Restep—an economical
and INNOVATIVE solution for
today’s HEALTHY Hospital.
“
“
The information presented in this brochure is intended to demonstrate a Stryker product. Always refer to the package
insert, product label and/or user instructions before using any Stryker product. Products may not be available in all
markets. Product availability is subject to the regulatory or medical practices that govern individual markets.
Please contact your Stryker representative if you have questions about the availability of Stryker products in your area.
Stryker Corporation or its divisions or other corporate affiliated entities own, use or have applied for the following
trademarks or service marks: Restep®. All other trademarks are trademarks of their respective owners or holders.
RM801005 Restep Pump Manual Cover.indd 2 1/19/17 2:54 PM

1
TABLE OF CONTENTS
INTRODUCTION......................................................................................................................... 2
Clinical Indication for use........................................................................................................ 2
Contraindications................................................................................................................... 2
Precautions........................................................................................................................... 3
GENERAL................................................................................................................................... 3
Symbols ............................................................................................................................... 3
Notes, Cautions, and Warning statements ............................................................................... 4
EMC Warning......................................................................................................................... 4
Hazard Information ................................................................................................................ 4
SYSTEM COMPONENTS............................................................................................................ 5
Pump Kit/Accessories ........................................................................................................... 5
Garments.............................................................................................................................. 6
SYSTEM INSTALLATION ............................................................................................................ 7
Battery Installation ................................................................................................................. 7
Charging the Battery.............................................................................................................. 7
Using the Bed Bracket ........................................................................................................... 8
GARMENT USE .......................................................................................................................... 9
Calf Garments ....................................................................................................................... 9
Bariatric Calf Garments........................................................................................................ 10
Thigh Garments................................................................................................................... 10
Foot Garments .................................................................................................................... 11
SYSTEM CONTROLS ............................................................................................................... 11
Front Control Panel..........................................................................................................11-12
PUMP OPERATION .................................................................................................................. 13
Switching the pump on and off ............................................................................................. 13
Garment TYPE selection....................................................................................................... 13
Garment MODE selection ..................................................................................................... 14
Mute................................................................................................................................... 14
WARNINGS AND ALARMS ....................................................................................................... 14
HIGH PRESSURE.................................................................................................................. 14
LOW PRESSURE .................................................................................................................. 14
CRITICAL LOW BATTERY....................................................................................................... 15
BAD BATTERY ..................................................................................................................... 15
TROUBLESHOOTING ............................................................................................................... 16
CLEANING ............................................................................................................................... 17
PREVENTIVE MAINTENANCE .................................................................................................. 18
HANDLING AND STORAGE...................................................................................................... 22
RETURNS ................................................................................................................................ 22
SPECIFICATIONS ..................................................................................................................... 23
EMC GUIDANCE AND DECLARATIONS...............................................................................24-27

2
INTRODUCTION
This manual should be used for the initial set up of the Restep® system and for reference purposes.
Clinical Indications for use
The primary application of the Restep®system is for the prevention of Deep Vein Thrombosis (DVT)
due to the presence of risk factors for thrombus formation during orthopedic, trauma, neurology,
urologic, critical care, general medicine, obstetrics, and general surgery.
This system should be used when prescribed by a physician.
Garments should be removed regularly to inspect the skin.
Patients with diabetes or vascular disease require frequent skin assessment.
When appropriate, patients should be instructed in the proper use of the system and any
problems should be reported to the nursing staff.
The garments should be applied to the patient prior to the induction of anesthesia.
If the garment cannot be applied to the operative limb during surgery, it may be applied to
the limb once the patient reaches the recovery room. For a non-surgical patient, the system
should be applied as soon as the risk of DVT is identified.
The system should be used continuously until the person is fully ambulatory. The therapy can
continue with leg garments for people with limited mobility.
Contraindications
The Restep®system should NOT be used in the following conditions:
Severe arteriosclerosis or active infection.
Suspected or known acute DVT.
Severe congestive heart failure or any condition where increased fluid to the heart
may be detrimental.
Existing pulmonary edema.
Local skin or tissue conditions in which the garments would interfere.
If in doubt, refer to the patient’s physician before using device.
CAUTION: US Federal law restricts this device to sale by or on the order of a physician.
Precautions
Do not drop the power adapter or pump as it may result in damage to the components
potentially affecting functional performance.
Remove pump and Bed Bracket (RSP166) if applicable from the footboard or bedrail prior to
moving the bed to prevent impact damage during transportation.

