Stryker Secure connect connected hospital 5212 Manual

SSeeccuurree®® CCoonnnneecctt™™

OOppeerraattiioonnss//MMaaiinntteennaannccee MMaannuuaall

5212

Connected Hospital®

5212-009-201 Rev A.0 2020/10

SSyymmbboollss

Refer to instruction manual/booklet

Consult instructions for use

General warning

Caution

Non-ionizing radiation

China RoHS with declarable substances

Catalogue number



Serial number

 

For US Patents see www.stryker.com/patents

Manufacturer

IIPPXX44 Protection from liquid splash

Class II electrical equipment: equipment in which protection against electric shock does not rely

on basic insulation only, but in which additional safety precautions such as double insulation or

reinforced insulation are provided, there being no provision for protective earthing or reliance

upon installation conditions.

87VL

Medical Equipment Classified by Underwriters Laboratories Inc. With Respect to Electric Shock,

Fire, and Mechanical Hazards Only in Accordance with ANSI/AAMI ES60601-1:2005/(R)2012

and A1:2012 C1:2009/(R)2012 and A2:2010/(R)2012, CAN/CSA-C22.2 No. 60601-1:14, IEC

60601-2-52:2009/A1:2015, CAN/CSA-C22.2 No. 60601-2-52:11 with Amendment 1:2017.

In accordance with European Directive 2012/19/EU on Waste Electrical and Electronic

Equipment (WEEE) as amended, this symbol indicates that the product should be collected

separately for recycling. Do not dispose of as unsorted municipal waste. Contact local distributor

for disposal information. Ensure infected equipment is decontaminated prior to recycling.

5212-009-201 Rev A.0 EN

TTaabbllee ooff CCoonntteennttss

Warning/Caution/Note Definition ..............................................................................................................................2

Summary of safety precautions ................................................................................................................................2

Introduction ...............................................................................................................................................................3

Product description .................................................................................................................................................3

Expected service life ...............................................................................................................................................3

Disposal/recycle.................................................................................................................................................3

Contraindications....................................................................................................................................................3

Specifications .........................................................................................................................................................3

Bluetooth radio specifications..............................................................................................................................4

Contact information.................................................................................................................................................5

Serial number location ........................................................................................................................................5

Installation.................................................................................................................................................................6

Installing SSeeccuurree CCoonnnneecctt ......................................................................................................................................6

Installation checklist..................................................................................................................................................8

Operation ..................................................................................................................................................................9

SSeeccuurree CCoonnnneecctt indicators/functions.......................................................................................................................9

Configuring the SSeeccuurree CCoonnnneecctt...........................................................................................................................10

Testing the SSeeccuurree CCoonnnneecctt.................................................................................................................................11

Preventive maintenance .........................................................................................................................................12

Cleaning and disinfecting with wipes......................................................................................................................13

Cleaning..................................................................................................................................................................14

Disinfecting .............................................................................................................................................................15

Troubleshooting ......................................................................................................................................................16

Service ....................................................................................................................................................................17

Replacing the battery (37-pin connector, left side) ...................................................................................................17

Replacing the battery (37-pin connector, right side) .................................................................................................19

SSeeccuurree CCoonnnneecctt locator assembly, left.................................................................................................................20

SSeeccuurree CCoonnnneecctt locator assembly, right...............................................................................................................25

Wireless notifications..............................................................................................................................................30

EMC information .....................................................................................................................................................31

Recycling passport .................................................................................................................................................35

521200380105/521200380110 ..............................................................................................................................35

700000886795........................................................................................................................................................36

700000915390........................................................................................................................................................37

SSeeccuurree CCoonnnneecctt association form.........................................................................................................................38

5212-009-201 Rev A.0 1 EN

WWaarrnniinngg//CCaauuttiioonn//NNoottee DDeeffiinniittiioonn

The words WWAARRNNIINNGG,CCAAUUTTIIOONN, and NNOOTTEE carry special meanings and should be carefully reviewed.

