0 QUICK GUIDE FOR USING YOUR RECEIVER 9
6.0 HBBTV 9
7.0 OPERATION 9
7.1 Selecting channels 9
7.2 Volume Control 10
7.3 Programme Information (Info banner) 11
7.4 Selecting audio language 11
7.5 Selecting subtitle language 11
7.6 Viewing the teletext 11
7.7 Electronic Programme Guide (EPG)* 12
7.8 Favourite channels 12
8.0 MAIN MENU 12
8.1 Installation 12
8.2 Channel 14
8.3 Setting 16
9.0 MULTIMEDIA 19
9.1 Movie 19
9.2 Music 20
9.3 Picture 20
9.4 Record Playback 21
9.5 Record Setting 21
9.6 Storage Device Setup 21
10.0 NETWORK 21
10.1 IP Setting 22
10.2 Wi-Fi Network 22
10.3 Weather 22
11.0 CONDITIONAL ACCESS 22
11.1 CA Menu 22
11.2 Software Update 23
11.3 USB Update 23
12.0 TROUBLESHOOTING 23
13.0 SPECIFICATIONS 24

3
English
English
1.0 INTRODUCTION
1.1 Safety Instructions
Read all of the instructions before operating the device. Keep these instructions well for later use.
Only use attachments/accessories specied or provided by the manufacturer (such as the exclusive
supply adapter, battery etc.).
Please refer to the information on the product enclosure for electrical and safety information
before installing or operating the apparatus.
To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.
The ventilation should not be impeded by covering the ventilation openings with items, such as
newspaper, table-cloths, curtains, etc.
The apparatus shall not be exposed to dripping or splashing and no objects lled with liquids, such
as vases, shall be placed on the apparatus.
This mark indicates a risk of electric shock.
To prevent injury, this apparatus must be securely attached to the oor/wall in accordance with
the installation instructions.
Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent
types.
The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as
sunshine, re or the like.
Excessive sound pressure from earphones and headphones can cause hearing loss.
Listening to music at high volume levels and for extended durations can damage one’s hearing.
In order to reduce the risk of damage to hearing, one should lower the volume to a safe,
comfortable level, and reduce the amount of time listening at high levels.
The mains plug or appliance coupler is used as disconnect device, it shall remain readily operable.
When not in use and during movement, please take care of the power cord set, e.g. tie up the power
cord set with cable tie or something like that. It shall be free from sharp edges or similar which can
cause abrasion of the power cord set. When put into use again, please make sure the power cord is not
damaged. The absence of a light indication on the apparatus does not mean that it is fully disconnected
from the mains.To disconnect the apparatus completely, the mains plug must be pulled out.
Attention should be drawn to environmental aspects of battery disposal.
No naked ame sources, such as lighted candles, should be placed on the apparatus.
To prevent the spread of re, keep candles or other open ames away from this product at
all times.
Equipment with this symbol is a Class II or double insulated electrical appliance. It has been
designed in such a way that it does not require a safety connection to electrical earth.
Precautions
Never try to open the device. It is dangerous to touch the inside of the device due to high voltages
and possible electrical hazards. Opening the device will void the warranty of the product. Refer all
maintenance or servicing to suitably qualied personnel.
When you are connecting cables, be sure that the device is disconnected from the mains
supply voltage. Wait a few seconds after switching o the device before you move the device or
disconnect any equipment.
It is a necessity that you only use an approved extension and compatible wiring that is suitable for the
electrical power consumption of the installed equipment. Please ensure that the electrical power supply
corresponds with the voltage on the electrical identication plate at the back of the device.
Operating Environment
Do not install this equipment in a conned space such as a bookcase or similar unit.
Do not use the set near damp, and cold areas, protect the set from overheating.
Keep away from direct sunlight.
Do not use the set near dust place.
Do not place candles near the opening area, to avoid ammable foreign material from entering the
device.,