3
Do not lean on the pump when it is hanging from the footboard or bedrail as this may result in
a fracture of the bracket housing.
Place the equipment in a location where it will not be susceptible to impact forces from other
equipment or personnel.
Pump hooks are designed for bed attachment only.
It is not recommended that pumps or Bed Brackets (RSP166) if applicable are permanently
fastened or tied to objects.
Only the pump and garment combinations provided by Stryker Sustainability Solutions should
be used. The correct function of the product cannot be guaranteed if the incorrect pump/
garment combinations are used.
Regularly check the system while in use, assuring pump operation and garment fit.
Keep the pump away from sources of liquids and do not immerse in water.
Switch off the electrical supply to the pump by removing the power supply from the power
outlet and the pump before cleaning and inspection.
Do not use cleaning solutions that are known to damage plastics.
Do not autoclave any parts of the system.
Ensure the system is clean and dry prior to storage.
GENERAL
The Restep®system has been tested and certified for the following standards:
UL 60601-1 CAN/CSA C22.2 No. 601.1 EN 60601-1 IEC 60601-1 IEC 60601-1-2
The power adapter has been tested by the manufacturer and certified for the following standards:
UL 60601-1 CAN/CSA C22.2 No. 601.1 EN 60601-1
Symbols
Symbols used on this product are as below:
Read through all instructions before use.
NOTES
Indicates some tips or some information users
should be aware of.
Caution & Warning statements
CAUTION
Indicates correct operation or maintenance
procedures to prevent damage to or destruction
of the equipment or other property.
WARNING
Calls attention to a potential hazard that requires
correct procedures or practices in order to
prevent personal injury.
Type BF
Class II equipment
Consult instructions for use
Single patient use only, do not reuse
Manufacturer
REF Part Number
Serial Number
KWWSUHVWHSVWU\NHUFRP
Stryker Sustainability Solutions
Tempe, AZ
℞
ONLY
CAUTION: US Federal Law restricts this device
to sale by or on the order of a physician

4
EMC Warning
This product complies with the requirements of applicable EMC standards. The use of accessories
not specified by the manufacturer may result in increased emissions by, or decreased immunity of
the equipment, affecting its performance.
There is a possibility of electromagnetic interference with other devices. When there is suspicion
of possible EMC interference to the pump, it is recommended to shut down the electrical devices
nearby, one-by-one, to locate the possible interference source.
Consult an expert if you are not sure how to solve the interference problem.
WARNING: The equipment is not suitable for use in the presence of flammable anesthetic mixture
with air or with oxygen or nitrous oxide. Keep the pump and adapter at least one foot away from any
source of such mixture leaking, especially patient’s airway or anesthesia machines.
HAZARD INFORMATION
All Stryker Sustainability Solutions manufactured products are intended as medical devices in medical environments.
Where a product meets IEC 60601-1 it is under the principle that:
1. It is a more rigorous standard than other standards that could be adopted.
2. It provides the most appropriate safety level for subjects and operators.
Meeting IEC 60601-1 is in no way to be interpreted to mean that product safety is guaranteed in all circumstances of operation.
For example, when any electrical device is used, specific parts of the device are subject to voltage. If safety warnings are not
followed, hazards to personnel and property may potentially result. Personal injury and damage to property may also potentially
occur. The following safety rules should be followed:
1. DO NOT roll beds, stretchers, or other equipment over the AC Adapter Power Supply cord;
2. DO NOT attempt to repair broken AC Adapter Power Supply casings or cords;
3. DO NOT attempt to open or repair pumps. Although the Restep DVT Pump System is designed to be a low voltage device,
hazard information review, and good operational practice as described in this section should be applied.
KWWSUHVWHSVWU\NHUFRP
Stryker Sustainability Solutions
Tempe, AZ
℞
ONLY
Pump (Back Label)