WWAARRNNIINNGG

Alerts the reader about a situation which, if not avoided, could result in death or serious injury. It may also describe

potential serious adverse reactions and safety hazards.

CCAAUUTTIIOONN

Alerts the reader of a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to the

user or patient or damage to the product or other property. This includes special care necessary for the safe and effective

use of the device and the care necessary to avoid damage to a device that may occur as a result of use or misuse.

NNoottee -- Provides special information to make maintenance easier or important instructions clearer.

SSuummmmaarryy ooff ssaaffeettyy pprreeccaauuttiioonnss

Always read and strictly follow the warnings and cautions listed on this page. Service only by qualified personnel.

WWAARRNNIINNGG

• Portable RF communications equipment, including peripherals such as antenna cables and external antennas, should

be no closer than 12 inches (30 cm) to any part of the SSeeccuurree CCoonnnneecctt locator, including cables specified by the

manufacturer.

• Avoid stacking or placing equipment adjacent with other equipment to prevent improper operation of the product. If such

use is necessary, carefully observe stacked or adjacent equipment to make sure that they operate properly.

• The use of accessories, transducers, and cables, other than those specified or provided by the manufacturer, could

result in increased electromagnetic emissions or decreased electromagnetic immunity and result in improper operation.

CCAAUUTTIIOONN

• Improper usage of the product can cause injury to the patient or operator. Operate the product only as described in this

manual.

• Do not modify the product or any components of the product. Modifying the product can cause unpredictable operation

resulting in injury to patient or operator. Modifying the product also voids its warranty.

• Always match the dip-switches on SB1 and SB2 to the connected product configuration to avoid the risk of head wall

damage.

• Always match the dip-switches of a product to the head wall configuration if a nurse call communication cable needs to

be connected to avoid the risk of head wall damage.

• Always match the dip-switches on SB1 and SB2 to the product configuration to avoid the risk of head wall damage.

• Do not clean, disinfect, service, or perform maintenance while the product is in use.

• Always unplug the power cord from the wall outlet when large spills occur near the circuit boards and cables. Clean up

the fluid, and inspect the product. Fluids can cause unpredictable operation and decreased functionality of any electrical

product. Do not return the product to service until dry and tested for safe operation.

• Always wipe down with clean water (or 70% isopropyl alcohol, if using VViirreexx® TB) and dry each product after

disinfecting. Some disinfectants are corrosive in nature and may cause damage to the product. If you do not rinse and

dry the product, you may leave a corrosive residue on the surface of the product. This corrosive residue could cause

premature degradation of critical components. Failure to follow these disinfecting instructions may void your warranty.

EN 2 5212-009-201 Rev A.0

IInnttrroodduuccttiioonn

This manual assists you with the operation or maintenance of your Stryker product. Read this manual before operating or

maintaining this product. Set methods and procedures to educate and train your staff on the safe operation or maintenance

of this product.

CCAAUUTTIIOONN

• Improper usage of the product can cause injury to the patient or operator. Operate the product only as described in this

manual.

• Do not modify the product or any components of the product. Modifying the product can cause unpredictable operation

resulting in injury to patient or operator. Modifying the product also voids its warranty.

NNoottee

• This manual is a permanent part of the product and should remain with the product even if the product is sold.

• Stryker continually seeks advancements in product design and quality. This manual contains the most current product

information available at the time of printing. There may be minor discrepancies between your product and this manual. If

you have any questions, contact Stryker Customer Service or Technical Support at 1-800-327-0770.

PPrroodduucctt ddeessccrriippttiioonn

The Stryker Model 5212 SSeeccuurree®CCoonnnneecctt™ is a cable-free nurse call solution. SSeeccuurree CCoonnnneecctt allows for patient nurse

communication via the nurse call button, room controls, and TV controls without the need for any cables or wires.