4
English
WEEE Directive
Correct Disposal of this product. This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please use the return and collection systems
or contact the retailer where the product was purchased. They can take this product for environmental safe
recycling.
1.2 Storage
Your device has been carefully checked and packed before shipping. When unpacking it, make sure that all
the parts are included and keep the packaging away from children. We recommend that you keep the carton
during the warranty period, to keep your device perfectly protected in the event of repair or warranty.
1.3 Equipment Set-up
We recommend you to consult a professional installer to set up your equipment. Otherwise, please follow the
instructions below:
Refer to the user manual of your TV and your antenna.
Make sure that the HDMI cable and outdoor components are in a good condition and the HDMI
connections are well shielded and from good quality.
This user manual provides complete instructions for installing and using this receiver. The symbols serve as
follows.
WARNING: Indicates warning information.
NOTE: Indicates any other additional important or helpful information.
MENU Represents a button on the remote control or the receiver. (BOLD CHARACTERS)
Move to Represents a menu item within a screen. (Italic characters)
1.4 Accessories
1x user manual
1x remote control
2x 1.5 V batteries
1x power adapter 12 V, 2 A
1x tivùsat smartcard
WARNING: The batteries should not be recharged, disassembled, electrically short-circuited,
be mixed or used with other types of batteries. If rechargeable accumulators
instead of batteries are going to be used, we recommend using (e.g. NiMH) types
with low self-discharge to ensure long time operation of remote control.
NOTE: For the appropriate usage with this device, use only power adapters as listed
below (in case of a necessary exchange):
Model: CH-GSCV2000S012V24V;
Manufacturer:HUNAN GIANTSUN POWER ELECTRONICS CO.,LTD
The usage of other power adapters may cause damage to the device. Such
damage is not covered under warranty.

5
English
English
1.5 Usage of external USB devices
It is recommended to use USB 2.0 storage devices. If your device is not compatible to USB 2.0
specications, the playback with your receiver might not work properly.
If you are going to use external USB HDD (Hard Disk Drive) please consider that the power
specications might exceed the supported output of your receiver (5 V/800 mA). If so, please
connect your USB HDD to an according external power adapter.
STRONG cannot guarantee compatibility with all types of USB storage devices.
It is advised not to store important information on USB storage devices used with the receiver.
Always make backups of data on your USB storage device before using it with this receiver.
STRONG will not take responsibility for any loss of information or circumstances caused by loss of
information.
Please ensure that either the USB device is already formatted to NTFS or FAT32 or format the USB
device via your receiver. Formatting requires entering the PIN code (default 0000)
STRONG cannot guarantee the playback of all les although extensions are listed, as it depends on
le size, codec, bit rate and resolution.
2.0 YOUR RECEIVER
2.1 PIN CODE
The PIN code is set by the user during the installation wizard. To modify the code, go to the Setting menu,
Parental Control > PIN-Code Change.
2.2 Front Panel
Fig.1
1. IR Sensor Receives the commands of the remote control
2. LED Display Displays channel number, time, videotext page or recording modes
3. Wi-Fi LED: Shows the status of your Wi-Fi connection. GREEN: connection OK. GREEN
BLINKING: data transmit. NO LIGHT: no Internet connections.
2.3 Top cover
Fig.2
1. Standby indicator:
Shows power state of the receiver. White LED: the receiver is on. Less white LED: the
receiver is in standby mode.
2.4 Side Panel
Fig.3
1. Smart card slot
To insert your tivùsat smart card with the golden chip facing down.
2. USB To connect your USB storage device
2.5 Rear Panel
Fig. 4
1. SAT IN To connect to the LNB of your satellite antenna for reception of satellite broadcast
signal
2. TV SCART To connect to TV using a SCART cable
3. S/PDIF (optical)
To connect to a digital amplier or home theatre using a optical cable
4. HDMI To connect to the HDMI input of your TV set using a good quality HDMI cable
5. USB To connect your USB (3.0) storage device
6. ETHERNET To connect to a network switch, router or modem
7. IR To connect an infrared sensor (not included in the packaging)