5
SYSTEM COMPONENTS
A complete system should contain the following components. If any of the following items are
missing or damaged, please contact your Stryker Sustainability Solutions representative for
immediate assistance.
Pump
Item Number: RSP101
10.5’ Tube Set Extension
Item Number: RSP161
Bed Bracket
Item Number: RSP166
3-Prong Plug Extension
Item Number: RSP162
Battery Cover/Bed Bracket
Item Number: RSP163
Battery Cover
Item Number: RSP167
Carrying Strap
Item Number: RSP160
6’ Tube Set
Item Number: RSP154
Battery
Item Number: RSP152
12’ Power Adapter
Item Number: RSP159 or RSP164
Item Number: PUMPKIT includes the following items:
Accessories:
RSP164
RSP159

6
Garments
All Restep®DVT garments have a single center inflating bladder and adjustable straps with hook
tab attachments. The garment tube inlet to the garment should be rotated to the most comfortable
position for the tube set, depending on where the pump is placed.
NOTE: Garments are purchased and supplied separately.
Calf Garments
(up to 20”)
Item Number: RCG10
Calf garments are supplied in pairs.
Thigh Garments
(up to 26”)
Item Number: RTG30
Thigh Garments are supplied in pairs.
Bariatric Calf Garments
(20” - 26”)
Item Number: RBG60
Bariatric Garments are supplied in pairs.
Foot Garments
(universal size)
Item Number: RFG210
Foot garments are supplied in single units.

7
SYSTEM INSTALLATION
Battery installation
Unscrew the battery cover then
connect the battery male connector
to the female connector inside the
battery compartment. Ensure the
correct orientation of the connector.
Push the connectors firmly onto
the female connector to secure
the battery wires within the
battery compartment.
Fit the battery into the compartment.
Make sure that nothing gets in the
way of the battery cover.
Slide the battery cover RSP167 or
RSP163 close. Make sure it snaps
firmly into position.
Secure the battery cover RSP167 or
RSP163 with the screw.
Attach the shoulder strap to the pump
if needed for ambulation.
NOTE: The pump will not operate without a battery in place.
Charging the battery
Plug the adapter into a
wall AC outlet.
The adapter inlet is located
at the top of the pump.
Insert the adapter output
into the adapter inlet.

8
Charging the battery (continued)
NOTE:
•
In a nominal battery, charging may take 16-48 hours (the system may be used while recharging);
discharging a fully charged nominal battery (via battery-only operation) may take 8 hours. Overall battery
life/effectiveness is maintained by continuous full charging and discharging cycling routines.
• Charge the battery when the battery capacity is low. This will be indicated when the red LOW BATTERY
light is solid accompanied by a constant audible alarm when the pump is under battery-only operations.
• While charging the battery, the BATTERY CHARGE light (green) will be blinking. When the battery is
fully charged, an audible double-beep is presented once, and the BATTERY CHARGE light (green) will be lit constantly.
• While pump is not being used and idle the power adapter should be connected to the pump to insure a
charged battery during its next use. If the pump was left idle without being charged, it is recommended
that the pump be charged until the BATTERY CHARGE light emits a constant green light prior to utilization
without a power adapter.
• It is normal for the battery to get warm during charging and while in use.
CAUTION:
• Use only the provided manufacturer approved battery included in the package.
Replacement Item Number: RSP152.
• Disconnect the adapter from the pump before unplugging the adapter from the AC outlet. Disconnection
in reverse order may cause damage to the pump.
• Use only the provided manufacturer approved power adapter included in the package. DO NOT USE any
other power adapters with the Restep® system. Replacement Item Number: RSP164.
Using the bed bracket (RSP163)
The pump may be attached to a bed frame with the supplied embedded bed bracket. Unfold the bed
bracket arms and place the hooks over the bed footboard, or another convenient place where it can
be easily seen and heard.
Using the bed bracket (RSP166)
The pump may be attached to a bed frame with the bed bracket. Insert the pump into the bed
bracket. Hang the black mounting arm of the bed bracket over the bed footboard, or another
convenient place where it can be easily seen and heard.