EExxppeecctteedd sseerrvviiccee lliiffee

The SSeeccuurree CCoonnnneecctt has a 10 year expected service life under normal use conditions and with appropriate periodic

maintenance.

The battery has a two year expected service life under normal use conditions.

DDiissppoossaall//rreeccyyccllee

Always follow the current local recommendations and/or regulations governing environmental protection and the risks

associated with recycling or disposing of the equipment at the end of its useful life.

CCoonnttrraaiinnddiiccaattiioonnss

None known.

SSppeecciiffiiccaattiioonnss

Overall length, width, and depth 16.3 in. x 3.3 in. x 4.3 in. 41.1 cm x 8.4 cm x 10.9 cm

Weight 4 lb 1.8 kg

5212-009-201 Rev A.0 3 EN

System voltage rating AC supply: 100-240 VAC, 50/60 Hz, 0.8A

SSeeccuurree CCoonnnneecctt: 18 VDC, 1.67A

Wireless connection

Uses infrared (IR) LED and Bluetooth based on Stryker

proprietary communication scheme

NNoottee -- Minimum signal strength of the SSeeccuurree CCoonnnneecctt must

be within 3dB of the connected product. Make sure the product

is within 5.5 ft (1.7 m) of the SSeeccuurree CCoonnnneecctt.

Stryker reserves the right to change specifications without notice.

Specifications listed are approximate and may vary slightly from product to product or by power supply fluctuations.

EEnnvviirroonnmmeennttaall ccoonnddiittiioonnss OOppeerraattiioonn SSttoorraaggee aanndd ttrraannssppoorrttaattiioonn

Ambient temperature

95 °F

(35 °C)

50 °F

(10 °C)

140 °F

(60 °C)

-40 °F

(-40 °C)

Relative humidity (non-condensing)

75%

30%

95%

10%

Atmospheric pressure

106 kPa

70 kPa

106 kPa

50 kPa

In accordance with the European REACH regulation and other environmental regulatory requirements, the components that

contain declarable substances are listed.

DDeessccrriippttiioonn NNuummbbeerr SSuubbssttaannccee ooff vveerryy hhiigghh ccoonncceerrnn

((SSVVHHCC)) cchheemmiiccaall nnaammee

Wallside room interface board 521200380950

Decamethylcyclopentasiloxane,

dodecamethylcyclohexasiloxane, lead,

octamethylcyclotetrasiloxane

BBlluueettooootthh rraaddiioo ssppeecciiffiiccaattiioonnss

IItteemm

SSppeecciiffiiccaattiioonn -- CChhiippsseett WWTT3322ii ((SSiilliiccoonn LLaabbss))

UUnniitt

CChhaannnneell MMiinn MMaaxx

Operating frequencies 79 2.4 2.4835 GHz

Receiving bandwidth Not applicable 1 MHz

Maximum ERP Not applicable -24.148 dBW

EN 4 5212-009-201 Rev A.0

CCoonnttaacctt iinnffoorrmmaattiioonn

Contact Stryker Customer Service or Technical Support at: 1-800-327-0770.

Stryker Medical

3800 E. Centre Avenue

Portage, MI 49002

USA

NNoottee -- The user and/or the patient should report any serious product-related incident to both the manufacturer and the

Competent authority of the European Member State where the user and/or patient is established.

To view your operations or maintenance manual online, see https://techweb.stryker.com/.

Have the serial number (A) of your Stryker product available when calling Stryker Customer Service or Technical Support.

Include the serial number in all written communication.

SSeerriiaall nnuummbbeerr llooccaattiioonn

You can find the serial number (A) and bed bay identification number (BBID) on the bottom of the product (Figure 1).