6
English
8. DC POWER To connect to the original included main power adapter (Input ~230 V 50~60 Hz/
Output 12 V, 2 A DC )
2.6 Remote Control
Fig. 5
1. qTurns the receiver ON/Standby
2. !To turn the sound on or o
3. AUDIO Displays the audio selection menu with selections for available languages and
audio modes
4. P to display the previous page
5. P+ to display the next page
6. LIST Displays the channel list.
7. RED Flexible functions in OSD menu and Teletext.
8. GREEN Flexible functions in OSD menu and Teletext.Changes the picture resolution in
viewing mode.
9. YELLOW Flexible functions in OSD menu and Teletext.Changes the picture Aspect Ratio in
viewing mode.
10. BLUE In viewing mode: displays the schedule menu for easy setup timers; Flexible
functions in OSD menu and Teletext.
11. MENU To open the main menu in viewing mode or to go one step back in the menu
12. EPG Viewing mode: Displays the EPG (Electronic Programme Guide)
13. pqSwitches to the next/previous channel in viewing mode, switches to the next/
previous page in channel list or moving the highlight up/down in the menu
14. OK Viewing mode: Displays the channel list. Menu: activation of the highlighted item
15. tuDecreasing/increasing the volume level in viewing mode/navigating through the
menus/changing values of settings in a menu
16. BACK To back to the previous programme
17. EXIT Cancellation of current process/exit from main menu to viewing mode
18. V+/ Increases/decreases the volume level in TV mode
19. To access the tivùon! sevices
20. INFO Press to display channel number/name and current/coming information. Press
twice to display detailed event information.
21. CH /CH Channel up/down
22. 0~9 Channel number and numeric value input
23. TV/R Toggles between TV and radio mode
24. Mail list
25. SUB To select subtitles language out of available ones on the current channel
26. TEXT To open Teletext if available on the current channel.
27. FAV To access your favourite channels. Toggles between available favourite groups
28. MEDIA Direct access to Multimedia menu
29. 2Starts the Timeshift function, holds play during playback
30. 5Searches backwards during playback/Timeshift. Each pressing increases the speed
(x2 – x32)
31. 6Searches forwards during playback/Timeshift. Each pressing increases the
speed (x2 – x32)
32. 4Starts the recording function
33. uStarts/resumes the playback
34. 7Jumps to the previous le during playback.
35. 8Jumps to the next le during playback.
36. 3Stops playback of multimedia les

7
English
English
NOTE Some functions and commands related to the tivùon! service may undergo some
changes after software updates.
If the receiver has not been yet updated, the tivùon! services will be accessed by
pressing the GREEN button on the remote control.

8
English
2.7 Installing the batteries
Fig. 6
Remove the battery cover from the remote control and put 2x AAA size batteries inside the compartment.
The diagram inside the battery compartment shows the correct way to install the batteries.
1. Open the cover
2. Install batteries
3. Close the cover
NOTE: The batteries should not be recharged, disassembled, electrically short-circuited,
be mixed or used with other types of batteries.
2.8 Using the remote control
Fig. 7
To use the remote control, point it towards the front of the digital receiver. The remote control has a range of
up to 7 metres from the receiver, if properly aligned towards the IR eye on the front panel.
The remote control will not operate if its path is blocked.
NOTE: Sunlight or very bright light might decrease the sensitivity of the remote control.
3.0 CONNECTIONS
This section explains the most important functions to ensure that you can directly watch television with your
new receiver. Please note additional adjustments may be required.
NOTE: Do not connect the receiver to the main power yet.
3.1 Connecting the antenna and LNB (Low Noise Block) to the receiver
Fig. 8
Connect the LNB of your satellite antenna to the SAT IN connector of your receiver using a good quality coaxial
cable and suitable‘F-connector’ plugs.
3.1.1 Connection of multiple xed antennas via DiSEqC 1.0
Fig. 8
1. Connect the LNBs of your xed antenna to the inputs of a DiSEqC 1.0 switch using a good quality
coaxial cable and suitable‘F-connectors’.
2. Connect the output or“to receiver” of the DiSEqC 1.0 switch to the SAT IN connector on your
receiver. Use good quality coaxial cable and suitable “F-connectors”.
3. Plug the power adapter jack to the receiver and the other end to a suitable wall outlet.
3.2 Connecting to a digital audio amplier
Fig. 8
Connect one end of a good quality optical audio cable to the S/PDIF output of your receiver and the other end
to the optical audio input of your home theatre, amplier or any other device supporting digital audio.