9
GARMENT USE
Secure the pump at the foot of the bed or in place of use.
The pump connectors are located at the top left of the pump.
Attach the 6 ft. or 10.5 ft. tube set to the pump by pushing
in the silver latch on the female pump connector and then
inserting the male tube connector into the pump connector
until a click is heard.
Calf Garments
The calf garments may be used on either leg. Unfold the garment(s) and position the inflatable center
bladder directly behind the patient’s calf. The outlet tube on the garment should not be in direct
contact with the patient’s skin.
SNUGLY wrap the calf garment(s) around the patient’s leg and secure the hook tabs onto the loop
material. Repeat for the other leg, or store the unused garment and tube for later use. Attach the
garment(s) to the tube set by pushing in the silver latch on the female tube connector and inserting
the male garment connector firmly into the tube connector until a click is heard.
NOTE: Ensure the pump is held firmly onto the bed frame while used in bed. During ambulation or
transportation, ensure that the pump is secured. Rotate the outlet tube on the garment to eliminate kinks in
the tubing. Tubing may become a trip hazard during ambulation if the shoulder strap is not used to secure
excess tubing.

10
Bariatric Calf Garments
The bariatric calf garments are specially shaped to conform better to the bariatric patient’s lower
legs. The bariatric calf garments may be used on either leg. Unfold the garment(s) and position the
inflatable center bladder directly behind the patient’s calf. The outlet tube on the garment should not be
in direct contact with the patient’s skin.
SNUGLY wrap the bariatric calf garment(s) around the patient’s leg and secure the hook tabs onto
the loop material. Repeat for the other leg, or store the unused garment and tube for later use.
Attach the garment(s) to the tube set by pushing in the silver latch on the female tube connector and
inserting the male garment connector firmly into the tube connector until a click is heard.
NOTE: Ensure the pump is held firmly onto the bed frame while used in bed. During ambulation or
transportation, ensure that the pump is secured. Rotate the outlet tube on the garment to eliminate kinks in
the tubing. Tubing may become a trip hazard during ambulation if the shoulder strap is not used to secure
excess tubing.
Thigh Garments
The thigh garments may be used on either leg. Unfold the garment(s) and position the inflatable center bladder
directly behind the patient’s calf and rear of the thigh, with the square-shaped, cut-out directly behind the
patient’s knee. The outlet tube on the garment should not be in direct contact with the patient’s skin.
SNUGLY wrap the thigh garment(s) around the patient’s leg and thigh and secure the hook tabs onto the loop
material. Repeat for the other leg, or store the unused garment and tube for later use. Attach the garment(s) to
the tube set by pushing in the silver latch on the female tube connector and inserting the male garment connector
firmly into the tube connector until a click is heard.
NOTE: Ensure the pump is held firmly onto the bed frame while used in bed. During ambulation or
transportation, ensure that the pump is secured. Rotate the outlet tube on the garment to eliminate kinks in
the tubing. Tubing may become a trip hazard during ambulation if the shoulder strap is not used to secure
excess tubing.

11
Foot Garments
The foot garments may be used on either foot. Unfold the garment(s) and position the inflatable
center bladder directly below the arch of the patient’s foot. The outlet tube should be adjusted so it is
parallel with the patient’s toes.
NOTE: Do not use calf garments and foot garments on the same patient at the same time.
Snugly wrap the garment(s) around the patient’s foot and secure the hook tabs. Wrap the ankle
straps around the back of the ankle and on top of the foot. Repeat for the other foot, or store the
unused garment and tube for later use. Attach the garment(s) to the tube set by pushing in the silver
latch on the female tube connector and inserting the male garment connector firmly into the tube
connector until a click is heard.
NOTE:
• Foot garments should be removed prior to patient ambulation or transportation.
•
See online IFU for full details: http://restep.stryker.com
SYSTEM CONTROLS
Front control panel
The functions of the Restep®system pump are described below.
1. Power Switch
2. Alarm Graphic
3. Garment Type Selection Key
4. Mode Selection Key
5. Mute Key
6. Battery Status Indication
7. Alarm Indication, HIGH/LOW Pressure
8. Garment Type Indication
9. Mode Indication
10. Alarm/Mute Indication
16
27
38
49
510