FFiigguurree 11 –– SSeerriiaall nnuummbbeerr//BBBBIIDD llooccaattiioonn

5212-009-201 Rev A.0 5 EN

IInnssttaallllaattiioonn

IInnssttaalllliinngg SSeeccuurree CCoonnnneecctt

TToooollss rreeqquuiirreedd::

• #2 Phillips screwdriver

• #1 Phillips screwdriver

• Straight pick

• Tape measure

• Level

• Pencil

• Tools required for hospital supplied fasteners

PPrroocceedduurree::

1. Record the SSeeccuurree CCoonnnneecctt BBID (

Serial number location

(page 5)) and room number/patient position on the

SSeeccuurree

CCoonnnneecctt association form

(page 38).

2. Using a straight pick, configure the SB1 and SB2 dip-switches (A) to match the nurse call system and nurse call

communication cable (Figure 2).

CCAAUUTTIIOONN -- Always match the dip-switches on SB1 and SB2 to the connected product configuration to avoid the risk of

head wall damage.

NNoottee -- To confirm dip-switch configuration, contact Stryker customer service or technical support (

Contact information

(page 5)).

FFiigguurree 22 –– SSwwiittcchh ccoonnffiigguurraattiioonn

3. Using a straight pick, turn the SSeeccuurree CCoonnnneecctt OONN//OOFFFF switch (B) to the OONN position (Figure 2).

4. Install the two supplied IPX labels (C) over the dip-switch and the OONN//OOFFFF cutouts located on the back of the SSeeccuurree

CCoonnnneecctt (Figure 2).

5. Using a tape measure and pencil, mark the center of the product location between 4 in. - 5 in. (10.2 cm - 12.7 cm) from

the floor (Figure 3).

NNoottee -- The marked mounting location on the wall must be within 0.5 in. (1.3 cm) left or right from the center line of where

the product will be positioned for the SSeeccuurree CCoonnnneecctt to work properly.

EN 6 5212-009-201 Rev A.0

± 0.5 in. (± 1.3 cm)

4 in. - 5 in. (10.2 cm - 12.7 cm)

FFiigguurree 33 –– MMoouunnttiinngg ssppeecciiffiiccaattiioonnss

6. Center the mounting plate (D) on the mark that was made in step 5 and use a pencil to mark the bottom of the mounting

plate (D) (Figure 3).

NNoottee -- The bottom of the mounting plate must be 4 in. - 5 in. (10.2 cm - 12.7 cm) from the floor.

7. Using a level on the bottom of the mounting plate (D), make sure that the bottom of the mounting plate (D) is level when

you position the mounting plate (D) on the reference marks made in steps 5 and 6 (Figure 3).

8. Use a pencil to mark the three screw holes of the mounting plate (D).

9. Using the appropriate tool with the hospital supplied fasteners (E, not included), secure the mounting plate (D) to the

wall (Figure 3).

10.Attach the SSeeccuurree CCoonnnneecctt (F) to the mounting plate (D) (Figure 3).

11.Using a #2 Phillips screwdriver, secure the SSeeccuurree CCoonnnneecctt (F) to the mounting plate (D) with the two supplied screws

(700001126359) (G) (Figure 3).

12.Plug the SSeeccuurree CCoonnnneecctt power supply into a hospital grade protective earthed wall outlet.

NNoottee -- Position the power supply in an accessible location.

13.On the SSeeccuurree CCoonnnneecctt, plug in the female end of the power supply.

14.On the SSeeccuurree CCoonnnneecctt, plug in the nurse call communication cable.

15.Using a #1 Phillips screwdriver, secure the nurse call communication cable to the SSeeccuurree CCoonnnneecctt.

16.Connect and secure the nurse call communication cable to the nurse call system wall plug.

17.Configure the SSeeccuurree CCoonnnneecctt, see

Configuring the SSeeccuurree CCoonnnneecctt

(page 10).

18.Follow the procedure in the product manual to connect the product to the SSeeccuurree CCoonnnneecctt.

CCAAUUTTIIOONN -- Always match the dip-switches of a product to the head wall configuration if a nurse call communication

cable needs to be connected to avoid the risk of head wall damage.

NNoottee

• If a SSeeccuurree CCoonnnneecctt is moved, repeat steps 1 and 10-17.