9
English
English
3.3 Basic connection using an HDMI cable
Fig. 9
1. Connect the LNB of your satellite antenna to the SAT IN connector of your receiver using a good
quality coaxial cable and suitable‘F-connector’ plugs.
2. Connect one end of a good quality HDMI cable to the HDMI output on your receiver and the
other end to the HDMI input of your TV.
3. Plug the power adapter to a suitable wall outlet.
3.4 Basic connection using a SCART cable
Fig. 9
1. Connect the LNB of your satellite antenna to the SAT IN connector of your receiver using a good
quality coax cable and suitable‘F-connector’ plugs.
2. Connect one end of a good quality Scart cable to the TV SCART connector on your receiver and
the other end to the SCART input of your TV.
3. Plug the power adapter to a suitable wall outlet.
3.5 Connecting to the Internet
The receiver connects to the Internet through the Internet router or DSL/cable modem in your home network.
It connects to the home network over its Ethernet port or Wi-Fi.
Fig. 10
Connect one end of the Ethernet cable to the receiver and the other end to the LAN port at the router or DSL/
cable modem. To connect the receiver through Wi-Fi, set it during the First Time Installation or select Network
then WiFi Network in the main menu.
3.6 Connection to main power supply
Fig. 10
After all the connections are done you can connect your receiver to power using the supplied external AC/DC
adapter. Now plug the adapter into the wall socket.
4.0 STARTING UP FOR THE FIRST TIME
Once you properly installed and connected all cables of the receiver, setup your receiver step by step by First
Time Installation procedure.
It will guide you through the basic installation and channel searching process.
4.1 Language, audio and video
The receiver turns on displaying the Welcome message, press OK to go to the next step. In this page it is
possible to set Language, Resolution, Aspect Ratio and Audio Format. Press OK to select the option you need to
change then pqto change selection. To conrm and exit press OK.
4.2 PIN code creation
Create and conrm the PIN code, then select AVANTI and conrm with OK to continue.
4.3 Internet Connection
If the Ethernet cable has already been connected, the receiver will display Connesso on Connessione Ethernet, if
not the receiver will display Collega il cavo. In this case connect the Ethernet cable to the Ethernet port and the
receiver will detect the connection automatically.
If you intend to connect the receiver via Wi-Fi connection, select Elenco reti and the receiver will display a list of
all available networks. Select your network by pressing OK and insert the password.
To go to the next step, select Avanti and conrm with OK.

10
English
4.4 Satellite System
In this page it is possible to set the Antenna type, Satellite and LNB Power. In case you want to change the
default settings please check the 8.1.1 Antenna Setting chapter.
To go to the next step select Avanti and conrm with OK.
4.5 Search Channel
On Tipo di ricerca please set the search type choosing between tivùsat +free to air and tivùsat to store only the
tivùsat programmes.
To start the channel search, select Avanti and conrm with OK.
NOTE: If you see the messages No list found or No channels found, please check the
antenna connections and signal levels of the satellite dish.
5.0 QUICK GUIDE FOR USING YOUR RECEIVER
We at STRONG understand that you can’t wait to enjoy your new tivùsat receiver.
However, we advise you to read this manual to get the best performance from your STRONG tivùsat receiver.
To turn your receiver ON or to go to Standby mode, press qon the remote control. Choose channels with CH
/CH or pq. Alternatively, you can also enter the channel number with the 0~9 buttons on the remote
control or press OK in viewing mode to display the channel list. The volume can be adjusted with V+/ or with
tu.
6.0 HbbTV
This receiver supports HbbTV (Hybrid Broadcast and Broadband TV). This means that high-quality content is
combined via satellite with the latest OTT applications, including the tivùon! OpApp coming up soon. To get
the full benet of HbbTV, your receiver must be connected to the Internet (via the Ethernet socket) or WiFi.
Thanks to HbbTV, you have access to the tivùon! Improved Electronic TV Programme Guide (EPG), up-to-date
information from leading TV channels, including video on demand (VOD) services, such as“tivùon!”, “RaiPlay”
and“Mediaset Play”applications, games and, of course, further program content such as digital teletext.The
availability of HbbTV content is dependent on the TV channels and is also provided by them. As soon as a
HbbTV channel from tivùsat bouquet has been selected, the receiver recognizes that HbbTV contents are
available and starts the application. Once the HbbTV content has been loaded, some of the buttons on your
remote control have special functions, just follow the instructions on the screen. Not all portals oer the same
functions, so we recommend that you familiarize yourself with the peculiarities of various portals and possibly
use available additional information. Press the EXIT key to exit the HbbTV application and return to TV mode.
7.0 OPERATION
In viewing mode, several features are available to make watching TV a true pleasure. This paragraph describes
these features. Please also read chapter 8to get familiar with the menu of your new tivùsat receiver.
7.1 Selecting channels
There are dierent ways to change channels with your receiver.
Via direct access
Via the channel list
Via the CH /CH or pqbuttons
Via the BACK button