12
1. Power Switch
Press the Power Switch to turn the power ON/OFF, and to start/stop the pump.
2. Alarm Graphic
This is NOT a key. This graphic highlights the function of the HIGH/LOW pressure alarm indicators.
3. Garment Type Selection Key
TYPE selection key is inactivated after 60 seconds of initially powering on the pump.
Press the TYPE key to select either LEG GARMENTS (default) or FOOT GARMENTS.
4. Mode Selection Key
MODE selection key is inactivated after 60 seconds of initially powering on the pump.
Press the MODE key to select dual garment (default) or SINGLE GARMENT.
5. Mute Key
Press the Mute Key to silence the audible alarm. If the mute key is enabled (alarm silenced)
it will disable (alarm reactivated) automatically after 3 minutes.
6. Battery Status Indication
BATTERY CHARGE light (solid green) = battery fully charged state reached
BATTERY CHARGE light (flashing green) = battery charging
LOW BATTERY light (solid red) with constant audible alarm, pump has vented and powered
down to a suspended/safe mode = low battery/charge required
LOW BATTERY light (flashing red) no audible alarm = bad battery (cannot reach fully charged
state in 48 hours); pump is on suspended mode and requires all power sources to be
removed (AC power adapter and battery) in order to reset
7. Alarm Indication
► HIGH PRESSURE light (solid red) with beeping audible alarm = garment not deflating
► HIGH PRESSURE light (solid red) with constant audible alarm = high pressure/kinked tubing
► LOW PRESSURE light (solid yellow) with constant audible alarm = no garment
► LOW PRESSURE light (solid yellow) with beeping audible alarm = low pressure
8. Garment Type Indication
► LEG GARMENT light = calf, bariatric calf, and thigh garments in use
► FOOT GARMENT light = foot garments in use
► The default setting is LEG garment mode. Press this key to select FOOT garments.
9. Mode Indication
The SINGLE GARMENT light is lit when selected for any single garment, including the foot garment.
10.Mute Indication
The MUTE light (yellow) is lit when the MUTE mode is enabled. This function will disable after
3 minutes of activation to allow the user to hear future audible alarms.

13
PUMP OPERATION
Switching the pump on and off
Light Indicators while pump is off
No light = pump off and not connected to power
BATTERY CHARGE light (flashing green) = battery charging
BATTERY CHARGE light (solid green) = battery charged
To start pump operation, press the POWER button once and wait. The pump will undergo a software
auto-check for a few seconds. During this time, the LEG GARMENT light may flash. After the auto-check
is completed, the LEG GARMENT light will be lit constantly.
NOTE: When the POWER button is pressed, Restep pumps using Software PSoC Version 2.3 will also produce
an audible beep and the BATTERY CHARGE and LOW BATTERY lights will flash simultaneously. A label indicating
Software PSoC Version 2.3 can be found on the back of the pump if applicable. Please be patient and do not
press the POWER button again or you may turn the pump off.
The pump will now begin its normal operation cycle. Allow the pump to run for several cycles to allow
the garments to inflate and fit their shape to the patient’s extremity. During this time the
“LOW PRESSURE” alarm may activate. If, after a few cycles, this alarm does not reset, please refer
to the trouble-shooting guide.
To end pump operation, press POWER button again. When the pump is powered down during an
inflation cycle, the Garment TYPE light will flash while the valves open and drain the pressure from the
garment. This ensures the system is left in a safe deflated mode for the patient.
NOTE: You may change the TYPE or MODE settings only within the first 60 seconds of the initial Power button
press; after 60 seconds, TYPE and MODE selection keys are inactivated. It is NOT recommended to change
garments after initial setup while pump is in use. The pump should be turned off during a garment change to
avoid unnecessary alarm disturbance to the patient.
Garment TYPE selection
The user may select between the LEG GARMENTS type or FOOT GARMENTS type by pressing the Type
Selection Key. Press this key until the desired type is illuminated by the garment type indicator LED.
LEG: This is the default setting for calf, bariatric calf, and/or thigh garments. The operating inflated
pressure is 40mmHg and the compression delivered is considered a uniform-type compression. The
LEG GARMENT light will flash during initial setup of the pump and then will be lit constantly during use.
FOOT: Select this button for foot garment use. The operating inflated pressure is 80mmHg and the
compression delivered is considered a uniform-type compression. The FOOT GARMENT light will be lit
constantly when selected.
Note: Ensure the garments on the patient and the garment TYPE selection are the same. Do not mix leg and
foot garments on the same patient. If desired, a calf and thigh garment may be used simultaneously.