• If a product is moved to another configured SSeeccuurree CCoonnnneecctt, no change needs to be made as the product will

connect automatically.

5212-009-201 Rev A.0 7 EN

IInnssttaallllaattiioonn cchheecckklliisstt

Follow this checklist for the 5212 SSeeccuurree CCoonnnneecctt:

Confirm that you do not have any unused components after installation. Your SSeeccuurree CCoonnnneecctt does not ship with

any extra components

Check that the SSeeccuurree CCoonnnneecctt ID number and room number/location has been recorded on the

SSeeccuurree CCoonnnneecctt

association form

(page 38)

Use a tape measure to check that the SSeeccuurree CCoonnnneecctt is installed at the horizontal center of the wall behind the bed

location

Use a tape measure to check that the bottom of the SSeeccuurree CCoonnnneecctt is installed 4 in. - 5 in. (10.2 cm - 12.7 cm) from

the floor

Use a level to confirm that the mounting plate is level

All fasteners are tight with no signs of protruding or missing fasteners

Power supply is plugged into a hospital grade protective earthed wall outlet and to the SSeeccuurree CCoonnnneecctt

Nurse call communication cable is plugged into the SSeeccuurree CCoonnnneecctt and the nurse call system

Product ID number:

Installed by: Date:

Inspected by: Date:

NNoottee -- Maintain a copy of this record for at least 10 years.

EN 8 5212-009-201 Rev A.0

OOppeerraattiioonn

SSeeccuurree CCoonnnneecctt iinnddiiccaattoorrss//ffuunnccttiioonnss

The SSeeccuurree CCoonnnneecctt has indicator symbols and a nurse call cord out cancel button (A) that is located on top of the

product. This button cancels the alert if the nurse call communication cable is unplugged.

IInnddiiccaattoorr IInnddiiccaattoorr lliigghhtt SSttaattuuss

Solid Connected

Pulse Connecting

Flash Connection error

Pulse AC power unplugged

Flash Low battery

Pulse Nurse call communication cable unplugged

Solid The SSeeccuurree CCoonnnneecctt is not configured

Flash Error (reference product display for error detail)

Flash Battery error

5212-009-201 Rev A.0 9 EN

CCoonnffiigguurriinngg tthhee SSeeccuurree CCoonnnneecctt

TToooollss rreeqquuiirreedd::

•SSeeccuurree CCoonnnneecctt scanner (521200380700) (option) or SSeeccuurree CCoonnnneecctt compatible product

• Stryker service tool (521205080001) (option)

NNoottee -- Stryker service tool required if you use the SSeeccuurree CCoonnnneecctt scanner.

CCAAUUTTIIOONN -- Always match the dip-switches on SB1 and SB2 to the product configuration to avoid the risk of head wall

damage.

PPrroocceedduurree::

• Using the SSeeccuurree CCoonnnneecctt scanner:

1. Using the Stryker service tool, select the supplied soft configuration and settings.

2. Select SSaavvee CCoonnffiigguurraattiioonn (A) (Figure 4).

FFiigguurree 44 –– SSttrryykkeerr sseerrvviiccee ttooooll

• Using a PPrrooCCuuiittyy™ bed:

1. Apply the brakes.

NNoottee -- See the Model 3009 PPrrooCCuuiittyy Operations Manual for steps to apply the brakes.

2. Confirm the SSeeccuurree CCoonnnneecctt connection to PPrrooCCuuiittyy.

NNoottee -- The icon will appear on the PPrrooCCuuiittyy home screen when SSeeccuurree CCoonnnneecctt has connected.

3. Enter the service menu and select CCoonnffiigguurraattiioonn (B) (Figure 5).

NNoottee -- See the Model 3009 PPrrooCCuuiittyy Maintenance Manual for steps to access the service menu.