11
English
English
7.1.1 Direct access
To gain direct access to a certain channel simply enter its number with the 0~9 keys on the remote control.
Channel numbers can be up to 4 digits long. Entering numbers and values with less than 4 digits is possible.
Just wait a few seconds and your receiver will switch to the selected channel.
7.1.2 Channel list
Press OK or the LIST button in viewing mode to display the channel list.
Use pqto highlight your channel of choice and press OK to select the highlighted channel for preview. Use
the FAV button to get access to a group of favourite lists. Press OK to select only channels from a particular list.
Refer to chapter 8.2.2 TV Channel Manager to organize channels into favourite lists.
The channel list is equipped with a Channel Filter function to make it easier to nd channels. Use RED button
to get access to TV Program List lter. There are 4 options to help to nd channel. Use pq to select option.
Use tuto switch between Order option, Clas parameter and Programme list.
Use OK to conrm selection.
ALL for sequential search through complete list of all channels, which are stored in your receiver
from all satellites.
A-Z to search for the channel from the list in alphabetical order. In Group parameter dene rst
letter of channel name. At right side on screen you will see only channels, which name
starting from selected letter.
FAV to search for the channel within your favourite lists.
SAT to search for the channel by satellites, which channels were stored to receiver.
NOTE: The bottom row on the screen provides technical information of the selected
channel.
The channel list is also equipped with another option to facilitate the search for a channel. Use the GREEN
button to display the search engine and insert the name of the channel you need to nd. Use pqand tu
to compose the channel name then press RED button to search or EXIT to select the channel list with the
search results on the left.
7.1.3 Using the CH /CH or pqbuttons
CH or pwill switch to a higher channel.
CH or qwill switch a lower channel.
7.1.4 Using the BACK button
Use the BACK button to return to the last viewed channel. By pressing this button, the receiver displays the TV
recent list. This list contains the last channels viewed. Use pqto select the channel you need then conrm
with OK.
7.2 Volume Control
The volume control allows you to adjust the audio volume. Press V+/ or tubutton to adjust the audio
volume. Press the !button to temporarily mute audio. Press it again to come back to normal volume.
NOTE: The !function remains set while you switch channels.

12
English
7.3 Programme Information (Info banner)
Programme information is always displayed for a certain period of time whenever you switch channels.
You can also view the programme information by pressing the INFO button while watching a programme.
Press EXIT to hide the info banner.
Info banner:
Indicates channel number and name
Indicates current time and date
Informs about current programme name
Indicates name and schedule of the next programme
Displays satellite signal strength and quality bars
Provides programme encryption information
Provides video and audio parameters for broadcasted programme
Provides subtitle and teletext information (displayed if available with the programme broadcast).
Use the pqbuttons of the remote control to switch channels.
7.3.1 Extended information panel
To access the extended information, press INFO button:
once during presence of the information banner on screen
twice in viewing mode.
The details of the current programme information (name and description of the current programme) will be
provided in an additional window*. If the programme description does not t in the display area, you can use
pqto scroll through this information. To view information about the next programme, press INFO another
time. Press EXIT to close extended information panel.
NOTE: You can change the on-screen duration of the info banner in the System Settings
menu. Please refer to section 8.3.2 for more details.
* Information will be displayed if available. Availability depends on the broadcaster.
7.4 Selecting audio language
Some channels support a choice of audio formats and/or languages.
Press AUDIO in viewing mode to display a list of available audio languages.
Use pqto highlight the language of choice and press OK to conrm.
With tuyou can additionally select audio mode of Stereo (for stereo sound), Mix (both speakers will produce
same mixed from both channels sound) and Left or Right (both speakers will produce sound respectively from
left or right sound channel).
7.5 Selecting subtitle language
Press SUB in viewing mode to display a list of available subtitle languages. Use pqto select the subtitle
language and press OK to conrm. Additionally you can adjust your preferred subtitle language as described
in chapter 8.3.1.
NOTE: Please consider that this function supports DVB and TXT subtitles and this
selection only displays them temporarily. Subtitles may not be supported by
every channel or broadcaster.
7.6 Viewing the teletext
To access the teletext, press the TEXT button in viewing mode. Use 0~9 or pqbuttons to select the number
of the page you wish to see. Press EXIT to go back to viewing mode.