14
Garment MODE selection
The two modes available are DUAL GARMENT mode and SINGLE GARMENT mode. All garments can be
used in either mode. Press this key until the desired mode is illuminated by the mode indicator LED.
DUAL GARMENTS: This is the default setting for the pump. Each garment inflates for 12 seconds
and then deflates for 48 seconds per cycle. Inflation alternates between the two garments during
each cycle. One garment will inflate and then deflate and 30 seconds later the second garment will
inflate and then deflate.
SINGLE GARMENT: Press the MODE key once to select the SINGLE GARMENT mode. Only one
garment is used on the patient (either extremity). This garment inflates for 12 seconds and then
deflates for 48 seconds per cycle.
Note: It does not matter which extremity the garment is placed on or which connector is used.
The pump will detect this during its first inflation cycles and compensate accordingly.
Mute
When an alarm occurs, the pump will give the appropriate audible tone to inform the user of the alarm
and light the appropriate ALARM light. The user may silence the audible tone by pressing the MUTE key.
WARNINGS AND ALARMS
HIGH PRESSURE
This alarm may sound if a blockage exists between the pump and garment connections.
Check connectors between the garments and pump. If there is a disconnection, reconnect it.
Ensure that the tube set is not kinked, bent, and/or blocked. If present, reposition the tubes
to clear the blockage.
Ensure the garment is wrapped snugly around the extremity as required. If not, refit
the garment.
If the alarm continues, there may be an internal pump fault indicating the pump may
need servicing. Remove pump from service and contact your Stryker Sustainability Solutions
representative. DO NOT CONTINUE TO USE.
LOW PRESSURE
This alarm may sound when a garment is new and is first applied to the patient. Allow the system
to stabilize the pressure within the garment for five (5) cycles and check that the alarm has ceased.
If the alarm persists, check for air leakage between the pump and the garment connections:
If the alarm persists:
Ensure that garments are fully connected to the pump garment ports.
• Check for air leakage between the pump and the garment connections.
• If there is a disconnection, reconnect it.
• If air hose presents a leak, replace the hose.
Ensure there are no splits or tears in the garments.
Ensure correct garment type and garment mode has been selected.
Ensure the garment is wrapped snugly around the extremity as required. If not, refit the
garment as required.
If the alarm continues, change garments.
If the alarm still continues after garment change, there may be an internal pump fault
indicating the pump may need servicing. Remove pump from service and contact your
Stryker Sustainability Solutions representative. DO NOT CONTINUE TO USE.