EN 10 5212-009-201 Rev A.0

FFiigguurree 55 –– PPrrooCCuuiittyy sseerrvviiccee mmeennuu

4. In the configuration menu, select RRoooomm IInntteerrffaaccee CCoonnffiigguurraattiioonn (C) (Figure 6).

FFiigguurree 66 –– PPrrooCCuuiittyy ccoonnffiigguurraattiioonn mmeennuu

5. Input the supplied settings and select SSaavvee.

TTeessttiinngg tthhee SSeeccuurree CCoonnnneecctt

TToooollss rreeqquuiirreedd::

•SSeeccuurree CCoonnnneecctt scanner (521200380700) (option) or SSeeccuurree CCoonnnneecctt compatible product

• Stryker service tool (521205080001) (option)

NNoottee -- Stryker service tool required if you use the SSeeccuurree CCoonnnneecctt scanner.

PPrroocceedduurree::

• Using the SSeeccuurree CCoonnnneecctt scanner:

∘ Using the Stryker service tool test function, activate the nurse call.

• Using a PPrrooCCuuiittyy bed:

∘ Using the footboard and siderail control panels, activate the nurse call.

NNoottee -- See the Model 3009 PPrrooCCuuiittyy Operations Manual for steps to activate nurse call.

5212-009-201 Rev A.0 11 EN

PPrreevveennttiivvee mmaaiinntteennaannccee

Remove product from service before you perform the preventive maintenance inspection. Check all items listed during

annual preventive maintenance for all Stryker Medical products. You may need to perform preventive maintenance checks

more often based on your level of product usage. Service only by qualified personnel.

Inspect the following items:

All fasteners are secure

The SSeeccuurree CCoonnnneecctt casing is not cracked or damaged

Mounting plate not cracked or damaged

The SSeeccuurree CCoonnnneecctt front label is not damaged

Replace the battery (every two years)

Product serial number:

Completed by:

Date:

EN 12 5212-009-201 Rev A.0

CClleeaanniinngg aanndd ddiissiinnffeeccttiinngg wwiitthh wwiippeess

For United States only. Confirm availability for your configuration or region. Call Stryker Customer Service: 1-800-327-

0770.

Stryker’s preferred wipes (2060-000-001 6'' x 10'' or 2060-000-002 9'' x 12'') include the following active ingredients:

• n-Alkyl (60% C14, 30% C16, 5% C12, 5% C18) dimethyl benzyl ammonium chloride - 0.154%

• n-Alkyl (68% C12, 32% C14) dimethyl ethylbenzyl ammonium chloride - 0.154%

• Isopropanol - 21.000%

Non-active ingredient: Ethylene Glycol Monobutyl Ether – < 3%

NNoottee -- For safety information, read the product label.

To clean or disinfect the external product surface:

1. To clean, wipe external surfaces with a fresh, clean wipe to remove all visible soils. Repeat as necessary until the

product is clean.

NNoottee

• Use as many wipes as necessary.

• Complete step 1 before you disinfect.

2. To disinfect, wipe external surfaces with a fresh, clean wipe until wet. Allow the external surface to remain wet for two

minutes at room temperature.

3. Allow the product to dry before you return it to service.

5212-009-201 Rev A.0 13 EN

CClleeaanniinngg

CCAAUUTTIIOONN

• Do not clean, disinfect, service, or perform maintenance while the product is in use.

• Always unplug the power cord from the wall outlet when large spills occur near the circuit boards and cables. Clean up

the fluid, and inspect the product. Fluids can cause unpredictable operation and decreased functionality of any electrical

product. Do not return the product to service until dry and tested for safe operation.

Recommended cleaning method:

1. Using spray or pre-soaked wipes, hand wash all exposed surfaces of the product with a mild detergent.

2. Follow the cleaning solution manufacturer’s instructions for appropriate contact time and rinse requirements.

3. Dry the product before you return it to service.

NNoottee -- Avoid oversaturation. Do not allow the product to remain wet.

EN 14 5212-009-201 Rev A.0

DDiissiinnffeeccttiinngg