13
English
English
7.7 Electronic Programme Guide (EPG)*
The Electronic Programme Guide is a very useful function that allows you to watch programme schedules and
information on screen and not to miss any important event by setting Timer for it.
Press EPG button to activate this guide (you can also enter Electronic Programme Guide through the
menu). Use pqto select a channel. Use tuto scroll through programmes on selected channel to display
programme information on the screen or to book timer for it. Press RED or GREEN buttons to scroll through
programmes to display programme information for the next/previous day. Press INFO button to display
detailed information for selected programme. Press OK button to book or 4button to set the Timer of the
selected programme (timer will be set for this event). To view the booked events and timers check the Timer
menu. Press EXIT to go back to viewing mode.
* The tivúsat Oine EPG will be available after a software update.
NOTE: Availability of EPG data depends on broadcaster.
7.7.1 Booking a programme from EPG
Select a programme as described above. Press OK button.
Selected programme will be booked. Next to the programme name the symbol will appear and the programme
will be added in the Timer list. To cancel programme booking just press the OK button again. You can also make a
correction of the booking event via Timer list. Please refer to section Timer 8.2.4. for more details.
7.7.2 Recording a programme from EPG
Select a programme as described above. Press 4button.
Selected programme will be booked. Next to the programme name the 4symbol will appear and the programme
will be added in the Timer list. To cancel programme booking just press the 4button again. You can also make a
correction of the booking event via Timer list. Please refer to section Timer 8.2.4. for more details.
7.8 Favourite channels
Use the FAV button to access your favourite channel groups. Using pqselect created earlier one of available
favourite groups and press OK or tto switch to channel list within selected group. Use pqto select
channel and press OK to start viewing it. Now you will navigate (switch channels with CH /CH or pq
buttons) only within this group. To get access to channel outside this group you could use direct access (enter
channel number with 0~9 keys) or switch to another favourite group with FAV or OK button. Select TV in
list of favourite channel groups to return to full channel list. Please refer to section 8.2.2 for details on how to
manage favourite lists.
8.0 MAIN MENU
The main menu gives you access to Installation, Channel, Settings, Multimedia, Network and Conditional Access
functions. To access the main menu, press MENU in viewing mode. Throughout the main menu, use MENU
and BACK to get back to the previous screen and EXIT to quit. Throughout the Menu, use tuto select the
main menu item and pqto highlight the submenu of choice and press OK to select.
8.1 Installation
This section contains information of how to add or modify your antenna parameters, to search for channels
and programmes list. A factory reset can be performed as well.
8.1.1 Antenna Setting
All settings and changes will be saved at exitting the menu. Conrm the pop-up.
The Signal Strength and Signal Quality of the signal are displayed for your convenience while setting up, at the
bottom at the screen. If settings are correct, and satellite dish is aligned, some level should appear.