15
CRITICAL LOW BATTERY
This alarm will sound during battery-only pump operation when the battery is near depletion.
The following actions will be initiated by the pump when this alarm is activated:
A solid tone, audible alarm will begin and continue for 10 minutes.
This alarm cannot be disengaged by pressing the MUTE button.
The garments will be vented immediately
The pump operations will be suspended for 10 minutes
If the User connects the AC Adapter Power Supply to the pump within 10 minutes of alarm
initiation, the pump will automatically resume operations (POWER button press is not required)
and begin charging the battery.
If the AC Adapter Power Supply is not connected to the pump after 10 minutes of alarm initiation,
the pump will completely power off and will not power on until the AC Adapter Power Supply is
connected to the pump.
If the interval between achieving full battery charge to a critical low battery alarm begins to
be noticeably shorter over time (battery operation run-time), the battery pack may require
a replacement.
If a new, replacement battery is observed to have a short battery operation run-time, there may
be an internal pump fault indicating the pump may need servicing. Remove pump from service
and contact your Stryker Sustainability Solutions representative. DO NOT CONTINUE TO USE.
BAD BATTERY
This alarm is presented when a battery does not complete charging while connected to the AC Adapter
Power Supply after 48 hours. The alarm is an indicator that the battery pack may have a fault or has
reached its limit to properly maintain useful charge. Remove pump from service and contact your Stryker
Sustainability Solutions representative. DO NOT CONTINUE TO USE.
The following actions will be initiated by the pump when this alarm is activated:
If the alarm condition initiates while the pump is powered on and operating, then the LOW
BATTERY (LED) will begin flashing;
• The flashing LED cannot be disengaged by a MUTE button press.
• The pump will vent garments and power off.
• Once the pump is powered off, the LED will continue to flash and the pump cannot be
powered on again, until;
– AC Adapter Power Supply is disconnected
– Battery Pack is removed and replaced with a new Battery Pack;
– Any attempt to power on the pump without executing the steps above will result in
an audible double beep upon POWER button press, indicating that the pump has
been locked in a power down mode.
If this alarm condition initiates while pump is not operating, but being charged by the AC Adapter
Power Supply, then the LOW BATTERY (LED) will begin flashing;
• The pump cannot be powered on, until
– AC Adapter Power Supply is disconnected
– Battery Pack is removed and replaced with a new Battery Pack
– Any attempt to power on the pump without executing the steps above will result in an
audible double beep upon POWER button press. The double beep indicates that the
pump has been locked in a power down mode.

16
TROUBLESHOOTING
Problems Solutions
The pump
doesn’t work
• Check if the battery charge is too low, plug in the power adapter to charge the
battery. The Battery Charging light should flash.
• If the Battery Charging light does not flash, ensure there is power to the socket
you have used or try another socket.
• Press Power Switch and see if the pump works correctly. If it does, the system
may be used.
• If pump does not operate when power switch is pressed and an audible alarm is
present, ensure a functional battery is properly installed.
• If the pump only works while plugged into a power source, replace the existing
battery with a fully charged battery. After charging, turn the pump on and see if it
works properly.
• If the pump does not work correctly after these initial troubleshooting steps, remove
pump from service and contact your Stryker Sustainability Solutions representative
for immediate assistance.
It is not recommended for the user to open the enclosure and
try to repair anything inside the pump.
HIGH/LOW
Pressure Alarm
• Check if the garment connection tubes are properly connected to the pump
and the tube set. Allow the pump to operate for five (5) cycles after switching
the pump on.
• Re-arrange the tubes if they are kinked.
• Check that the garments are wrapped snugly around the extremity. If not, reapply
the garments.
• Verify correct garment type and garment mode has been selected for the
garment used on the patient.
• Ensure there are no splits or tears in the garments. If present, replace
the garments.
• Replace the garments with new garments if alarm persists. Switch pump on and
allow pump to operate for five (5) cycles. If alarm persists, remove from service.
• The initial alarm will continue until manually muted/reset. The alarm will not activate
until another alarm event occurs.
• If the pump does not work correctly after these initial troubleshooting steps,
remove pump from service and contact your Stryker Sustainability Solutions
representative for immediate assistance.