14
English
Antenna Type:
For a xed dish, with a single LNB, select Fixed-LNBOnly (Default)
For a xed dish set up, with more than 1 LNB, but max. 4 LNBs, including a DiSEqC 1.0 switch, select Fixed-
DiSEqC 1.0. If selected here, then select the corresponding ports at DiSEqC 1.0 below.
For the use of a SCR system (SatCR, Satellite Single Cable distribution) select SCR and then select the
corresponding User Band in the User Band and User Frequency options below.
For a Motor-driver dish set-up, using a DiSEqC 1.2 motor, select DiSEqC 1.2.
With DiSEqC 1.2 it is necessary to search and store every satellite position manually. This is very cumbersome
(and old fashion) to do so. Select a position (1 to 63) with Go To for a satellite and then with Move drive the
antenna until the satellite is found and optimise reception. Then store the position and satellite with Save
Position. Proceed for the next satellite.
GoToX is the unocial successor to DiSEqC 1.2, sometimes called DiSEqC 1.3 Modern Motor-drives
are all DiSEqC 1.3 type. It involves a predened satellite list and corresponding positions
to those satellites, in the receiver and a algorithm to determine where the satellite is, given
its geographical location. Only need is to enter the geographical location where the dish is
installed. All satellites can now be found automatically. If GoToX is selected, set the location
in the options below. At Satellite chose the satellite of your choice.
Satellite: Select a satellite to be congured.
LNB Power: Set the LNB power On or O.
LNB Type: Select the LNB type. The Universal LNB (09750/10600 MHz) is supported and is the most
common on the market for European Ku-band use. Standard refers to C-Band LNBs, Wide C
refers to wide band C-band LNBs.
LNB Freq: Set the frequency of the selected LNB type.
Default is 9750/10600. The Universal LNB (09750/10600 MHz) is the most common on the
market for European Ku-band use.
It is also possible to select alternative frequencies for Universal LNB types.
Transponder: Select one of the available transponders of the chosen satellites in order to check your
reception or to align the antenna.
Move: To drive the antenna until the satellite is found and optimise reception
Sat Degree: Satellite position.
Ant Position: To enter the geographical position of the dish.
Go To: To make the dish move to the set position.
The following 2 options will only show when at Antenna Type the Fixed DiSEqC 1.0 option is selected.
22KHz Tone: Switch the 22 KHz oscillator signal to ON (22K) or OFF (0). Only for C-Band LNB use. Refer to
manual of LNB.
DiSEqC 1.0: Select the correct port of the corresponding LNB.
Available options: O, Port A, …, Port D.
The following 2 options will only show when at Antenna Type the SCR option is selected.
User Band Select the User Band you are assigned to in the SCR system. Max. 8 users.
User Frequency Displays the corresponding Frequency for the User Bands. If the User Frequency does not
correspondent with any of the default User Bands for you particular SCR LNB, press OK and
select User Dene and enter the correct User Frequency for the correct User Band. Then press
OK again.

15
English
English
NOTE: If an SCR LNB is used, please refer to the manual of the respective LNB to obtain
technical data on user bands numbers and corresponding frequencies. SCR cannot
be combined with any other DiSEqC function. SCR can only work in combination
with an optional multi-output (max. 8) satellite splitter and an SCR LNB. SCR systems
are mainly installed by professional experts, who then assign the User Band and
Frequencies. If such a system is readily installed in your apartment block, refer to the
original installer or the maintenance department of the housing block.
The Signal Strength and Signal Quality of signal are displayed for convenientness while setting up, at the
bottom at the screen.
The following 3 options will only show when at Antenna Type the DiSEqC 1.2 option is selected.
Go To The receiver can save up to 64 dierent positions. First select one Position by pressing OK
button, then use Move by pressing the tubuttons to reach the correct satellite position.
Once the signal is strong enougt select Save Position to save this position.
Move Press tuto adjust the dish position according with the strength signal on the signal bars.
Save Position Press OK to save the Dish position.
8.1.2 Channel Search
Satellite: Select a satellite to be congured
Channel Type: Choose the kind of channel type you want to install. Available options: TV, Radio and
TV&Radio
Search Type: Set the search type. Available options: One transponder to store the programme of only
one transponder, tivùsat to store tivùsat programmes only, Free-To-Air to store Free-To-Air
programmes only, tivùsat +Free to air to store tivùsat and free to air programmes, All to store
all kind of programmes.
Transponder: Select the transponder belonging to the satellite selected. In case it has been
selected the option One transponder on Search Type the receiver will scan only the transponder selected.
Search: Press OK button to start the search.
8.1.3 Update tivùsat List
It useful to periodically check if a new programme list is available, provided by tivùsat on satellite.
8.1.4 Factory Reset
This option allows you to reset the receiver back to the factory settings, which also clears all stored channels.
You are asked to enter your PIN code. Enter the correct PIN code using the 0~9 buttons. A conrmation
window is displayed. Select OK to load factory settings. Select Cancel to cancel. Press EXIT to leave.
WARNING: By resetting your receiver to factory default, all your settings and stored channels
will be permanently deleted. Please use this option with caution.
8.1.5 Delete Browsing Data
Use this item to delete browsing data. At the end of the deletion process the receiver will restart automatically.
8.2 Channel
8.2.1 Electronic Programme Guide
This menu item opens the Electronic Programme Guide (EPG).
Use the navigational buttons and the buttons as indicated on screen to select a programme for recording. The
EPG information is maintained by the provider.