17
CLEANING
This section describes the procedures to clean the Restep®system after patient use. Cleaning should be
in accordance with existing hospital guidelines.
Pump
Check for external damage before cleaning.
DO NOT immerse or soak the pump.
Clean with a soft cloth dampened with water and a mild disinfectant and/or detergent.
Excess fluid should be avoided.
Spray cleaning solution on a piece of cloth and clean the faceplate and the pump with the cloth.
Allow surface to thoroughly dry after cleaning.
DO NOT spray any cleaning solution directly on the surface of the pump.
DO NOT use a Hypocarbonate or phenol based cleaning solutions as these may cause damage to
the enclosure. Allow the solution to work for 10 minutes or in accordance with the time stated by
the cleaning product used.
After the pump is thoroughly cleaned and dried, switch the pump ON and test system function.
Unplug the pump and store it in an appropriate place.
Accessories
Check for damage before cleaning.
DO NOT immerse or soak the accessories.
Clean with a soft cloth dampened with water and a mild disinfectant and/or detergent.
Excess fluid should be avoided.
Spray cleaning solution on a piece of cloth and clean the accessory with a cloth. Allow surface
to thoroughly dry after cleaning.
DO NOT spray any cleaning solution directly on any accessory.
DO NOT use a Hypocarbonate or phenol based cleaning solution as these may cause damage.
DO NOT use a Ethanolamine based cleaning solution for the Bed Bracket (RSP166).
Allow the solution to work for 10 minutes or in accordance with the time stated by the
cleaning product used.
After the accessory is thoroughly cleaned and dried, test function.
Store in appropriate place.
NOTE: DO NOT IMMERSE PUMP OR ACCESSORIES IN WATER. DO NOT USE a Hypocarbonate or phenol based
cleaning solutions as those may cause damage. DO NOT USE a Ethanolamine based cleaning solution for the Bed
Bracket (RSP166).
CAUTION: DO NOT allow excess cleaning solution on control panel of pump or inside accessories, damage
may occur.
Garments
Garments are single patient use and should be collected for reprocessing after each patient use.
Stryker Sustainability Solutions provides a full reprocessing service for used garments.

18
PREVENTIVE MAINTENANCE
General
The Restep®system should be inspected and tested by a qualified biomedical service technician
annually as part of Preventive Maintenance to ensure proper operation of the pump and garment
system. Inspection and testing will verify that the buttons, speaker, lights, compressors,
transducers, and solenoids function properly.
Visually inspect power adapter for abrasions, bent pins, damaged cables, and excessive wear.
Make sure the garment tubes are correctly connected and ensure they are not kinked, broken, or damaged.
Visually inspect battery for signs of damage.
Replace battery annually to ensure optimal performance of the pump.
NOTE 1: Battery (Item Number RSP152) is available from Stryker Sustainability Solutions.
NOTE 2: DO NOT disassemble the pump housing as this will void the warranty. If the pump is not operating prop-
erly, contact your Stryker Sustainability Solutions representative.
NOTE 3: Restep Pump inspection and testing may take approximately 15 minutes to execute.
Materials Needed:
1 x Calibrated Manometer (Minimum Accuracy: of at least ± 1% of full scale and Maximum Pressure:
at least 200mmHg)
2 x 6’ Tube Set (RSP154)
1 x Calf Garments (RCG10)
1 x Foot Garments (RFG210)
1 x 1/8” Plastic Barbed Tee Connector
Light, Button, and Speaker Verification Testing
Ensure battery (RSP152) is installed in pump. Pump will not operate without battery in place.
Plug the Power Adapter (RSP159 or RSP164) into a wall outlet. Insert the power adapter output
into the pump adapter inlet, located at the top of the pump.
Without connecting garments, turn on the pump by pressing the POWER button. The BATTERY
CHARGE light (green) and the LEG GARMENTS light (green) should illuminate within 5 seconds.
Within approximately 60 seconds, the LOW PRESSURE light (yellow) should illuminate with a
constant audible alarm emitting from the speaker.
Press the MUTE key and the MUTE light (yellow) should illuminate and silence the audible alarm.
Turn off the pump by pressing the POWER button. Allow pump to completely shut-off.
A male-to-male connector is necessary to test the HIGH PRESSURE light. To assemble the male-
to-male connector, one 6’ Tube Set (RSP154) is necessary. The male-to-male connector can be
made as shown below:
